- Page 1 3-PT REVERSIBLE DIRT SCOOP BE-RS30G OPERATIONS & PARTS MANUAL FOR MODELS: • BE-RS30G PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 2 TABLE OF CONTENTS Intended Use & Important Safety Information Specific Operation Warnings & Assembly Instructions Before Each Use Maintenance & Replacement Parts Exploded view & Parts Breakdown Warranty...
- Page 3 Also use non-skid safety shoes, hardhat, gloves, dust collection systems, and hearing protection when appropriate. This applies to all persons in the work area. • Do not overreach. Keep proper footing and balance at all times. BE-RS30G USER MANUAL...
- Page 4 1, size 3-point hitch. The scoop allows you to attach your tractor to the front or rear of the scoop, enabling it to work forward as a slip scraper or in reverse as a shovel. Scoop, dig, carry, dump, and spread. The parts and accessories are pictured: BE-RS30G USER MANUAL...
- Page 5 2. Install part 62 (bolt), part 69 (nut nylon insert), and part 17 (hinge tube) on the U type connection board. 3. Install part 3 (lift pin cat 1) in the bottom connection point of the three point suspension. BE-RS30G USER MANUAL...
- Page 6 5. Install part 156 (bolt), part 69 (nut), and part 2 (scoop latch/bar) together. 6. The final assembly will look this this: Final Comments With a little practice working the attachment combinations and adjustments, you will be able to efficiently operate the unit in a short amount of time. BE-RS30G USER MANUAL...
- Page 7 • Remove the bracing and rotate the scoop down so that it is laying on the ground or use auxiliary supports such as planted posts, to prevent the possibility of the unit tipping over. BE-RS30G USER MANUAL...
- Page 8 • When ordering parts, the following information will be required: item description, item model number, item serial number/item lot date code, and the replacement part reference. • The distributor reserves the rights to make design changes and or improvements to product lines and manuals without notice. BE-RS30G USER MANUAL...
- Page 9 3/4” x 3” Bolt 3/4” Nut with Nylon Insert Fine 3/4” Flat Washer Lift Pin Cat 1 Hinge Tube Frame Scoop 24” 3/4” x 3-1/2” Bolt 1/2” x 3-1/2” Bolt 3/4” x 3” Bolt Scoop Latch Bar BE-RS30G USER MANUAL...
- Page 10 Northern Tool and Equipment Company, Inc. (“We’’ or ‘”Us’’) warrants to the original purchaser only (“You’’ or “Your”) that the NorTrac product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in accordance with product instructions.
- Page 11 BE-RS30G USER MANUAL...
- Page 12 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-RS30G USER MANUAL...
