Hoover HV-RBF121 Instruction Manual

Hoover HV-RBF121 Instruction Manual

121 l bar fridge

Advertisement

Quick Links

121 L Bar Fridge
Model Number: HV-RBF121
INSTRUCTION MANUAL
AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761
E209

Advertisement

loading
Need help?

Need help?

Do you have a question about the HV-RBF121 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoover HV-RBF121

  • Page 1 121 L Bar Fridge Model Number: HV-RBF121 INSTRUCTION MANUAL AFTER SALES SUPPORT (AU) 1300 886 649 (NZ) 0800 836 761 E209...
  • Page 2: Table Of Contents

    Contents General Safety Instructions Product Overview Getting Started Instructions FAQs and Troubleshooting Guide Other Useful Information After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
  • Page 3: General Safety Instructions

    General Safety Instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
  • Page 4 General Safety Instructions (Cont.) To reduce the risk of fire, electric shock or injury, always follow basic safety precautions and accident prevention measures when using this appliance, including the following: Electrical safety • Voltage: Plug the appliance in a 220–240 V, 50 Hz, properly earthed power outlet, which must be in good working order.
  • Page 5 General Safety Instructions (Cont.) • Usage restrictions: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. •...
  • Page 6 General Safety Instructions (Cont.) • Location: Install the appliance in an area that meets the following requirements: • Ambient temperature: The ambient temperatures must correspond to the climate class (T) indicated on the rating plate of the appliance (16 °C–43 °C). •...
  • Page 7: Product Overview

    Product Overview Scope of delivery Bar Fridge Other inclusions (not shown) Instruction manual Door Hinge Cover Quick start guide Freezer Compartment Warranty certificate Thermostat Control Adjustable Shelf Small Glass Shelf Levelling Feet Door Balconies (x3) NOTE: Due to continued product improvement, images and illustrations in this manual may vary slightly from the product purchased.
  • Page 8: Getting Started

    Getting Started Unpacking • Packaging materials: This product has been packaged to protect it against transportation damage. Remove all packaging materials from around and inside the appliance and keep the original packaging carton and materials in a safe place. It will help prevent any damage if the product needs to be transported in the future, and you can use it to store the appliance when it is not in use.
  • Page 9 Getting Started (Cont.) • Overhanging wall units: To ensure best performance, if the appliance is positioned below an overhanging wall unit, the minimum distance between the top of the cabinet and the wall unit must be at least 100 mm. Ideally, however, the appliance should not be positioned below overhanging wall units.
  • Page 10: Instructions

    Instructions Temperature regulation This refrigerator has an adjustable thermostat in the main compartment, so you can adjust the temperature of the fridge. First Use The first time you turn the unit on, set the temperature control to 7 (coldest) for 2–3 hours before loading the compartments.
  • Page 11 Instructions (Cont.) Fresh food storage The fridge compartment is suitable for short-term storage of all your fresh food. • The temperature inside the fridge compartment varies depending on the amount of food stored and the frequency of door opening. It is low enough to limit some bacterial growth, but it is not suitable for long-term storage of perishable foods.
  • Page 12 Instructions (Cont.) The freezer compartment The freezer compartment, located at the top of the appliance, is equipped with a glass shelf and door balcony for convenient access and organised storage. It is suitable for freezing domestic quantities of fresh food and long-term storage (up to three months) of frozen food.
  • Page 13 Instructions (Cont.) Energy saving tips • Locate the appliance in the coolest area of the room, away from heat-producing appliances and out of direct sunlight. • Let hot foods cool to room temperature before placing them in the freezer. Overloading the compartments forces the compressor to run longer. •...
  • Page 14: Faqs And Troubleshooting Guide

    FAQs and Troubleshooting Guide If you experience a problem with the appliance, check in the following table for solutions to help you solve the problem. If none of the solutions offered help you solve the problem, please contact our after sales support centre for advice. Problem Possible cause The appliance does not...
  • Page 15 FAQs and Troubleshooting Guide (Cont.) Problem Possible cause The appliance freezes or • The temperature is set too cold. Turn it to a warmer cools too much. setting temporarily. Food in the freezer • The freezer temperature is set too warm; set it to a compartment is not colder setting.
  • Page 16: Other Useful Information

    Other Useful Information WARNING! To reduce the risk of electric shock or injury, always switch off the appliance and disconnect it from the power supply before cleaning or maintenance. Cleaning the appliance For hygienic reasons the appliance interior, including the interior accessories, should be cleaned regularly.
  • Page 17 Other Useful Information (Cont.) Defrosting the bar fridge • For efficient operation and minimum energy consumption, defrost the bar fridge when the frost on the chiller compartment walls is building up; do not let frost build up to more than 5 mm thickness. •...
  • Page 18 Other Useful Information (Cont.) Reversing the door swing This refrigerator can be opened from either side to suit your individual installation requirements. If you want to open the door from the other side, follow the instructions below and on the following page to reverse the door swing. Tools required: Phillips head screwdriver, flat-bladed screwdriver, hexagonal spanner Help required: We recommend you ask another person to help you during assembly.
  • Page 19 Other Useful Information (Cont.) 5. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it (Fig. 10). Fig. 10 Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet (Fig. 11). Fig. 11 Reattach the fridge door. Ensure the door is aligned horizontally and vertically so that the seals are closed on all sides before finally tightening the top hinge (Fig.
  • Page 20 Other Useful Information (Cont.) Replacing the interior light The fridge comes with a 10 W interior light Fig. 14 bulb, which is situated behind the temperature control. When it needs replacement, proceed as follows: Make sure the unit is disconnected from the power supply and the temperature control is set to 0.
  • Page 21 Other Useful Information (Cont.) Technical specifications Model HV-RBF121 Rated voltage 220 – 240 V~ Rated frequency 50 Hz Rated current 0.6 A Climate category Electrical protection class Total input power 90 W Refrigerant R600a (32 g) Insulation blowing agent Cyclopentane...
  • Page 22 Other Useful Information (Cont.) Responsible disposal At the end of its working life, do not throw this appliance out with your household waste. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately. Observe any local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately for recycling and recovery of the refrigerant and blowing agent.
  • Page 23 This page has been left blank intentionally. After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
  • Page 24 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on (AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
