  • Page 1 O W N ER' S MA N UAL...
  • Page 3 VÄLKOMMEN! We hope you will enjoy many years of driving pleasure in your Volvo. The The owner's manual is also available as a mobile app (Volvo Manual) and car has been designed for the safety and comfort of you and your pas- on the Volvo Cars support site (support.volvocars.com).

  • Page 4: Table Of Contents

    YOUR VOLVO SAFETY Owner's information Volvo ID Safety Owner's manual in centre display Creating and registering a Volvo ID Safety during pregnancy Navigate in the owner's manual in Drive-E - cleaner driving pleasure Whiplash Protection System the centre display IntelliSafe-driver support...
  • Page 5 DISPLAYS AND VOICE CONTROL Child seat positioning Instruments and controls in left-hand Activating and deactivating centre display 107 drive car Child seat mounting Navigating in the centre display's views Instruments and controls in right- Overview table for location of child seats Managing subviews in centre display hand drive car Table for location of child seats...
  • Page 6 LIGHTING WINDOWS, GLASS AND MIRRORS Selecting driver profile Lighting control Windows, glass and mirrors Renaming a driver profile Adjusting light functions via the cen- Pinch protection for windows and tre display sun blinds Protect driver profile Adapting the headlamp pattern from Reset sequence for pinch protection Linking remote control key to driver the headlamps...
  • Page 7 SEATS AND STEERING WHEEL CLIMATE Manual front seat Climate Activating and deactivating the heated steering wheel* Power* front seat Climate zones Activating and deactivating automatic Climate control - sensors Adjusting the power* front seat start of heated steering wheel* Perceived temperature Storing position for seat, door mirrors Activating auto climate control and head-up display*...
  • Page 8 KEY, LOCKS AND ALARM Lock confirmation Locking and unlocking from inside Start and switch off preconditioning* the car Lock indication setting Preconditioning time setting* Unlocking the tailgate from the Remote control key Adding and editing time setting for inside of the car preconditioning* Locking and unlocking with the Activating and deactivating child...
  • Page 9 DRIVER SUPPORT Driving support systems Managing speed for the cruise control Starting overtaking assistance with adaptive cruise control Speed-dependent steering force Deactivate Cruise Control and set it in standby mode Limitations for overtaking assistance Electronic stability control with adaptive cruise control Reactivating Cruise Control from Sport mode for electronic stability control 282 standby mode...
  • Page 10 Limitations of Pilot Assist Messages for City Safety Limitations of Road Sign Information Symbols and messages for Pilot Assist* Rear Collision Warning Driver Alert Control Limitations of Rear Collision Warning Activate/deactivate Driver Alert Control Radar unit Limitations for radar device BLIS* Select rest stop guidance in the event of a warning from Driver Alert...

  • Page 11: Symbols And Messages For Park

    STARTING AND DRIVING Steering assistance upon risk of Symbols and messages for Park Starting the car head-on collision assist camera Switching off the car Activating/deactivating Steering Park Assist Pilot* Ignition positions assistance in the event of a collision Parking variants with Park Assist Pilot risk with oncoming Selecting ignition mode Parking with Park Assist Pilot...
  • Page 12 Auto braking after a collision Winter driving Towbar-mounted bicycle rack* Gearbox Driving in water Towing Manual gearbox Opening and closing the fuel filler flap Fitting and removing the towing eye Gear positions for automatic gearbox Filling fuel Recovery ® Changing gear with steering wheel Handling of fuel HomeLink paddles*...
  • Page 13 SOUND, MEDIA AND INTERNET ® Sound, media and Internet Connecting a phone to the car via Playing back DivX Bluetooth manually Audio settings Settings for video Disconnecting a Bluetooth-con- Sound experience* ® Media via Bluetooth nected phone Apps ® Connecting a device via Bluetooth Switch between Bluetooth-con- nected phones Downloading apps...
  • Page 14 WHEELS AND TYRES User terms and conditions and data Tyres Emergency puncture repair kit sharing Dimension designation for tyre Using a puncture repair kit Activating and deactivating data sharing Dimension designation for wheel rim Inflating tyres with the compressor Storage space on hard disk from the puncture repair kit Tyres' rotation direction License agreement for audio and media...
  • Page 15 LOADING, STORAGE AND MAINTENANCE AND SERVICE PASSENGER COMPARTMENT Volvo service programme Cleaning the interior Passenger compartment interior Data transfer between car and work- Cleaning the centre display shop via Wi-Fi Tunnel console Cleaning fabric upholstery and headlining 625 Download Center...
  • Page 16 SPECIFICATIONS ALPHABETICAL INDEX Filling washer fluid Type designations Alphabetical Index Dimensions Weights Towing capacity and towball load Engine specifications Engine oil — specifications Adverse driving conditions for engine oil Coolant — specifications Transmission fluid — specifications Brake fluid — specifications Fuel tank - volume ®...
  • Page 17 OWNER'S INFORMATION...
  • Page 18 The owner's manual is available in the car's cen- here are options for visual navi- on fuses and specifications, as tre display, as a mobile app and on the Volvo gation with exterior and interior well as a summary of important Cars support site.
  • Page 19 Owner's manual in centre display (p. 17) • while driving. Owner's Manual in mobile devices (p. 20) • Volvo Cars support site (p. 21) • Owner's manual Reading the owner's manual (p. 21) • Top view with button for owner's manual.
  • Page 20 OWNER'S INFORMATION Navigate in the owner's manual in Related information Contextual owner's manual the centre display Navigate in the owner's manual in the centre • display (p. 18) The digital owner's manual can be accessed Navigating in the centre display's views from the centre display top view in the car.
  • Page 21 OWNER'S INFORMATION Opening the menu in the top menu 2. Tap on a hotspot. Quick Guide Press the symbol to access a > The title of the article about the area is Press in the upper list in the owner's –...
  • Page 22 Google Play. app. Alternatively, you can Reading the owner's manual (p. 21) • search for "Volvo manual" in Related information the App Store or Google Play. Reading the owner's manual (p. 21) • The app contains a video along with exterior and...
  • Page 23 The intention of this owner's information is to mobile phone. explain all of the possible features, functions and Downloadable information options included in a Volvo vehicle. It is not intended as an indication or guarantee that all of Maps these features, functions and options are For cars equipped with Sensus Navigation there included in every vehicle.
  • Page 24 In the event of uncertainty over what is standard Phone New message Black ISO symbols on yellow warning field, white or an option/accessory, contact a Volvo retailer. text/image on black message field. Used to indi- Decals cate the presence of danger which, if the warning...
  • Page 25 OWNER'S INFORMATION White ISO symbols and white text/image on Position lists Risk of property damage black message field. Red circles containing a number are used in overview images where different components NOTE are pointed out. The number recurs in the position list featured in connection with the It is not intended that the decals illustrated in illustration that describes the item.
  • Page 26 ® manual comes from FSC -certified forests or Owner's Manual in mobile devices (p. 20) • other controlled sources. Volvo Cars support site (p. 21) • Related information Drive-E - cleaner driving pleasure (p. 28) •...

  • Page 27: Your Volvo

    YOUR VOLVO...

  • Page 28: Volvo Id

    Creating and registering a Volvo ID Create a Volvo ID with the Volvo On Call Volvo ID is a personal ID that gives access to a It is possible to create a Volvo ID in different 1. Download the latest version of the Volvo On wide range of services via a single username ways.
  • Page 29 3. Follow the instructions that are automatically sent to the email address linked to your Volvo ID. > Your Volvo ID is now registered to the car. Volvo ID services can now be used. Related information Volvo ID (p. 26) •...

  • Page 30: Drive-E - Cleaner Driving Pleasure

    Volvo Car Corporation is constantly working on the development of safer and more efficient Environmental care is one of Volvo Cars’ core val- inside a Volvo is, for example, cleaner than the air Fuel consumption ues and influences all operations. The environ- outside thanks to the climate control system.
  • Page 31 Contributing to a better environment ised Volvo workshop is recommended. An energy-efficient and fuel-efficient car not only The material used in the interior of a Volvo is contributes to a reduced impact on the environ- carefully selected and has been tested in order to...
  • Page 32 YOUR VOLVO Related information Fuel consumption and CO emissions • (p. 656) Economical driving (p. 455) • Start and switch off preconditioning* • (p. 225) The owner's manual and the environment • (p. 24) Air quality (p. 199) • * Option/accessory.

  • Page 33: Intellisafe-Driver Support

    If the Driving support systems (p. 280) • IntelliSafe is the Volvo Cars concept for car driver does not react to the warning and the risk safety. IntelliSafe comprises a number of sys- Active main beam (p.

  • Page 34: Sensus - Online Connectivity And 21 Entertainment

    YOUR VOLVO Sensus - online connectivity and Information when it is needed, where it entertainment is needed The different displays in the car provide informa- Sensus makes it possible to surf the Internet, tion at the right time. The information is shown in...
  • Page 35 YOUR VOLVO Different types of information are shown in different displays depending on how the information should be prioritised. traffic warnings, speed information and naviga- Driver display Head-up display* tion* information. Road Sign Information and incoming phone calls are also shown in the head- up display.
  • Page 36 YOUR VOLVO Many of the main functions of the car are con- trolled from the centre display, a touch screen which reacts to touch. The number of physical buttons and controls in the car is therefore mini- mal. The screen can even be operated while wearing gloves.

  • Page 37: Software Updates

    Similarly, the system never registers who is driving the vehicle or the geo- So that you as a Volvo customer get the best As part of Volvo's safety and quality assurance, graphic location of the accident or near-miss sit-...

  • Page 38: Terms & Conditions For Services

    Customer Privacy Policy Volvo will not contribute to the above-described information being disclosed to third parties with- Volvo offers services so that you can drive your Volvo respects and safeguards the personal out the vehicle owner's consent. To comply with Volvo as safely and as comfortably as possible.

  • Page 39: Important Information On Accessories And Auxiliary Equipment

    • The equipment described in the owner's manual your Volvo. Always seek the advice of a Connection of equipment to the car's diag- • is not available in all cars - they have different trained and qualified Volvo service technician nostic socket (p.

  • Page 40: Connection Of Equipment To The Car's Diagnostic Socket

    NOTE car's diagnostic socket costs arising as a result of the installation of Volvo Cars accepts no liability for the conse- non-original accessories. Incorrect connection and installation of software quences if unauthorised equipment is con-...

  • Page 41: Showing The Car's Identification Number

    1. Press Settings in the top view in the centre system you must only set and change the Your new Volvo is, or can be, equipped with con- display. itinerary when the car is parked. tent-rich entertainment and communications sys- Never program the audio system while •...

  • Page 43: Safety

    SAFETY...

  • Page 44: Safety

    The car is equipped with a number of sensors does not have full functionality. Volvo recom- that react in the event of an accident and activate mends that an authorised Volvo workshop different safety systems, such as different types should be contacted as soon as possible.

  • Page 45: Whiplash Protection System

    Never modify or repair the seat or WHIPS ing wheel). The aim should be to position the the risk of whiplash injuries. The system consists yourself. Volvo recommends that an author- seat with as large a distance as possible between of energy absorbing backrests and seat cushion, ised Volvo workshop should be contacted.

  • Page 46: Pedestrian Protection System

    The rear section of the bonnet is raised. • If a backrest in the rear seat is lowered or a An automatic alarm is sent via Volvo On Call*. • rear-facing child seat is used in the rear seat, the corresponding front seat must be moved The sensors are active at a speed of approx.
  • Page 47 WARNING in the event of a collision. Volvo recommends contacting an authorised Volvo workshop in the event of any damage to the front of the car in order to ensure that the system is intact. Symbols in the driver display...

