Nortrac 51448 Owner's Manual

3-pt. box scraper

Advertisement

Quick Links

3-Pt. Box Scraper
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Items #51448, #51449, #51450
SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 51448 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nortrac 51448

  • Page 1 3-Pt. Box Scraper Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Items #51448, #51449, #51450 SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing a NorTrac™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Assembly Instructions .......................... 6 Operating Instructions .......................... 8 Maintenance ............................9 Parts Diagram ............................10 Parts List .............................. 11 Replacement Parts ..........................
  • Page 4: Intended Use

    Intended Use The NorTrac 3-Pt. Box Scraper features a rugged, welded, steel frame and reversible 1/2" x 6" high- carbon, steel blade. The scraper is a category 1, 3-point hitch. Technical Specifications 6’ Location Description 4’ 5’ #51448 #51449 #51450 Box Overall Height 34-5/8"...
  • Page 5  Keep children and bystanders away from the work area while operating the box scraper. Do not allow children to handle the box scraper.  Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your work area.
  • Page 6: Specific Operation Warnings

    Specific Operation Warnings To prevent serious injury or death:  Read and understand this Owner’s Manual before operating, servicing, or repairing equipment.  Stop the engine, remove the key, and set brake before dismounting the tractor.  Operate from the tractor seat only. ...
  • Page 7 working on the assembly to trip.  Do not lift heavy parts or assemblies. Use a crane, jack, tackle, fork trucks, or other lifting mechanical devices.  Preview the assembly instructions before proceeding further.  If the assembly instructions call for parts or assemblies to be blocked up, use only blocking material that is in good condition and is capable of handling the weight of the assembly to be blocked.
  • Page 8: Operating Instructions

    2. Assemble the left & right 3 Point Lift Bracket (#10) and the left & right Brace (#8) first, using 2 sets of M16 x110 Bolts (#2), M16 Lock Washers (#7), and M16 Nuts (#6). Connect them to the Scraper Box Frame (#1) with 2 sets of M16 x 60 Bolts (#9), M16 Lock Washers (#7) M16 Nuts (#6), and 2 sets of Lift Pins (#11), M22 Lock Washers (#5), and M22 Nuts (#4).
  • Page 9: Maintenance

    ⚠CAUTION To prevent property damage, watch for and avoid catching the rake on stumps, large rocks, large dirt piles, and other immovable objects. ⚠WARNING DO NOT TAKE A DITCH AT 90° (straight on)! Always approach from an angle or damage may occur. ⚠CAUTION Before dismounting power unit or performing any adjustments to the box scraper, make sure to disengage power to equipment, lower 3-point hitch and all raised components to the ground, operate...
  • Page 10: Parts Diagram

    3. Never use your hands to locate a hydraulic leak on attachments. Use a small piece of cardboard or wood. 4. Never replace hex bolts with less than grade five bolts unless otherwise specified. Refer to bolt torque chart for head identification marking. Storage Safety 1.
  • Page 11: Parts List

    Ripper Adjustment 2-1/8’’ 2-1/8’’ 2-1/8’’ 48’’ 60’’ 72’’ Box Overall Width Box Over Depth 29-1/4’’ 29-1/4’’ 29-1/4’’ Parts List Item Description Quantity Scraper Box Frame Bolt M16x110 Spacer 4/5/6 Nut M22 Lock Washer M22 Nut M16 Vary Lock Washer M16 Vary Brace Bolt M16x60...
  • Page 12: Replacement Parts

    Hair Pin *Optional Parts Replacement Parts  For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.  Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ...
  • Page 13: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the NorTrac product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 14 of 14...

This manual is also suitable for:

5144951450
