- Page 1 ＰＴ－ＰＥＸ０２ＧＢ ＰｏＥ Ｅｘｔｅｎｄｅｒ Ｑｕｉｃｋ Ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ www.procetpoe.com...
- Page 2 Ｄｅｃｌａｒａｔｉｏｎ Ｔｈｉｓ ｄｏｃｕｍｅｎｔ ｂｅｌｏｎｇｓ ｔｏ ＰＲＯＣＥＴ ｃｏｍｐａｎｙ． Ｉｔ ｉｓ ｎｏｔ ａｌｌｏｗｅｄ ｔｏ ｒｅｐｒｏｄｕｃｅ ａｎｄ ｍｏｄｉｆｙ ｗｉｔｈｏｕｔ ｔｈｅ ｏｒｉｇｉｎａｌ ａｕｔｈｏｒ＇ｓ ｐｅｒｍｉｓｓｉｏｎ． Ｉｔ ｉｓ ＰＲＯＣＥＴ＇ｓ ｐｏｌｉｃｙ ｔｏ ｉｍｐｒｏｖｅ ｉｔｓ ｐｒｏｄｕｃｔｓ ａｓ ｎｅｗ ｔｅｃｈｎｏｌｏｇｙ， ｃｏｍｐｏｎｅｎｔｓ， ｓｏｆｔｗａｒｅ， ａｎｄ ｆｉｒｍｗａｒｅ ａｔ ａｎｙ ｔｉｍｅ． ＰＲＯＣＥＴ， ｔｈｅｒｅｆｏｒｅ， ｒｅｓｅｒｖｅｓ ｔｈｅ ｒｉｇｈｔ ｔｏ ｃｈａｎｇｅ ｓｐｅｃｉｆｉｃａｔｉｏｎｓ ｗｉｔｈｏｕｔ ｐｒｉｏｒ ｎｏｔｉｃｅ． Ｐｌｅａｓｅ ｆｏｌｌｏｗ ＷＥＥＥ （Ｗａｓｔｅ Ｅｌｅｃｔｒｉｃａｌ ａｎｄ Ｅｌｅｃｔｒｏｎｉｃ Ｅｑｕｉｐｍｅｎｔ） ｄｉｓｐｏｓａｌ ｉｎｓｔｒｕｃｔｉｏｎｓ ｆｏｒ ｏｌｄ ｅｌｅｃｔｒｏｎｉｃ ｐｒｏｄｕｃｔｓ． Ｐｌｅａｓｅ ｄｏ ｎｏｔ ｄｉｓｐｏｓｅ ｏｆ ｔｈｅ ｏｌｄ ｐｒｏｄｕｃｔ ｉｎ ｙｏｕｒ ｇｅｎｅｒａｌ ｈｏｕｓｅｈｏｌｄ ｗａｓｔｅ ｂｉｎ． Ｔｈｅ ｓｙｍｂｏｌ ｉｎｄｉｃａｔｅｓ ｔｈａｔ ｔｈｅ ｐｒｏｄｕｃｔ ｓｈｏｕｌｄ ｎｏｔ ｂｅ ｄｉｓｃａｒｄｅｄ ａｓ ｕｎｓｏｒｔｅｄ ｗａｓｔｅ ｂｕｔ ｍｕｓｔ ｂｅ ｓｅｎｔ ｔｏ ｓｅｐａｒａｔｅ ｃｏｌｌｅｃｔｉｏｎ ｆａｃｉｌｉｔｉｅｓ ｆｏｒ ｒｅｃｏｖｅｒｙ ａｎｄ ｒｅｃｙｃｌｉｎｇ． Ｃｏｐｙｒｉｇｈｔ ©2０２２Ｃｒｅａｔｉｖｅ Ｌｉａｎｊｉｅ Ｎｅｔｗｏｒｋ Ｔｅｃｈｎｏｌｏｇｙ Ｃｏ．Ｌｔｄ Ａｌｌ ｒｉｇｈｔｓ ｒｅｓｅｒｖｅｄ． Ｄｅｃｌａｒａｔｉｏｎ...
- Page 3 Ｏｖｅｒｖｉｅｗ The installation Guide for PT-PEX02GB and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product.