  • Page 48: Putting On And Taking Off Seatbelts

    Make sure that all passengers have fastened Never modify or repair the seatbelts yourself. their seatbelts before starting to drive. Volvo recommends that an authorised Volvo workshop should be contacted. Putting on seatbelts If the seatbelt has been subjected to a major 1.
  • Page 49 SAFETY Seatbelt tensioner WARNING The car is fitted with standard seatbelt tension- Each seatbelt is designed for only one person. ers and electric* seatbelt tensioners that can tension the seatbelts in critical situations and WARNING collisions. Remember not to clip or hook the seatbelt to Standard seatbelt tensioner hooks or other interior fittings, as this pre- All the seatbelts are equipped with a standard...

  • Page 50: Resetting The Electric Seatbelt Tensioner

    WARNING > The seatbelt and electric seatbelt ten- sioner are reset. Never modify or repair the seatbelts yourself. Volvo recommends that an authorised Volvo workshop should be contacted. WARNING If the seatbelt has been subjected to a major Never modify or repair the seatbelts yourself.

  • Page 51: Door And Seatbelt Reminder

    SAFETY Door and seatbelt reminder Seatbelt reminder Rear seat The seatbelt reminder in the rear seat has two The system reminds unbelted occupants to wear subfunctions: a seatbelt, and also warns about an open door, bonnet or lid. Provides information on which seatbelts are •...
  • Page 52 The car is equipped with airbags and inflatable is recommended: Putting on and taking off seatbelts (p. 46) curtains for driver and passengers. • Recovering the car. Volvo recommends that it • NOTE is transported to an authorised Volvo work- shop. Do not drive with deployed airbags.
  • Page 53 WARNING Volvo recommends that an authorised Volvo workshop should be contacted for repair. Defective work in the airbag system could cause malfunction and result in serious per- sonal injury.
  • Page 54 WARNING Volvo recommends that an authorised Volvo workshop should be contacted for repair. Label on the passenger side's sun visor. Defective work in the airbag system could...

  • Page 55: Activating And Deactivating Passen

    SAFETY Activating and deactivating WARNING WARNING passenger airbag* Never allow anybody to stand or sit in front of If the car is not equipped with a switch to acti- The passenger airbag can be deactivated if the the front passenger seat. vate/deactivate the passenger airbag, the air- car is equipped with a switch, Passenger Airbag bag will always be activated.
  • Page 56 SAFETY Activating passenger airbag 2. Confirm the message by pressing the right- Deactivating passenger airbag hand steering wheel keypad's O button. Pull the switch outward and turn from OFF Pull the switch outward and turn from ON (B) to ON (A). (A) to OFF (B).
  • Page 57 SAFETY Side airbags 2. Confirm the message by pressing the right- Related information hand steering wheel keypad's O button. Seatbelt tensioner (p. 47) • The side airbags on the driver's and passenger Child seats (p. 59) seats act to protect the chest and hips in the •...
  • Page 58 Volvo recommends the use only of car seat WARNING covers approved by Volvo. Other seat covers may impede the operation of the side airbags.

  • Page 59: Starting And Moving The Car After

    Volvo recommends that engaging an author- brake system. ous traffic situation for example. ised Volvo workshop to check and restore the If the car has been in a collision, the message Starting the car after safety mode car to normal status after...
  • Page 60 • tus. Recovery (p. 482) • Volvo has child safety equipment (child seats and attachment devices) which is designed for fitting IMPORTANT in this particular car. Using Volvo's child safety If the message Safety mode See Owner's...
  • Page 61 SAFETY Child seats i-Size/ISOFIX mounting points for child seats • NOTE (p. 61) Suitable child seats should always be used When using child safety equipment, it is Child seat positioning (p. 62) when children are travelling in the car. • important to read the installation instructions Activating and deactivating passenger air- •...

  • Page 62: Upper Mounting Points For Child Seats

    SAFETY Upper mounting points for child Lower mounting points for child WARNING seats seats The child seat's upper straps must be routed The car is equipped with upper mounting points The car is equipped with lower mounting points through the hole in the head restraint leg for child seats on the rear seat's outer seats.

