27ST220L
Instruction Manual
EN Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 27ST220L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bosch 27ST220L

Summary of Contents for Bosch 27ST220L

  • Page 1 27ST220L Instruction Manual EN Monitor...
  • Page 2 27ST220L SAFETY INSTRUCTIONS - Read before operating equipment This product was designed and manufactured to meet strict quality and 11. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed safety standards.
  • Page 3 27ST220L NTRODUCTION Philips Institutional TV Software Your Philips Institutional Television can be configured to operate in either "Consumer" or "Commercial" operational modes. Commercial Mode: Your Philips Institutional Television is configured at the Factory to operate in Commercial mode. When the television is in Commercial mode, access to its operation from its front panel controls or from a guest-mode remote can be limited, depending upon the settings of the Institutional TV features.
  • Page 4 27ST220L ITV M & A & C PCW227S, PCW227C) TEMS VAILABILITY ONSUMER OMMERCIAL ODES MODELS The following table summarizes the Commercial and Consumer menu items available on your Philips Institutional tele- vision. The functions of these menu items will be discussed in greater detail later in this booklet. Menu items denoted with a “>”...

  • Page 5: Keyboard Lock

    Refer also to the sections in this documentation regarding the use of the front panel controls, specifically front key- board lock-out*. The 27ST220L front panel consists of power on/off, volume, and channel controls. Channel - and Channel + normally change the television’s channel or input to any of the channels or inputs currently in the Channel Ring (see Channel Ring).

  • Page 6: How T O Use The O N -Screen Menu

    27ST220L CREEN This section explains the Philips Institutional Television’s menu items. As described previously, the availability of each item depends upon the television’s current operational mode (Consumer or Commercial) and the type of remote control command (guest or setup) issued.
  • Page 7 27ST220L CREEN ONTINUED CABLE TUNING (OFF / ON) SETUP CONSUMER FEATURES MENU Your Philips television can be configured to operate in either Cable TV or broadcast / off-air tuning modes. In other words, the TV must be configured depending upon whether a a Cable TV signal or a normal antenna signal is applied to its 75-ohm ANT/CABLE plug.
  • Page 8 27ST220L CREEN ONTINUED MIN VOLUME / MAX VOLUME* (VOL |||||---- nn) SETUP CONSUMER FEATURES MENU Applicable / available only to the Commercial Mode / setup menu. Limits the range throughout which the television’s volume can be adjusted by a guest mode remote control, or by the television’s front panel keyboard (provided the front panel keyboard has not been locked out, see KEYBOARD LOCK).

  • Page 9: Welcome Message

    27ST220L CREEN ONTINUED WELCOME MESSAGE* (>) SETUP CONSUMER FEATURES MENU Applicable / available only to the Commercial Mode / setup menu. The Welcome Message feature makes it possible for an on-screen message to appear whenever the television is first turned on. The message will remain until any front-panel keyboard command or remote control command is received.

  • Page 10: V-Chip Set Up

    27ST220L A/CH A/V SWITCH* (OFF / ON) SETUP CONSUMER FEATURES MENU Available in / applicable to Commercial Setup Menu / Commercial Mode. Alternate channel Audio / Video switch- ing. When A/CH A/V SWITCH is OFF, the remote-control A / CH (alternate channel) command causes the televi- sion to select the channel / input that was selected just prior to the currently-selected one.
  • Page 11 27ST220L ANELS Rear Jack Panel Front Jack Panel Jack Panel Information - The setting of the Commercial menu item EXT AUD/VID OUT determines whether or not signals will be present at the rear jack panel’s Monitor Out jacks. If EXT AUD/VID OUT is set to OFF, no signals will be present at these jacks.

  • Page 12: Default Settings

    Tel: 800-326-3270 The Netherlands Republic of Singapore Fax: 1-717-735-6560 Tele +31 40 27 87113 Tel: 65 (6) 319 3486 www.boschsecurity.com © 2004 Bosch Security Systems GmbH 3935 890 47412 04-46 | November 10, 2004 | Data Ssubject to change without notice.
