Instruction Manual
AV Receiver
DRX-2.4
En

Advertisement

loading
Need help?

Need help?

Do you have a question about the DRX-2.4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Integra DRX-2.4

Summary of Contents for Integra DRX-2.4

  • Page 1 Instruction Manual AV Receiver DRX-2.4...
  • Page 2 Table of contents Firmware Update Speaker Layout Troubleshooting Main Room Main Room Room Supplementary Information Zone 2 Zone 2 Zone 2 Zone 2 Speaker Connections Reducing the Power Consumption in Standby State When the following functions are enabled, the power consumption in standby state increases.
  • Page 3 Connections Before starting the procedure Firmware Update Connecting the TV Update Information of the firmware To ARC/eARC TV Firmware Update Procedure To Non-ARC TV Part Names Connecting the SUB Monitor Front Panel SUB Monitor Display Connecting Playback Devices Rear Panel Connecting an AV Component with HDMI Jack Remote Controller Mounted...
  • Page 4 Registering this unit with an Amazon account Windows Media Player 12 settings ® Operating this unit Playing Back Amazon Music Play Queue Registering This Unit with Amazon Music Adding Play Queue Information Playing Amazon Music using the Integra Control Pro 79 Sort and Delete...
  • Page 5 2. Speaker Speaker Combinations 3. Audio Adjust General Specifications 4. Source 5. Listening Mode Preset 6. Hardware 7. Multi Zone 8. Miscellaneous Web Setup Menu operations Initial Setup with Auto Start-up Wizard Operations Integra Control Pro Main features Initial Setup...
  • Page 6 Before starting the procedure „ What's in the box „ Note • Connect speakers with an impedance of 4 Ω to 16 Ω. • The power cord must be connected only after all other connections are completed. • We will not accept any responsibility for damage arising from the connection with equipment manufactured by other companies.
  • Page 7 Firmware Update Updating the Firmware via Network This unit is equipped with a function to update the firmware via network or USB port when the firmware update is announced after purchase. This enables • While updating the firmware, do not do the following: various functions to be added and operations to be improved.
  • Page 8 Updating via USB represents an alphanumeric character.) Refer to the following descriptions and check. • While updating the firmware, do not do the following: Error Code – Disconnecting and reconnecting cables, USB storage device, speaker • -01, -10: setup microphone or headphones, or performing operations on the unit Ethernet cable not found.
  • Page 9 4. Connect the USB storage device to the USB port of this unit. • Others: • If an AC adapter is supplied with the USB storage device, connect the AC After removing the power plug once, insert it to the outlet, and then start the adapter, and use it with a household outlet.
  • Page 10 Part Names Front Panel • The reception range of the remote controller is within a distance of approx. 16´/5 m, and an angle of 20° in vertical direction and 30° to right and left. 5. Listening Mode button: Press "Movie/TV", "Music"...
  • Page 11 Front Panel 15. Zone 2 button: Controls the multi-zone function. 19. Setup Mic jack: Connect the supplied speaker ( →p85) setup microphone. ( →p131) Off button: Switches the multi-zone function off. ( →p85) 16. Zone 2 Level buttons: Adjust the volume of the multi-zone function.
  • Page 12 Display B: Audio is output only to ZONE B. AB: Audio is output to both ZONE A and ZONE B. 3. Lights according to the type of input digital audio signal and the listening mode. 4. Lights in the following conditions. RDS (Australian and Asian models): Receiving RDS broadcasting.
  • Page 13 Rear Panel 5. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable connected to an AV component. 6. ETHERNET port: Connect to the network with an Ethernet cable. 7. USB port: Connect a USB storage device to play music files ( →p88).
  • Page 14 Rear Panel PRE OUT FRONT jacks: Connect to a power amplifier. ( →p46) 14. SUBWOOFER PRE OUT jacks: Connect a powered subwoofer with a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack.
  • Page 15 Remote Controller On/Standby button selected, pressing and holding this button for 5 2. Input selector buttons: Switches the input to be seconds or more will switch to the pairing mode. played. button: Returns the display to the previous 3. Play buttons: Used for playback operations state while setting.
  • Page 16 Remote Controller 12. Tone buttons: Adjusts the sound quality. Press 19. Mode button: Switches between automatic "Treble", "Bass", or "Vocal" to select what you tuning and manual tuning for AM/FM stations want to adjust, then adjust with + and -. ( →p64).
  • Page 17 Inputting Characters You can input characters or symbols on the keyboard displayed on the TV • Select "A/a" to switch between upper and lower cases. (Can also be switched screen such as when inputting a password for Wi-Fi Setup ( →p116) or naming with the Mode button on the remote controller.) a preset radio station ( →p111).
  • Page 18 Speaker Layout This unit can be used in different ways, depending on the layout of the speakers you are installing. Select the speaker layout that suits the installation environment, then confirm the methods for installation and connection. Speaker Layout 3.1ch 5.1ch 7.1ch ‰...
  • Page 19 Speaker Layout The listening room and the speaker layout 1. ZONE A Speakers The speaker system set up in the main room (where this unit is located). 2. ZONE 2 Speakers The 2 ch speaker system set up in a separate room (ZONE 2). This enables you to play the same source in the main room and the separate at the same time, or to play separate sources.
  • Page 20 Speaker Layout 3.1 Channel System A 3.1 Channel System that combines front speakers with a center speaker and a subwoofer. Basic system ( →p26) 3.1 ch + ZONE 2 ( →p26) 3.1 ch (Bi-Amping (Front)) ( →p26) Main Room Zone 2 Zone 2 3.1ch 5.1ch...