  • Page 63: I-Size/Isofix Mounting Points For

    SAFETY i-Size/ISOFIX mounting points for The mounting points in the front seat are only Lift the covers in order to access the mounting child seats mounted if the vehicle is equipped with a switch points. to activate/deactivate the passenger airbag*. The car is equipped with i-Size/ISOFIX mount- Related information...
  • Page 64 SAFETY Child seat positioning Label for passenger airbag NOTE It is important to position the child seat in the Regulations regarding the placement of chil- right place in the car and this depends, amongst dren in cars vary from country to country. other things, on the type of child seat and Check what does apply.
  • Page 65 • being tensioned at the mounting point. If this into the seat's horizontal adjustment bar or in by Volvo, are universally approved or are is not possible, follow the recommendations springs, rails or beams under the seat. Sharp semi-universal, and where the car is included from the child seat manufacturer.
  • Page 66 SAFETY Overview table for location of child Table for location of i-Size child seats • i-Size Universally Other seats (p. 67) child approved child child Table for location of ISOFIX child seats • The table gives an overview of the types of child seats seats secured seat cat-...
  • Page 67 SAFETY Table for location of child seats NOTE using the car's seatbelts Always read the owner's manual section on The table gives a recommendation for which installing a child seat before installing one in child seats suit which locations, and for what the car.
  • Page 68 Volvo recommends: Volvo rear-facing seat (type approval E5 04212). Volvo recommends rear-facing child seat for children in this mass group. Volvo recommends: Booster cushion with and without back (type approval E5 04216); Volvo booster seat (type approval E1 04301312). Seatbelts (p. 45) •...
  • Page 69 Suitable for i-Size "universal" child seat, front-facing and rear-facing. X: Not suitable for universally approved child seats. Volvo recommends rear-facing child seats for this group. Volvo recommends: BeSafe iZi Kid X2 i-Size (type approval E4-129R-000002). Related information Child seat positioning (p. 62) •...
  • Page 70 SAFETY Table for location of ISOFIX child The child seat must be approved in accordance NOTE seats with UN Reg R44 and the car model must be Always read the owner's manual section on included in the manufacturer's vehicle list. The table gives a recommendation for which installing a child seat before installing one in ISOFIX child seats suit which locations, and for...
  • Page 71 Works for the installation of ISOFIX child seats that are semi-universally approved (IL) if the car is equipped with the ISOFIX console accessory (the accessory range varies depending on market). There are no upper mounting points for child seats here. Volvo recommends: Volvo infant seat secured using the ISOFIX fixture system (type approval E1 04301146). Applicable if the car is not fitted with an ISOFIX bracket.
  • Page 72 SAFETY Overview table for location of child seats • (p. 64) Table for location of child seats using the • car's seatbelts (p. 65) Table for location of i-Size child seats (p. 67) • i-Size/ISOFIX mounting points for child seats •...
  • Page 73 DISPLAYS AND VOICE CONTROL...
  • Page 74 DISPLAYS AND VOICE CONTROL Instruments and controls in left- Steering wheel adjustment hand drive car Horn The overviews show where the displays and controls near the driver are located. Left-hand steering wheel keypad Steering wheel and instrument panel Bonnet opening Display lighting, tailgate unlocking/opening*/ closing*, halogen headlamp levelling Roof console...
  • Page 75 DISPLAYS AND VOICE CONTROL Instruments and controls in right- Display lighting, tailgate unlocking/opening*/ hand drive car closing*, halogen headlamp levelling The overviews show where the displays and Bonnet opening controls near the driver are located. Horn Steering wheel and instrument panel Steering wheel adjustment Left-hand steering wheel keypad Roof console...
  • Page 76 DISPLAYS AND VOICE CONTROL Driver's door Centre display Memories for power front seat*, door mirror Hazard warning flashers, defrosting, media and head-up display* settings Gear selector Central locking Start knob Power windows, door mirrors, electric child safety lock* Drive mode control* Adjusting front seat Parking brake Related information...
  • Page 77 You ment, settings and which functions are active at should visit a workshop immediately. Volvo that time. recommends an authorised Volvo workshop. The driver display is activated as soon as a door is opened, i.e.
  • Page 78 DISPLAYS AND VOICE CONTROL On the left In the middle On the right – Instantaneous fuel consumption Navigation map* – Phone App menu (activated via steering wheel keypad) – Voice recognition – Depends on drive mode selected. Accumulated mileage. Driver display, 8-inch Location in the driver display: On the left In the middle...
  • Page 79 DISPLAYS AND VOICE CONTROL On the left In the middle On the right Door and seatbelt information Clock Tachometer/ECO gauge Distance to empty tank Status of the Start/Stopp function App menu (activated via steering wheel keypad) Outside temperature gauge – Instantaneous fuel consumption Indicator and warning symbols –...
  • Page 80 DISPLAYS AND VOICE CONTROL Related information Driver display settings (p. 79) • Warning symbols in the driver display • (p. 88) Indicator symbols in the driver display • (p. 86) Trip computer (p. 80) • Messages in the driver display (p. 97) •...
  • Page 81 DISPLAYS AND VOICE CONTROL Driver display settings Settings via the centre display Selecting language 1. Tap on Settings in the centre display's top Settings for the driver display's display options Selecting information type view. can be made via the driver display's application 1.
  • Page 82 DISPLAYS AND VOICE CONTROL Fuel gauge Trip computer The fuel gauge in the driver display shows the The car's trip computer records vales such as fuel level in the tank. e.g. distance, fuel consumption and average speed whilst driving. In order to facilitate fuel-efficient driving, informa- tion is recorded about both instantaneous and average fuel consumption.
  • Page 83 DISPLAYS AND VOICE CONTROL Distance to empty tank Distance to empty tank • The trip computer calculates the remaining mile- Tourist - alternative speedometer • age with the fuel available in the tank. Units for distance, speed, etc. can be changed via The calculation is based on the average fuel con- system settings in the centre display.
  • Page 84 DISPLAYS AND VOICE CONTROL Show trip data in the driver display Show trip statistics in the centre display 1. Open the app menu in the driver display by • (p. 83) pressing (1). The trip computer's recorded and calculated val- Driver display (p.
  • Page 85 DISPLAYS AND VOICE CONTROL Resetting the trip meter Show trip statistics in the centre Related information display Trip computer (p. 80) • Reset the trip meter using the left-hand stalk Resetting the trip meter (p. 83) switch. Trip statistics from the trip computer are dis- •...
  • Page 86 DISPLAYS AND VOICE CONTROL Settings for trip statistics Resetting the trip meter (p. 83) • Reset or adjust settings for trip statistics. 1. Open the Driver performance app in app view in order to show the trip statistics. 2. Press Preferences Trip statistics from the trip computer change graph scale.
  • Page 87 DISPLAYS AND VOICE CONTROL Time and date Outside temperature gauge Automatic time for cars with GPS When the car is equipped with a navigation sys- The clock is shown in both the driver display and The outside temperature is shown in the driver Auto Time tem, can be selected.
  • Page 88 The car's may be due to a fault in the car's regular brake system continues to emissions system. Drive to a work- work, but without the ABS function. shop for checking. Volvo recom- mends that an authorised Volvo workshop is contacted.
  • Page 89 DISPLAYS AND VOICE CONTROL Symbol Specification Symbol Specification Symbol Specification Left and right-hand direction Main beam On Rain sensor on indicator The symbol illuminates when main This symbol illuminates when the The symbol flashes when the direc- beam is on and with main beam rain sensor is on.
  • Page 90 Grey symbol: Lane assistance is on Symbol Specification safety systems. Read the message but road lines are not detected. in the driver display. Volvo recom- Warning Amber symbol: Lane assistance mends that an authorised Volvo warns/intervenes. The red warning symbol illuminates workshop is contacted.
  • Page 91 The following text is CONNECTION WITH THE SOFTWARE OR THE immediately and check the engine Volvo's agreement with the manufacturer or USE OR OTHER DEALINGS IN THE oil level, top up if necessary. If the developer.
  • Page 92 DISPLAYS AND VOICE CONTROL AND FITNESS FOR A PARTICULAR PURPOSE endorse or promote products derive from this BSD 4-clause "Original" or "Old" License ARE DISCLAIMED. IN NO EVENT SHALL THE software without specific prior written Copyright (c) 1982, 1986, 1990, 1991, 1993 REGENTS OR CONTRIBUTORS BE LIABLE permission.
  • Page 93 DISPLAYS AND VOICE CONTROL OR TORT (INCLUDING NEGLIGENCE OR distribution) o You can use this software for BSD 2-clause “Simplified” license Copyright (c) <YEAR>, <OWNER> All rights OTHERWISE) ARISING IN ANY WAY OUT OF whatever you want, in parts or full form, THE USE OF THIS SOFTWARE, EVEN IF without having to pay us.
  • Page 94 DISPLAYS AND VOICE CONTROL must contact us to verify this. The FreeType documentation. The copyright notices of the Discusses bugs, as well as engine internals, project is copyright (C) 1996-1999 by David unaltered, original files must be preserved in design issues, specific licenses, porting, etc. Turner, Robert Wilhelm, and Werner all copies of source files.
  • Page 95 DISPLAYS AND VOICE CONTROL libpng versions 0.97, January 1998, through For the purposes of this copyright and license, Libpng License 1.0.6, March 20, 2000, are Copyright (c) 1998, "Contributing Authors" is defined as the following This copy of the libpng notices is provided for 1999 Glenn Randers-Pehrson, and are set of individuals: your convenience.
  • Page 96 DISPLAYS AND VOICE CONTROL 1. The origin of this source code must not be Permission is hereby granted, free of charge, to This software is provided 'as-is', without any misrepresented. any person obtaining a copy of this software and express or implied warranty. In no event will the associated documentation files (the "Software"), authors be held liable for any damages arising 2.
  • Page 97 DISPLAYS AND VOICE CONTROL Application menu in driver display Except as contained in this notice, the name of SGI Free Software B License Version 2.0. Silicon Graphics, Inc. shall not be used in SGI FREE SOFTWARE LICENSE B (Version 2.0, Application menu (app menu) in the driver dis- advertising or otherwise to promote the sale, use Sept.
  • Page 98 DISPLAYS AND VOICE CONTROL Handling the application menu in Opening/closing the app menu Functions the driver display Press on open/close (1). – Trip com- Selection of trip meter, selec- The application menu (the app menu) in the (It is not possible to open the app menu puter tion of what to show in the driver display is operated with the steering...
  • Page 99 DISPLAYS AND VOICE CONTROL Messages in the driver display Service messages Shown below is a selection of important service The driver display can show messages to inform messages and their meanings. or assist the driver in the event of different events.
  • Page 100 Left/right Part of message, shown together with information on where the problem has arisen. Confirm An authorised Volvo workshop is recommended. Message in the driver display and the steering wheel's Some messages in the driver display contain one Related information right-hand keypad.
  • Page 101 DISPLAYS AND VOICE CONTROL Handling a message saved from the Managing a new message Reading a saved message driver display For messages with buttons: To read a saved message immediately: Whether saved from the driver display or the 1. Navigate between the different buttons that Press the button to the right of the –...
  • Page 102 > The owner's manual opens in the centre display and shows information linked to the message. Saved messages in the app are deleted automat- ically each time the engine is started. Market dependent. Volvo ID and selected workshop also need to be registered.
  • Page 103 DISPLAYS AND VOICE CONTROL Overview of centre display Many of the car's functions are controlled from the centre display. Presented here is the centre display and its options.
  • Page 104 DISPLAYS AND VOICE CONTROL Three of the centre display's basic views. Swipe right or left to access the function or app view respectively Function view - car functions that are acti- functions are also so-called trigger functions, ting options. Examples of these include vated or deactivated with a press.
  • Page 105 DISPLAYS AND VOICE CONTROL are also made from the function view, but Extra subview - recently used apps or car Changing the appearance in the centre dis- • adjustments are made using the steering functions that do not belong in any of the play (p.
  • Page 106 DISPLAYS AND VOICE CONTROL Managing the centre display ing apps can be performed by touching the IMPORTANT screen in different ways. Many of the car's functions are controlled and Do not use sharp objects on the screen as regulated from the centre display. The centre An infrared light curtain just above the surface of they may scratch it.
  • Page 107 DISPLAYS AND VOICE CONTROL Procedure Execution Result Drag Changes between different views, scrolls a list, text or view. Hold depressed and drag in order to move apps or map points on the map. Drag horizontally or vertically across the screen. Swipe/drag quickly Changes between different views, scrolls a list, text or view.
  • Page 108 DISPLAYS AND VOICE CONTROL Returning to home view from another drag the control to the desired temperature, • view − tap on in order to raise or lower the • 1. Briefly press the home button below the cen- temperature gradually, or tre display.
