Kiwi Camping SAVANNA POD KC074-413 Pitching Instructions

PITCHING INSTRUCTIONS
Your tent includes:
11 x pegs
2 x ropes
1 x BLACK fibreglass pole (4370mm x 9.5mm)
1. Once your Kiwi Camping
Savanna 4 Shelter is pitched on
dry level site and clear of any
sharp objects, remove the pod
from its carry bag, untie fabric
ties and unroll the Pod.
2. Layout the Pod next to your
shelter with the Pod door facing
into the Shelter.
3. Zip the pod onto your Savanna
4 Shelter starting at the base
corner and zipping up to meet at
centre. Repeat this step to zip up
the other side. Attach the toggle
at the centre on the shelter.
4. Peg out the four corners of Pod
starting at front (closest to the
Shelter) lining the pegs up with
the shelter webbing. Ensure you
include both the floor webbing
and fly shock cord when pegging
out.
5. Peg out the sides of the pod,
including the floor webbing and
fly shock cord.
Filename: 5309_KC074-413 Savanna 4 Pod_instruct
Dimensions: 280mm W x 220mm H
Colour: Black
SAVANNA POD
For Savanna 4 Deluxe Shelter
Model No. KC074-413
6. Assemble the BLACK pole by
interlocking the sections and
thread through the power mesh
pole sleeve and fit into the pin
and ring fitting on the floor. Your
Pod is now erect.
7. Peg out the centre back pegging
point.
8. Finally, rope out guy ropes.
REVERSE THE PROCEDURE TO LOWER THE TENT

PACKING INSTRUCTIONS

Pack the pole and pegs into their bags. Evenly lay out the pod. Fold
the pod from each side to the centre. Adjust to the length of the poles.
Place the poles onto the folded pod and roll them inside so that the
floor is on the outside. Store and pack the pod in it's bag.