  • Page 21 Speaker Layout 5.1 Channel System This is a basic 5.1 Channel System. Basic system ( →p26) 5.1 ch + ZONE 2 ( →p26) 5.1 ch (Bi-Amping (Front)) ( →p26) Main Room Zone 2 Zone 2 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 22 Speaker Layout 7.1 Channel System This is a 7.1 Channel System that consists of the basic 5.1 Channel System and added surround back speakers. Basic system ( →p27) 7.1 ch + ZONE 2 ( →p27) Main Room Zone 2 Zone 2 3.1ch 5.1ch 7.1ch...
  • Page 23 Speaker Layout 3.1.2 Channel System A Speaker System that is a 3.1 Channel System with one set of height speakers added. 3.1.2 ch (Front High or Rear High) ( →p28) 3.1.2 ch (Top Front or Top Middle or Top Rear) 3.1.2 ch (Dolby Enabled Speakers (Front)) ( →p28) ( →p28)
  • Page 24 Speaker Layout 5.1.2 Channel System A Speaker System that is a 5.1 Channel System with one set of height speakers added. 5.1.2 ch (Front High or Rear High) ( →p29) 5.1.2 ch (Top Front or Top Middle or Top Rear) 5.1.2 ch (Dolby Enabled Speakers (Front or ( →p29) Surround)) ( →p29)
  • Page 25 Speaker Installation How the speakers are set up depends on the size and shape of the room, so here we introduce just a basic layout example. The alphabetic symbols used in this chapter represent the following speakers: Front speaker Left Front speaker Right Center speaker Surround speaker Left...
  • Page 26 Speaker Installation „ 3.1 Channel System „ 5.1 Channel System a: 22° to 30° a: 22° to 30°, b: 120° FL, FR Place the Left and Right Front Speakers to match ear height. FL, FR Place the Left and Right Front Speakers to match ear height. The center speaker should be set up facing the listening position at The center speaker should be set up facing the listening position an angle.
  • Page 27 Speaker Installation „ 7.1 Channel System a: 22° to 30°, b: 90° to 110°, c: 135° to 150° FL, FR Place the Left and Right Front Speakers to match ear height. The center speaker should be set up facing the listening position at an angle.
  • Page 28 Speaker Installation „ 3.1.2 Channel System Top Speakers High Speakers a: 22° to 30° a: 30° to 55° 3´ (0.9 m) b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position.
  • Page 29 Speaker Installation „ 5.1.2 Channel System Top Speakers High Speakers a: 22° to 30° b: 120° a: 30° to 55° 3´ (0.9 m) b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position. TML, TMR Fit top middle speakers on the ceiling directly above the listening position.
  • Page 30 Speaker Connections (Before starting the procedure) Speaker Connections and "Speaker Impedance" Settings 4-16 3.1 Channel System 33, 34, 35 Speaker Connections 5.1 Channel System 36, 37, 38 7.1 Channel System 39, 40 3.1.2 Channel System 41, 42, 43 5.1.2 Channel System 44, 45 3.1ch 5.1ch...
  • Page 31 Speaker Connections Speaker Connections and "Speaker Impedance" Settings Connections „ (Note) Speaker Impedance Connect speakers with an impedance of 4 Ω to 16 Ω. If any of the speakers to be connected has an impedance of 4 Ω or more and less than 6 Ω, set "Speaker Impedance"...
  • Page 32 Speaker Connections „ Connect the Subwoofer a Subwoofer cable Connect a powered subwoofer with this unit using a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack. 3.1ch 5.1ch 7.1ch 3.1.2ch...
  • Page 33 Speaker Connections „ 3.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 34 Speaker Connections „ 3.1 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 35 Speaker Connections „ 3.1 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 36 Speaker Connections „ 5.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 37 Speaker Connections „ 5.1 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 38 Speaker Connections „ 5.1 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 39 Speaker Connections „ 7.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 40 Speaker Connections „ 7.1 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch While ZONE 2 playback is being performed, surround back speakers installed in the main room cannot play audio. 7.1ch 3.1.2ch 5.1.2ch...
  • Page 41 Speaker Connections „ 3.1.2 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 42 Speaker Connections „ 3.1.2 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 43 Speaker Connections „ 3.1.2 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch 7.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of 3.1.2ch your speakers as well.
  • Page 44 Speaker Connections „ 5.1.2 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 45 Speaker Connections „ 5.1.2 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch While ZONE 2 playback is being performed, height speakers installed in the main room cannot play audio. 3.1.2ch 5.1.2ch...
  • Page 46 Speaker Connections Connecting a Power Amplifier Power amplifier You can connect a power amplifier to the unit and use the unit as a pre-amplifier in order to produce a large volume that cannot be output with the unit only. Connect the front speakers to the power amplifier. For details, refer to the power amplifier's instruction manual.
  • Page 47 Connections Connecting the TV Connecting the SUB Monitor Connecting Playback Devices Connecting an AV Component in a Separate Room (Multi-zone Connection) Connecting Antennas Network Connection Connections Connecting the Power Cord...
  • Page 48 Connections Connecting the TV By connecting a TV to this unit, you can show the video from AV devices connected to this unit on the TV and also play the sound from the TV through this unit. To ARC/eARC TV IN(ARC) If the TV supports the ARC (Audio Return Channel) function (*), use only the HDMI cable to connect with the TV.
  • Page 49 Connections Connecting the SUB Monitor SUB Monitor This unit has multiple HDMI OUT jacks, and another TV or projector can be connected to the HDMI OUT SUB jack. • Switch between MAIN and SUB using the HDMI Main/Sub button on the remote controller ( →p15) or "Quick Menu"...
  • Page 50 Connections Connecting Playback Devices Connecting an AV Component with HDMI Jack Mounted This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer Electronics Control) standard, you can use the HDMI CEC function (*) that enables linking with input selectors, etc.