  • Page 109 DISPLAYS AND VOICE CONTROL Activating and deactivating centre Navigating in the centre display's 1. Give a long press on the physical home but- display views ton below the screen. > The screen goes dark except for the cli- The centre display can be dimmed and reactiva- There are five different basic views in the centre mate row, which continues to be shown.
  • Page 110 DISPLAYS AND VOICE CONTROL pressing on the tab or by dragging/swiping from Climate view NOTE the top downwards across the screen. The climate row is always visible at the bottom of In home view standard mode - briefly press the screen. The most common climate settings In the top view, access is always available to: the home button.
  • Page 111 DISPLAYS AND VOICE CONTROL Application view app view, such as the number of unread text Function view messages for Messages Tap on an app to open it. It then opens in the Media subview to which it belongs, such as You can scroll down in the app view, depending on the number of apps.
  • Page 112 DISPLAYS AND VOICE CONTROL Depending on the amount of functions, it is also possible here to scroll downward in the view. Do this by swiping/dragging from the bottom and up. Unlike in app view, where an app is opened with a press, a function is activated or deactivated by pressing the relevant function button.
  • Page 113 DISPLAYS AND VOICE CONTROL Managing subviews in centre display Home view consists of four subviews: Navigation Media Phone and an extra sub- view. These views can be expanded.
  • Page 114 DISPLAYS AND VOICE CONTROL Expanding a subview from default mode Standard mode and expanded mode of a subview in the centre display.
  • Page 115 DISPLAYS AND VOICE CONTROL Expanding a subview: When a new subview is opened in full-screen There is always the option to go back to home mode, no information from the other subviews is view by pressing the home button. To go back to For tiles Navigation Media...
  • Page 116 DISPLAYS AND VOICE CONTROL Function view in centre display Different types of buttons home view by swiping from left to right across There are three different types of buttons for car the screen All the buttons for car functions are located in functions;...
  • Page 117 DISPLAYS AND VOICE CONTROL The buttons' different modes The function is deactivated when the LED indica- tor is extinguished. When the LED indicator illuminates in green on a function or parking button, the function is acti- vated. When a function is activated, extra text with an explanation for certain functions is shown.
  • Page 118 DISPLAYS AND VOICE CONTROL Moving apps and buttons in centre Symbols in the centre display's NOTE display status bar Hide the apps that you rarely or never use by The apps and buttons for car functions in the Overview of the symbols that can be shown in moving them to the bottom, off the visible app view and function view respectively can be the centre display's status bar.
  • Page 119 DISPLAYS AND VOICE CONTROL Related information Symbol Specification Navigating in the centre display's views • Tethering activated (Wi-Fi hotspot). (p. 107) The car then shares the available Message in centre display (p. 132) • connection. • Internet-connected car* (p. 526) Car modem activated.
  • Page 120 DISPLAYS AND VOICE CONTROL Keyboard in centre display The centre display keyboard makes it possible make entries using keys. It is also possible to "draw in" letters and characters on the screen by hand. The keyboard can be used to enter characters, letters and numbers, e.g.
  • Page 121 DISPLAYS AND VOICE CONTROL The image shows an overview of some of the buttons which may be shown in the keyboard. The appearance varies depending on language settings and the context in which the keyboard is being used.
  • Page 122 DISPLAYS AND VOICE CONTROL entry, all letters are automatically lower case Variants of a letter or character Row of suggested words or characters unless otherwise set with the button. The suggested words are adjusted as new letters are being entered. Browse among the Number entry.
  • Page 123 DISPLAYS AND VOICE CONTROL Changing keyboard language in Enter the characters, letters and Switching between different languages centre display words manually in the centre in the keyboard display To make it possible to switch between different When a number of languages languages for the keyboard, the languages must have been selected in The centre display keyboard allows you to enter...
  • Page 124 DISPLAYS AND VOICE CONTROL Suggestions for characters/letters/word/ Writing characters/letters/words by hand Deleting/changing characters/letters written part of word. It is possible to scroll through 1. Write a character, a letter, a word or parts of by hand the list. a word in the area for hand-written letters (1).
  • Page 125 DISPLAYS AND VOICE CONTROL Changing the appearance in the Switching off and changing the Changing row in the free text field with centre display volume of the system sound in the handwriting centre display The appearance of the screen in the centre dis- play can be changed by selecting a theme.
  • Page 126 DISPLAYS AND VOICE CONTROL Changing system units Changing system language Other settings in the centre display's top view Units settings are defined in the centre display's Language settings are defined in the centre dis- Settings Settings menu. play menu You can change settings and information for many of the car's functions via the centre dis- 1.
  • Page 127 Third party apps are not included in the car's sys- A subcategory in the settings menu with different types tem from the beginning, but are the type that can of settings (here, a multi-selector button and radio but- Volvo ID be downloaded e.g. . Here the settings tons).
  • Page 128 (p. 124) ownership it is also important to change the Reset Personal Settings - clears personal • owner of the Volvo On Call* service. Table showing centre display settings • data and resets personal settings to their (p. 127) Related information default values.
  • Page 129 Driver Profiles . Other set- Car Wi-Fi Hotspot tings are global, which means they are not linked to a driver profile. Car Modem Internet Route and Guidance My Car Volvo On Call Traffic Subcategories Volvo Service Networks Media Displays Subcategories Climate...
  • Page 130 DISPLAYS AND VOICE CONTROL Driver profiles System They remain the same regardless of which driver profile is active. Many of the settings made in the car can be Subcategories adapted according to the driver's personal pref- Keyboard layout settings are an example of Driver Profile erences and can be saved in one or more driver global settings.
  • Page 131 DISPLAYS AND VOICE CONTROL Selecting driver profile Renaming a driver profile 4. Press Confirm > The driver profile is selected and the sys- When the centre display has been started, the It is possible to change the name of the different tem loads the settings for the new driver selected driver profile is shown at the top of the driver profiles used in the car.
  • Page 132 DISPLAYS AND VOICE CONTROL Protect driver profile Linking remote control key to driver Related information profile Driver profiles (p. 128) • In some cases it is preferable not to save various settings defined in the car to the active driver It is possible to link your key to a driver profile.
  • Page 133 DISPLAYS AND VOICE CONTROL Resetting settings in the driver 6. Press 2. Press System Driver Profiles. profiles > This key is now linked to the driver profile 3. Select the desired profile. The display returns and will remain linked as long as the Settings that have been saved to one or more Guest to the home view.
  • Page 134 DISPLAYS AND VOICE CONTROL Message in centre display Managing messages in the centre Pop-up messages display In some cases, a message is shown in the form The centre display can show messages to of a pop-up window. Pop-up messages have inform or assist the driver in the event of different Messages in the centre display are handled in higher priority than messages shown in the sta-...
  • Page 135 DISPLAYS AND VOICE CONTROL Handling a message saved from the 2. Tap on a message to expand/minimise. Managing a new message centre display For messages with buttons: > More information on the message is shown in the list and the image to the left Whether saved from the driver display or the Press the button to perform the action or –...
  • Page 136 DISPLAYS AND VOICE CONTROL Head-up display* NOTE The head-up display supplements the car's The driver's ability to see the information in driver display and projects information from the the head-up display is impaired by the follow- driver display onto the windscreen. The projec- ing: ted image can only be seen from the driver posi- use of polarising sunglasses...
  • Page 137 DISPLAYS AND VOICE CONTROL Activating and deactivating the The snowflake symbol illuminates in Related information head-up display* the event of a risk of icy conditions. Activating and deactivating the head-up dis- • play* (p. 135) The head-up display can be activated and deac- tivated when the car has been started.
  • Page 138 DISPLAYS AND VOICE CONTROL Settings for head-up display* Adjusting brightness and vertical Lowering the position position Adjust the settings for the head-up display's pro- Confirm jection onto the windscreen. The brightness of the graphics is automatically Settings can be defined when the car has been adapted to their background light conditions.
  • Page 139 Activating and deactivating the head-up dis- certain functions in the media player, Bluetooth- • unit is replaced. Calibration means that the pro- play* (p. 135) connected phone, climate system and Volvo's jected image is rotated clockwise or anticlock- navigation system*. Driver profiles (p. 128) •...
  • Page 140 DISPLAYS AND VOICE CONTROL responses from the system. The voice recognition Using voice recognition Example of voice recognition control system uses the same microphone as Bluetooth- Call [Forename] [Surname] Press , say " connected devices, and the voice recognition Depress the steering wheel [number category] "...
  • Page 141 DISPLAYS AND VOICE CONTROL Controlling a telephone with voice this function to work, the car must be con- Digits nected to the Internet. The number commands are stated differently recognition depending on the function to be controlled: Call a contact, have messages read aloud or Related information Phone numbers and postcodes must be dictate brief messages with voice control com-...
  • Page 142 DISPLAYS AND VOICE CONTROL Voice control of radio and media " Radio FM " - starts FM radio. Settings for voice recognition • " Radio AM " - starts AM radio. • Commands for radio and media player device Settings for the voice control system are control are shown below.
  • Page 143 DISPLAYS AND VOICE CONTROL Related information Voice recognition (p. 137) • Using voice recognition (p. 138) • Controlling a telephone with voice recogni- • tion (p. 139) Controlling climate control with voice recog- • nition (p. 198) Voice control of radio and media (p. 140) •...
  • Page 145 LIGHTING...
  • Page 146 Rotating ring in the left-hand stalk switch. Volvo recommends that mode is used When the car's electrical system is in ignition when the vehicle is driven.
  • Page 147 LIGHTING Adjusting light functions via the Adapting the headlamp pattern Thumbwheel in instrument panel centre display from the headlamps Several light functions can be adjusted and acti- The headlamp pattern can be reset when chang- vated via the centre display. For example, active ing from right to left-hand traffic, and vice versa.
  • Page 148 LIGHTING Position lamps Daytime running lights position from another position to switch on only the position lamps instead of other lighting. Position lamps can be used so that other road The car has sensors that detect the light condi- users can see the car if it stops or is parked. The tions in the surroundings.
  • Page 149 LIGHTING Dipped beam Tunnel detection If the stalk switch rotating ring is in the The car detects when it is driven into a tunnel position, the daytime running lights (DRL ) are When driving with the stalk switch's rotating ring and switches from daytime running lights to switched on when the car is driven in daylight.
  • Page 150 LIGHTING Using main beam Active main beam Deactivate by moving the stalk switch back- wards. Main beam is operated with the left-hand stalk Active main beam is a function which uses a switch. Main beam is the car's strongest lighting camera sensor at the top edge of the wind- When main beam has been activated the and should be used when driving in the dark for...
  • Page 151 LIGHTING If active main beam is deactivated while main If this symbol is shown in the driver dis- beam is on, the lighting is immediately reset to play, together with the message Active dipped beam. High Beam Temporarily unavailable , then switching between When active main beam is activated, the symbol main and dipped beam must be performed man- illuminates with a white glow in the driver...
  • Page 152 LIGHTING Using direction indicators Related information NOTE Lighting control (p. 144) • The car's direction indicators are operated with This automatic flashing sequence can be • Using main beam (p. 148) the left-hand stalk switch. The direction indicator • stopped by moving the stalk switch lamps flash three times or continuously, depend- Limitations for camera unit (p.
  • Page 153 LIGHTING Active bending lights* Front fog lamps/cornering lights* The function is only active in weak daylight or darkness and only when the car is moving and Active bending lights are designed to provide The front fog lamps emit a stronger beam than dipped beam is switched on.
  • Page 154 LIGHTING Rear fog lamp Press the On/Off button. The symbol in NOTE the driver display illuminates when the rear fog The rear fog lamp is considerably stronger than Regulations on the use of fog lamps vary lamp is switched on. the normal rear lights and should only be used in from country to country.
  • Page 155 LIGHTING Brake lights Emergency brake lights Hazard warning flashers The brake light automatically comes on during Emergency brake lights are activated to alert Hazard warning flashers warn other road users braking. vehicles behind about heavy braking. by means of all of the car's direction indicators being activated simultaneously.
