Temperature Compensated Crystal Oscillator (TCXO)
· Package size (5.0 mm × 3.2 mm × 1.45 mm)
· Ultra high stability TCXO
· Output waveform : CMOS
· Reference weight Typ.72 mg
[ 1 ] Product Number / Product Name / External dimendions
(1-1) Product Number / Ordering Code
X1G0052310015xx
last 2 digits code(xx) define Quantity.
The standard is "00", 1 000 pcs/Reel.
(1-2) Product Name / Model Name
TG5032CGN
[ 2 ] Operating range
Parameter
Supply voltage
Operating temperature range
Output load
[ 3 ] Frequency characteristics
Parameter
Output Frequency
Frequency tolerance *1
Frequency / temperature
characteristics
Frequency / load coefficient
Frequency / voltage coefficient
Frequency aging
Holdover stability,
constant temperature
Holdover stability,
constant temperature
Holdover stability
(Free-run accuracy)
*1 Include initial frequency tolerance and frequency deviation after reflow cycles.
*2 Measured in the elapse of 24 hours after reflow soldering.
*3 This includes initial frequency tolerance, frequency / temperature characteristics, frequency / load coefficient, frequency/voltage
coefficient and frequency aging (+25 °C, 20 years) .
[ 4 ] Electrical characteristics
Parameter
Current consumption
High level output voltage
Low level output voltage
Rise time
Fall time
Symmetry
[ For other general specifications, please refer to the attached Full Data Sheet below ]
20.000000 MHz CAGHNA
Specifications
Symbol
Min.
V
3.135
CC
GND
0
T_use
-40
Load_C
13.5
Specifications
Symbol
Min.
fo
-
f_tol
-1.0
fo-Tc
-0.1
fo-Load
-0.1
fo-V
-0.1
CC
-0.5
f_age
-3.0
-
-0.01
-0.04
-
-
-4.6
Specifications
Symbol
Min.
I
-
CC
Voʜ
90 % Vcc
Voʟ
-
tr
-
tf
-
SYM
45
1/22 Page
Unit
Typ.
Max.
3.3
3.465
V
-
0
V
-
+85
°C
15
16.5
pF
(Vcc = 3.3 V, GND = 0.0 V, Load = 15 pF, T_use = +25 °C)
Unit
Typ.
Max.
20
-
MHz
-
+1.0
x10⁻⁶
-
+0.1
x10⁻⁶
-
+0.1
x10⁻⁶
-
+0.1
x10⁻⁶
-
+0.5
x10⁻⁶
-
+3.0
x10⁻⁶
-
+0.01
x10⁻⁶
-
+0.04
x10⁻⁶
-
+4.6
x10⁻⁶
(Vcc = 3.3 V, GND = 0.0 V, Load = 15 pF, T_use = +25 °C)
Unit
Typ.
Max.
-
5.0
mA
-
-
V
-
10 % Vcc
V
-
8.0
ns
-
8.0
ns
-
55
%
Conditions
-
-
-
-
Conditions
-
T_use = +25 °C ±2 °C
After 2 reflows *2
T_use = -40 °C to +85 °C
(Reference to (fmax+fmin)/2)
Load ±10 %
Vcc ±5 %
T_use = +25 °C first year
T_use = +25 °C 20 years
T_use = +25 °C, 24 hours
(after 10 days of continuous
operation)
T_use = +25 °C, 24 hours
(after 48 hours of continuous
operation)
*3
Conditions
Vcc = 3.3 V
-
-
10 % Vcc to 90 % Vcc level
90 % Vcc to 10 % Vcc level
50 % Vcc Level
No.: TG5032CGN ver1.0