  • Page 51 Connections Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using an analog audio cable. You can also connect a turntable that has an MM- type cartridge to the PHONO jack. • If the turntable has a built-in phono equalizer, connect it to any of the AUDIO IN jacks other than the PHONO jack.
  • Page 52 Connections Connecting an AV Component in a Separate Room (Multi-zone Connection) Connecting a TV (ZONE 2) While a disc is played on a Blu-ray Disc player in the main room (where this unit is located), you can play the video and audio of the same Blu-ray Disc player or another AV component on the TV equipped with an HDMI IN jack in a separate room (ZONE 2).
  • Page 53 Connections Connecting an Integrated Amplifier (ZONE 2) You can enjoy 2 ch audio in the separate room (ZONE 2) while performing playback in the main room (where this unit is located). Use an analog audio cable to connect the ZONE 2 PRE/LINE OUT terminal on this unit to the input jack on an integrated amplifier in the separate room.
  • Page 54 Connections Connecting Antennas Connect the antenna to this unit, and set up the antenna at the best position for listening while receiving radio signals. Attach the indoor FM antenna to the wall using push pins or adhesive tape. (North American (Australian and models) Asian models)
  • Page 55 Connections Network Connection This unit can be connected to the network using a wired LAN or Wi-Fi (wireless LAN). You can enjoy network functions such as Internet radio by network connection. If connection is made by the wired LAN, connect the router and the ETHERNET jack with the Ethernet cable as shown in the illustration.
  • Page 56 Connections Connecting External Control Devices IR IN/OUT port When connecting a remote control receiver unit consisting of an IR Receiver, etc. to this unit, operation using the remote controller is possible even if the remote control signal is difficult to reach (due to installation in the cabinet, etc.).
  • Page 57 Connections 12V TRIGGER OUT jack When connecting a device equipped with a TRIGGER IN jack such as a BD/DVD player to this unit, the device can be turned on or set to standby by interlocking the operation on this unit. When the desired input is selected on the unit, power link operation will be activated with a control signal of maximum 12 V/100 mA from the 12V TRIGGER OUT A jack or maximum 12 V/25 mA when using the 12V TRIGGER OUT B or C jack.
  • Page 58 Connections Connecting the Power Cord Connect the power cord after all the connections are completed. • This model includes a removable power cord. Be sure to connect the power cord to the AC INLET of the unit first, and then connect it to the outlet. Always disconnect the outlet side first when disconnecting the power cord.
  • Page 59 Playback Basic Operations AV Component Playback BLUETOOTH Playback ® Listening To the Radio Listening Mode Quick Menu Network Services Playback Spotify AirPlay ® DTS Play-Fi ® Amazon Alexa Amazon Music Connecting the Sonos System for Playback Internet Radio Convenience functions Multi-zone Playing different audio and video USB Storage Device...
  • Page 60 Playback AV Component Playback You can play the audio from AV components, such as Blu-ray disc players through this unit. • When a TV is connected to the HDMI OUT SUB jack, use the HDMI Main/Sub button or "Quick Menu" ( →p70) to switch between MAIN and SUB. Basic Operations Perform the following procedure when this unit is on.
  • Page 61 If a password is requested, enter "0000". • This unit is displayed as "Integra DRX-2.4 XXXXXX". This display can be The illustration shows an image. changed using the Friendly Name function ( →p117) or Integra Control Pro ( →p132) (available on iOS or Android™).
  • Page 62 Playback Transmitting audio from this unit to BLUETOOTH wireless technology enabled devices Pairing 1. Press the input selector you want to play. • Select a source other than "BLUETOOTH". This function does not work if you select "BLUETOOTH". • This function can be used in one location, either the main room (where this unit is located) or a separate room (ZONE 2).
  • Page 63 Playback Playing Back 1. Do the play operations on the AV component connected to this unit. Do the play operations on this unit when the input is TUNER or NET. You cannot adjust the volume of the BLUETOOTH wireless technology enabled device on this unit.
  • Page 64 Playback Listening To the Radio You can receive AM/FM radio stations on this unit with the built-in tuner. Listening To the AM/FM Radio Tuning into a Radio Station Perform the following procedure when this unit is on. „ Tuning Automatically 1.
  • Page 65 Playback Using RDS (Australian and Asian models) „ Tuning Manually Note that if you tune manually, the reception for FM broadcasts will be monaural RDS stands for Radio Data System, and is a method of transmitting data in FM rather than stereo, irrespective of the sensitivity of the reception. radio signals.
  • Page 66 Playback • Unusual characters may be displayed when the unit receives unsupported characters. This is not a malfunction. Also, if the signal from a station is weak, information may not be displayed. ‰ Presetting a Radio Station ( p67)
  • Page 67 Playback Presetting a Radio Station „ Registration Procedure „ Selecting a Preset Radio Station You can preset up to 40 of your favorite AM/FM radio stations. 1. Press Tuner. 2. Press the cursors to select a preset number. After tuning in to the AM/FM radio station you want to register, perform the following procedure.
  • Page 68 Playback Listening Mode This unit is equipped with a variety of listening modes, and you can select the optimum listening mode for movies, TV, music, and games by pressing Movie/TV, Music, and Game. ( →p148) • For details of the effects of each listening mode, refer to "Listening Mode Effects" ( →p154). •...
  • Page 69 Playback Checking the input format and listening mode By repeatedly pressing on the remote controller or Info on the main unit, the main unit display changes in the following order: • The display content for the BLUETOOH input is different. •...
  • Page 70 Playback Quick Menu Menu operations You can quickly adjust the settings you frequently use, such as tone adjustments, etc. You can make the settings on the TV screen during playback. Press Q on the remote controller to display the Quick Menu. Quick Menu BD/DVD HDMI...