  • Page 156 LIGHTING Using home safe lighting Approach light duration NOTE Some of the exterior lighting can be kept Approach lighting is switched on when the car is Regulations for the use of hazard warning switched on to work as home safe lighting after unlocked and is used to switch on the car's flashers may vary between countries.
  • Page 157 LIGHTING Interior lighting Auto function for passenger compartment Rear roof lighting lighting The rear area of the car has reading lighting, The interior is equipped with several different which is also used as passenger compartment Reading lamp, right-hand side types of lighting to improve the experience. This lighting.
  • Page 158 LIGHTING Adjusting interior lighting The reading lamps are switched on or off by display and also precisely adjusted using the briefly pressing the button on the lamp. Bright- thumbwheel in the instrument panel. The lamps inside the car come on differently ness is adjusted by holding the button pressed in.
  • Page 159 LIGHTING Changing the brightness of the lights 1. Press Settings in the top view in the centre display. 2. Press My Car Lights and Lighting Interior Lighting Interior Mood Lighting. 3. Under Interior Mood Light Intensity , select from High Changing the colour of the light 1.
  • Page 161 WINDOWS, GLASS AND MIRRORS...
  • Page 162 WINDOWS, GLASS AND MIRRORS Windows, glass and mirrors Pinch protection for windows and Using windscreen and headlamp washers • sun blinds (p. 173) The car contains controls for windows, glass Activating and deactivating the heated wind- and mirrors. Some of the windows in the car are •...
  • Page 163 Controls for front windows. Operating power windows (p. 162) • The power windows are equipped with pinch pro- tection. If any fault arises with the pinch protec- tion, a reset sequence can be tested. An authorised Volvo workshop is recommended. * Option/accessory.
  • Page 164 WINDOWS, GLASS AND MIRRORS Operating power windows WARNING Using the driver's door control panel, all power Check that children or other passengers are windows can be operated - using the control not at risk of crushing when all the windows panels in the other doors operates the power are closed with a remote control key or key- window in the individual door.
  • Page 165 WINDOWS, GLASS AND MIRRORS Rearview and door mirrors Adjusting rearview mirror dimming Activating and deactivating the heated rear • window and door mirrors (p. 218) The rearview mirrors and door mirrors are used Bright light from behind could be reflected in the to give the driver better visibility to the rear.
  • Page 166 WINDOWS, GLASS AND MIRRORS Angling the door mirrors Automatic dimming* NOTE Bright light from behind is automatically dimmed To ensure better visibility to the rear, the door If the sensors are obscured by e.g. parking by the interior rearview and door mirrors. Auto- mirrors need to be set to the preferences of the permits, transponders, sun visors or objects in matic dimming is always active while driving, apart...
  • Page 167 WINDOWS, GLASS AND MIRRORS Folding in rearview mirrors electrically* Engage reverse gear and press the L or R 1. Tap on Settings in the centre display's top – button. view. The mirrors can be retracted for parking/driving in narrow spaces. Note that the button may need to be pressed 2.
  • Page 168 WINDOWS, GLASS AND MIRRORS Panorama roof* Wind deflector WARNING The panorama roof is divided into two glass sec- Children, other passengers or objects may be tions. The front section can be opened vertically trapped by the moving parts. at the rear edge (ventilation position) or horizon- Always operate the windows with caution.
  • Page 169 WINDOWS, GLASS AND MIRRORS Operating the panorama roof* ment of both panoramic roof and sun blind are IMPORTANT also stopped if the roof control is operated again The panoramic roof and sun blind are operated Remove ice and snow before opening the •...
  • Page 170 WINDOWS, GLASS AND MIRRORS Open and close ventilation position Fully open and close the panoramic Automatic operation roof using the roof control 1. Open the sun blind to maximum position - press the control backward to the position for automatic opening and release. 2.
  • Page 171 WINDOWS, GLASS AND MIRRORS Automatic closing of the panoramic Pinch protection for windows and sun blinds Locking and unlocking with the remote con- • • roof's* sun blind (p. 160) trol key (p. 239) Keyless locking and unlocking* (p. 261) •...
  • Page 172 WINDOWS, GLASS AND MIRRORS Wiper blades and washer fluid Using windscreen wipers Intermittent wiping Set the number of sweeps per time unit Together with the washer fluid, the wipers are The windscreen wiper cleans the windscreen. with the thumbwheel when intermittent used to improve visibility as well as headlamp Different settings for the windscreen wiper are wiping is selected.
  • Page 173 WINDOWS, GLASS AND MIRRORS Using the rain sensor Wiper blades and washer fluid (p. 170) Activate the rain sensor by pressing the rain sen- • sor button Using the rain sensor's memory function • The rain sensor automatically starts the wind- (p.
  • Page 174 WINDOWS, GLASS AND MIRRORS Using the rain sensor's memory Related information Replacing windscreen wiper blades (p. 638) • function Using windscreen and headlamp washers • Replacing the wiper blade, rear window • (p. 173) (p. 636) The rain sensor automatically starts the wind- Using automatic rear windscreen wiping screen wipers based on how much water it •...
  • Page 175 WINDOWS, GLASS AND MIRRORS Using windscreen and headlamp Filling washer fluid (p. 640) • IMPORTANT washers Wiper blades in service position (p. 639) • Avoid activating the washer system when it is Windscreen and headlamp washers clean the Replacing windscreen wiper blades (p. 638) •...
  • Page 176 WINDOWS, GLASS AND MIRRORS Using the rear window wiper and Wiper blades in service position (p. 639) • washer Replacing windscreen wiper blades (p. 638) • Rear window wiper and washer clean the rear Replacing the wiper blade, rear window •...
  • Page 177 WINDOWS, GLASS AND MIRRORS Using automatic rear windscreen wiping when reversing Engaging reverse gear while the windscreen wipers are on initiates rear window wiping. The function stops when reverse gear is disengaged. 1. Press Settings in the top view in the centre display.
  • Page 179 SEATS AND STEERING WHEEL...
  • Page 180 SEATS AND STEERING WHEEL Manual front seat Raise/lower the seat by means of adjusting Adjusting the lumbar support* in the front • the control up/down. seat (p. 186) The car's front seats have different setting Change the backrest inclination by turning Adjusting the passenger seat from the driv- options for optimum seating comfort.
  • Page 181 SEATS AND STEERING WHEEL Power* front seat Adjusting the power* front seat Using a stored position for seat, door mirrors • and head-up display* (p. 181) The car's front seats have different setting Set the preferred seat position using the control options for optimum seating comfort.
  • Page 182 SEATS AND STEERING WHEEL Storing position for seat, door Raise/lower the seat by means of adjusting Adjusting the passenger seat from the driv- • mirrors and head-up display* the control up/down. er's seat* (p. 187) Move the seat forward/backward by adjust- You can store the position for power* seat, door ing the control forward/backward.
  • Page 183 SEATS AND STEERING WHEEL Using a stored position for seat, 2. Press and hold the M button depressed. The Adjusting the lumbar support* in the front • door mirrors and head-up display* light indicator in the button illuminates. seat (p. 186) Adjusting the passenger seat from the driv- 3.
  • Page 184 SEATS AND STEERING WHEEL Massage settings* in the front seat Adjusting* the length of the seat cushion in Closed front door • the front seat (p. 184) Hold one of the memory buttons 1 ( ) or 2 – Both the multi-function control on the seat and Massage settings* in the front seat (p.
  • Page 185 SEATS AND STEERING WHEEL Adjusting massage settings* in the Intensity : Select between Normal Adjusting the lumbar support* in the front • • front seat High seat (p. 186) Speed Slow Normal Adjusting the passenger seat from the driv- : Select between •...
  • Page 186 SEATS AND STEERING WHEEL Adjusting* the length of the seat 2. Select Massage in the seat settings view. 2. Select Cushion extension in the seat set- cushion in the front seat tings view. 3. To choose between the different massage functions, select either directly in the centre Depending on equipment level selected, seat Press the front section of the four-way...
  • Page 187 SEATS AND STEERING WHEEL Adjusting the side support* in the Related information 2. Select Side bolsters in the seat settings front seat view. Manual front seat (p. 178) • Power* front seat (p. 179) Increase comfort in the front seat by adjusting Press the front section of the four-way •...
  • Page 188 SEATS AND STEERING WHEEL Adjusting the lumbar support* in the The lumbar support is adjusted using the multi- 2. Select Lumbar in the seat settings view. front seat function control in cars with four-way lumbar sup- Press the round button up /down •...
  • Page 189 SEATS AND STEERING WHEEL Adjusting the passenger seat from Related information the driver's seat* Manual front seat (p. 178) • Power* front seat (p. 179) The front passenger seat can be adjusted from • the driver's seat. Adjusting the power* front seat (p. 179) •...
  • Page 190 SEATS AND STEERING WHEEL Lowering the backrests in the rear Massage settings* in the front seat (p. 182) • IMPORTANT seat Adjusting the side support* in the front seat • The armrest* for the centre seat must be (p. 185) The rear seat's backrest is divided into two raised before lowering the seat.
  • Page 191 SEATS AND STEERING WHEEL sides of the seat with the handles in the rear Lowering the backrest using buttons in the Lowering the backrests using handles in the seat. cargo area rear seat To facilitate folding of the rear seat, the car must Ensure that there are no occupants or objects in be stationary and the tailgate open.
  • Page 192 SEATS AND STEERING WHEEL Adjusting the head restraints in the 4. If necessary, raise the centre seat's head Pull up the backrest's locking handle rear seat restraint. while folding the backrest forward at the same time. The locking handle for the head Adjust the centre seat head restraint according restraints is pulled up automatically when the WARNING...
  • Page 193 SEATS AND STEERING WHEEL Fold down the rear seat's outer head restraints using handles For cars with electronically controlled rear seat folding*, the outer head restraints can be folded using handles on the top side of the seat, see figure .
  • Page 194 SEATS AND STEERING WHEEL Steering wheel controls and horn Horn The steering wheel houses the horn and con- trols for e.g. the driver support systems and voice recognition. Related information The horn is located in the centre of the steering wheel. Lowering the backrests in the rear seat •...
  • Page 195 SEATS AND STEERING WHEEL Steering lock Adjusting the steering wheel regulated according to the car's speed in order to give the driver enhanced road responsiveness. The steering wheel lock makes it difficult to steer The steering wheel can be adjusted in different the car if it is stolen, for example.
  • Page 196 SEATS AND STEERING WHEEL Adjusting the steering wheel in a car without a knee airbag Lever for steering wheel adjustment. 1. Pull the lever backwards to release the steer- ing wheel. 2. Adjust the steering wheel to the position that suits you.
  • Page 197 CLIMATE...
  • Page 198 CLIMATE Climate Climate zones 4-zone climate* The car is equipped with electronic climate con- The number of climate zones that the car is divi- trol. The climate control system cools or heats as ded into governs the options for setting different well as dehumidifies the air in the passenger temperatures for different parts of the passenger compartment.
  • Page 199 CLIMATE Climate control - sensors Perceived temperature With the Interior Air Quality System* there is also an air quality sensor that is fitted into the climate The climate control system has a number of sen- The climate control system regulates the climate control system air intake.
  • Page 200 CLIMATE Controlling climate control with " Air condition on "/" Air condition off " - " Turn on seat ventilation "/" Turn off seat • • activates/deactivates the air conditioning. ventilation voice recognition " - activates/deactivates the seat ventilation*. " Recirculation on "/"...
  • Page 201 The indicator is visible in the climate row Use cleaning agents and car care products rec- when the climate view is not open. ommended by Volvo to clean the interior. If the conditions have not been met then the Clean Zone text is white.
  • Page 202 CLIMATE Clean Zone Interior Package* Interior Air Quality System* That the air quality system Interior Air Quality • System* is activated. Clean Zone Interior Package (CZIP) comprises Interior Air Quality System (IAQS) is a fully auto- That the ventilation fan is activated. a series of modifications that keep the passen- matic air quality system that separates gases •...
  • Page 203 It is possible to set whether the air quality sensor To maintain high climate system performance, should be activated/deactivated. the filter must be changed at regular intervals. Follow the Volvo Service Programme for the rec- 1. Press Settings in the top view in the centre ommended replacement intervals.
  • Page 204 CLIMATE Air distribution Changing air distribution The climate control system distributes the The air distribution can be changed manually if incoming air via a number of different vents in required. the passenger compartment. Automatic and manual air distribution With auto-regulated climate control running the air distribution takes place automatically.
  • Page 205 CLIMATE Opening, closing and aiming the air Related information Opening and closing the air vents vents Air distribution (p. 202) Air vents for the front seat: • Opening, closing and aiming the air vents Some air vents in the passenger compartment •...
