- Page 1 IB/DRC500L cover 6/7/02 10:25 AM Page 1 DVD Player User’s Guide Please read this User’s Guide before using your product for the first time. www.rca.com/latinamerica Tocom: 15909580 DRC500L...
- Page 2 Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial andmodel numbers in case you need them. The numbers are located on the back of the player. Model number: DRC500L Serial Number:...
-
Page 3: Table Of Contents
Audio CDs ...29 Programmed Play ...31 Video CDs ...34 MP3 Files...35 Viewing JPEG files ...37 Chapter 4: The DVD Players Menu System Creating a Password and Setting Ratings ...39 TV Aspect ...43 Linear PCM ...46 Languages Menu...47 Chapter 5: Additional Information Troubleshooting ...51... -
Page 4: Chapter 1: Setup And Connections
IB/500L Body 6/7/02 11:12 AM Page 2 Chapter 1: Setup and Connections Things to consider before you connect Protect components from overheating • Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely. •... -
Page 5: Choose Your Connection
IB/500L Body 6/7/02 11:12 AM Page 3 Choose Your Connection There are several ways to connect your DVD player. Please use the following chart to determine which connection is best for you. Turn to the appropriate page, and connect your DVD Player. Components Chapter 1: Setup and Connections Cables Needed... -
Page 6: Connection: Dvd + Tv + Vcr
IB/500L Body 6/7/02 11:12 AM Page 4 Chapter 1: Setup and Connections Back of TV (example) CABLE/ANTENNA AUDIO S-VIDEO VIDEO COMPONENT DIGITAL OUT VIDEO OUT VIDEO OUT AUDIO OUT VIDEO OUT COAXIAL OPTICAL S-VIDEO Back of DVD Player OUT TO TV AUDIO VIDEO IN FROM ANTENNA... -
Page 7: Connection: Dvd + Tv
IB/500L Body 6/7/02 11:12 AM Page 5 Back of TV (example) AUDIO S-VIDEO VIDEO COMPONENT DIGITAL OUT VIDEO OUT AUDIO OUT VIDEO OUT VIDEO OUT OPTICAL COAXIAL S-VIDEO Back of DVD Player The back of your TV and VCR might look different than the ones pictured here. -
Page 8: Connection: Dvd + Tv + Audio Receiver
IB/500L Body 6/7/02 11:12 AM Page 6 Chapter 1: Setup and Connections Connection: DVD + TV + Audio Receiver Both Dolby Digital® and DTS® are audio formats used to record 5.1-channel audio signals onto the digital track of film (while the film is being made). Both of these formats provide up to six separate channels: left, right, center, left rear, right rear, and common subwoofer. - Page 9 IB/500L Body 6/7/02 11:12 AM Page 7 DVD Player + TV + Audio Receiver 1. Connect the left and right audio cables to your audio/video receiver and to the AUDIO OUT L (left – white) and R (right – red) jacks on the back of your DVD Player. 2.
-
Page 10: Install Batteries In The Remote Control
IB/500L Body 6/7/02 11:12 AM Page 8 Chapter 1: Setup and Connections Install Batteries in the Remote 1. Remove the battery compartment cover on the back of the remote. 2. Insert new batteries. Match the polarities (+ and –) on the batteries with the diagram on the remote. -
Page 11: Turn On The Tv And Dvd Player
IB/500L Body 6/7/02 11:12 AM Page 9 ON•OFF ZOOM RANDOM MUTE PLAY MODE Up arrow button REPEAT GO BACK GUIDE INFO DISC Right arrow button Left arrow MENU CLEAR OK button button Down arrow INPUT ANTENNA button REVERSE PLAY FORWARD MARKER STOP PAUSE... -
Page 12: Chapter 2: The Remote Control
A Tour of the Remote You can use this remote to control compatible components. The component buttons are programmed to operate some PROSCAN, RCA and GE components. The buttons must be programmed to operate other brands of components. (See page 13 for instructions.) - Page 13 IB/500L Body 6/7/02 11:12 AM Page 11 Chapter 2: The Remote Control AUDIO Accesses various audio features while playing a disc. CH + Advances to the next chapter, track, index or MP3 title. CH – Reverses to the preceding chapter, track, index or MP3 title. CLEAR Allows you to clear information, such as remove the Info display from the screen.
- Page 14 SUBTITLE OPEN•CLOSE This remote operates most RCA, GE, and Proscan TVs. OPEN•CLOSE Press to open and closed the disc tray. PAUSE Pauses disc play. When disc play is paused, press PAUSE again to advance one frame. PLAY Begins disc play (and closes disc tray if it is open).
