Cedar Creek
Outdoor Gas Fireplace
LED MODEL
MODELS
Natural Gas
RFP-36LECO-NLED
RFP-48LECO-NLED
RFP-60LECO-NLED
RFP-72LECO-NLED
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATION PRECAUTION:
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MANTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
Description
36" LED Linear Fireplace
48" LED Linear Fireplace
60" LED Linear Fireplace
72" LED Linear Fireplace
PN#90230
#20-024
Advertisement
Table of Contents
Related Manuals for Renaissance RFP-36LECO-NLED
Summary of Contents for Renaissance RFP-36LECO-NLED
- Page 1 Cedar Creek Outdoor Gas Fireplace #20-024 Installation and Operating Instructions LED MODEL MODELS Natural Gas Description RFP-36LECO-NLED 36” LED Linear Fireplace RFP-48LECO-NLED 48” LED Linear Fireplace RFP-60LECO-NLED 60” LED Linear Fireplace RFP-72LECO-NLED 72” LED Linear Fireplace INSTALLER: Leave this manual with the appliance.