- Page 4 Ｔａｂｌｅ ｏｆ ｃｏｎｔｅｎｔｓ １ Ｉｎｔｒｏｄｕｃｔｉｏｎ ０１ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１ １．２ Ａｐｐｅａｒａｎｃｅ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１ １．３ Ｓｐｅｃｉｆｉｃａｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０３ ２ Ｉｎｓｔａｌｌａｔｉｏｎ ｐｒｅｐａｒａｔｉｏｎ ０４ ２．１ Ｐａｃｋａｇｅ ｃｏｎｔｅｎｔｓ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ２．２ Ｉｎｓｔａｌｌａｔｉｏｎ ｔｏｏｌｋｉｔ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ２．３ Ｉｎｓｐｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ３ Ｉｎｓｔａｌｌａｔｉｏｎ ０６ ３．１ Ｗａｌｌ ｍｏｕｎｔｉｎｇ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０６ ３．２ Ｓｌｏｔ-fasten ｍｏｕｎｔｉｎｇ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０８ ３．３ Ｇｒｏｕｎｄｉｎｇ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０９ ３．４ Ｉｎｓｐｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．１１ Ｔｈｅ ｔａｂｌｅ ｏｆ ｃｏｎｔｅｎｔｓ...
- Page 5 １ Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ PT-PEX02GB is an industrial-rated PoE Extender with two PoE output ports, specially designed for complex backhaul and networking applications. Enclosed in a high-impact metal shell. The 3 ports 10/100/1000Mbps includes: 1 x PoE-powered input port with 802.3bt/PoE++ at 60W or higher of 95W(Max ) and 2 x PoE output ports with 6KV (10/700us) surge protection.
- Page 6 Ｓｉｄｅ ｖｉｅｗ Ｂｏｄｙ ｓｃｒｅｗｓ １－２ Ｓｉｄｅ ｖｉｅｗ Ｆｒｏｎｔ ｖｉｅｗ ＲＪ４５ Ｄａｔａ Ｉｎｄｉｃａｔｏｒ ＲＪ４５ Ｐｏｗｅｒ Ｉｎｄｉｃａｔｏｒ ＧＮＤ Ｔｅｒｍｉｎａｌ ＰｏＥ Ｉｎｐｕｔ Ｐｏｒｔ ＰｏＥ Ｏｕｔｐｕｔ Ｐｏｒｔ１ ＰｏＥ Ｏｕｔｐｕｔ Ｐｏｒｔ １－３ Ｆｒｏｎｔ ｖｉｅｗ ０２ Ｉｎｔｒｏｄｕｃｔｉｏｎ...
- Page 7 Ｉｎｄｉｃａｔｏｒｓ Display: Ｉｔｅｍｓ Ｓｔａｔｕｓ Ｄｅｓｃｒｉｐｔｉｏｎ ＰｏＥ ｌｏａｄ Ｓｏｌｉｄ Ｇｏｏｄ Ｐｏｗｅｒ ｉｎｄｉｃａｔｏｒ Ｆｌａｓｈｉｎｇ Ｄｅｔｅｃｔｉｏｎ ｌｏａｄ Ｇｒｅｅｎ Ｌｉｇｈｔ Data Ｓｏｌｉｄ Ｇｏｏｄ ｃｏｎｎｅｃｔｉｏｎ indicator Ｄａｔａ ｔｒａｎｓｍｉｔｔｉｎｇ Ｆｌａｓｈｉｎｇ Yellow Light Ｓｙｓｔｅｍ ａｂｎｏｒｍａｌ ｏｒ ｐｏｗｅｒ ｏｆｆ ＯＦＦ １．３ Ｓｐｅｃｉｆｉｃａｔｉｏｎ Ｉｔｅｍｓ Ｄｅｓｃｒｉｐｔｉｏｎ ４４－５７Ｖ １．５Ａ Ｍａｘ Ｉｎｐｕｔ ４／５（＋），７／８（－），３／６（＋），１／２（－） Ｐｏｗｅｒ ｐｉｎｓ ５５Ｖ ／ ０．５５Ａ ＊ ２Ｐｏrt ｓ（Ｔｏｔａｌ ６０Ｗ） Ｏｕｔｐｕｔ ３／６（＋）， １／２（－） Ｐｏｗｅｒ ｐｉｎｓ １０／１００／１０００Ｍｂｐｓ Ｄａｔａ ｓｐｅｅｄ －４０℃ ｔｏ ６５℃ Ｗｏｒｋ ｔｅｍｐ． Ｏｐｅｒａｔｉｎｇ ２０％－８０％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ...