-
Page 15: Programming The Remote
2. Press the ON•OFF button (if the TV turns on or off, this remote will operate the TV). 3. To control a TV that is not from RCA, GE, Proscan or RCA Scenium you’ll need to enter the specific code for the brand of TV you have. See the following page for code list. -
Page 16: Remote Control Codes
IB/500L Body 6/7/02 11:12 AM Page 14 Chapter 2: The Remote Control TV Codes 1096, 1097, 1098, 1100, 1107, 1116, 1118, 1119, 1124, Admiral ...1115, 1224 1143, 1191, 1224, 1226 Adventura ...1224 Colortyme ..1116, 1118, 1121, Aiko ...1124 1241, 1014 Akai...1063, 1090, 1116 Concerto ...1116, 1118, 1096 Alba ...1033... - Page 17 1155, 1169, 1170 Simpson ...1119 Radio Shack ...1034, 1037, Sony ...1002, 1114, 1115, 1151, 1189, 1219 1245, 1254 RCA ...1000, 1017, 1025, Soundesign 1094, 1119, 1149 1053, 1054, 1055, 1056, 1051, 1058, 1076, 1102, 1110, Spectricon ...1029, 1098 1228, 1236 Squareview ...1015, 1234...
-
Page 18: Chapter 3: Playing Discs
IB/500L Body 6/7/02 11:12 AM Page 16 Chapter 3: Playing Discs VIDEO CD This DVD Player is capable of playing the following types of discs: •DVD discs •Video CD discs •Audio CD discs •CD-R discs, CD-RW discs •DVD+RW, DVD-RW, DVD-R, DVD-ROM (with movie information). -
Page 19: Loading And Playing Discs
IB/500L Body 6/7/02 11:12 AM Page 17 Loading and Playing Discs Turn on the TV and your DVD Player (press STANDBY/ON on the player or press the DVD button on the remote control). 1. Press the OPEN•CLOSE button (the disc tray opens). This is an example of a 2. -
Page 20: Using A Disc Menu
IB/500L Body 6/7/02 11:12 AM Page 18 Chapter 3: Playing Discs (DVDs) Using a Disc Menu A disc is capable of having an on-screen menu that is separate from the DVD player’s menu system and on-screen Info Display. Although the content and operation of disc menus vary from disc to disc, the following example will give you an idea of what to expect. -
Page 21: Using The On-Screen Info Display
IB/500L Body 6/7/02 11:12 AM Page 19 Chapter Title Audio Using the On-Screen Info Display The on-screen Info Display contains many playback features. To see the Info Display, press the INFO button on the remote while a disc is playing (the Info Display appears across the top of the screen). Each feature is represented by an icon. Use the left/right arrow buttons to move through the different icons in the Info Display. -
Page 22: Selecting A Title
IB/500L Body 6/7/02 11:12 AM Page 20 Chapter 3: Playing Discs (DVDs) Selecting a Title Some discs contain more than one title. For example, there might be four movies on one disc (each movie might be considered a title). Each title is divided into chapters. To select a title: 1. - Page 23 IB/500L Body 6/7/02 11:12 AM Page 21 Programmed Play To use the programmed play option, you must create a play list to set the order you want the chapters (or tracks on a CD) on the disc to play in. The Memory Edit screen varies depending on the type of disc (DVD or CD) you are playing. Creating a Program List for a DVD Video Disc 1.
-
Page 24: Disc Playback Features
IB/500L Body 6/7/02 11:12 AM Page 22 Chapter 3: Playing Discs (DVDs) Inserting Items in the Play List 1. If a disc is playing, press STOP to put the player in stop mode. 2. Press PLAY MODE on the remote (the Memory Edit screen is displayed). 3. - Page 25 IB/500L Body 6/7/02 11:12 AM Page 23 Frame Advance Press PAUSE when a disc is playing to freeze the picture. Each time you press the PAUSE button, the picture advances one frame. Press PLAY to resume normal playback. Zoom When playing DVD discs and Video CDs, you can magnify the screen during normal playback. For DVD discs, Zoom has 3 levels (x1, x2, x4).
