Cooper Lighting Metalux WE Series Specifications

D I M E N S I O N S
LAMPS A
2 Lamp 7-1/2" (191mm)
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : W E - 2 3 2 A - 1 2 0 V - E B 8 1 - U
Number
Series
of Lamps
WE= Series
2=2 Lamps
(Not Included)
Wattage (Length)
40=40W T12 (48")
32=32W T8 (48")
A=Acrylic Refractor/Lens
(1)
Voltage
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal Voltage 120-277
Options
GL=Single Element Fuse
GM=Double Element Fuse
Emergency - for EM installed, see EM options table
L E N S R E T E N T I O N
Lens is mechanically retained by end caps.
(Not Recommended For Sloped Ceiling Applications.)
(1)
NOTES: Products also available in non-US voltages and frequencies for international markets.
(3) (4)
2 point suspension recommended. Not for continuous row mounting.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
COOPER LIGHTING - METALUX
B
2-5/8" (67mm)
(1)
Ballast Type
LE3=T12 Magnetic Energy Saving
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
No. of
Harmonic Distortion < 20%
Ballast
1, 2 or 3
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
(2)
EB2 =T12 Electronic Rapid Start.
No. of Ballast
1 or 2
(For complete details on generic or to specify
manufacturer's ballast see pg. 469)
(2)
Not available when specifying emergencies, voltage must be specific.
D E S C R I P T I O N
The WE Economy Wraparound
features value and energy
efficient performance. The
luminaire's characteristic clean,
low profile design is appealing
and functional. The WE utilizes a
clear, low brightness, extruded
acrylic refractor and injection
molded end caps for dependable
performance and good looks.
The efficient and economical
WE wrap has been designed as
an economical choice for value
engineered applications. It is
an ideal choice for most any
wraparound situation including
schools, retail, file and copy
areas and storage spaces.
Options Packaging
(See Options U=Unit Pack
Section)
®
WE SERIES
4 ' S u r f a c e
2 L a m p s
S U R F A C E C O M M E R C I A L
G R A D E W R A PA R O U N D
• Equipped with energy
saving ballasts/complies
with federal energy
efficiency standards
• Low profile
• Low brightness extruded
acrylic refractor
• Full decorative injection
molded end caps
• Lens retained by end caps
• Stem or surface mounting
(not for continuous row
mounting)
(3) (4)
• Baked white enamel finish
• UL/CUL Listed. Suitable for
damp locations.
COOPER LIGHTING
423