  • Page 71 Playback „ HDMI „ Room EQ HDMI Out: Select the HDMI OUT jack to output video signals from "MAIN", It cannot be set if the listening mode is Direct. "SUB", and "MAIN+SUB". AccuEQ: Enable or disable the equalizer function that corrects for sound A/V Sync: If the video is behind the audio, you can delay the audio to offset the distortion caused by the acoustic environment of the room.
  • Page 72 Playback Spotify Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how.
  • Page 73 Confirm that this unit and the PC are connected to the same network beforehand. Then, press NET on the remote controller. Next, click the AirPlay icon in iTunes, select this unit from the displayed devices, and start play of a music file. iPhone Integra DRX-2.4 XXXXXX e.g., iOS 10...
  • Page 74 AirPlay-enabled iPhone device. Integra DRX-2.4 XXXXXX You can also play the music files on a PC with iTunes (Ver. 12.8 or later) Integra XXXXXXXX equipped. Confirm that this unit and the PC are connected to the same network Integra XXXXXXXX beforehand.
  • Page 75 "Group playback" that plays the same music in https://integrahometheater.jp/playfi/info_i.html separate rooms at home. To enjoy this function, download Integra Music Control • To use a music streaming distribution service, user registration may be App (available on iOS or Android™).
  • Page 76 Refer to "Integra Control Pro" ( →p132) for information about the app. 2. Start Integra Control Pro and tap the unit when displayed. 3. Tap "NET" or "NETWORK" at the top of the Integra Control Pro screen, and after switching to the network menu, tap the "amazon alexa" icon.
  • Page 77 Playback Operating this unit 7. When registration is finished, the screen returns to the one for Integra Control Pro. Follow the on screen instructions and talk to the terminal with Amazon Alexa (an Amazon Echo, etc.), and confirm that you can use voice You can use voice commands to adjust the volume on this unit, start and stop commands.
  • Page 78 Playback Amazon Music Registering This Unit with Amazon Music 1. Register with the Amazon account on Integra Control Pro. This cannot be set with operations on this unit. Refer to "Integra Control Pro" ( →p132) for information about the app.
  • Page 79 Playing Amazon Music using the Integra Control Pro 1. Start up Integra Control Pro. This unit is automatically displayed after startup. Then, tap and select this unit displayed. 2. Tap "NET" or "NETWORK" on the upper part of the screen to switch to the network screen.
  • Page 80 Playback Connecting the Sonos System for Playback How to Connect This Unit and Sonos Connect 1. Connect the Sonos Connect to the AUDIO IN jack of this unit with the RCA audio cable supplied with the Sonos Connect. Any input jacks other than the PHONO jack can be used.
  • Page 81 Playback cannot find the Sonos Connect to be interlocked, return to the previous screen, turn off the product you do not want to interlock, and try again. Output Zone: With the cursors / , select the ZONE where you want to listen to the music.
  • Page 82 Playback Internet Radio By connecting this unit to an Internet-connected network, you can enjoy Internet radio services such as TuneIn Radio. • To play Internet radio services, the network needs to be connected to the Internet. • Depending on the Internet radio service, a user registration may be required on your PC beforehand. For details of each service, visit the website of each service. Playing Back Perform the following procedure when this unit is on.
  • Page 83 Playback Internet Radio Service Menu You can bookmark specific stations, or delete stations that have been bookmarked. The displayed menu varies according to the service being selected. The menu icon is displayed while a station is being played. When only this icon is displayed, pressing Enter will display the menu on the screen.
  • Page 84 "BLUETOOTH". You cannot select different stations of AM/FM broadcasts for the main room and separate room. Using Integra Control Pro ( →p132) is convenient for operations of multi-zone playback. You can use it on mobile devices, such as a smartphone and tablet to which Integra Control Pro (available on iOS or Android™) has been downloaded.
  • Page 85 Playback Playing Back In remote controller operation, while pressing and holding the Zone 2 Shift button, press other buttons for operation. 1. While pressing and holding the Zone 2 Shift button on the remote controller, point the remote controller at this unit and press . •...
  • Page 86 Playback • When video and audio via HDMI input are output to ZONE 2, set "1. Input/Output Assign" - "TV Out / OSD" - "Zone 2 HDMI" ( →p101) to "Use" on the Setup menu. • DSD audio signals cannot be output to ZONE 2 with the "NET" input selector. •...
  • Page 87 Playback Playing different audio and video Displaying Your Favorite Video on TV While Playing Music While listening to the music from a CD or BLUETOOTH enabled device, you can display video on TV from an AV component such as a Blu-ray Disc player. •...
  • Page 88 Playback USB Storage Device You can play music files stored on a USB storage device. Supported Audio Formats USB Storage Device Requirements MP3 (.mp3) • This unit can use USB storage devices that comply with the USB mass • MPEG-1/MPEG-2 Audio Layer 3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, storage class standard.
  • Page 89 Playback Playing music files saved on a USB storage device Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. 2. Plug your USB storage device containing music files into the USB port of this unit’s rear panel.
  • Page 90 Playback • This unit supports the gapless playback of the USB storage device in the following conditions. When continuously playing WAV, FLAC and Apple Lossless files with the same format, sampling frequency, the number of channels and quantization bit rate. •...
  • Page 91 Playback Music Server Streaming play of music files stored on PCs or NAS devices connected to the same network as this unit is supported. • The network servers this unit is compatible with are those PCs with players installed that have the server functionality of Windows Media Player 12, or NAS that ®...
  • Page 92 Playback Playing Back Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2. Start the server (Windows Media Player 12 or NAS device) containing the ®...