-
Page 26: Using Subtitles
IB/500L Body 6/7/02 11:12 AM Page 24 Chapter 3: Playing Discs (DVDs) Using Subtitles By default, subtitles are off. To turn subtitles on: While a disc is playing, press the INFO on the remote. You can change the subtitle language while you’re watching a DVD disc, but only if the disc was created with subtitles. - Page 27 IB/500L Body 6/7/02 11:12 AM Page 25 Using the Repeat Feature The default mode for the Repeat feature is Off. There are five Repeat options: • All Discs – Repeats all discs in the player • One Disc – repeats the disc that is playing •...
-
Page 28: Using Bookmarks
IB/500L Body 6/7/02 11:12 AM Page 26 Chapter 3: Playing Discs (DVDs) 4. If the display has left the screen, stop the repeat (Repeat Off). 5. Press CLEAR to remove the display from the screen. Using Bookmarks The Bookmark feature lets you mark a point on the disc that you can go to quickly. You can store up to nine bookmarks per disc. -
Page 29: Changing The Audio Language
IB/500L Body 6/7/02 11:12 AM Page 27 Changing the Audio Language If the disc was recorded in different languages, you can use the Info Display to temporarily change the DVD Player’s Audio Language setting. Chapter 3: Playing Discs (DVDs) 1. While a disc is playing, press INFO on the remote. 2. -
Page 30: Changing The Camera Angle
IB/500L Body 6/7/02 11:12 AM Page 28 Chapter 3: Playing Discs (DVDs) Changing the Camera Angle Some discs contain multiple angles of a particular scene or sequence. If the disc only has one angle, this feature won’t work. When multiple angles are available, the Angle icon appears in the upper right corner of the screen. -
Page 31: Audio Cds
IB/500L Body 6/7/02 11:12 AM Page 29 Audio CDs Your DVD Player has many of the same features as an audio CD player. The on-screen Info Display lets you choose various playback features. The Time Display The time display has four options: •... - Page 32 IB/500L Body 6/7/02 11:12 AM Page 30 Chapter 3: Playing Discs (Audio CDs) Selecting a Play Mode You can choose what order the tracks play on a disc. The standard play mode is the default. To select another play mode, a disc must be in the DVD player.
-
Page 33: Programmed Play
IB/500L Body 6/7/02 11:12 AM Page 31 Programmed Play To use the programmed play option, you must create a play list to set the order you want the tracks on the disc(s) to play in. Creating a Program List for an Audio Disc 1. - Page 34 IB/500L Body 6/7/02 11:12 AM Page 32 Chapter 3: Playing Discs (Audio CDs) 4. Use the arrow buttons to highlight the row you want to insert your selection (your selection is inserted above that row). 5. Use the arrow buttons to highlight the Insert option and press OK. The Repeat Feature The default mode for the Repeat feature is Off.
- Page 35 IB/500L Body 6/7/02 11:12 AM Page 33 Press REPEAT to stop the repeat (Repeat Off). 5. Press CLEAR to remove the display from the screen. How to Cancel Repeat There are three ways to cancel Repeat: • Press STOP twice. •...
-
Page 36: Video Cds
IB/500L Body 6/7/02 11:12 AM Page 34 Chapter 3: Playing Discs (Audio CDs) Video CDs (VCDs) Like DVD video discs, Video CDs contain picture and sound content. Video CDs (VCDs) are encoded in a different format. VCDs don’t hold as much information as DVD discs and the picture quality is not as high. Because a VCD contains less information than a DVD disc, some of the features provided by the player may not work with some VCDs. -
Page 37: Mp3 Files
IB/500L Body 6/7/02 11:12 AM Page 35 What is MP3? MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into MP3 format with little loss of quality, while taking up much less space. CD-R or CD-RW discs that have been encoded in MP3 format that can be played on your DVD player. In this manual, CD-R and CD-RW discs will be referred to as MP3 discs. - Page 38 IB/500L Body 6/7/02 11:12 AM Page 36 Chapter 3: Playing Discs (MP3s) Selecting Folders and Songs Playback begins automatically when you insert an MP3 disc into the player. The player begins playing the songs in the order they were burned on the disc.
-
Page 39: Viewing Jpeg Files
IB/500L Body 6/7/02 11:12 AM Page 37 Chapter 3: Playing Discs (JPEGs) Deleting songs from the Playlist To delete a song from the playlist: 1. Press STOP to put the player in stop mode. 2. Use the arrow buttons to highlight the song you want to delete. 3. - Page 40 IB/500L Body 6/7/02 11:12 AM Page 38 Chapter 3: Playing Discs (JPEGs) 1. When JPEG is selected, use the right arrow button to bring up the SLIDE SHOW icon. This does not start playback. Press the right arrow button again (the slide show speeds are displayed). 2.
