- Page 1 DVD Player User’s Guide Changing entertainment. Again. DRC310N...
- Page 2 Product Registration: Please fill out the product registration card (packed separately) and return it immediately. For U.S. customers: Your RCA Consumer Electronics product may also be registered at www.rca.com/productregistration Registering this product allows us to contact you if necessary.
-
Page 3: Table Of Contents
Front of the DVD Player ...5 Connect the DVD Player ...6 Point the remote in the right direction ...8 Turn on the TV and the DVD player ...8 Using different menus ...8 How to find your TV’s Video Input Channel ...9 Chapter 2:The Remote Control Button descriptions for DVD mode ...10... -
Page 4: Chapter 1: Setup And Connections
Chapter 1 Things to consider before you connect Protect components from overheating • Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely. • Don’t stack components. • If you place components in a stand, make sure you allow adequate ventilation. •... -
Page 5: Back Of The Dvd Player
Back of DVD Player: Explanation of Jacks and Cables There are several ways to connect your DVD Player to your TV depending upon the cables you have and the jacks that are on the back of your TV. Different jacks and cables provide a different level of performance.The jacks on the back of your DVD Player and the cables used to connect... -
Page 6: Connections And Setup
L/Mono) audio jack on the TV and don’t connect the right audio part of the cable. DIGITAL AUDIO OUT/OPTICAL and COAXIAL Use one of these jacks to connect your DVD Player to a Dolby Digital or Digital Out Optical DTS receiver or decoder. Some receivers have either the COAXIAL or cable OPTICAL type of Digital Audio Input jack, and some have both. -
Page 7: Front Of The Dvd Player
STANDBY/ON STOP NEXT PLAY/PAUSE Front of the DVD Player (buttons appear left to right below) 1 STANDBY/ON - Turns the player on and off.The indicator lights when the player in standby mode (off but still plugged into an AC outlet). -
Page 8: Connect The Dvd Player
The back of your TV and VCR might look different than the ones pictured here. Details about the different kinds of cables used to connect your DVD player are on page 3. Don’t connect the DVD player to the VCR, or through the VCR. Doing so could negatively affect the picture quality and/or disable the DVD player. - Page 9 If your TV has component video jacks (Y, Pb, Pr), use video-grade cables (not provided) to connect the TV to the DVD player’s COMPONENT VIDEO OUT (Y, Pb, Pr) jacks. It is essential to match the color coded connectors with a compatible TV. If your TV or monitor has progressive scanning capability, you need to turn the VIDEO SELECTION switch to the PROGRESSIVE SCAN ONLY position.
-
Page 10: Point The Remote In The Right Direction
Point the Remote in the Right Direction and Put it in DVD Mode When you want the remote to operate the DVD Player, point the remote at the DVD Player, not the TV. Make sure the remote is in DVD mode - press the DVD button. Also, you must make sure... -
Page 11: How To Find Your Tv's Video Input Channel
Channel that corresponds to the jacks you used to connect the DVD Player to the TV.The Video Input Channel(s) varies for different brands and different models of TVs. If your TV is an RCA, GE, or Proscan brand, the DVD’s remote probably operates it. Just press the TV button, and then press the INPUT button until you see the DVD’s main menu, screen saver, or the disc you’re... -
Page 12: Chapter 2:The Remote Control
Chapter 2 Button Descriptions for DVD Mode In addition to operating your DVD Player, the remote that came with it will operate most RCA, GE, and Proscan TVs and VCRs. However, this page only describes the buttons on the remote that you will use with your DVD Player. -
Page 13: Button Description For Tv And Vcr Modes
SPEED In VCR mode, accesses the timer recording menu in some models. TIMER Puts the remote in TV mode so it operates the TV (RCA, GE, and Proscan TVs only). Functions as a TV/VCR button in VCR mode. TV•VCR Puts the remote in VCR mode so it operates the VCR (RCA, GE, and Proscan VCRs only). -
Page 14: Chapter 3: Playing Discs
The DVD Player reads the disc’s table of contents, and then one of three things happens depending on how the disc was programmed: •... -
Page 15: Search Options
You can also use the following search features: Picture Scan - When you’re playing a disc, each time you press FORWARD or REVERSE, your DVD Player scans the disc faster until you reach the fastest scan speed.To resume normal playback, press PLAY. -
