Summary of Contents for Renaissance LINEAR 50
- Page 1 RENAISSANCE LINEAR 50 Keep these instructions for future use. RL50-OW – 2015-08...
- Page 2 Dear Customer, The Renaissance Linear 50 is a member of the Renaissance Fireplaces family of ultra-high end fireplaces. The LINEAR 50 is unique in its design. The 50" wide opening provides an enormous linear space to watch the fire. It combines technology with elegance, allowing you to enjoy an open fire in a modern fashion.
-
Page 3: Table Of Contents
TABLE OF CONTENTS GETTING STARTED: WHAT TO KNOW AND DO BEFORE THE FIRST FIRING MPORTANT AFETY AND PERATION RECAUTIONS Do's and Don'ts Avoiding Excessive Temperatures EATURES Unique Decorative Fireplace Options ROPER What to Burn at All Times ... -
Page 4: Getting Started: What To Know And Do Before The First Firing
GETTING STARTED: WHAT TO KNOW AND DO BEFORE THE FIRST FIRING GETTING STARTED: WHAT TO KNOW AND DO BEFORE THE FIRST FIRING IMPORTANT SAFETY AND OPERATION PRECAUTIONS S AND If this fireplace is not properly installed, a house fire could result. For your safety the fireplace should be installed by a professional following the installation directions. -
Page 5: Avoiding Excessive Temperatures
THIS WOOD LOAD IS MORE THAN SUFFICIENT TO FILL THE FIREBOX COMPLETELY WITH FLAMES AND PROVIDE A LARGE AMOUNT OF RADIANT HEAT. THE RENAISSANCE LINEAR 50 WILL BURN WITH LARGE HIGH FLAMES REGARDLESS OF HOW THE WOOD IS PLACED IN THE UNIT. STACKING THE WOOD TIPI-STYLE AGAINST THE BACK OF THE FIREPLACE IS ACCEPTABLE BUT CAN COSMETICALLY DAMAGE THE FIREBOX REFRACTORY BRICKS IF YOU’RE NOT CAREFUL PLACING THE... -
Page 6: Features
IREPLACE The LINEAR 50 fireplace is a decorative fireplace that provides a magnificent view of the fire. It is defined as a fireplace (primarily for aesthetics) under the 2015 EPA (United States Environmental Protection Agency) regulation since it offers more than 500 square inches of pure fire viewing (710 square inches are visible). -
Page 7: What Never To Burn
DO NOT BURN DRIFTWOOD, TREATED WOOD, COAL, GARBAGE, OR PLASTIC. EVER TO Never use flammable liquids such as gasoline, kerosene, charcoal lighter fluids to start or refresh a fire in the LINEAR 50. Never burn driftwood, treated wood, coal, garbage, or plastic. -
Page 8: Operating The Fireplace
UTSIDE ONTROL The LINEAR 50 is designed to use outside air for combustion. The control for the outside air is located on the left side beyond the door rail, approximately half way up (see Figure 2). You need to fully open the glass door and the firescreen to have access to the outside air control. -
Page 9: Chimney Damper
Always start by opening the chimney damper. There are a number of ways to arrange your firewood to build a fire in your LINEAR 50. Always build and maintain the fire well behind the ash step refractory bricks, never against or close to the glass door or the firescreen. In all cases, you want to start with a number of pieces of easily lit material, such as newspaper. -
Page 10: Controlling The Fire
CONTROLLING THE FIRE The LINEAR 50 fireplace is designed to provide warm radiant heat. Although it does not come with a draft control, you will find that you can control the intensity of the fire and the quantity of flames quite well by varying the size and placement of the logs. Burning with the glass door or the firescreen closed will also affect heat transfer. -
Page 11: Maintenance
Do not use abrasive cleaners. AINT You can touch up the metal areas of the face of the LINEAR 50 with Stove Bright Metallic Black high temperature paint which is available at most fireplace dealers. Follow the directions outlined on the spray can. -
Page 12: Guillotine System
(regular grease will not withstand the heat of the fireplace) on each guide rail (left and right) just below the bottom of the door and move your door up and down a couple of times to distribute the grease all over the guide rails. Repeat for the firescreen. You can purchase additional high temperature grease from your Renaissance dealer. WARNING: DO NOT USE TEFLON-BASED OR SILICON-BASED PRODUCTS SUCH AS JIG-A-LOO BECAUSE THEY ARE NOT MEANT TO BE USED IN A HIGH TEMPERATURE ENVIRONMENT. -
Page 13: Adjusting The Glass Door For Proper Seal
This gasket will rarely need to be changed but it may require some adjustment. Please see your Renaissance dealer on this subject. 4. There is a stainless steel gasket that seals the bottom... -
Page 14: Chimney Cleaning
CHIMNEY CLEANING A fireplace as clean burning as the LINEAR 50 does not produce a lot of creosote, but the chimney should nevertheless be inspected for creosote buildup after a couple of months of using it. This will allow you to visualize the amount of creosote that is accumulating and adjust the frequency of checking the chimney accordingly. -
Page 15: Replacement Parts
REPLACEMENT PARTS A complete list of replacement parts is available on our web site: www.renaissancefireplaces.com. LISTING LABEL The listing label has been placed on a thin steel plate attached by a cable inside the guillotine bay on the far right of the firebox. Both the firescreen and the glass door must be open to access it. -
Page 16: Warranty
LIMITATIONS: All items found to be defective will be replaced or repaired upon return of the defective part to an authorized Renaissance Fireplaces™ dealer. Renaissance Fireplaces™ will not be responsible for freight costs related to shipping replacement parts. ... - Page 17 Renaissance Fireplaces™ is free of liability for any damages caused by the appliance, as well as material and labor charges incurred in the removal or re-installation of any Renaissance Fireplaces™ fireplace under this warranty. Incidental or consequential damages are not covered by this warranty.
