- Page 1 Installation instructions Please keep and read this instruction manual before installation, we also prepared an instruction video to help on Amazon Page. If you need further assistance, please contact Customer Service by email: geonfino@afterservice.vip...
-
Page 2: Installation Overview
Installation Overview Package List Prepare the door and check dimensions Install the latch and strike Confirm the direction of the door Install the keypad Install the interior assembly ProgrammingInstructions Low Power/Emergency Power... - Page 3 Measure to confirm that the door is 1-3/5" to 2"(40mm to 50mm) thick. Measure to confirm that the backset is either 2-3/8" or 2-3/4"(60 or 70mm). Measure to confirm that the hole in door frame is drilled a minimum of 1" (25mm) deep. Measure to confirm that the hole in the door is 2- 1/8"(54mm).
- Page 4 with the face of the latch No, adjustment is required. Proceed to the next step. Rotate and pull the latch as shown to extend the latch. When the door is pushed inwards, the latch tongue is installed outwards.
- Page 5 Install the strike on the door frame. IMPORTANT: Make sure the hole in door frame is drilled a minimum of 1" (25mm) deep.
- Page 6 keypad handle setting The connected spindle pushes the knob into the groove so that the knob is flush with the groove. Once the square pole is fully pressed in with the connecting pedestal, the front handle can no longer rotate Interior assembly handle setting Remove the mounting plate Please keep press the Button of the Spindle.
- Page 7 Remove the rear handle. Fix the front handle Fix the front handle with screws. with screws.
- Page 8 Groove Grab the square pole and pill it outward...
- Page 10 Press the lock cover as shown so that the other end is tilted up to remove the lock cover, and then insert the key to unlock the lock.
- Page 11 The property After entering a failed code 5 times, the unit will shut down for 5 minutes. The user can prevent the exposure of the PIN code to strangers by entering random digits before or after the correct PIN code. IMPORTANT: Do not load batteries until the lock is completely installed.
- Page 12 Turn on the Bluetooth and enter the interface of adding lock in app. After the administrator successfully adds the lock, owner owns the highest administrative rights to the lock. The owner can send keys to the others. Meanwhile, the owner can increase the key management that is about to expire.
- Page 13 The manager can delete an ekey, reset an ekey, and adjust the ekey. He can also check the lock record. One-time passcode can only be used for one time, and is available for 6 hours. It will automatically expire.
- Page 14 All generated passcodes can be viewed and managed in the password management module. This includes the right to change password, clear password, reset password and unlock password. The system adds new ways of communication, such as Facebook Messenger and WhatsApp, with the aim of helping users to share the access code.
- Page 15 Then, when the RFID card is close to the card sensing area of the lock for 2-3 seconds, the RFID card can be added successfully.
- Page 16 It records who comes and goes. When it comes to 24/7 access logs, get all logs about door unlock/lock anytime anywhere. place...
- Page 17 The smart lock connects directly via bluetooth, so it is not attacked by the network. The gateway is a bridge between smart locks and home Wi-Fi networks. Through the gateway, user can remotely view and calibrate the lock clock, read the unlock record, meanwhile, can remotely delete and modify the password.
- Page 18 Enabled Disabled 5 times 5 times...
- Page 19 Its operation The lock cannot be unlocked with the keypad. Despite several attempts to unlock the door, it could not be opened.
- Page 20 As an innovative and high high-tech, GEONFINO is dedicated to R&D, designing, producing and marketing of Smart lock TEL: +1 833 637 2188 products. Our top-guns in the Smart lock field have constantly developed a series of products with features like fashion, human care, energy efficiency, and environment protection.
