Quatech PCD-B/UPCI-E Specifications

PCMCIA Card Drives
PCD-B/XXX Series
PCD-X/XXX Series
Quatech PCMCIA Card Drives allow
desktop PCs to access
technology used in laptop, notebook
and handheld computers.
particularly useful for
devices such as Quatech multiport
serial cards, as a single product can
be shared between desktop and
mobile systems.
Available for PCI and Universal PCI
low profile interfaces,
PCMCIA Card Drives
accommodate a wide variety of
devices. The single slot rear units
support both 16-bit PCMCIA cards
and 32-bit CardBus cards.
makes them ideal for using with a
wide variety of wireless LAN devices
including network cards, Bluetooth,
GPS, GSM and GPRS.
Introducing Quatech's new PCMCIA
Card Drive, the PCD-X/XC34.
provides a PCMCIA slot via an
Expresscard interface. Now you can
access 3G Wireless Internet Modem
cards via Expresscard.
X/XC34 also works
CompactFlash, Memory Stick, Smart
Media, Wide Area Network cellular,
802.11a/b/g wireless LAN, Ethernet
LAN, ATA, MMC and SD cards using
suitable adapter
separately).
PCD-B/PCI-ST, 1 slot PCMCIA card drive for PCI (rear)
PCD-B/UPCI-E, 1 slot PCMCIA card drive for UPCI Low profile (rear)
PCD-X/XC34, 1 slot PCMCIA card drive for Expresscard
1 PCMCIA slots per unit
Supports Type I, II and III PC Cards
Supports 3.3V and 5V PCMCIA Cards
Supports 16-bit PC Cards and 32-bit CardBus Cards
Available for 3.5" internal drive chassis (optional 5.25" bay adapter available) or rear slot
installation (PCI)
PCI, UniversalPCI or ExpressCard interfaces
the
ATA disk interface support
This is
PCD-B/UPCI-E Specifications
PCMCIA
Bus Interface
OS Support
Connector
Controller
Sockets
Mount Location
Quatech
Supported Card Types
can
Operating Temperatures
Certifications
Warranty
PCD-B/PCI-ST Specifications
This
Bus Interface
OS Support
Connector
Controller
Sockets
Mount Location
It
Supported Card Types
Operating Temperatures
Certifications
Warranty
The PCD-
with
PCD-X/XC34 Specifications
Bus Interface
OS Support
Mount Location
Supported Card Types
(available
Certifications
Warranty
KEY FEATURES
Universal PCI (PCI Specification 2.2)
Windows 95/98/Me/2000/XP/Vista
68 pin PCMCIA compliant static protected connectors with card eject buttons
1410 or 1211 controller chip, Intel 82365 compatible register set, supports sleep &
suspend modes
One PCMCIA slots operating at 3.3V or 5V
Rear low profile PCI slot
Type I and II 16-bit PCMCIA or 32-bit CardBus cards
)
0-50 C
CE, FCC Class B, RoHS, WEEE
1 year
PCI (PCI Specification 2.3)
Windows 95/98/Me/2000/XP/Vista
68 pin PCMCIA compliant static protected connectors with card eject buttons
1410 or 1211 controller chip, Intel 82365 compatible register set, supports sleep &
suspend modes
One PCMCIA slots operating at 3.3V or 5V
Rear PCI slot
Type I and II 16-bit PCMCIA or 32-bit CardBus cards
0-50 ) C
CE, FCC Class B, RoHS, WEEE
1 year
PCMCIA to ExpressCard
Windows XP/Vista or Mac OS X 10.4.8 and later
Full-sized External Drive Unit
Type I and II 16-bit PCMCIA or 32-bit CardBus cards
CE, FCC Class B, RoHS, WEEE
1 year
5675 Hudson Industrial Parkway Hudson, OH 44236
1.800.553.1170 +1330.655.9000 www.quatech.com
