Nortrac 3-Pt. Landscape Rake Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

3-Pt. Landscape Rake
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item # 51454, #51455, #51456
SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3-Pt. Landscape Rake and is the answer not in the manual?

Questions and answers

Related Manuals for Nortrac 3-Pt. Landscape Rake

Summary of Contents for Nortrac 3-Pt. Landscape Rake

  • Page 1 3-Pt. Landscape Rake Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 51454, #51455, #51456 SAVE THESE INSTRUCTIONS...
  • Page 2 This 3-Pt. Landscape Rake is designed for certain applications only. Northern Tool & Equipment is not responsible for issues arising from modification or improper use of this product such as an application for which it was not designed.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Assembly Instructions .......................... 6 Before Each Use ............................ 8 Operating Instructions .......................... 9 Maintenance ............................10 Parts Diagram ............................11 Parts List ..............................

  • Page 4: Intended Use

    Intended Use The NorTrac 3-Pt. Landscape Rake is ideal for grading, leveling, spreading, and removing stones from lawns. It’s designed with a 3-point hitch which fits category 1 pins. Technical Specifications Property #51454 #51455 #51456 Ship Weight 207. lbs. 235.0 lbs.

  • Page 5: Specific Operation Warnings

     Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your work area. Some of these hazards may be hidden from your view and may cause personal injury and/or property damage if contacted. PERSONAL SAFETY ...

  • Page 6: Assembly Instructions

     Read and understand the Owner’s Manual before operating, servicing, or repairing the equipment.  Stop the engine, remove the key, and set the brake before dismounting the tractor.  Operate from the tractor seat only.  DO NOT operate without guards in place and in good condition. ...
  • Page 7 1. Take all the components out from the packing crate. 2. Install the tooth support (part No.15) and tines (part No.16) onto the mounting frame, and then tighten them with M10 x 30 bolt and M10 nut. Assemble the main frame weldment (part No.1) with the mounting frame using a slotted nut and draw pin.

  • Page 8: Before Each Use

    Before Each Use Tractor Requirements and Preparation The Landscape Rake fits category 1 hitches. Check the tractor’s 3-point hydraulic lift system. It should operate up and down smoothly and have enough power to lift the rake. Refer to your tractor’s Owner’s Manual or dealer for any adjustments necessary to put the 3-point hydraulic lift system in good working order.

  • Page 9: Operating Instructions

     Check for ditches, stumps, holes, or other obstacles that could cause the tractor to roll.  Be sure tractor tires and rims are in good condition. Inflate tires to proper air pressure.  All persons should be at least twenty-five feet (25') away during operation. Clear the area of helpers, bystanders, and especially children.

  • Page 10: Maintenance

     Do not lift heavy parts or assemblies. Use a crane jack, block and tackle, forklift, or other mechanical lifting device.  Never put hands or any other body part under blocked-up assemblies, if at all possible.  After completing assembly, thoroughly inspect the machine to be sure that all nuts, bolts, hydraulics, fittings, or any other fastened assemblies have been thoroughly tightened.

  • Page 11: Parts Diagram

    5. Store the rake in a clean, dry place. Inside storage will reduce the maintenance and make for a longer rake life. 6. Lay the unit on the ground or ensure that the main frame is stable by using auxiliary supports, such as planted posts, to prevent the possibility of the unit tipping over.

  • Page 12: Replacement Parts

    Reference Number Description Quantity Lock Washer 22 Nut M22x1.5 Steel Collar Slotted Nut M30 Bolt M16x100 Hair Pin 4’: 24, Nut M10 5’:30, 6’: 36 4’: 4, Tooth Support 5’:5, 6’:6 4’: 24, Tooth 5’:30, 6’: 36 Tine bar Weldment 4’: 24, Bolt M10x30 5’:30,...

  • Page 13: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Nortrac product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 14 of 14...
