- Page 1 Trumpet Crown & Trumpet Classic SolarSeries ™ Floating Fountain Owner’s Manual #654814...
-
Page 2: Table Of Contents
Fountain Set Up & Installation 14-15 Initial Start-Up Maintenance & Winter Storage Troubleshooting - Fountain Replacement Parts 17-18 Warranty See Video Instructions of the Airmax SolarSeries Fountain Trumpet Installation Online Airmax, Inc. | 15425 Chet's Way, Armada, MI 48005 | Phone: 866-424-7629 | www.airmaxeco.com... -
Page 3: System Components
SolarSeries Floating Fountain Owner’s Manual 1. System Components SolarSeries Fountain Components SolarSeries Power Cord w/strain relief cable attachment (Available in 100’– 300’ Lengths) SolarSeries Fountain with power unit and float SolarSeries Fountain Disconnect Switch & Controller Assembly SolarSeries Solar Panel Components Spray Patterns SolarSeries MC4 Cables... - Page 4 1. System Components - Continued Airmax EasyMount™ Assembly Components 1. EasyMount Main Assembly (2) 2. Panel Support Rail Extension with Hardware (4) 3. Tilt Support Hardware (4) 4. U-Bolts with Hardware (4) 5. Solar Panel Clamp, Single-Sided (8) 6. Solar Panel Clamp, Double-Sided (4)
-
Page 5: Safety
• Airmax is not responsible for equipment damage or failure, losses, injury or • NEVER lift or drag the fountain by the power cord. death resulting from failure to follow safety precautions, misuse or abuse •... -
Page 6: B) Post Installation
3. System Installation - Continued B) Post Installation Fig. 3 Winter Production Winter Production 1) Ensure that holes for the solar mounting pole will not interfere with any @ 45º Latitude @ 30º Latitude underground utilities. 2) Locate the system away from irrigation sprinklers. Solar Panels 50' Tall Obstruction... -
Page 7: C.) Easymount Main
8) Plumb posts with a level and brace using 2x4 studs, clamps and stakes (recommended). Allow a minimum of 48 hours’ cure time before installing 10 - 12" the Airmax EasyMount Assemblies and solar panels. Fig. 9 Grounding Rods 6" From Inside Edge of Concrete 9) Before moving on to the installation of the EasyMount system, drive an 8’... - Page 8 41° to 45° (S. Idaho – Northern Michigan) 55° or 60° Note: Airmax recommends leaving your tilt angle set for optimum 46° to 50° (S. Washington – S. Canada) 60° performance during the winter months when daylight hours are reduced by nearly 50%.
-
Page 9: D.) Solar Panel Installation
3. System Installation - Continued 7) Continue by installing a panel support rail extension. First, remove the bolts, lock Fig. 7 washers and nuts from the end of the rail extension connector to attach to the panel support rail. Tighten using one 7/16” wrench and one 7/16” socket wrench (Fig. - Page 10 3. System Installation - Continued 3) Next, position a single-sided solar panel clamp at the top edge of one panel Fig. 3 support rail and hand tighten only (Fig. 3). Repeat for the second panel support rail extension. 4) Position the first solar panel so that the wiring junction will face the interior, Fig.
- Page 11 3. System Installation - Continued 7) Use your tape measure to center both the upper and lower solar panel widthwise Fig. 7 on the panel support rails. It should measure approximately 17-1/2" from panel support rail to the edge of the solar panel on each side. Once the panels are properly centered, secure all clamps using a 7/16”...
- Page 12 3. System Installation - Continued 12) Feed the remainder of the grounding cable down the pole and attach in Fig. 12 3–4 places using the cable ties provided (Fig. 12). Be sure to run the grounding cable down the south side of the pole (facing the solar panels) so that it does not interfere with installation of the Disconnect Switch and Controller Assembly in Section E.
-
Page 13: E.) Disconnect Switch
Recommended Final Grade and Surface Prep: To prevent possible damage to equipment during lawn maintenance AND to prevent vegetation growth from obstructing exposure, the immediate areas beneath and around your Airmax SolarSeries assembly can be prepped with ground fabric and finished with stone or mulch. -
Page 14: F) Fountain Set Up & Installation
2) Assembling the Unit (Fig. 2) a) Lay the float flat on the ground with Airmax logo facing up. Place the fountain Fig. 2 pump assembly into the center of the float. Lift the float straight up and ensure that the fountain pump lead power cord passes through the center hole. -
Page 15: Initial Start-Up
Before reinstalling the fountain in the spring, check the condition of the power cord and quick disconnect connectors, and replace any o-rings that may be cracked or missing. b) Contact your local Airmax Certified Repair Center for annual inspection, preventative maintenance and cleaning of the fountain motor assembly. -
Page 16: Troubleshooting - Fountain
Remove fountain, clean or replace impeller * If your issue persists or is not covered in the troubleshooting guide above, please contact your Certified Airmax Service Technician to perform any troubleshooting measures you are uncomfortable with or are unable to perform yourself. -
Page 17: Replacement Parts
11. #654816 – Motor Assembly 12. #651861 – Stainless Cooling Shroud Assembly, 1/2 – 3/4 HP 13. #653209 – Intake Basket Assembly, 3/4 – 1 HP 14. #651500 – Float, 34”, Blue w/Airmax Logo ITEM NO. PART NUMBER DESCRIPTION QTY. - Page 18 7. Replacement Parts & Accessories - Continued SolarSeries Disconnect Switch & Controller Assembly 1. #654817 – Fountain Disconnect Switch & Controller Assembly Complete 2. #654812 – Replacement Disconnect Switch 3. #654813 – Replacement Fuse for Disconnect Switch 4. #654819 – Fountain Disconnect Switch &...
-
Page 19: Warranty
Modification or repair by an unauthorized repair facility will void the warranty. In no case will Airmax, Inc. or its dealers accept responsibility for any costs incurred by the user during installation, removal, inspection, evaluation, repair, parts replacement, or for return freight. Nor will any liability be accepted for loss of use, loss of profits, loss of goodwill, for consequential damage, or for personal injuries to the purchaser or any person. - Page 20 Crown & Trumpet Pattern Optional Double Arch Pattern Optional Double Arch & Geyser Pattern Optional Single Arch Pattern For Information on Spray Patterns, Visit Us Online at airmaxeco.com Airmax, Inc. 15425 Chets Way Street Armada, MI 48005 (866) 4-AIRMAX airmaxeco.com #652318 V1...