-
Page 41: Creating A Password And Setting Ratings
IB/500L Body 6/7/02 11:12 AM Page 39 The DVD Player Menu System The DVD player menu system is not the same as the disc menu or the Info Display. If you are playing a disc, press STOP and MENU (the menu appears). Path Items A path menu item has an arrow on the right side to let you know this item is a path to more options. - Page 42 IB/500L Body 6/7/02 11:12 AM Page 40 Chapter 4: DVD Menu System Creating a Password 1. If a disc is playing, press STOP and MENU (the menu appears). 2. Use the arrow buttons to highlight the Password option. Press OK. The password choices appear on the right.
- Page 43 IB/500L Body 6/7/02 11:12 AM Page 41 Clearing Your Password If you want to turn the password off so all discs can be viewed: 1. If a disc is playing, press STOP and MENU (the menu appears). 2. Use the arrow buttons to highlight the Password option. Press OK. The password choices appear on the right. 3.
- Page 44 IB/500L Body 6/7/02 11:12 AM Page 42 Chapter 4: DVD Menu System 1. If a disc is playing, press STOP and MENU (the menu appears). 2. Use the arrow buttons to highlight the Rating option. Press OK (the 8-level rating limits list appears). 3.
-
Page 45: Tv Aspect
IB/500L Body 6/7/02 11:12 AM Page 43 TV Aspect The TV aspect adjusts the way a movie appears on your TV. Stand TVs are 4 x 3 format. Depending on the type of television you have, you may want to adjust the screen setting (also called the aspect ratio). Chapter 4: DVD Menu System 1. - Page 46 IB/500L Body 6/7/02 11:12 AM Page 44 Chapter 4: DVD Menu System 4 x 3 Standard – Choose this setting if you want the movie to fill the entire screen of your TV. This might mean that parts of the picture (the left and right edges) won’t be seen.
- Page 47 IB/500L Body 6/7/02 11:12 AM Page 45 Dynamic Range This feature compresses the dynamic range (quietest sound to loudest sound) of a disc's soundtrack. For example, action scenes might be very loud, while whispered dialog is quiet. The Dynamic Range feature evens out the range of volume by making loud sounds quieter and soft sounds louder.
-
Page 48: Linear Pcm
IB/500L Body 6/7/02 11:12 AM Page 46 Chapter 4: DVD Menu System You can check both options if your receiver is capable of decompressing both types of audio. The default is DTS. To change the digital output: 1. If a disc is playing, press STOP and MENU (the menu appears). 2. -
Page 49: Languages Menu
IB/500L Body 6/7/02 11:12 AM Page 47 Chapter 4: DVD Menu System Languages Menu The Menus option lets you set language options for the DVD Player’s menu system, disc menus, the dialog (audio) of titles, and the subtitles. Changing the Player Menus Language Preferences You can choose one of three languages for the text that appears within the on-screen menu system. - Page 50 IB/500L Body 6/7/02 11:12 AM Page 48 Chapter 4: DVD Menu System Changing the Subtitles Language Preference The Subtitles menu lets you choose a language for the subtitles. The default is Auto. To change the subtitle language preference: 1. If a disc is playing, press STOP and MENU (the menu appears). 2.
- Page 51 IB/500L Body 6/7/02 11:12 AM Page 49 Chapter 4: DVD Menu System How to Set Other as the Subtitle Language Preference If the language you want to use isn’t listed, you can use the Other option to select the language of your choice. 1.
-
Page 52: Language Code List
IB/500L Body 6/7/02 11:12 AM Page 50 Chapter 4: DVD Menu System Language Code List Don’t forget to press the OK button after you enter the code. Abkhazian ...6566 English ...6978 Afar ...6565 Esperanto...6979 Afrikaans ...6570 Estonian ...6984 Albanian...8381 Faroese ...7079 Ameharic ...6577 Fiji...7074 Arabic...6582... -
Page 53: Chapter 5: Additional Information
IB/500L Body 6/7/02 11:12 AM Page 51 Chapter 5: Additional Information Troubleshooting If you are experiencing product operation problems, please review the troubleshooting section before you call for service. Refer to the Limited Warranty for information on how to obtain repair service. Player won’t work •... - Page 54 IB/500L Body 6/7/02 11:12 AM Page 52 Chapter 5: Additional Information • Sound is muted when you’re using search features (fast forward, reverse, frame advance, etc.). • If you connected an audio receiver to your DVD Player, make sure you chose the correct input setting on the receiver. •...
