- Page 1 QUICK START GUIDE REFRIGERATORS • CRE & CWC Models 30658_D...
- Page 2 ® to preserve the right product, in the right place, at the right temperature. Since 2014, U-Line has been part of the Middleby family of brands. All products are designed, engineered, and assembled in Milwaukee, Wisconsin, USA, and select products are available worldwide.
-
Page 3: Table Of Contents
This Quick Start Guide covers the basics of installation and general use of your product. CONTENTS Safety and Warning Environmental Requirements Electrical Door Swing Door Adjustments General Installation Control Operation First Use Airflow & Product Loading Interior Adjustments Cleaning Warranty For more details, see the complete User Guide & Service Manual on u-line.com. -
Page 4: Safety And Warning
QUICK START GUIDE Safety and Warning NOTICE DANGER Please read all instructions before installing, operating, or servicing the appliance. Service must be done by factory authorized service personnel. Any parts shall be replaced Use this appliance for its intended purpose only and follow with like components. -
Page 5: Environmental Requirements
QUICK START GUIDE 16-1/2" 16-1/2" Environmental Requirements 90° 90° Door Swing Door Swing NOTICE This model is intended for indoor/interior applications only and is not to be used in installations that are open/ Electrical installation must observe all state and Stainless Models Black and White Models local codes. -
Page 6: Door Adjustments
QUICK START GUIDE Door Adjustments Remove hinge pin from bottom hinge and install in left-hand bottom hinge. DOOR ALIGNMENT AND ADJUSTMENT Align and adjust the door if it is not level or not sealing properly. If the door is not sealed, the unit may not cool Bottom Bottom Right Hinge... -
Page 7: General Installation
QUICK START GUIDE General Installation Anti-Tip Bracket LEVELING INFORMATION FLOOR MOUNTED ANTI-TIP INSTALLATION CAUTION Locate two anti-tip brackets included with the kit. Place the unit into the area where it will be installed. To comply with applicable federal, state, and local Check the door, sides, and top for a proper fit. -
Page 8: Control Operation
If the temperature displayed is different than selected, the unit is progressing towards the selected temperature. Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. U-Line recommends allowing the unit to reach set points before loading. -
Page 9: Airflow & Product Loading
Larger diameter champagne and Magnum bottles only fit on wine racks when noted on the product 7⁄16” 19⁄32” specifications. When determining capacities U-Line (64mm) (66 mm) uses typical 12 oz. cans, 12 oz. bottles, 750 mL white wine and red wine bottles shown below. -
Page 10: Interior Adjustments
QUICK START GUIDE Interior Adjustments (RE Models) scratching interior of unit. Once removed, retract the slides. Slide-out Metal Shelf Removal Note: The slides on the shelf have a thin coating which All models feature side mounted rack supports with 19 is used to block moisture and provide lubrication. - Page 11 QUICK START GUIDE Interior Adjustments (WC Models) Once removed, retract the slides. Note: The slides on the rack have a thin coating which All models feature side mounted rack supports with 19 is used to block moisture and provide lubrication. Use adjustment positions.
- Page 12 QUICK START GUIDE Wine Storage Options WINE RACK BOTTLE POSITION Specially designed horizontal wine racks properly position the bottles so the wine remains in contact with the cork, which ensures the cork does not become dry. Racks are designed to accommodate typical 750ml wine bottles as follows: UCWC515 15”...
-
Page 13: Cleaning
QUICK START GUIDE Cleaning CLEAN INTERIOR COMPONENTS CLEANING VS. SANITIZING Use warm or hot water with dish soap to clean all removed This guide will address both the cleaning and the sanitizing components and interior surfaces. You may use a vinegar and of the unit. - Page 14 QUICK START GUIDE INTERIOR CLEANING & SANITIZING Remove Wine Rack NOTICE Fully extend empty rack Do not use any solvent-based or abrasive cleaners. These types of cleaners may transfer taste and/or odor to the interior products and damage or discolor the interior. Remove Slide-out Metal Shelf Remove all items from shelf.
- Page 15 QUICK START GUIDE Remove 4 rack supports by removing 4 screws on each Remove evaporator cover. one. a. Remove thermistor cover - use a flat tool to pry out the push pin fastener b. Remove 8 screws (3 on each side 2 on top) Remove screws and spacers from evaporator and carefully pull evaporator forward - just enough to be able to wipe both surfaces of the evaporator and the...
- Page 16 QUICK START GUIDE Remove LED Light Cover Remove Door, Brackets, and Hinge With a flat screwdriver, carefully pry LED light cover Hold door to keep it from falling. from ceiling. LED light strip will hang down loosely. Remove top hinge pin. Remove door by tilting forward and lifting door off bottom hinge.
- Page 17 QUICK START GUIDE DEFROSTING Under normal conditions this unit does not require manual defrosting. Minor frost on the rear wall or visible through the evaporator plate vents is normal and will melt during each cycle. If there is excessive build-up of 1/4” (6 mm) or more, manually defrost the unit.
- Page 18 For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.
