- Page 2 FITTINGS Φ6x85 Φ8x2.2 M4x10 145x28 A x 4 B x 2 C x 4 D x 2 140x12 ST 3.9x12 Φ8x4 E x 1 F x 1 G x 4 PARTS 1 x 1 2 x 1 3 x 1 4 x 1 5 x 1 6 x 1...
- Page 3 STEP ONE 1. Insert legs 1 & 2 into panels 3 & 4 as shown in the diagram. IMPORTANT: Make sure the holes in leg 2 face towards the back of the item as shown in the diagram. STEP TWO 1.
- Page 4 STEP THREE 1. Attach panel 6 to the assembled unit as shown in the diagram. STEP FOUR 1. Attach bottom panel 10 to the assembled unit as shown in the diagram. STEP FIVE 1. Attach shelf 11 to panels 3 & 4 as shown in the diagram Page 4 of 7...
- Page 5 STEP SIX 1. Attach panel 9 to the assemlbed unit as shown in the diagram. NOTE: Take care to ensure panel 9 is located correctly before clicking into place. STEP SEVEN 1. Place hanging rail 12 onto the hanging rail brackets on side panels 3 &...
- Page 6 STEP EIGHT 1. Attach 2 x handles (D) to door panels 7 & 8 with 4 x wing screws (C) & 4 x plastic washers (G). Tighten by hand. STEP NINE 1. Attach door panel 7 to the assembled unit with 2 x hinges (A) &...
- Page 7 NOTE: Wall fixings are not included, please source suitable fixings for your wall type, if in doubt please consult a qualified trades person Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 7 of 7...