- Page 8 ２.Ｉｎｓｔａｌｌａｔｉｏｎ ｐｒｅｐａｒａｔｉｏｎ ２．１ ｐａｃｋａｇｅ ｃｏｎｔｅｎｔｓ Ｏｐｅｎ ｔｈｅ ｂｏｘ ｏｆ ｔｈｅ ＰＴ－ＰＥＸ０２ＧＢ ａｎｄ ｃａｒｅｆｕｌｌｙ ｕｎｐａｃｋ ｉｔ， tｈｅ ｂｏx ｓｈｏｕｌｄ ｃｏｎｔａｉｎ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｉｔｅｍｓ： Ｇｒｏｕｎｄ ｌｕｇ ＰＴ－ＰＥＸ０２ＧＢ Ｏｐｅｒａｔｉｏｎ ｍａｎｕａｌ Ｗｉｒｅ＆２．５ ｓｃｒｅｗ ２．２ Ｉｎｓｔａｌｌａｔｉｏｎ ｔｏｏｌｋｉｔ Ｔｈｅｓｅ ｔｏｏｌｓ ｍａｙ ｂｅ ｎｅｅｄｅｄ ｄｕｒｉｎｇ ｅｑｕｉｐｍｅｎｔ ｉｎｓｔａｌｌａｔｉｏｎ and should be prepared by yourself： ｌｅｖｅｌ ｒｕｌｅｒ， ｍａｒｋｉｎｇ ｐｅｎ， ｃｒａｆｔ ｋｎｉｆｅ， ｗｉｒｅｓ...
- Page 9 ＰＤ ０１ ＰｏＥ Ｓｗｉｔｃｈ ＰＴ－ＰＥＸ０２ＧＢ OLink POWER ＰＤ ０２ ２－１ Ｄｅｖｉｃｅ ｃｏｎｎｅｃｔｉｏｎ Ｃｏｎｎｅｃｔ ＰｏＥ ＩＮ ｔｏ ＰｏＥ ｓｗｉｔｃｈ， ｔｈｅ ｙｅｌｌｏｗ ｄａｔａ ｉｎｄｉｃａｔｏｒ ａｎｄ ｇｒｅｅｎ ｐｏｗｅｒ ｉｎｄｉｃａｔｏｒ ａｒｅ ｏｎ， ｗｈｉｌｅ ｔｈｅ ｃｏｎｎｅｃｔｉｏｎ ｉｓ ｄｏｎｅ． Ｎｏｗ ｙｏｕ ｃａｎ ｃｏｎｎｅｃｔ ｔｈｅ ｅｘｔｅｎｄｅｒ ｗｉｔｈ ＰＤｓ ｉｎ ｔｗｏ ＰｏＥ ｏｕｔｐｕｔ ｐｏｒｔ． Ｔｈｅ ｙｅｌｌｏｗ ｄａｔａ ｉｎｄｉｃａｔｏｒ ａｎｄ ｇｒｅｅｎ ｐｏｗｅｒ ｉｎｄｉｃａｔｏｒ ａｒｅ ｏｎ， ａｎｄ ｔｈｅ ＰＤｓ ａｒｅ ｓｕｃｃｅｓｓｆｕｌｌｙ ｃｏｎｎｅｃｔｅｄ． Ｃａｕｔｉｏｎ： Ｗｅ ｒｅｃｏｍｍｅｎｄ ｔｏ ｕｓｅ Ｃａｔ５ ｏｒ ｈｉｇｈｅｒ ＵＴＰ／ＳＴＰ ｃａｂｌｅｓｆ ｏｒ １００ Ｂａｓｅ－ＴＸ Ｅｔｈｅｒｎｅｔ； Ｗｅ ｒｅｃｏｍｍｅｎｄ ｔｏ ｕｓｅ Ｃａｔ5e ｏｒ ａｂｏｖｅ ＵＴＰ／ＳＴＰ ｃａｂｌｅｓ ｆｏｒ １０００Ｂａｓｅ－Ｔ ｏｒ ２．５ＧＢａｓｅ－Ｔ Ｅｔｈｅｒｎｅｔ．...