  • Page 206 CLIMATE Air vents for the rear seat: Aiming the air vents The air vent's lever The air vent's lever Move the lever sideways/vertically in order to – Move the lever up/down to open/close the – aim the air flow from the nozzle. air flow from the nozzle.
  • Page 207 CLIMATE Table of air distribution options The air distribution can be changed manually if required. The following options are available for setting. Air distribution Purpose If all air distribution buttons are deselected in manual mode, the climate control system returns to automatically regulated climate control. Main air flow from the defroster vents.
  • Page 208 CLIMATE Air distribution Purpose Main air from the defroster vents and air vents in the instrument panel. Provides good comfort in hot and dry climates. Some air flows from other air vents. Main air flow from the defroster vents and air vents at the floor. Some air Provides good comfort and good demisting in a cold or flows from other air vents.
  • Page 209 CLIMATE Related information Air distribution (p. 202) • Opening, closing and aiming the air vents • (p. 203) Changing air distribution (p. 202) •...
  • Page 210 CLIMATE Climate controls Main climate In addition to the climate row's functions, other The climate control system's functions are con- main climate functions can also be controlled in trolled from physical buttons in the centre con- Main climate tab. sole, the centre display and the climate controls at the rear of the tunnel console*.
  • Page 211 CLIMATE Fan control for front seat (with 2-zone cli- Climate controls at rear of tunnel mate, the control is shared with the rear console* seat). AUTO - Auto regulating the climate. Rear climate control* All climate functions for the rear seat can be regulated in the Rear climate tab.
  • Page 212 CLIMATE Activating and deactivating heated selected climate settings are shown. The screen 2. Repeatedly press the button for heated seats front seat* locks automatically after a period of inactivity. in order to change between the four levels: High Medium The seats can be heated in order to increase Related information >...
  • Page 213 CLIMATE Activating and deactivating Activating and deactivating heated Activating and deactivating the heated automatic start of heated front seat* rear seat* rear seat from the rear seat With 2-zone climate: The seats can be heated in order to increase The seats can be heated in order to increase comfort for driver and passengers when it is comfort for driver and passengers when it is cold.
  • Page 214 CLIMATE Activating and deactivating With 4-zone climate*: ventilated front seat* The seats can be ventilated to provide increased comfort in a hot climate, for example. The ventilation system consists of fans in the seats and backrests that draw air through the seat upholstery.
  • Page 215 CLIMATE Activating and deactivating the Activating and deactivating Related information heated steering wheel* automatic start of heated steering Climate controls (p. 208) • wheel* Activating and deactivating automatic start of The steering wheel can be heated in order to • increase comfort for the driver when it is cold.
  • Page 216 CLIMATE Activating auto climate control Activating and deactivating air 2. Give a short or long press on AUTO recirculation With auto climate control activated, multiple cli- Short press - air recirculation, air condi- • mate functions are controlled automatically. Air recirculation shuts out bad air, exhaust tioning and air distribution are controlled gases, etc.
  • Page 217 CLIMATE Activating and deactivating time Activating and deactivating max IMPORTANT setting for air recirculation defroster If the air in the car is recirculated for too long Air recirculation shuts out bad air, exhaust Max defroster is used to quickly remove mist and then there is a risk of misting on the insides gases, etc.
  • Page 218 CLIMATE Cars with heated windscreen: Activating and deactivating max Related information defroster from centre display Climate controls (p. 208) • Press the button repeatedly in order to – switch between the three levels: Activated heated windscreen • Activated heated windscreen and max •...
  • Page 219 CLIMATE Activating and deactivating the Activating and deactivating heated NOTE heated windscreen* windscreen from centre display The heated windscreen may affect the per- A heated windscreen is used to quickly remove formance of transponders and other commu- mist and ice from the window. nication equipment.
  • Page 220 CLIMATE Activating and deactivating Activating and deactivating the Activating and deactivating heated rear automatic start of heated heated rear window and door window and door mirrors from centre mirrors windscreen* display A heated windscreen is used to quickly remove The heated rear window and door mirrors are mist and ice from the window.
  • Page 221 CLIMATE Activating and deactivating Regulating fan level for front seat NOTE automatic starting of the heated The fan can be set to several different automati- The climate control system automatically rear window and door mirrors cally controlled fan speeds for the front seat. adjusts the air flow within the selected fan The heated rear window and door mirrors are level based on requirements.
  • Page 222 CLIMATE Regulating fan level for rear seat* Regulating the fan level for the rear NOTE seat from the rear seat The fan can be set to several different automati- The climate control system automatically 1. Press the unlocking button on the tunnel cally controlled fan speeds for the rear seat.
  • Page 223 CLIMATE Regulating temperature for front Regulating temperature for rear seat* seat The temperature can be set to the desired num- The temperature can be set to the desired num- ber of degrees for the rear seat's climate zones. ber of degrees for the front seat's climate zones. Regulating temperature for rear seat from front seat Temperature control.
  • Page 224 CLIMATE Synchronising temperature The temperature in the car's different climate zones can be synchronised with the temperature set on the driver's side. Temperature control. Temperature control on the climate panel at the rear of the tunnel console. 3. Regulate the temperature by means of the 2.
  • Page 225 CLIMATE Activating and deactivating air Related information NOTE conditioning Climate controls (p. 208) • Close all side windows and the panoramic The air conditioning cools and dehumidifies roof* for air conditioning to work optimally. incoming air as required. NOTE It is not possible to activate the air condition- ing when the fan control is in position.
  • Page 226 CLIMATE Parking climate* Preconditioning* Related information Climate (p. 196) • Parking climate control is a generic term for vari- Preconditioning of the car before driving can ous functions that improve the passenger com- reduce wear and energy needs during a journey. Preconditioning* (p.
  • Page 227 > Preconditioning is started/switched off the selected settings can be managed from a and the button is illuminated/extin- device that has the Volvo On Call* app. Precondi- guished. tioning heats* the passenger compartment to a comfortable temperature or ventilates the pas- Certain markets.
  • Page 228 CLIMATE Adding and editing time setting for Preconditioning time setting* 3. Press Add timer preconditioning* > A pop-up window is shown. The timer can be set so that the preconditioning is finished at a predetermined time. The timer for preconditioning can manage up to 8 time settings.
  • Page 229 CLIMATE Activating and deactivating time Activating and deactivating time setting for • WARNING setting for preconditioning* preconditioning* (p. 227) Do not use preconditioning if the car is equip- Removing time setting for preconditioning* • A time setting in the timer for preconditioning ped with a heater*: (p.
  • Page 230 CLIMATE Removing time setting for Adding and editing time setting for precondi- • WARNING preconditioning* tioning* (p. 226) Do not use preconditioning if the car is equip- Activating and deactivating time setting for A time setting for preconditioning that is no •...
  • Page 231 CLIMATE Starting and switching off climate Climate comfort when parking* NOTE comfort when parking* The climate in the car's passenger compartment It is not possible to start climate comfort can be maintained while the car is parked, e.g. if Climate comfort retention maintains the climate retention if there is not enough residual heat the engine needs to be switched off but the in the passenger compartment after driving.
  • Page 232 Symbols and messages for parking Messages relating to parking climate control can This symbol illuminates in the driver climate control* also be displayed in a device which has the Volvo display when the parking heater is On Call* app. active.
  • Page 233 CLIMATE Heater* NOTE NOTE The heater helps the engine and passenger Make sure that there is enough charge in the Make sure there is enough fuel in the car's compartment reach the correct temperature battery if the heater needs to be used. fuel tank if the heater needs to be used.
  • Page 234 The parking heater starts automatically if the ing from the parking heater, switch off the parking climate's preconditioning* is activated heater and, if possible, pull out its fuse. Volvo and the passenger compartment needs to be recommends that an authorised Volvo work- heated up.
  • Page 235 This is per- fectly normal. NOTE The additional heater starts and is controlled Volvo recommends that the automatic start automatically when heating is required while the for the additional heater should be switched car is being driven.
  • Page 237 KEY, LOCKS AND ALARM...
  • Page 238 KEY, LOCKS AND ALARM Lock confirmation Indication in lock buttons Lock and alarm indicator When the car is locked or unlocked the direction Front door indicators confirm that locking or unlocking was correctly performed. Exterior indication Locking The car's hazard warning flashers indicate •...
  • Page 239 KEY, LOCKS AND ALARM Lock indication setting Remote control key In rear door* It is possible to select how the car confirms The remote control key locks and unlocks the locking and unlocking in the centre display set- doors, tailgate and fuel filler flap. The remote tings menu.
  • Page 240 KEY, LOCKS AND ALARM Keyless locking and unlocking of doors, tailgate Remote control key buttons matically when the button is held depressed. (Passive Entry*) is also available as an option. The tailgate is also closed with a long press The key then has a range extending in a semicir- –...
  • Page 241 Volvo On Call, and reactivated when the Related information car is unlocked using Volvo On Call or by Locking and unlocking with the remote con- pressing the key's unlock button. •...
  • Page 242 Volvo On Call, and reactivated when the car is unlocked using Volvo On Call or by NOTE pressing the key's unlock button. Always try moving closer to the car and mak- ing another unlock attempt.
  • Page 243 KEY, LOCKS AND ALARM Settings for remotely controlled and Unlocking the tailgate with the 1. Press the remote control key's button. inside unlocking remote control key > The lock and alarm indicator on the instru- It is possible to select different sequences for It is possible to unlock just the tailgate by press- ment panel extinguishes in order to show remotely controlled unlocking.
  • Page 244 KEY, LOCKS AND ALARM Remote control key range cular area with a radius of approx. 1.5 metres Keyless and touch-sensitive surfaces* • (5 feet) on both long sides and approx. 1 metre (p. 260) In order for the remote control key to work prop- (3 feet) from the tailgate.
  • Page 245 Hold the remote control key with the The battery for the remote control key should be front visible and the Volvo logo facing the replaced if: right way - slide the button at bottom edge by the key ring to the right. Slide the front the information symbol illuminates and side's shell a few millimetres upwards.
  • Page 246 KEY, LOCKS AND ALARM Use a screwdriver or similar to turn the bat- The battery (+) side is facing upwards. Then Turn the key, move the button to the side tery cover anticlockwise until the markings carefully prize loose the battery as illustrated. and slide the back shell a few millimetres meet at the OPEN text.
  • Page 247 KEY, LOCKS AND ALARM NOTE Volvo recommends that the batteries to be used in the remote control key fulfil UN Manual of Test and Criteria, Part III, sub- section 38.3. Batteries fitted in the factory or replaced by an authorised Volvo workshop fulfil the above criteria.
  • Page 248 One or more Red Key can be ordered from a Volvo retailer. A total of eleven keys with restric- tions can be programmed and used for a single car - at least one must be a normal remote con- trol key.
  • Page 249 KEY, LOCKS AND ALARM Red Key settings* The restrictions are intended to act as measures Speed reminder (On/Off): to reduce the risk of accidents, thereby making it Setting interval: 0-250 km/h (0-160 mph) • The holder of a regular remote control key can feel safer to hand over the car to e.g.
  • Page 250 Hold the remote control key with the blade: front visible and the Volvo logo facing the Refit the shell by pressing it downward right way - slide the button at bottom edge the left-hand front door can be opened •...
  • Page 251 KEY, LOCKS AND ALARM Locking and unlocking with the 5. Pull out the handle. 2. Then turn the start knob clockwise and detachable key blade release it. > The door opens. > The control automatically returns to its Amongst other things, the detachable key blade Locking will be performed in the same way, but starting position - the alarm signal stops can be used to unlock the car from the outside -...
  • Page 252 KEY, LOCKS AND ALARM Immobiliser NOTE The electronic immobiliser is a theft protection A door's lock reset only locks that partic- • system that prevents an unauthorised person ular door - not all doors simultaneously. from starting the car. A manually locked rear door with acti- •...