Page 16: Using The On-Screen Info Displays
Playing Discs Using the On-Screen Info Displays The Info Display appears across the top of the screen when you press the INFO button on the remote while you’re playing a disc. Use the an icon is highlighted, follow the on-screen instructions, and use the remote to scroll through the options. -
Page 17: How To Navigate In The Info Display
Left Down Time Display (all Info Displays) This feature displays the time that has elapsed during playback. For DVD discs, the time displayed refers to the current title and acts as a Time Search feature.You can skip right to any scene. Highlight the Time Display, and use the number buttons on the remote to enter the elapsed time you want to go to.You must use two digits for each field. -
Page 18: Screen Fit Icon
Changing the subtitle language with the Info Display will only affect the disc you are currently playing.When the disc is removed or the player is turned off, the subtitle language will revert to the language setting specified through the DVD player’s main menu. -
Page 19: Play Mode Icon
Random Play: Audio CDs (tracks play in random order). Program Play: Audio CDs (create your own playlist by defining the order of the tracks in the DVD Player’s Program Play menu— page 24.) Introscan: Audio CDs. Plays the first 10 seconds of each track. -
Page 20: Playing Discs
Note:The player defaults to Standard Playback whenever you put a new CD into the DVD player. Program Play (Audio CDs) The Program Play Mode is only available after you set up a program through the DVD Player’s menu. Go to page 24 for instructions. -
Page 21: Bookmark Icon
Bookmark Icon (DVD and Audio CD Info Display) The Bookmark feature lets you mark a point on the disc so you can quickly start playing the disc from a bookmarked point. Creating a Bookmark Highlight the Bookmark icon on the Info Display. Press OK (the Bookmark Banner appears). Highlight an unused bookmark.When the disc reaches the scene you want to mark, press the OK button on the remote (the bookmark icon changes to two icons side-by-side: an arrow and a trash can). -
Page 22: Camera Angle Icon
Playing Discs Camera Angle Icon (DVD Info Display) Some discs contain multiple angles of a particular scene or sequence. If the disc only has one angle, this feature won’t work. Currently, very few discs have this feature. While a disc is playing, press ANGLE on the remote. If the disc wasn’t created with multiple angles, (the invalid symbol) appears. - Page 23 PLAY 01.THE REASON -3.jA- - LET_S_ 04. WHY ON WHY 02.IMMORTALIT 03.TREAT HER 04.WHY ON WHY 05.LOVE IS IN Example of mp3 files. wiseview.jpg Press Play to start. Example of JPEG files. Fast Normal Slow Press OK to select a slideshow speed. Example of projection speed screen.
-
Page 24: Musical Slide Show
Playing Discs Musical Slide Show: playing JPEG and mp3 or WMA music files at the same time You can display JPEG files while listening to mp3 or WMA music files recorded on the same disc. Insert the disc containing the two types of files in the player. Select an image file using the selection.The name of the folder where the file is located and the name of the file appear on the right in the "Current selection"... -
Page 25: The Dvd Player Menu System
The DVD Player Menu System The DVD player menu system is not the same as the disc menu or the Info Display.The DVD player menu appears when there’s no disc playing. If you are playing a disc, press STOP on the remote control to stop playback (the DVD player menu appears). -
Page 26: Program Play
AutoPlay You can set up the DVD Player so a disc automatically starts playing whenever the disc is inserted. Highlight AutoPlay and press OK (On appears next to the AutoPlay menu).To turn AutoPlay off, just press OK again while AutoPlay is highlighted. -
Page 27: Parental Control Menu
You can set up ratings limits and lock your player in order to control the type of content people watch on your DVD Player.The padlock icon indicates whether the player is locked or unlocked. Locked: You need to enter the password in order to play discs that have a higher rating than what you’ve allowed.When the player is locked, nobody can access the... -
Page 28: Unlocking Your Player
Menu System Unlocking your DVD Player If you’re playing a disc, press STOP (the DVD Player’s main menu appears). Press the button until screen appears). Use the number buttons to enter the password you created, and press OK (the Control menu items appear). -
Page 29: Rated Titles