- Page 10 ３.Ｉｎｓｔａｌｌａｔｉｏｎ Ｔｈｉｓ ｐｒｏｄｕｃｔ ｉｓ ｓａｆｅ ｔｏ ｕｓｅ ｆｏｒ slot-fasten mounted ａｎｄ ｗａｌｌ－ｍｏｕｎｔｅｄ ｉｎｓｔａｌｌａｔｉｏｎ． ３．１ Ｗａｌｌ ｍｏｕｎｔｉｎｇ Ｔｈｅ ｄｅｖｉｃｅ ｗｉｌｌ ｂｅ ｆｉｘｅｄ ｏｎ ｔｈｅ ｗａｌｌ ｗｉｔｈ ｓｃｒｅｗ ｉｎｔｏ ｔｈｅ ｐｏｌｅｓ， ａｎｄ ｔｈｅ ｈｏｌｅ ｄｉａｍｅｔｅｒ ｓｈｏｕｌｄ ｂｅ ｂｅｔｗｅｅｎ ８ｍｍ ｔｏ１０ｍｍ． ３．１．１Ｍａｒｋ ｔｈｅ ｓｃｒｅｗ ｈｏｌｅ ｐｏｓｉｔｉｏｎｓ ｗｉｔｈ ｍａｒｋｉｎｇ ｐｅｎｓ． Ａｓ ｓｈｏｗｅｄ ｉｎ３－１． ｔｈｅ ｈｏｌｅ ...
- Page 11 ３．１．２Ｄｒｉｌｌ ａｎ ８ｍｍ ｄｉａｍｅｔｅｒ ｈｏｌｅ ａｔ ｔｈｅ ｍａｒｋｅｄ ｐｏｓｉｔｉｏｎ ａｎｄ ｆｉｘ ｔｈｅ ｅｘｐａｎｓｉｏｎ ｂｏｌｔ ｉｎｔｏ ｔｈｅ ｈｏｌｅ ｂｙ ｈｉｔｔｉｎｇ ｉｔ ｗｉｔｈ ａ ｒｕｂｂｅｒ ｈａｍｍｅｒ． ３．１．３Fｉｘ ｔｈｅ ｐｒｏｄｕｃｔ ｗｉｔｈ ｓｃｒｅｗｓ ａｎｄ ｔｉｇｈｔｅｎ them ｉｎｔｏ ｔｈｅ ｅｘｐａｎｓｉｏｎ ｂｏｌｔｓ． Ａｓ ｓｈｏｗｅｄ ｉｎ３－２． Ｅｘｐａｎｓｉｏｎ ｂｏｌｔｓ Ｓｅｌｆ－ｔａｐｐｉｎｇ ｓｃｒｅｗｓ Ｐｒｏｄｕｃｔ ｍｏｕｎｔｉｎｇ ｈｏｌｅｓ Wall ３－２ Ｉｎｓｔａｌｌａｔｉｏｎ Ｃａｕｔｉｏｎ ｉｎ ｄｒｉｌｌｉｎｇ ｐｒｏｃｅｓｓ： · ｋｅｅｐ ｔｈｅ ｄｒｉｌｌ ｂｉｔ ｐｅｒｐｅｎｄｉｃｕｌａｒ ｔｏ ｔｈｅ ｗａｌｌ ｓｕｒｆａｃｅ， ｈｏｌｄ ｔｈｅ ｄｒｉｌｌ ｈａｎｄｌｅ ｔｉｇｈｔｌｙ ｗｉｔｈ ｂｏｔｈ ｈａｎｄｓ， ｍａｉｎｔａｉｎ ａ ｓｔｅａｄｙ ｄｉｒｅｃｔｉｏｎ ｔｏ ａｖｏｉｄ ｓｈａｋｉｎｇ...
- Page 12 Ｂｏｌｔ ｄｅｐｔｈ≥６０ｍｍ ３－３ Ｂｏｌｔ ｄｅｐｔｈ ３．２ Ｓｌｏｔ-fasten ｍｏｕｎｔｉｎｇ Ｕｓｅ ｔｈｅ ｓｌｏｔ-ｆａｓｔｅｎ ｍｏｕｎｔｉｎｇ ｔｏ ｆｉｘ ｔｈｅ ｐｒｏｄｕｃｔ ｏｎ ｔｈｅ ｗａｌｌ ｗｉｔｈ ｓｃｒｅｗｓ． ３．２．１Ｌｏｏｓｅｎ ｔｈｅ ｓｃｒｅｗｓ ａｎｄ ｐｕｔ ｔｈｅ ｐｒｏｄｕｃｔ ｓｌｏｔ ｉｎｔｏ ｔｈｅ ｓｃｒｅｗ． Ａｓ ｓｈｏｗｅｄ ｉｎ ３－４． Ｐｒｏｄｕｃｔ ｓｌｏｔ Ｗａｌｌ ｗｉｔｈ ｓｃｒｅｗ ３－４ Ｓｌｏｔ-fasten ｍｏｕｎｔｉｎｇ ０８ Ｉｎｓｔａｌｌａｔｉｏｎ...