  • Page 253 KEY, LOCKS AND ALARM Type approval for the remote Lock system keyless start (Passive control key system Start) and keyless locking/unlocking (Passive Entry*) Type approval for the car's remote key system can be seen in the following tables. For more information about type approval, see support.volvocars.com.
  • Page 254 KEY, LOCKS AND ALARM Country/Area Type approval Brazil MT-3245/2015 Indonesia Nomor: 38301/SDPPI/2015 Malaysia RAAT/37A/1215/S(15-5198) Mexico IFETEL: RLVDEVO15-0396 Russia The United Arab Emirates ER37847/15 DA0062437/11...
  • Page 255 KEY, LOCKS AND ALARM Country/Area Type approval Namibia TA-2016-02 South Africa TA-2014-1868 Remote control key Country/Area Type approval Europe Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio equipment HUF8423 conforms to directive 2014/53/EU. The full text of the EU declaration of conformity can be found at support.volvocars.com.
  • Page 256 KEY, LOCKS AND ALARM Country/Area Type approval Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10668 ANRT 2015 Date d’agrément: 24/07/2015 Mexico IFETEL Marca: HUF Modelo (s): HUF8423 NOM-121-SCT1-2009 La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
  • Page 257 KEY, LOCKS AND ALARM Country/Area Type approval Oman Serbia...
  • Page 258 KEY, LOCKS AND ALARM Country/Area Type approval South Africa TA-2015-432 The United Arab Emirates Key Tag Country/Area Type approval Europe Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio equipment HUF8432 conforms to directive 2014/53/EU. The full text of the EU declaration of conformity can be found at support.volvocars.com.
  • Page 259 KEY, LOCKS AND ALARM Country/Area Type approval Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10667 ANRT 2015 Date d’agrément: 24/07/2015 Mexico IFETEL Marca: HUF Modelo (s): HUF8432 NOM-121-SCT1-2009 La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
  • Page 260 KEY, LOCKS AND ALARM Country/Area Type approval Oman Serbia...
  • Page 261 KEY, LOCKS AND ALARM Country/Area Type approval South Africa TA-2015-414 The United Arab Emirates Related information Remote control key (p. 237) •...
  • Page 262 KEY, LOCKS AND ALARM Keyless and touch-sensitive Related information NOTE surfaces* Keyless locking and unlocking* (p. 261) • It is important that only one touch-sensitive If the car is equipped with keyless locking and Keyless unlocking of the tailgate* (p. 262) •...
  • Page 263 KEY, LOCKS AND ALARM Keyless locking and unlocking* Touch the marked surface towards the rear – on the outside of a door handle after the The car is locked and unlocked from the outside door has been closed, or press the lock using the door or tailgate handles if the car is button on the bottom edge of the tailgate equipped with keyless locking/unlocking...
  • Page 264 KEY, LOCKS AND ALARM Settings for Keyless entry* Keyless unlocking of the tailgate* Keyless unlocking Grasp a door handle or press the rubberised It is possible to select different sequences for For keyless unlocking of the tailgate, all you have –...
  • Page 265 KEY, LOCKS AND ALARM Antenna locations for the start and 2. Lift by the outside handle in order to fully WARNING lock systems open the tailgate. People with pacemaker operations should not The car is equipped with a keyless start and lock come closer than 22 cm (9 inches) to the IMPORTANT system...
  • Page 266 KEY, LOCKS AND ALARM Locking and unlocking from inside Locking using a button in the front door Alternative unlocking method the car Press the button - both front doors must – be closed. The doors and tailgate can be locked and unlocked from inside using the central locking >...
  • Page 267 KEY, LOCKS AND ALARM Unlocking the tailgate from the Related information Related information inside of the car Settings for remotely controlled and inside Locking and unlocking from inside the car • • unlocking (p. 241) (p. 264) The tailgate can be unlocked from the inside by Unlocking the tailgate from the inside of the pressing a button on the instrument panel.
  • Page 268 KEY, LOCKS AND ALARM Activating and deactivating child 2. Press the button in the driver's door control Symbol Message Specification safety locks panel. Rear child Child safety > The driver display shows the message The child safety locks prevent children from locks are acti- lock Acti- Rear child lock Activated...
  • Page 269 KEY, LOCKS AND ALARM Automatic locking when driving Opening and closing the power*- NOTE operated tailgate The doors and tailgate are locked automatically A door's knob control only blocks that • when the car starts to move. The car's tailgate can be opened and closed particular door - not both rear doors electrically.
  • Page 270 KEY, LOCKS AND ALARM Foot movement* under the rear bumper. Long press on the instrument panel's – Press the button on the underside of – – button. Keep it depressed until the tailgate the tailgate to close. starts to open. Closing >...
  • Page 271 KEY, LOCKS AND ALARM Cancel opening or closing Closing and locking Long press on the button on the remote – Cancel opening or closing in one of the following control key. Press the button on the underside of – ways: the tailgate to close it and simultaneously >...
  • Page 272 KEY, LOCKS AND ALARM Programming maximum opening for Related information WARNING power operated tailgate* Programming maximum opening for power • Observe the risk of trapping when opening/ operated tailgate* (p. 270) Adapt the tailgate's opening position to low roof closing. Before starting opening/closing, Opening and closing the tailgate with foot height.
  • Page 273 KEY, LOCKS AND ALARM Opening and closing the tailgate NOTE with foot movement* If the system has been operating continu- • To facilitate the operation of the tailgate when ously for a long time, it is switched off to your hands are occupied, it can be opened and avoid overload.
  • Page 274 KEY, LOCKS AND ALARM Opening and closing with foot Do not leave your foot positioned under the car Related information during the kicking motion. This could cause acti- movement Keyless and touch-sensitive surfaces* • vation to fail. (p. 260) Cancelling opening or closing with foot Opening and closing the power*-operated •...
  • Page 275 KEY, LOCKS AND ALARM Private locking Activating and deactivating private 2. Enter the desired security code. locking > The security code is saved. The private The tailgate can be locked with the private lock- locking function is now ready for activa- ing function which prevents it from being Private locking is activated with a function button tion.
  • Page 276 If the cause of alarm activation is not rectified, the alarm cycle is repeated up to 10 times If private locking is activated and the car is unlocked via Volvo On Call* or the Volvo On Call* app, private locking will be deactivated automatically.
  • Page 277 - the alarm has been triggered. failure Service required . In which Movement and tilt sensors* case, contact a workshop - an authorised Volvo workshop is recommended. Movement and tilt sensors react to movements inside the car, if the window is broken or if any- one tries to steal the wheels or tow the vehicle away.
  • Page 278 KEY, LOCKS AND ALARM Activating and deactivating alarms* Deactivate the alarm 3. Turn the start knob clockwise and release it. Unlock and disarm the car alarm as follows: > The alarm is deactivated. The alarm is armed when the car is locked. press the remote control key's unlock button •...
  • Page 279 The car can only be unlocked with the remote Double lock* (p. 277) • control key, keyless unlocking or the Volvo On Call* app when double locks are activated. The front left door can also be unlocked with the detachable key blade. If the car is unlocked with the detachable key blade, the alarm will be trig- gered.
  • Page 280 KEY, LOCKS AND ALARM Temporarily deactivating double WARNING locks* Do not allow anyone to remain in the car with- If someone is going to stay in the car but the out first deactivating the double lock in order doors must be locked from the outside, then the to avoid the risk of anyone being locked in.
  • Page 281 DRIVER SUPPORT...
  • Page 282 DRIVER SUPPORT Driving support systems Speed-dependent steering force Rear Collision Warning (p. 363) • BLIS* (p. 364) The car is equipped with different driver support • Speed related power steering causes the steer- systems which can assist the driver in different ing wheel force to increase with the speed of the Cross Traffic Alert* (p.
  • Page 283 DRIVER SUPPORT Electronic stability control Change the steering force level* WARNING To select the steering force level, go to the "Drive Electronic Stability Control (ESC ) helps the The stability system ESC is supplemen- • modes" section and see the description at the driver to avoid skidding and improves the car's tary driver support intended to facilitate alternative INDIVIDUAL under the heading...
  • Page 284 Stability Control (p. 283) Limitation for sport mode in Electronic Stabil- • ity Control (p. 283) Engine Drag Control Trailer stability assist is included when the Volvo genuine towbar is installed. Trailer Stability Assist Electronic Stability Control Trailer Stability Assist * Option/accessory.
  • Page 285 DRIVER SUPPORT Activating/deactivating Sport mode Limitation for sport mode in Related information in Electronic Stability Control Electronic Stability Control Electronic stability control (p. 281) • There are certain limitations associated with the Towbar* (p. 471) • The ESC system is always activated — it can- ESC Sport Mode not be switched off.
  • Page 286 Stop the car in a safe place, switch off the engine and start it again. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. • A text message can be cleared by briefly press- If a message remains: Contact a workshop –...
  • Page 287 DRIVER SUPPORT Speed Limiter Related information : From active mode - deactivates/ Limitations for Speed Limiter (p. 289) changes the speed limiter to standby mode • A speed limiter (SL ) can be likened to a Activating and starting the Speed Limiter reverse cruise control - the driver regulates the •...
  • Page 288 DRIVER SUPPORT Activating and starting the Speed Managing speed for the speed mum speed that can be stored is 30 km/h Limiter limiter (20 mph). When the speed limiter is in standby mode The speed limiter function (SL ) must first be The speed limiter (SL ) can be set to different –...
  • Page 289 DRIVER SUPPORT Deactivate the speed limiter and set The speed set after the last button press is Temporary deactivation with the • it in standby mode stored in the memory. accelerator pedal The speed limiter can also be temporarily deacti- The speed limiter (SL ) can be temporarily Related information...
  • Page 290 DRIVER SUPPORT Reactivating the Speed Limiter from Deactivating the speed limiter Press the steering wheel button (2). – standby mode > The Speed Limiter indicators and symbols The speed limiter (SL ) can be deactivated. in the driver display change colour from The speed limiter (SL ) can be reactivated after GREY to WHITE —...
  • Page 291 DRIVER SUPPORT Limitations for Speed Limiter Automatic speed limiter 3. Press the steering wheel button again. The Automatic Speed Limiter (ASL) function On steep downhill gradients the speed limiter’s helps the driver to adapt the car's maximum > Another function is activated. braking effect may be inadequate and hence the speed to the speed shown on the road signs.
  • Page 292 DRIVER SUPPORT Is SL or ASL active? WARNING Colour of sign Meaning Symbols in the driver display show which speed symbol The ASL function is supplementary driver • limiter function is active: support intended to facilitate driving and Greenish yellow ASL is active make it safer –...
  • Page 293 DRIVER SUPPORT Activate/deactivate Automatic Related information NOTE Speed Limiter Speed Limiter (p. 285) • If the Automatic Speed Limiter function is • The automatic speed limiter function (ASL) can Automatic speed limiter (p. 289) • activated, road sign information is shown be activated and deactivated as a supplement to Activating/deactivating Road Sign Informa- •...
  • Page 294 DRIVER SUPPORT Changing the tolerance for the Activating/deactivating Road Sign Informa- • Press the steering wheel button – automatic speed limiter tion (p. 374) until 70 km/h (43 mph) in the centre of the speedometer (4) changes to 75 km/h The Automatic Speed Limiter function (ASL) can (47 mph).
  • Page 295 DRIVER SUPPORT Limitations for automatic speed Cruise control : Reduces stored speed limiter The cruise control (CC) helps the driver maintain Marker for stored speed Automatic speed limitation (ASL) takes place an even speed, resulting in more relaxed driving on motorways and long, straight roads in regular The car's current speed using speed information from the RSI function...
  • Page 296 DRIVER SUPPORT Activating and starting Cruise Change between Cruise control and adaptive • WARNING Control cruise control (p. 315) The cruise control function is supplemen- • The cruise control function (CC ) must first be tary driver support intended to facilitate selected and activated in order to be able to reg- driving –...
  • Page 297 DRIVER SUPPORT Managing speed for the cruise 30 km/h (20 mph) or higher. The lowest speed The speed set after the last button press is • control that can be stored is 30 km/h (20 mph). stored in the memory. If the driver increases the car's speed using the To start the cruise control: Cruise control (CC...
  • Page 298 DRIVER SUPPORT Deactivate Cruise Control and set it Cruise control dependence on drive Standby mode on driver intervention in standby mode mode The cruise control is temporarily deactivated and set in standby mode if: The cruise control's way of maintaining a speed Cruise control (CC ) can be temporarily deacti- may vary depending on the selected drive...
  • Page 299 DRIVER SUPPORT Reactivating Cruise Control from Deactivating cruise control To start cruise control from standby mode: standby mode Cruise Control — CC can be deactivated. Press the steering wheel button (2). – Cruise control (CC ) can be temporarily deacti- >...
  • Page 300 DRIVER SUPPORT Distance Warning* NOTE The Distance Warning function can assist the In cars equipped with Adaptive Cruise Con- driver to notice that the time interval to the vehi- trol*, it is possible to switch between cruise cle ahead may be too short. control and Adaptive Cruise Control –...
