6. Technical Specifications

STATUS
ALARM
HA
POWER
USB USB MGMT CONSOLE
MGMT 1 / MGMT 2 WAN 1 / 1 WAN 2 / 2
FAIL OPEN FAIL OPEN
USB Port Console Port WAN Ports
USB Management Management
Port Ports
Interface Type Protocol
Ethernet Ports RJ-45 Gigabit Ethernet FortiASIC-accelerated switched Ethernet ports for
3 - 18
Ethernet Ports RJ-45 Gigabit Ethernet FortiASIC-accelerated switched Ethernet ports.
19 - 22
SFP Ports SFP 1Gbps/auto
19 - 22
WAN1, 1 RJ-45 Gigabit Ethernet FortiASIC-accelerated bypass protected port pair.
WAN2, 2 RJ-45 Gigabit Ethernet FortiASIC-accelerated bypass protected port pair.
MGMT 1 and RJ-45 Gigabit Ethernet Client ports for management. The default IP
MGMT 2
USB USB-A USB 2.0
USB MGMT USB-B USB 2.0
Console RJ-45 RS-232 serial
Hardware Specification
Internal Storage
Memory
DC Power
Redundant Power Supply
Power Consumption (Avg / Max)
Heat Dissipation
1 http://www.fortinet.com/products/fortigate/600C.html
Front
3 / 4 5 / 6 7 / 8 9 / 10 11 / 12 13 / 14 15 / 16 17 / 18 19 / 20
Ethernet
Ports 3 -18
DC Power Connection
Back
Description
connection to your network and the Internet.
Shared with SFP ports 19 to 22.
FortiASIC-accelerated small form-factor pluggable
transceiver. Shared with Ethernet ports 19 to 22.
address of MGMT 1 is 192.168.1.99.
USB server ports for USB key, modem, or
management functions.
USB client port for management.
Optional connection to the management computer.
Provides access to the CLI.
Description
non-removable, 64GB Solid State Drive (SSD)
Refer to the product datasheet
-48V DC
Optional
Refer to the product datasheet
Refer to the product datasheet

7. LED Specifications

21 / 22 19 / 20 21 / 22
SHARED INTERFACES
USB USB MGMT
Shared
Status, Alarm, HA, & Power LEDs
Ports 19 - 22
LED
STATUS
ALARM
HA
POWER
MGMT Ports
Activity
MGMT Speed
Ethernet Ports
Activity
Ethernet Port
Speed
1
SFP Ports
1
1
Management Ports Ethernet Ports
STATUS
ALARM
HA
POWER
CONSOLE
MGMT 1 / MGMT 2 WAN 1 / 1 WAN 2 / 2 3 / 4 5 / 6 7 / 8 9 / 10 11 / 12 13 / 14
FAIL OPEN FAIL OPEN
State Description
Green The unit is operating normally.
Flashing Green The unit is turning on.
Off The unit is off.
Not in use.
Green The unit is operating in normal HA mode.
Red The unit is operating in failover HA mode.
Off The unit is not operating in HA mode.
Green The unit is on.
Off The unit is off.
Green Port is active.
Flashing Green Port is transmitting and receiving data.
Off Port is not in use.
Green Port is connected at 1Gbps.
Amber Port is connected at 100Mbps.
Off Port is connected at 10Mbps or is not in use.
Green Port is active.
Flashing Green Port is transmitting and receiving data.
Off Port is not in use.
Green Port is connected at 1Gbps.
Amber Port is connected at 100Mbps.
Off Port is connected at 10Mbps or is not in use.
Green Port is active.
Flashing Green Port is transmitting and receiving data.
Off Port is not in use.
SFP Ports
15 / 16 17 / 18 19 / 20 21 / 22 19 / 20 21 / 22
SHARED INTERFACES