  • Page 93 Playback Controlling Remote Playback from a PC 6. Select the target server with the cursors, and press Enter to display the items list screen. You can use this unit to play music files stored on your PC by operating the PC •...
  • Page 94 The Play Queue information is effective until the power cord of this unit is removed from the outlet. Refer to "Integra Control Pro" ( →p132) for information about the app.
  • Page 95 Playback 2. Tap the " " icon of the track to sort, and drag the icon to the destination. 3. To delete a track, slide the track to the left until the trash icon changes to " ". If the device is on iOS, slide the " "...
  • Page 96 Playback Connecting a transmitter for playback When you connect wireless headphones or a wireless speaker transmitter to the ZONE B LINE OUT terminal of this unit, you can play back the same source through the wireless headphones or wireless speakers as in the main room. Connections Setting Up 1.
  • Page 97 Setup Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Setup menu. Setup 1. Input/Output Assign 1. TV Out / OSD 2. Speaker 2. HDMI Input 3. Audio Adjust 3.
  • Page 98 Setup Setup Menu Menu list 1. Input/Output Assign 1. TV Out / OSD Make settings for TV output and On-Screen Displays (OSD) that appear on the TV. p100 2. HDMI Input You can change input assignment between the input selectors and HDMI IN jacks. p102 3.
  • Page 99 Setup 5. Listening Mode Preset 1. BD/DVD Preset the favorite listening mode when "BD/DVD" input is selected. p113 2. GAME Preset the favorite listening mode when "GAME" input is selected. p113 3. CBL/SAT Preset the favorite listening mode when "CBL/SAT" input is selected. p113 4.
  • Page 100 Setup Setup 1. Input/Output Assign 1. Input/Output Assign „ 1. TV Out / OSD ‰ 1080p -> 4K Upscaling (Default Value: Off) When a TV supporting 4K is used, video signals input with 1080p can be Make settings for TV output and On-Screen Displays (OSD) that appear on the automatically output with 4K.
  • Page 101 Setup Setup 1. Input/Output Assign ‰ HDMI 4K/8K Signal Format (Default Value: 4K Standard) ‰ Zone 2 HDMI (Default Value: Not Use) Set the 4K/8K signal format input and output by this unit. Set to suit the TV or Make the setting when you output to the Zone 2 TV connected to the HDMI OUT player connected.
  • Page 102 Setup Setup 1. Input/Output Assign „ 2. HDMI Input ‰ Mini Player OSD (Default Value: Always On) You can display on the TV the images from another input selected last while You can change input assignment between the input selectors and HDMI IN playing the audio from NET or BLUETOOTH input.
  • Page 103 Setup Setup 1. Input/Output Assign „ 3. Digital Audio Input „ 4. Analog Audio Input Change input assignment between the input selectors and DIGITAL IN Change input assignment between the input selectors and AUDIO IN jacks. If COAXIAL/OPTICAL jacks. If you do not assign a jack, select "---". you do not assign a jack, select "---".
  • Page 104 Setup Setup 2. Speaker 2. Speaker „ 1. Configuration ‰ Zone 2 Preout (Default Value: Zone 2) Set an output destination of the audio output from ZONE 2 PRE/LINE OUT/ Change the settings of connection environment of the speakers. ZONE B LINE OUT jack. ‰...
  • Page 105 Setup Setup 2. Speaker „ 2. Crossover Surround Back: Select the crossover frequency from "40 Hz" to "200 Hz" to start outputting Change the settings of crossover frequencies. frequencies for each channel. ‰ Front (Default Value: 100 Hz) "Full Band": Full band will be output. Center (Default Value: 100 Hz) •...
  • Page 106 Setup Setup 2. Speaker „ 3. Distance „ 4. Level Calibration Set the distance from each speaker to the listening position. Adjust the volume level of each speaker. ‰ Front Left (Default Value: 12.0 ft/3.60 m) ‰ Front Left (Default Value: 0.0 dB) Center (Default Value: 12.0 ft/3.60 m) Center...
  • Page 107 Setup Setup 2. Speaker „ 5. Dolby Enabled Speaker „ 6. Equalizer Settings Change the settings of Dolby Enabled Speakers. You can adjust the output volume of the range for each connected speaker. • This setting can be selected when "Configuration" - "Height Speaker" is set to Adjust the volume of different sound ranges for each speaker.
  • Page 108 Setup Setup 2. Speaker „ 7. Speaker Virtualizer The Speaker Virtualizer function can be switched between On and Off. ‰ Speaker Virtualizer (Default Value: On) Listening modes such as T-D that have virtual speaker effects can be selected. Listening modes such as T-D that have virtual speaker effects cannot be selected.
  • Page 109 Setup Setup 3. Audio Adjust 3. Audio Adjust „ 1. Multiplex/Mono „ 2. Dolby Change the settings of multiplex audio playback. Change the setting of when Dolby signals are input. ‰ Multiplex Input Channel (Default Value: Main) ‰ Loudness Management (Default Value: On) Set the audio channel or language to be output when playing multiplex audio or When playing Dolby TrueHD, enable the dialog normalization function which multilingual broadcasts, etc.
  • Page 110 Setup Setup 3. Audio Adjust „ 4. LFE Level Set the low-frequency effect (LFE) level for Dolby Digital series, DTS series, Multichannel PCM, and DSD signals. ‰ LFE Level (Default Value: 0 dB) Select the low-frequency effect (LFE) level of each signal from "0 dB" to "-∞ dB".
  • Page 111 Setup Setup 4. Source 4. Source „ 1. My Input Volume „ Audio Select Set a volume value for each input selector. Select the priority for input selection when multiple audio sources are connected to one input selector, such as connections to both the "BD/DVD" HDMI IN jack ‰...