- Page 55 IB/500L Body 6/7/02 11:12 AM Page 53 icon appears on screen The feature or action cannot be completed at this time because: • The disc’s software restricts it. • The disc’s software doesn’t support that feature (e.g., angles). • The feature is not available at the moment. •...
-
Page 56: Handling Cautions
IB/500L Body 6/7/02 11:12 AM Page 54 Chapter 5: Additional Information • If you’re trying to skip through the warning information and credits at the beginning of a movie, you won’t be able to. This part of the movie is often programmed to prohibit skipping through it. Camera angle cannot be changed •... - Page 57 IB/500L Body 6/7/02 11:12 AM Page 55 Maintenance of Cabinet For safety reasons, when cleaning the cabinet be sure to disconnect the AC power cord from the AC outlet. • Do not use benzene, thinner, or other solvents for cleaning. •...
-
Page 58: Description Of Jacks
Audio Input jacks (left and right) on your TV or receiver. VIDEO OUT – If you are using color-coded red, yellow and white RCA cables, connect the yellow video cable to this jack and to the Video Input jack on your TV. -
Page 59: Front Panel Controls
IB/500L Body 6/7/02 11:12 AM Page 57 Chapter 5: Additional Information Front Panel Controls STANDBY/ON – Turns the player on and off. The indicator lights when the player is in Standby mode. PHONES – Plug headphones in here. LEVEL - Adjusts volume for headphones. DISK SELECT - Selects the desired disk slot. -
Page 60: Explanation Of Input Jacks And Cables
This section describes the jacks and cables you can use to make connections (only audio/video cables are packed with your DVD Player — you can purchase cables online at www.rca.com/latinamerica or go to your local electronics store). There are several ways to connect your DVD Player to your TV depending upon the cables you have and the jacks that are on the back of your TV. - Page 61 Note: Remember to connect the left and right audio cables because the S-Video cable carries only the picture signal, not the sound. AUDIO OUT Audio/Video Jacks and Cables (RCA-type) Audio These jacks are used to send the audio from the disc you’re playing in the DVD Player to the TV. The audio jacks and cables are often color-coded (red for right audio, and white for left audio).
-
Page 62: Limited Warranty
IB/500L Body 6/7/02 11:12 AM Page 60 Chapter 5: Additional Information How to find your TV’s Video Input Channel In order to see what’s playing on your DVD Player, you need to tune the TV to the Video Input Channel that corresponds to the jacks you used to hook up the recorder to the TV. - Page 63 IB/500L Body 6/7/02 11:12 AM Page 61 POLIZA DE GARANTIA Comercializadora Thomson de México S.A de C.V. garantiza este producto en todas sus partes y mano de obra, contra cualquier defecto de fabricación y funcionamiento, a partir de la fecha de entrega al cliente final. Bajo el siguient e término: Producto Partes Televisores c/cinescopio de 36,6...
- Page 64 IB/500L Body 6/7/02 11:12 AM Page 62 Chapter 5: Additional Information México, D.F. Estado de México Digital Service Vallejo Digital Service Tultitlán Av. 3 A No. 12, Local 2 Av. López Portillo Km. 21 # 90A Col. Santa Rosa Col. Bello Horizonte México, D.F.
- Page 65 IB/500L Body 6/7/02 11:12 AM Page 63 GUERRERO Multiserv Prof. Zamora Nueva Elec. Auditron Colon No. 181-1 Ote. Aquiles Serdán No. 14B Col. Centro Col. Centro Zamora, Mich. C.P. 59600 Acapulco, Gro. C.P. 039300 Tel/Fax (351) 5155416 Tel (744) 4826242 MORELOS Tel/Fax (744) 4832062 Electrónica Hertz...
-
Page 66: Video Input Channel
ELECTRONICA DEL SUR Punta Arenas ELECTRONICA JOSSEAU ------------------------------------------------------------------------------------------------------ CHILE S.A THOMSON MULTIMEDIA CHILE S.A., Bucarest 178 - Santiago - Fono: 800 722 722 (800 RCA RCA). DIRECCION TELEF. FAX Avda. Sta. María 1361 253361 Este producto ha sido fabricado con componentes de óptima calidad y ha sido revisado por personal técnico Tarapacá... - Page 67 6/7/02 11:12 AM Page 66 Visit our website at www.rca.com/latinamerica Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product. Thomson multimedia Inc.
