4k 60 hz usb type-c to hdmi over cat6 extender
Hide thumbs Also See for B1271A1CH:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
4K 60 Hz USB Type-C™ to
HDMI over Cat6 Extender
Model: B127-1A1-CH
USB Type-C and USB-C are trademarks of USB Implementers Forum
Este manual esta disponible en español en la página de Tripp Lite:
tripplite.com/support
Ce manuel est disponible en français sur le site Web de Tripp Lite :
tripplite.com/support
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по адресу:
tripplite.com/support
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
1

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite B1271A1CH

Summary of Contents for Tripp Lite B1271A1CH

  • Page 1 USB Type-C and USB-C are trademarks of USB Implementers Forum Este manual esta disponible en español en la página de Tripp Lite: tripplite.com/support Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com/support Русскоязычная версия настоящего руководства...

  • Page 2: Package Contents

    Package Contents • Local Transmitter Unit • Receiver Unit • External Power Supply (Input: 100-240V, Output: 24V 1A) • Plug Adapters: NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS 1363 (UK) and AS/NZS 3112 (Australia) • Mounting Hardware • Owner’s Manual Optional Accessories •...

  • Page 3: Product Features

    Product Features • Extends a 4K (3840 x 2160 @ 60 Hz) 4:4:4 signal up to 125 ft. (38 m) from the source. • USB-C PD 3.0 port provides device charging while supporting an input up to 60W (20V 3A). •...
  • Page 4 Disclaimer Before installation, check the following settings of your source(s) and TV/monitor(s): 1. Set to display at 60 Hz. Double-check factory settings, as the default may be set to a lower frequency (Hz) than advertised. 2. Ensure the input setting of your monitor is set at HDMI 2.0. Some displays may have default setting at HDMI 1.4.

  • Page 5: Mounting Instructions

    Mounting Instructions Mounting hardware is included to allow for a variety of mounting methods. The following images illustrate how the included mounting brackets can be attached for different installations. Wall-Mount 19"-Wide Rack-Mount Pole-Mount...

  • Page 6: Installation

    (AWG) size higher than 24 AWG, will result in a shorter extension distance. Higher gauge cabling, such as 26 AWG, has a more limited transmission capability than lower gauge cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid-wire cabling.
  • Page 7 Installation 3. Optional: Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT or P568-XXX-2A-Series cables), connect the HDMI source to the LOCAL port on the local transmitter unit. 4. Optional: Using your source’s PD power adapter, plug the USB-C connector into the CHARGE IN port on the local transmitter unit.

  • Page 8: Warranty And Product Registration

    1-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