  • Page 112 Setup Setup 4. Source „ Video Select Analog When giving priority to the input signal from AUDIO IN jacks • This item can be selected only when the input to be set When "TUNER", "NET", or "BLUETOOTH" input is selected, you can set the is assigned to the AUDIO IN jack in the "1.
  • Page 113 Setup Setup 5. Listening Mode Preset 5. Listening Mode Preset You can preset your favorite listening mode to each input. (For example, you can always apply straight decode to the Dolby TrueHD source of Blu-ray Disc to play it in unchanged sound field.) When the list of input sources is displayed, set the signal type and listening mode.
  • Page 114 When this function is used When "Last" is selected, you can switch the input of the unit When this function is not used using the remote controller or the Integra Control Pro even in the standby mode. Auto, Select one of these settings when you have connected Auto (Eco) equipment that conforms to the CEC standard.
  • Page 115 Setup Setup 6. Hardware ‰ Audio TV Out (Default Value: Auto) ‰ Audio Return Channel (eARC supported) (Default Value: On) You can enjoy audio through the speakers of the TV while this unit is on. You can enjoy the sound of an HDMI-connected ARC-compatible TV or eARC- •...
  • Page 116 Setup Setup 6. Hardware „ 2. Network ‰ DHCP (Default Value: Enable) Change the settings of the Network function. Enable Auto configuration by DHCP • When LAN is configured with a DHCP, set "DHCP" to "Enable" to configure Disable Manual configuration without DHCP the setting automatically.
  • Page 117 6. Hardware ‰ Friendly Name (Default Value: Integra DRX-2.4 XXXXXX) ‰ AirPlay Device Name (Default Value: Integra DRX-2.4 XXXXXX) Change the model name of this unit which is displayed on the device Change the model name of this unit which is displayed on the AirPlay- connected to the network to an easily recognized name.
  • Page 118 Setup Setup 6. Hardware ‰ AirPlay Password (Default Value: -) ‰ Network Check (Default Value: -) You can set a password of up to 31 characters so that only users that have You can check the network connection. input can use AirPlay. Press Enter when "Start"...
  • Page 119 Setup Setup 6. Hardware „ 3. Bluetooth ‰ Pairing Information (Default Value: -) You can initialize the pairing information stored on this unit. If you are no longer Change the settings for the BLUETOOTH function. able to connect with a device you have paired, try doing this. ( →p140) •...
  • Page 120 Setup Setup 6. Hardware ‰ Search Devices (Default Value: -) ‰ Device (Default Value: -) Search for a BLUETOOTH wireless technology enabled device that is able to Displays the name of the BLUETOOTH enabled device connected to the unit. receive the audio from this unit. Select "Start" then press Enter. A list of the •...
  • Page 121 Standby" or "Network Standby" is enabled, the unit enters the Hybrid Standby application such as Integra Control Pro that can control this unit. mode which minimizes the increase in power consumption.) •...
  • Page 122 Setup Setup 6. Hardware „ 5. 12V Trigger A ‰ Bluetooth Wakeup (Default Value: Off) This function wakes up the unit on standby by connecting a BLUETOOTH Set when outputting the control signal (maximum 12 V/100 mA) through the 12V enabled device.
  • Page 123 Setup Setup 6. Hardware „ 6. 12V Trigger B „ 7. 12V Trigger C Set when outputting the control signal (maximum 12 V/25 mA) through the 12V Set when outputting the control signal (maximum 12 V/25 mA) through the 12V TRIGGER OUT B jack.
  • Page 124 Setup Setup 6. Hardware „ 8. Works with SONOS ‰ Preset Volume (Default Value: Main=Last / Zone 2=Last) Change the settings to connect with the Sonos Connect. You can set the volume beforehand for playing back the Sonos Connect. You can set volumes for the main room (where this unit is located) and separate (SONOS-1/SONOS-2) room (ZONE 2) respectively.
  • Page 125 Setup Setup 7. Multi Zone 7. Multi Zone „ 1. Zone 2 „ 2. Remote Play Zone Change the settings for Zone 2. Change the settings for remote play. ‰ Output Level (Default Value: Fixed) ‰ Remote Play Zone (Default Value: Auto) Select whether to adjust the volume on the integrated amplifier in the separate When playing with AirPlay or Spotify Connect, or when using the Music Server room or on this unit when outputting to Zone 2.
  • Page 126 Press Enter to select when updating the firmware via USB. • This setting cannot be selected if a USB storage device is not connected or If multiple Integra/ONKYO products are installed in the same room, select the there is no updatable firmware in the USB storage device.
  • Page 127 Setup Setup 8. Miscellaneous „ 5. Lock Lock the Setup menu so that the settings cannot be changed. ‰ Setup Parameter (Default Value: Unlocked) Lock the Setup menu so that the settings cannot be changed. Locked The menu is locked. Unlocked The menu is unlocked.
  • Page 128 Setup Web Setup Menu operations Device Information You can make the settings for the network function of this unit using an Internet browser on a PC, smartphone, etc. You can change the Friendly Name or AirPlay Device Name, set an AirPlay Password, etc.
  • Page 129 Setup Initial Setup with Auto Start-up Wizard Operations When you turn the unit on for the first time after purchase, the Initial Setup screen is automatically displayed on the TV to allow you to make settings TV’s REMOTE required for startup using simple operations following on-screen guidance. Inputs 1.
  • Page 130 Setup „ Network Connection Keyboard Input 1. A confirmation screen asking you whether to agree to the privacy statement To switch between upper and lower cases, select "A/a" on the screen, and press is displayed during network setting. If you agree, select "Accept" and press Enter on the remote controller.
