lapara UPS 1K User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
USER MANUAL
Online UPS
1K/2K/3K
Uninterruptible Power Supply System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPS 1K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for lapara UPS 1K

Summary of Contents for lapara UPS 1K

  • Page 1 USER MANUAL Online UPS 1K/2K/3K Uninterruptible Power Supply System...

  • Page 2: Table Of Contents

    Table of Contents 1. Important Safety Warning ............... 1 1.1. Transportation ....................1 1.2. Preparation ......................1 1.3. Installation ......................1 1.4. Operation ......................1 1.5. Maintenance, service and faults ................2 2. Installation and setup..............3 2.1. Rear panel view ....................3 2.2.

  • Page 3: Important Safety Warning

    1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully 1.1.

  • Page 4: Maintenance, Service And Faults

    1.5. Maintenance, service and faults The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified maintenance personnel. Caution - risk of electric shock. Even after the unit is disconnected from the mains (building wiring outlet), components inside the UPS system are still connected to the battery and electrically live and dangerous.

  • Page 5: Installation And Setup

    2. Installation and setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. NOTE: There are two different types of online UPS: standard and long-run models. Please refer to the following model table.

  • Page 6: Setup The Ups

    2.2. Setup the UPS Before installing the UPS, please read below to select proper location to install UPS. 1. UPS should be placed on the flat and clean surface. Place it in an area away from vibration, dust, humidity, high temperature, flammable liquids, gases, corrosive and conductive contaminants.
  • Page 7 negative pole of battery pack to negative pole of external battery connector in UPS. Polarity misconnection will cause UPS internal fault. It’s recommended to add one breaker between positive pole of battery pack and positive pole of external battery connector in UPS to prevent damage to battery packs from internal fault.
  • Page 8 To allow for unattended UPS shutdown/start-up and status monitoring, connect the communication cable one end to the USB/RS-232 port and the other to the communication port of your PC. With the monitoring software installed, you can schedule UPS shutdown/start-up and monitor UPS status through PC. The UPS is equipped with intelligent slot perfect for either SNMP or AS400 card.

  • Page 9: Operations

    3. Operations 3.1. Button operation Button Function Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: When the UPS is on battery mode, press and hold this button for at least 5 seconds to disable or enable the alarm system.
  • Page 10 Display Function Backup time information Indicates the estimated backup time. H: hours, M: minute, S: second Configuration and fault information Indicates the configuration items, and the configuration items are listed in details in section 3-5. Indicates the warning and fault codes, and the codes are listed in details in section 3-7 and 3-8.

  • Page 11: Audible Alarm

    3.3. Audible Alarm Battery Mode Sounding every 5 seconds Low Battery Sounding every 2 seconds Overload Sounding every second Fault Continuously sounding Bypass Mode Sounding every 10 seconds 3.4. LCD display wordings index Abbreviation Display content Meaning Enable Disable Escape High loss Low loss Battery...

  • Page 12: Ups Setting

    3.5. UPS Setting There are three parameters to set up the UPS. Parameter 1 Parameter 1: It’s for program alternatives. Refer to below table. Parameter 2 and parameter 3 are the setting options or values for each program. Parameter 2 Parameter 3 01: Output voltage setting Interface...
  • Page 13 04: ECO enable/disable Interface Setting Parameter 3: Enable or disable ECO function. You may choose the following two options: ENA: ECO mode enable DIS: ECO mode disable (Default) 05: ECO voltage range setting Interface Setting Parameter 2 & 3: Set the acceptable high voltage point and low voltage point for ECO mode by pressing Down key or Up key.
  • Page 14 08: Bypass frequency range setting Interface Setting Parameter 2 & 3: Set the acceptable high frequency point and acceptable low frequency point for Bypass mode by pressing the Down key or Up key. HLS: Bypass high frequency point For 50Hz output frequency models: 51-55Hz: setting the frequency high loss point from 51Hz to 55HZ(Default: 53.0Hz) For 60Hz output frequency models:...

  • Page 15: Operating Mode Description

    13: Charger maximum current setting Interface Setting Parameter 3: Set up the charger maximum current. 1/2/4/6/8: setting the charger maximum current 1/2/4/6/8* in Ampere. (Default: 8A) *Note: This setting is only available for super charger. 14: Charger Boost voltage setting Interface Setting Parameter 3: Set up the charger boost voltage.

  • Page 16: Faults Reference Code

    Bypass mode When input voltage is within acceptable range but UPS is overload, UPS will enter bypass mode or bypass mode can be set by front panel. Alarm is sounding every 10 second. Standby mode UPS is powered off and no output supply power, but still can charge batteries.

  • Page 17: Troubleshooting

    4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm even The AC input power is not Check if input power cord though the mains is normal. connected well.

  • Page 18: Storage And Maintenance

    Symptom Possible cause Remedy Fault code is shown as 14 and The UPS shut down Check output wiring and if automatically because connected devices are in the icon is lighting on short circuit occurs on the short circuit status. LCD display and alarm is UPS output.

  • Page 19: Specifications

    6. Specifications MODEL LA-ON-1K-LCD-V.09 (L*) LA-ON-2K-LCD-V.09 (L*) LA-ON-3K-LCD-V.09 (L*) CAPACITY** 1000 VA / 900 W 2000 VA / 1800 W 3000 VA / 2700 W INPUT Nominal Voltage 230 VAC or 120 VAC 110 - 300 VAC ± 5% or 55 - 150 VAC ± 5% @ 50% load Voltage Range 160 - 300 VAC ±...
  • Page 20 Manual de usuario SAI Online 1K/2K/3K Sistema de Alimentación Ininterrumpida...

This manual is also suitable for:

Ups 2kUps 3kUps 1k-lUps 2k-lUps 3k-l
