Mini Wi-Fi Home Hotspot 600 Kit
User Guide
1
Plug in extender near your router
1 Plug one end of the ethernet cable into a spare ethernet socket on your router/hub.
2 Plug the other end into the extender; it's called 'Broadband Extender' on the top.
IMPORTANT: to work properly,
extender and hotspot must be
plugged directly into the wall
socket and not into extension leads.
3 Plug the extender directly into a wall power socket. Make sure the socket's switched on.
Data
Etherenet
Power
1
Data
Etherenet
Power
2
3
Advertisement
Related Manuals for BT Mini Wi-Fi Home Hotspot 600 Kit
Summary of Contents for BT Mini Wi-Fi Home Hotspot 600 Kit
- Page 1 Mini Wi-Fi Home Hotspot 600 Kit User Guide Plug in extender near your router 1 Plug one end of the ethernet cable into a spare ethernet socket on your router/hub. 2 Plug the other end into the extender; it’s called ‘Broadband Extender’ on the top. IMPORTANT: to work properly, extender and hotspot must be Data Data plugged directly into the wall Etherenet Etherenet Power Power socket and not into extension leads. 3 Plug the extender directly into a wall power socket. Make sure the socket’s switched on.
-
Page 2: Connect Your Devices
Plug in your home hotspot 1 Plug the hotspot directly into a wall power socket near the device you want to connect. Make sure the socket’s switched on. 2 Wait for connection to complete. Give it a couple of minutes. If everything’s okay, the Wireless, WPS/Link and Power lights will be on. Wireless WPS/Link Power If the WPS/Link light doesn’t light up, see Connection help overleaf. Mini Wi-Fi Home Hotspot Connect your devices You can connect your devices using wi-fi or the ethernet cable. The hotspot can support separate devices connected to the ethernet ports and wi-fi at the same time. - Page 3 Wireless network/SSID: BTHomeSpot-XXX it’s called BTHomeSpot-XXX. Wireless key: XXXXXXXX 3 Enter your hotspot’s wireless key printed on the pull-out card. Admin password: XXXXXXX 4 Complete the connection on your device. Your new Wi-Fi Home Hotspot and your existing wireless broadband router will show up as two separate networks. If your device shows both networks, it’s worth giving both of them a go as one might be faster and more reliable than the other. Wi-Fi cloning optional feature The hotspot supports an additional wi-fi cloning feature that enables it to clone your router’s name (SSID) and wireless key. If your device (e.g. laptop) is already configured to connect to your router, it will automatically connect to your new hotspot. This feature requires your router to support WPS; most recent routers do e.g. BT Home Hub 3 and later. 1 Plug the hotspot into a power socket near your broadband wireless router (e.g. in the same room). Wait until the Wireless light is steady green. 2 Press the WPS button on your router. 3 Within 2 minutes, press and hold the WPS/Link button on the hotspot for at least 15 seconds, until the Wireless light flashes orange and green. 4 Wait until the Wireless light returns to steady green. Now plug the hotspot back in where you want to extend coverage and wait for it to restart. 5 When in range, your wi-fi device will automatically connect to the hotspot.
-
Page 4: Light Status
Light status Mini Wi-Fi Home Hotspot Light Colour Status What’s happening Power Green Hotspot running normally Flashing Hotspot pairing Green Slow flashing Hotspot in power saving mode Hotspot turned off or boot-up failed WPS/Link Green Hotspot connected to network, high transfer speed Green Flashing Hotspot connected to network, low transfer speed Hotspot booting-up or boot-up failed or hotspot not connected to network Wireless Green Wireless enabled, data is being transmitted/received Hotspot booting-up or boot-up failed, or hotspot wireless disabled Orange Wireless security disabled on the hotspot or guest network Green/Orange Slow flashing Wi-Fi cloning in progress Green/Orange Fast flashing Wi-Fi cloning failed Broadband Extender 600 Light Status... -
Page 5: Connection Help
• Try to move the device nearer to your hotspot, which can improve the wireless signal quality. • Thick/concrete walls and ceilings may affect wi-fi. WPS/Link light is off or flashing • If you are adding the hotspot to your existing network, press the WPS/Link button on your hotspot for 1 second (Power light starts flashing). Within 2 minutes, press the Link button on one of the broadband extenders already in your home for 1 second to complete the connection. The WPS/Link light will be steady green. • To check if your home’s electrical wiring is affecting your broadband extenders, try plugging units in the same room. Some old wiring or fuse boxes might affect your network performance. • House appliances that draw large amounts of power, like refrigerators, freezers, microwaves and air conditioning systems, might cause interference with your network. • For best network performance, use broadband extenders from BT. • If there are no spare ports on your router/hub, you can unplug one of your existing devices and use an alternative like wi-fi or purchase a switch. Reset to factory settings If your extender or hotspot stops working or becomes unpaired, you can reset both to their factory settings: 1 Make sure the extender or the hotspot is plugged in and the power socket’s switched on. 2 Press the Link button on the extender for more than 15 seconds or the Reset button on the hotspot for 1 second to restore factory default settings. Give it a couple of minutes. If everything’s okay, the Power indicator on both will light up. ... -
Page 6: General Information
For a copy of the Declaration of Conformity over 28 days old from the date of purchase may be please refer to bt.com/minihomehotspot600 replaced with a refurbished or repaired product. This product uses open source codes available from The conditions of this guarantee are: bt.com/help/gplcode • the guarantee shall only apply to defects that occur within the 3 year guarantee period Mini Wi-Fi Hotspot 600 Power consumption In operation 4.7 Watts • proof of purchase is required • the equipment is returned to BT or its agent Network standby 2.7 Watts as instructed. Off mode 0.1 Watts This guarantee does not cover any faults or defects Broadband Extender 600 Power consumption caused by accidents, misuse, fair wear and tear, In operation 2.5 Watts neglect, tampering with the equipment, or any attempt at adjustment or repair other than through Network standby 1.9 Watts... - Page 7 Box contents Wireless Data WPS/Link Ethernet Power Power Ethernet cable Broadband Mini Wi-Fi Home Extender 600 Hotspot 600 Find out more • If you need more help, go to bt.com/minihomehotspot600 where you can view Frequently Asked Questions. • If you cannot find the answer to your problem in the Frequently Asked Questions, then please call our free Helpline on 0808 100 6116*. Our dedicated advisors are more likely to be able to help you than the retailer where you made your purchase. * Calls made from within the UK mainland network are free. Mobile and international call costs may vary. Offices worldwide The services described in this publication are subject to availability and may be modified from time to time. Services and equipment are supplied subject to British Telecommunications plc’s respective standard conditions of contract. Nothing in this publication forms any part of a contract. © British Telecommunications plc 2015. Registered Office: 81 Newgate Street, London EC1A 7AJ. Registered in England No. 1800000. Designed and produced by The Art & Design Partnership Ltd. Printed in China / Issue 1 / ADP11-15...