  • Page 131 Setup „ 2. Multi Zone Sound Check 1. Place the supplied speaker setup microphone at the listening position, and connect it to the Setup Mic jack on the main unit. Output test tones to ZONE 2 to enjoy audio in a separate room (ZONE 2) in addition to the main room.
  • Page 132 (internet radio or play of a music file) without looking at the TV. • To use Integra Control Pro, this unit needs to be connected to the same network as the mobile device.
  • Page 133 Troubleshooting Troubleshooting „ Listening Modes „ Video Before starting the procedure „ Linked operation Problems may be solved by simply turning the power on/off or disconnecting/ „ Tuner connecting the power cord, which is easier than working on the connection, setting and operating procedure.
  • Page 134 Troubleshooting When the unit is operating erratically ‰ Try restarting the unit ‰ Resetting the unit (this resets the unit settings to the default) Restarting this unit may solve the problem. Set the main unit to standby, then after waiting for 5 seconds or more, press and hold the On/Standby button of If the restart of the unit does not solve the problem, reset the unit, and restore the main unit for at least 5 seconds, and then restart the unit.
  • Page 135 Troubleshooting Troubleshooting „ Power ‰ When the power is turned on, "AMP Diag Mode" appears on the display of the main unit. • The protection circuit function may have operated. If the unit suddenly enters the standby state and "AMP Diag Mode" appears on the display of the main unit when the power is turned on again, this function is diagnosing whether or not the main unit is malfunctioning or there is an abnormality with the speaker cable connection.
  • Page 136 Troubleshooting ‰ No sound from the TV • Change the input selector on this unit to the position of the terminal to which the TV is connected. • If the TV doesn't support the ARC function, along with connection by HDMI, connect the TV and this unit using a digital optical cable. ( →p48) ‰...
  • Page 137 Troubleshooting ‰ Noise can be heard • Using cable ties to bundle audio pin cables, power cords, speaker cables, etc. may degrade the audio performance. Do not bundle the cords. • An audio cable may be picking up interference. Change the position of the cables. ‰...
  • Page 138 Troubleshooting ‰ About DTS signals • With media that switches suddenly from DTS to PCM, PCM playback may not start immediately. In such a case, stop playback on the player side for approx. 3 seconds or more. Then, resume playback. The playback will be performed normally. •...
  • Page 139 Troubleshooting ‰ Images flicker • The output resolution of the player may not be compatible with the resolution of the TV. If the player is connected to this unit with an HDMI cable, change the output resolution on the player. Also this may be solved by changing the screen mode on the TV. ‰...
  • Page 140 Troubleshooting ‰ Cannot connect a BLUETOOTH wireless technology enabled device (PC, smartphone, etc.) to this unit ( →p119) • Check if the BLUETOOTH function of the BLUETOOTH enabled device is enabled. • Initialize the pairing information and perform pairing again. Firstly delete all the pairing information saved on this unit.
  • Page 141 Troubleshooting „ Network function • If you cannot select a network service, start up the network function to select it. It may take approx. one minute to start it up. • When the NET indicator is blinking, this unit is not properly connected to the home network. •...
  • Page 142 Troubleshooting „ USB storage device ‰ USB storage device is not displayed • Check if the USB storage device or USB cable is securely inserted to the USB port of the unit. ( →p88) • Disconnect the USB storage device once from the unit, and then reconnect it. •...
  • Page 143 Troubleshooting „ ZONE B function ‰ Cannot output audio to ZONE B • To output audio to ZONE B, set the audio output destination for "Audio" - "Zone B" on Quick menu to "On (A+B)" or "On (B)" and also set ( →p96) "2.
  • Page 144 Troubleshooting „ Others ‰ Strange noise can be heard from the unit • If you have connected another device to the same outlet as this unit, strange noise may occur under the influence of the device. If the symptom is remedied by removing the power plug of the other device from the outlet, use different outlets for this unit and the device. ‰...
  • Page 145 Appendix Speaker Layouts and Selectable Listening Modes See the following table for selectable listening modes for each speaker layout. Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*1) (*1) (*1) (*2) (*2) (*2) (*2) (*2) DD (Dolby Audio - DD) (*1) (*1) (*1)
  • Page 146 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*3) (*3) (*3) ES Discrete (DTS-ES Discrete) ES Matrix (DTS-ES Matrix) DTS 96/24 (*3) (*3) (*3) DTS-HD HR (DTS-HD High Resolution) DTS-HD Master (DTS-HD Master Audio) DTS Express DTS:X DTS Neural:X DTS Virtual:X...
  • Page 147 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 Multich (Multichannel) (*1) (*1) (*1) (*1) (*1) (*3) (*3) (*3) (*1) (*1) (*1) (*2) (*2) (*2) (*2) (*2) Direct (*1) (*1) (*1) (*1) (*1) (*1) (*1) (*1) (*1) Stereo (*4) (*4) (*4) (*4)
  • Page 148 Appendix Listening Mode buttons and Selectable Listening Modes Refer to the following table for the listening modes that can be selected with each listening mode button. Listening Mode buttons Listening Mode buttons Listening mode Movie/TV Music Game Listening mode Movie/TV Music Game DD (Dolby Audio - DD)
  • Page 149 Appendix Listening Mode buttons Listening mode Movie/TV Music Game Orchestra Unplugged Studio-Mix TV Logic Unplugged Game-RPG Game-Action Game-Rock Game-Sports AllCh Stereo Mono Music T-D (Theater-Dimensional)
  • Page 150 Appendix Input Formats and Selectable Listening Modes You can select a variety of listening modes Listening mode DTHD according to the audio format of the signal to be DSur Direct (Dolby Audio (Dolby Audio Atmos input. (Dolby Audio (Dolby Audio Stereo - DD+) - TrueHD)
  • Page 151 Appendix Listening mode DTS-HD HR DTS-HD ES Discrete ES Matrix DTS 96/24 (DTS-HD High Master (DTS- (DTS-ES DTS (*2) Express (DTS-ES DTS:X Neural:X Virtual:X (*2) Resolution) HD Master Discrete) (*2) Matrix) (*5) (*6) (*9) (*10) Input format (*2) Audio) (*2) (*5) 2-channel signal input Analog / PCM...
