- Page 1 Bennett Collection Installation Manual Model: 50420 Brushed Nickel 50421 Matte Fresh White Fan weight ±2 lbs: 15.4 lbs (7.0 kg) ©2020 Hunter Fan Co. PG3885 r021720...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component. Hunter Pro Tip: Do not discard the hardware bags or mix parts from different bags. Make note of the symbol printed on each hardware bag.
-
Page 4: Choosing The Right Installation Location
Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Do this first! Hunter Pro Tip: The machine screws are the ones that came with your outlet box. WARNING To avoid possible electrical shock, before... -
Page 5: Hanging The Fan
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. Hunter Pro Tip: Here is how to connect the wires:... -
Page 6: Installing The Motor Housing
1886 Installing the Motor Housing Notch Motor Housing Screw Indentation Raise the motor housing up over the motor and ceiling bracket. Turn the motor housing so the screw holes align With a Phillips head screwdriver, install and the indentation in the housing locks into place with the four motor housing screws found in the notch in the ceiling bracket. - Page 7 1886 Assembling the Light Remove the cardboard plug guard before proceeding! Notch Push the connector and excess wire into the hole at the top of the light fixture. IMPORTANT Connect the plugs from the fan and light fixture. Make sure to line up The connector and excess wiring Raise the light kit to the bottom of the fan.
- Page 8 1886 Preparing the Remote The remote control is NOTICE already paired for use. For your convenience, a remote • Always purchase the correct size and function card is packed in grade of battery most suitable for the intended use. with your remote. •...
-
Page 9: Troubleshooting
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
