INSTRUCTION MANUAL
1/2" AIR-POWERED IMPACT WRENCH
A301
IMPORTANT:
Upon receipt of the product, read and follow all safety rules,
Operating Instructions before first use it.
And retain this manual for
future reference.
Advertisement
Table of Contents
Related Manuals for Aeropro A301
Summary of Contents for Aeropro A301
- Page 1 INSTRUCTION MANUAL 1/2” AIR-POWERED IMPACT WRENCH A301 IMPORTANT: Upon receipt of the product, read and follow all safety rules, operating instructions before first use it. And retain this manual for future reference.
- Page 2 TABLE OF CONTENTS: TECHNICAL SPECIFICATIONS SAFETY GUIDELINES KEY PARTS DIAGRAM IMPORTANT INFORMATION OPERATING INSTRUCTIONS MAINTENANCE TROUBLESHOOTING EXPLODED VIEW PARTS LIST TECHNICAL SPECIFICATIONS: Square drive head: 1/2”(13mm) Air hose required: 3/8”ID Capacity Bolt size: 5/8”(16mm) Air inlet:...
- Page 3 connect the tool to the compressor. Failure to comply will result in serious injury or loss of life. Risk of electric shock: Do not expose a compressor to rain. Store it indoors. Compressor must be grounded. Do not use grounding adaptors.
- Page 4 Always ensure the use of appropriately matched air tools and compressors. The compressor should be able to supply a minimal air delivery of 5 SCFM@90PSI to ensure the compressor can run continuously with the AEROPRO Air-Powered Impact wrench. Using tools or a combination of tools that together or separately require air pressure more than that of which the air compressor can deliver will reduce performance and could void the compressor or tool guarantee/warranty.
- Page 5 AIR SYSTEM Always use clean, dry, regulated, compressed air at 4 to 7bar (60 to 100PSI). Do not exceed the maximum and minimum pressure. Operating the tool at the wrong pressure (too low or too high) will cause excessive noise or rapid wear. ...
- Page 6 impact wrench. Failure to comply will result in serious injury or loss of life. Verify that the air supply is clean before operating the Air powered impact wrench. 1. Plug in compressor, turn it on set the pressure regulator to 90psi, attach one end of the air hose to the compressor and the other end of the air hose to the tool.
- Page 7 Moisture or restriction in the air pipe. Incorrect size or type of hose connector. Check the air supply and follow instructions. Grit or gum deposits in the tool may also reduce performance. Inspect the trigger, the spring, and the safety mechanism for free movement on a regular basis in order to ensure that the safety system is fully functional.
- Page 8 Issue date: A301 Impact Wrench Explosive View and Parts list Version no.: Qty. No. Description Qty. No. Description Qty. Qty. No. Description Description Gun body cover Pin 2.5×20 Pin 1.5×15 Switch Lever Press-oiling cup Regulating Valve Air Inlet Washer Air Inlet Plug...