  • Page 152 Appendix Listening mode Orchestra/ Unplugged/ AllCh T-D (Theater- Studio-Mix/ TV Logic/ Game- Stereo / (Multich Mono Dimensional) (*2)(*11) Action/ Game-Rock/Game- Mono Music PCM) (*2) (*9) Input format RPG/ Game-Sports (*7) (*8) 2-channel signal input Analog / PCM Music file / DSD (*1) DD / DD+ / DTHD DTS / DTS 96/24 / DTS Express / DTS-HD HR /...
  • Page 153 Appendix (*1) You cannot select any mode other than Stereo, AllCh Stereo and Mono Music if the sampling rate is 5.6/11.2 MHz. (*2) A center speaker or surround speakers need to be installed. (*3) If the input source is Blu-ray Disc and the speaker layout is 5.1 ch or less, DD+ cannot be selected. Instead, the listening mode for DD can be selected. (*4) This can only be selected when no surround back speaker is connected.
  • Page 154 Appendix Listening Mode Effects In alphabetical order • To enable transfer of this audio format, connect via an HDMI cable and set „ AllCh Stereo the audio output on the player to Bitstream output. • When "Speaker Virtualizer" ( →p108) is set to "Off" (Default: On), modes This mode is ideal for background music.
  • Page 155 Appendix „ DSD DSur (Dolby Audio - Surr) „ This mode is suitable for playing sources recorded in DSD. This listening mode expands 2 ch or 5.1 ch input signals to 5.1 ch, 7.1 ch or • This unit supports the DSD signal input from the HDMI input terminal. 5.1.2 ch.
  • Page 156 Appendix „ DTS Express to create spacious 3D sound including audio from up above without connecting height speakers. This mode faithfully reproduces the sound design recorded in the DTS Express This mode can be selected in any speaker layout such as front speakers-only audio format.
  • Page 157 Appendix „ Game-Action „ T-D (Theater-Dimensional) This mode is suitable for games with a lot of action. In this mode, you can enjoy a virtual playback of multichannel surround sound even with only two or three speakers. This works by controlling how sounds „...
  • Page 158 Appendix Speaker Combinations • Up to two powered subwoofers can be connected in either combination. SURROUND ZONE 2 Speaker Channels FRONT CENTER SURROUND HEIGHT Bi-AMP BACK (ZONE SPEAKER) 2.1 ch (*1) (*1) 3.1 ch (*1) (*1) 4.1 ch (*1) (*1) 5.1 ch (*1) (*1)
  • Page 159 Appendix General Specifications Amplifier Section North American models Australian and Asian models With 8 ohm loads, both channels driven, from 20- 20,000 Hz; rated 80 watts per channel minimum 7 ch × 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD Rated Output Power RMS power, with no more than 0.08% total harmonic (IEC)
  • Page 160 Appendix Tuner Section North American models Australian and Asian models FM Tuning Frequency Range 87.5 MHz - 107.9 MHz 87.5 MHz - 108.0 MHz, RDS 50 dB quieting sensitivity (FM MONO) 1.0 μV, 11.2 dBf (IHF, 1 kHz, 100% MOD) AM Tuning Frequency Range 530 kHz - 1710 kHz 522/530 kHz - 1611/1710 kHz...
  • Page 161 Appendix 2 ch linear PCM: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 16/20/24 bit Multi-channel linear PCM: Audio Format Maximum 7.1 channels, 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 16/20/24 bit Bitstream: Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-ES, DTS 96/24, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Express, DTS:X, DSD(2.8 MHz), PCM...
  • Page 162 Operation has been confirmed on the following devices: (As of April 2020) Toshiba brand televisions; Sharp brand televisions; Onkyo and Integra brand RIHD-compatible players; Toshiba brand players and recorders; Sharp brand players and recorders (when used with a Sharp brand television)
  • Page 163 Appendix Network Section North American models Australian and Asian models Ethernet LAN 1 (10BASE-T/100BASE-TX) Wireless LAN IEEE 802.11 a/b/g/n/ac standard (Wi-Fi standard) 5 GHz/2.4 GHz band ® MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR WMA (.wma) •...
  • Page 164 Appendix USB Section North American models Australian and Asian models 1 (Rear : Ver.2.0, 5V/1 A) MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR WMA (.wma) • 44.1 kHz, 48 kHz/Between 5 kbps and 320 kbps, and VBR •...
  • Page 165 Appendix General North American models Australian and Asian models Power Supply AC 120 V, 60 Hz AC 220 - 240 V, 50/60 Hz Power Consumption 460 W 450 W Full Standby mode 0.10 W 0.15 W Network Standby (wired) 1.6 W 1.7 W Network Standby (wireless) 1.7 W...
  • Page 166 Appendix Audio Outputs North American models Australian and Asian models PRE/LINE OUT (ZONE 2)(*) × 1 Analog PRE OUT (SUBWOOFER) × 2 *Can be changed to LINE OUT (ZONE B) and PRE OUT (FRONT). 9 (FRONT L/R, CENTER, SURROUND L/R, HEIGHT L/R or SURROUND BACK L/R, ZONE 2 L/R) Speaker Outputs •...
  • Page 167 SN 29403940_EN © Copyright 2020 Onkyo & Pioneer Corporation Japan. All rights reserved. https://www.onkyo.com/privacy/ F2006-0...
