Related Manuals for Hoover HV-RBM529
Summary of Contents for Hoover HV-RBM529
- Page 1 529 L Bottom Mount Refrigerator Model Number: HV-RBM529 INSTRUCTION MANUAL AFTER SALES SUPPORT (AU) 1300 886 649 (NZ) 0800 836 761 E209...
-
Page 2: Table Of Contents
Contents General Safety Instructions Product Overview Getting Started Instructions FAQs and Troubleshooting Guide Other Useful Information After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support... -
Page 3: General Safety Instructions
General Safety Instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. Keep the manual in a safe place for future reference, along with the completed warranty card, purchase receipt and carton. - Page 4 General Safety Instructions (Cont.) To reduce the risk of fire, electric shock or injury, always follow basic safety precautions and accident prevention measures when using this appliance, including the following: Electrical safety • Voltage: Plug the appliance in a 220–240 V, 50 Hz, properly earthed power outlet, which must be in good working order.
- Page 5 General Safety Instructions (Cont.) • Usage restrictions: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
- Page 6 General Safety Instructions (Cont.) • Level: Install the appliance level in order to ensure proper operation (see page 9). • Location: Install the appliance in an area that meets the following requirements: • Ambient temperature: The ambient temperatures must correspond to the climate class (T) indicated on the rating plate of the appliance (16 °C–43 °C).
-
Page 7: Product Overview
Product Overview Scope of delivery Top mount refrigerator Leveling feet Door balconies (3x half size, 1x full size) LED lighting and temperature control Door Hinge panel Other inclusions (not shown) Glass Fridge shelves (x2) Humidity Control Accessory kit (for door reversal) Fruit and Vegetable Crisper Drawers Instruction manual Steel wire freezer shelf... -
Page 8: Getting Started
Getting Started Unpacking • Packaging materials: This product has been packaged to protect it against transportation damage. Remove all packaging materials from around and inside the appliance and keep the original packaging carton and materials in a safe place. It will help prevent any damage if the product needs to be transported in the future, and you can use it to store the appliance when it is not in use. - Page 9 Getting Started (Cont.) • Overhanging wall units: To ensure best performance, if the appliance is positioned below an overhanging wall unit, the minimum distance between the top of the cabinet and the wall unit must be at least 300 mm. Ideally, however, the appliance should not be positioned below overhanging wall units.
-
Page 10: Instructions
Instructions Temperature regulation This refrigerator has a temperature control panel (Fig. 5) at the top of the fridge compartment. The fridge and freezer compartments have independent controls so you can adjust the temperature in each compartment separately according to the food stored. - Page 11 Instructions (Cont.) Alarm Function: When the fridge or freezer door is kept open for more than 120 seconds, an alarm will sound until the door has been properly closed. Alternatively, press the |ALARM OFF| button (a) to turn off the alarm. If a fault occurs (see page 17), an alarm will sound.
- Page 12 Instructions (Cont.) • To use the drawer in quick freezing mode, slide the humidity regulator to the left (Fig. 7). Do not store fresh fruit, vegetables, carbonated drinks, or other items that you do not wish to freeze in the drawer while it is in this mode. Fig.
- Page 13 Instructions (Cont.) The freezer compartment The freezer compartment, located at the top of the appliance, is equipped with a glass shelf and door balcony for convenient access and organised storage. It is suitable for freezing domestic quantities of fresh food and long-term storage (up to three months) of frozen food.
- Page 14 Instructions (Cont.) Energy saving tips • Locate the appliance in the coolest area of the room, away from heat-producing appliances and out of direct sunlight. • Let hot foods cool to room temperature before placing them in the freezer. Overloading the compartments forces the compressor to run longer. •...
-
Page 15: Faqs And Troubleshooting Guide
FAQs and Troubleshooting Guide If you experience a problem with the appliance, check in the following table for solutions to help you solve the problem. If none of the solutions offered help you solve the problem, please contact our after sales support centre for advice. Problem Possible cause The appliance does not... - Page 16 FAQs and Troubleshooting Guide (Cont.) Problem Possible cause The appliance freezes or • The temperature is set too cold. Turn it to a warmer cools too much. setting temporarily. Food in the freezer • The freezer temperature is set too warm; set it to a compartment is not colder setting.
- Page 17 FAQs and Troubleshooting Guide (Cont.) If you experience a problem with the appliance, check in the following table for potential errors. Check the inside of the fridge temperature control panel (see page 10), and if the LED lights are flashing, check the table below for information as to the nature of this issue.
-
Page 18: Other Useful Information
Other Useful Information WARNING! To reduce the risk of electric shock or injury, always switch off the appliance and disconnect it from the power supply before cleaning or maintenance. Cleaning the appliance For hygienic reasons the appliance interior, including the interior accessories, should be cleaned regularly. - Page 19 Other Useful Information (Cont.) Door reversal This appliance has the capability of opening the door from either the left or right side. If your set-up requires changing the opening direction, proceed as follow: IMPORTANT! You will need: • Make sure you have someone there to help you, do not try to do this on your own. •...
- Page 20 Other Useful Information (Cont.) Unscrew the screws from the middle hinge. Remove the hinge, then lift the freezer door up and away from the refrigerator (Fig. 9). Keep the screws in a safe location for later. Unscrew the screws from the bottom hinge, then remove the bottom hinge from the bottom right side of the refrigerator.
- Page 21 Other Useful Information (Cont.) Put down the refrigerator door bottom hinge vertically, take out the middle hinge from the opposite side (from the accessory bag) and assemble it to the fridge (Fig. 12). Fig. 12 Put down the freezer door on the middle hinge vertically, then take out the top hinge and cover (from the other wise) and assemble the top hinge, hinge cover, and hole cover (Fig.
- Page 22 Other Useful Information (Cont.) Defrosting the appliance Manually defrosting the freezer compartment is not necessary as this is a frost-free appliance which will be defrosted automatically. Storage If the appliance is not going to be used for an extended period of time, please store the unplugged, cleaned appliance safely in the original packaging in a dry location, out of reach of children.
- Page 23 Other Useful Information (Cont.) Technical specifications Model HV-RBM529 Rated voltage 220 – 240 V~ Rated frequency 50 Hz Rated current 1.5 A Climate category Electrical protection class Defrost power 200 W Refrigerant R600a (50 g) Insulation blowing agent Cyclopentane Fridge compartment volume...
- Page 24 Other Useful Information (Cont.) Responsible disposal At the end of its working life, do not throw this appliance out with your household waste. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately. Observe any local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately for recycling and recovery of the refrigerant and blowing agent.
- Page 25 This page has been left blank intentionally. After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 26 This page has been left blank intentionally. After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 27 This page has been left blank intentionally. After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 28 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on (AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