8 Least Restrictive 7 NC-17 *MPAA ratings 4 PG-13 may vary from 3 PG disc to disc. Password Required Free Access Free Access Unrated Titles Password Required To set Ratings for Rated Titles: Rating Limits menu enables you to block discs that contain movies that have a rating assigned to them (R, PG-13, PG, G, etc.) from being played unless you enter the password you created in the Password menu. -
Page 30: Display Menu
Menu System The Display Menu Display menu contains the settings that affect how a disc’s content looks on your TV.. Play Play Mode Parental Control TV Image Display Sound Black Level Languages To return to the previous menu, press button. TV Image TV Image menu adjusts the way a movie appears on... -
Page 31: Black Level
16x9 Widescreen – Choose this setting if your DVD Player is connected to a wide-screen TV. If you choose this setting and you don’t have a widescreen TV, the images on the screen might appear distorted due to vertical compression. If you play a disc recorded in 4 x 3 format on a widescreen TV, the left and right side of the screen will appear black. -
Page 32: Sound Menu
DVD Player, and to use the DVD Player’s Sound features. All of the submenus in the Sound menu have two settings: On and Off. Simply highlight the menu and press the OK button on the remote to change the current setting. -
Page 33: Languages Menu
Languages Notes: Discs are created differently.The DVD player can’t override some language preferences. If a disc’s software was created to play the movie (title) in a preferred language, the preference you set might be ignored. Also, if the language isn’t available on the movie you’re playing, the disc’s default language will be chosen. -
Page 34: Chapter 5:Additional Information
Note: If you prefer, we can provide you with the name of an Authorized Service Representative who will visit your home for a fee to install your electronic entertainment system and to instruct you in its operation. For details about this service, call 1-888-206-3359. For additional assistance while using your RCA product, please visit www.rca.com/customersupport. -
Page 35: Additional Information
The picture is distorted • Did you connect your VCR to the DVD Player? Disconnect it, and connect the VCR directly to the TV and the DVD Player directly to the TV. See chapter 1 for correct setup and connection information. - Page 36 The menu is displayed in a foreign language • The Language menu (Player Menus) is set to that language. Go to Languages in the main DVD player menu and select the Player Menus option. Highlight the language you prefer, and press Play doesn’t begin...
-
Page 37: Maintenance Of Cabinet
Maintenance of Cabinet For safety reasons, when cleaning the cabinet be sure to disconnect the AC power cord from the AC outlet • Do not use benzene, thinner, or other solvents for cleaning. • Wipe the cabinet with a soft cloth. Formation of Condensation •... -
Page 38: Recommendations And Information Concerning Discs
CD-Rs prevent optimal playback of these files on your DVD player (that is degraded sound quality and even, in some cases, inability of the player to read the file or files). - Page 39 CD-R and CD-RW discs with JPEG format “image” files To view your JPEG images on a TV set you do not need to record your photographs with a resolution above 400,000 pixels (which corresponds to an image format of about 720 x 576 dots) because of the resolution of most TVs.
-
Page 40: Limited Warranty
Additional Information Limited Warranty What your warranty covers: • Defects in materials or workmanship. For how long after your purchase: • 90 days from date of purchase - Unit exchange, which includes parts and labor. • 91 days to 1 year from date of purchase - Unit exchange, which includes parts only; you pay the labor. - Page 41 Thomson. Product Registration: Please complete the online Product Registration on www.rca.com/productregistration or complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.
-
Page 42: Accessories To Complement Your Dvd Player
1-800-338-0376 (Use this number only to place an order for accessory items.) You can buy some accessories on-line at www.rca.com/accessories (subject to availability) Note: Products shown might not be available from www.rca.com web site. Optical Plug to Optical Plug for Optical Audio connection to a compatible receiver. - Page 43 This page intentionally left blank.
- Page 44 Visit the RCA website at www.rca.com Please do not send any products to the Indianapolis address listed below or on the carton.This will only add delays in service for your product. Thomson Inc. 10330 North Meridian Street Indianapolis, IN 46290 ©2003 Thomson Inc.