- Page 13 ３．２．２ Ｍａｋｅ ｓｕｒｅ ｔｈｅ ｓｌｏｔ ｉｓ ｆｉｘｅｄ ｔｏ ｔｈｅ ｓｃｒｅｗｓ ｔｉｇｈｔｌｙ ａｎｄ ｔｉｇｈｔｅｎ ｔｈｅ ｓｃｒｅｗｓ． Ａｓ ｓｈｏｗｅｄ ｉｎ ３－５． Ｗａｌｌ ｗｉｔｈ ｓｃｒｅｗ ３－５ Ｓｌｏｔ-fasten ｉｎｓｔａｌｌａｔｉｏｎ ３．３ Ｇｒｏｕｎｄｉｎｇ ＰＲＯＣＥＴ ｏｕｔｄｏｏｒ ｄｕａｌ－ｐｏｒｔｓ sｐｌｉｔｔｅｒ ＰＴ－ＰＥＸ０２ＧＢ－ＯＴ ｈａｓ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｇｒｏｕｎｄｉｎｇ ｓｏｌｕｔｉｏｎｓ ｆｏｒ ｒｅｆｅｒｅｎｃｅ ｄｕｒｉｎｇｃｏｎｓｔｒｕｃｔｉｏｎ： Ｉｆ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ ｉｓ ｉｎ ｔｈｅ ｃｏｍｐｕｔｅｒ ｒｏｏｍ， ｉｔ ｃａｎ ｂｅ ｃｏｎｎｅｃｔｅｄ ｔｏ ｔｈｅ ｄｅｄｉｃａｔｅｄ ｇｒｏｕｎｄｉｎｇ...
- Page 14 ＧＮＤ Ｔｅｒｍｉｎａｌ ２．５ＭＭ ｓｃｒｅｗ Ｇｒｏｕｎｄｉｎｇ ｂｕｓｂａｒ ３－６ Ｇｒｏｕｎｄｉｎｇ For the safety of personnel and equipment in an environment without dedicated grounding equipment, a simple grounding device can be constructed as follows: a. Prepare a 6mm 2 grounding wire or a braided soft copper wire. b.
- Page 15 ＧＮＤ Ｔｅｒｍｉｎａｌ ２．５MM ｓｃｒｅｗ Ｇｒｏｕｎｄ ２２００ ｓｏｉｌ ＭＭ ３－７ Ｓｉｍｐｌｅ ｇｒｏｕｎｄｉｎｇ ３．４ Ｉｎｓｐｅｃｔｉｏｎ ａｆｔｅｒ ｉｎｓｔａｌｌａｔｉｏｎ Inspect the installed equipment before putting it into operation： • Ｍａｋｅ ｓｕｒｅ ｔｈｅ ＰｏＥ ｓｗｉｔｃｈ ｉｓ ｃｏｍｐｌｉａｎｔ ｗｉｔｈ ｏｕｒ ｐｒｏｄｕｃｔ． • Ｍａｋｅ ｓｕｒｅ ｔｈｅ Ｅｔｈｅｒｎｅｔ ｃａｂｌｅ ｃｏｎｎｅｃｔｉｏｎ ｉｓ ｃｏｒｒｅｃｔ． Make sure all connections are correct, and turn on the power, inspect all the indicators. Ｉｎｓｔａｌｌａｔｉｏｎ １１...
- Page 16 Qualification Card PASS Ｃｒｅａｔｉｖｅ Ｌｉａｎｊｉｅ Ｎｅｔｗｏｒｋ Ｔｅｃｈｎｏｌoｇｙ Ｃｏ．Ｌｔｄ ｗｗｗ．ｐｒｏｃｅｔｐｏｅ．ｃｏｍ...