  • Page 301 DRIVER SUPPORT Head up display for Distance WARNING NOTE Warning Distance warning only reacts if the time win- Strong sunlight, reflections, extreme light con- dow to the vehicle ahead is shorter than the In cars equipped with head up display*, a sym- trasts, the use of sunglasses, or if the driver is preset value –...
  • Page 302 DRIVER SUPPORT Activating/deactivating Distance Setting the time interval for warning Distance Warning The Distance Warning function can be deacti- The Distance Warning function can be set with vated. different time intervals. On/Off Different time intervals to the vehicle in front can be selected Press the Distance Alert but-...
  • Page 303 DRIVER SUPPORT Limitations of Distance Warning NOTE NOTE The Distance Warning function may have limita- The higher the speed the longer the cal- The function uses the car's radar unit, which • tions in certain situations. culated distance in metres for a given has some general limitations, see the section time interval.
  • Page 304 DRIVER SUPPORT Adaptive cruise control* is clear again the car returns to the selected Adaptive Cruise Control regulates the speed with speed. acceleration and braking. It is normal for the The adaptive cruise control (ACC ) helps the brakes to emit a low sound when they are being driver to maintain an even speed combined with used to adjust the speed.
  • Page 305 Maintenance of adaptive cruise control com- : From standby mode - activates the ponents must only be performed at a work- adaptive cruise control and stores current shop - an authorised Volvo workshop is rec- speed ommended. : From active mode - deactivates/...
  • Page 306 DRIVER SUPPORT Adaptive Cruise Control and Activating and starting Adaptive Cruise Con- Driver display • Collision risk warning trol (p. 305) Managing speed with Adaptive Cruise Con- • The adaptive cruise control can warn the driver if trol (p. 306) the distance to the vehicle ahead suddenly becomes too short.
  • Page 307 DRIVER SUPPORT Head up display for adaptive cruise Activating and starting Adaptive brake, the warning lamp and acoustic warning are control if there is a risk of collision Cruise Control activated to alert the driver that immediate inter- vention is required. In cars equipped with a head up display*, the Adaptive cruise control (ACC ) must first be...
  • Page 308 DRIVER SUPPORT Managing speed with Adaptive Starting/activating the adaptive cruise With the symbol/function (4) displayed, – Cruise Control control press the steering wheel button (1). In order to start the ACC the following require- The adaptive cruise control (ACC ) can be set >...
  • Page 309 DRIVER SUPPORT Setting time interval for adaptive Change a set speed with short presses on vehicle down to 0 km/h, a speed lower than – cruise control 30 km/h (20 mph) cannot be selected/stored. the steering wheel buttons (1) or (2) or by pressing and holding them.
  • Page 310 DRIVER SUPPORT Select one of the following options: NOTE - ACC focuses on optimal fuel economy, • The higher the speed the longer the cal- • which means longer time interval to the vehi- culated distance in metres for a given cle ahead.
  • Page 311 DRIVER SUPPORT Deactivating/reactivating Adaptive To temporarily switch off Adaptive Cruise Control the driver maintains a speed higher than the • Cruise Control and set it in standby mode: stored speed for longer than 1 minute. the clutch pedal is depressed for approx. 1 •...
  • Page 312 DRIVER SUPPORT engine speed is too low/high. Automatic standby mode • WARNING The adaptive cruise control is dependent on one or more wheels lose traction. • A significant increase in speed may follow other systems, e.g. Electronic Stability Control brake temperature is high. •...
  • Page 313 DRIVER SUPPORT Overtaking assistance with adaptive Starting overtaking assistance with Related information cruise control adaptive cruise control Adaptive cruise control* (p. 302) • Overtaking assistance requires a number of con- Starting overtaking assistance with adaptive Adaptive Cruise Control (ACC ) can assist the •...
  • Page 314 DRIVER SUPPORT Limitations for overtaking Changing target with adaptive Related information assistance with adaptive cruise cruise control Adaptive cruise control* (p. 302) • control In combination with automatic gearbox, the Overtaking assistance with adaptive cruise • The overtaking assistance function may have lim- control (p.
  • Page 315 DRIVER SUPPORT Automatic braking with adaptive WARNING NOTE cruise control When the adaptive cruise control is following ACC can keep the car stationary for a maxi- The Adaptive cruise control (ACC ) has a spe- another vehicle at speeds in excess of mum of 5 minutes.
  • Page 316 DRIVER SUPPORT Limitations for adaptive cruise This takes place if the adaptive cruise control is Related information control holding the car stationary with the foot brake and: Adaptive cruise control* (p. 302) • the driver opens the door or takes off his/her Limitations for camera unit (p.
  • Page 317 DRIVER SUPPORT Change between Cruise control and 3. Press the steering wheel button 3. Press the steering wheel button adaptive cruise control > Cruise control starts and stores the cur- > Adaptive cruise control starts and stores In a car with Adaptive Cruise Control (ACC) the rent speed.
  • Page 318 DRIVER SUPPORT Symbols and messages for Adaptive Cruise Control A number of symbols and messages regarding the adaptive cruise control (ACC ) can be shown via the driver display and/or the head-up display*. Here are some examples The previous illustration shows that the adap- The previous illustration shows that the adap-...
  • Page 319 Adaptive cruise control is set to standby mode. Unavailable The symbol is GREY. Adaptive Cruise Contr. The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Service required The symbol is GREY.
  • Page 320 DRIVER SUPPORT Pilot Assist The driver selects the desired speed and a time The current status of steering interval to the vehicle ahead. Pilot Assist scans assistance is indicated by the Pilot Assist helps the driver to drive the car the distance to the vehicle ahead and the lane's colour of the steering wheel's between the lane's side markings using steering...
  • Page 321 DRIVER SUPPORT Pilot Assist regulates the speed with acceleration The following applies for cars with manual gear- WARNING and braking. It is normal for the brakes to emit a box: The Pilot Assist function is supplementary • low sound when they are being used to adjust Pilot Assist can follow another vehicle at •...
  • Page 322 Maintenance of Pilot Assist internal compo- Overview nents must only be performed at a workshop ▶: Switches from adaptive cruise control to - an authorised Volvo workshop is recom- Controls Pilot Assist mended. Reduces the time interval to vehicles ahead...
  • Page 323 DRIVER SUPPORT Pilot Assist and Collision risk Setting the time interval for Pilot Assist Driver display • warning (p. 325) Deactivating/activating Pilot Assist (p. 326) • Pilot Assist can warn the driver if the distance to the vehicle ahead suddenly becomes too short. Overtaking assistance with Pilot Assist •...
  • Page 324 DRIVER SUPPORT Head-up display for Pilot Assist if WARNING there is a risk of collision Pilot Assist only gives warning about vehicles In cars equipped with a head up display*, the detected by its camera and radar unit – there- warning is shown on the windscreen by a flash- fore a warning may not occur or be delayed.
  • Page 325 DRIVER SUPPORT Activating and starting Pilot Assist Related information With the Adaptive cruise control in standby mode: Pilot Assist (p. 318) • Pilot Assist must first be activated and then 1. Press the steering wheel button ▶ (6). started to be able to control speed and distance Head-up display* (p.
  • Page 326 DRIVER SUPPORT Managing speed for Pilot Assist Hands on the steering wheel Change a set speed with short presses on – In order for Pilot Assist to function, the driver’s the steering wheel buttons (1) or Pilot Assist can be set to different speeds. hands must be on the steering wheel.
  • Page 327 DRIVER SUPPORT Setting the time interval for Pilot Automatic gearbox Assist Pilot Assist can follow another vehicle at speeds from 0 km/h up to 200 km/h (125 mph). Pilot Assist can be set with different time inter- vals. Note that the lowest programmable speed for Pilot Assist is 30 km/h (20 mph) - even though it Different time intervals to the is capable of following another vehicle down to 0...
  • Page 328 DRIVER SUPPORT Deactivating/activating Pilot Assist Select one of the following options: NOTE Pilot Assist can be temporarily deactivated so - Pilot Assist focuses on optimal fuel • The higher the speed the longer the cal- • that it is set in the standby mode and can be economy, which means longer time interval culated distance in metres for a given reactivated later.
  • Page 329 DRIVER SUPPORT Press the steering wheel button ◀ (3). A temporary increase in speed with the accelera- the driver's hands are not on the steering • – tor pedal, e.g. during overtaking, does not affect wheel. > Pilot Assist is switched off and changes the setting - the car returns to the last stored to the Adaptive cruise control in active the parking brake is applied.
  • Page 330 DRIVER SUPPORT Overtaking assistance with Pilot Reactivating Pilot Assist from the Limitations for overtaking assistance with • Assist Pilot Assist (p. 329) standby mode Pilot Assist can help the driver when overtaking other vehicles. How overtaking assistance works When Pilot Assist is following another vehicle and the driver indicates the intention to overtake by activating the direction indicator , Pilot Assist...
  • Page 331 DRIVER SUPPORT Start overtaking assistance with Limitations for overtaking Change the target with Pilot Assist Pilot Assist assistance with Pilot Assist In combination with automatic gearbox, Pilot Overtaking assistance requires a number of con- The overtaking assistance function may have lim- Assist has functionality for change of target at ditions.
  • Page 332 DRIVER SUPPORT Automatic braking with Pilot Assist Automatic standby mode with change of Cessation of automatic braking In some situations, automatic braking ceases on target Pilot Assist has a special brake function in slow coming to a standstill and Pilot Assist is set in Pilot Assist is disengaged and set in standby traffic and while stationary.
  • Page 333 DRIVER SUPPORT Limitations of Pilot Assist between the car and such obstacles. The WARNING driver must ensure him/herself that the The Pilot Assist function may have limitations in In certain situations, Pilot Assist steering car is at a suitable distance from such certain situations.
  • Page 334 DRIVER SUPPORT Symbols and messages for Steep roads and/or heavy load Limitations for camera unit (p. 345) • Pilot Assist* Bear in mind that Pilot Assist is primarily Limitations for radar device (p. 335) • intended for use when driving on level road surfa- A number of symbols and messages regarding ces.
  • Page 335 DRIVER SUPPORT Here are some examples The previous illustration shows that Pilot Assist The previous illustration shows that Pilot Assist is set to maintain 110 km/h (68 mph) and at the is set to maintain 110 km/h (68 mph) and at the The previous illustration shows that Pilot Assist same time is following a vehicle ahead which is...
  • Page 336 DRIVER SUPPORT Radar unit Related information Limitations for radar device (p. 335) • The radar unit is used by several driver support systems and has the task of sensing other vehi- Recommended radar device maintenance • cles. (p. 338) Type approval for radar device (p. 339) •...
  • Page 337 DRIVER SUPPORT Limitations for radar device The radar unit is placed inside the upper section If the driver display shows this symbol of the windscreen together with the car's camera and the message " Windscreen The radar unit has certain limitations - which in unit.
  • Page 338 Dirt has appeared between the inside of the windscreen and the camera Visit a workshop to have the windscreen inside the unit's cover cleaned - an and radar unit. authorised Volvo workshop is recommended. that drives in between your car and the vehi- NOTE cle ahead.
  • Page 339 DRIVER SUPPORT High temperature Damaged windscreen The same type or Volvo-approved wind- • screen wipers must be fitted during At very high temperatures the camera and radar replacement. unit can temporarily be switched off for IMPORTANT about 15 minutes after the engine is started so If a crack, scratch or stone chip in the wind- as to protect the unit's electronics.
  • Page 340 DRIVER SUPPORT Recommended radar device maintenance In order that the camera and radar unit shall function correctly, the windscreen in front of the unit must be kept clear of dirt, ice and snow, and be cleaned regularly with water and car shampoo. NOTE Dirt, ice and snow covering the camera and radar unit will reduce its function and may...
  • Page 341 DRIVER SUPPORT Type approval for radar device The type approval for the car's radar units in the , PA and BLIS functions can be read out here. ACC & Market BLIS Symbol Type approval ✓ Botswana Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
  • Page 342 DRIVER SUPPORT ACC & Market BLIS Symbol Type approval Hereby, Delphi Electronics and Safety declares that L2C0054TR is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU (RED). The original declaration of conformity can be accessed at the following link www.delphi.com/ automotive-homologation.
  • Page 343 DRIVER SUPPORT ACC & Market BLIS Symbol Type approval Type Approval No.: TRC/LPD/2014/255 ✓ Equipment Type: Low Power Device (LPD) Jordan ✓ TRC/LPD/2017/63 Certification No. ✓ MSIP-CMI- DPH-L2C0054TR Korea ✓ MSIP-CMM-HLA-RS4 AGREE PAR L’ANRT MAROC ✓ Morocco NUMÉRO D’AGRÉMENT: MR 9929 ANRT 2014 DATE D’AGRÉMENT: 26/12/2014 ✓...
  • Page 344 DRIVER SUPPORT ACC & Market BLIS Symbol Type approval ✓ Russia ✓ И011 14 Serbia И011 17 ✓ ✓ DA 105753 Singapore ✓ DA 103238 ✓ TA-2014/1824 South Africa ✓ TA-2016/3407 ✓ CCAB15LP0560T3 Taiwan ✓ CCAB17LP0470T5...
  • Page 345 DRIVER SUPPORT ACC & Market BLIS Symbol Type approval Delphi і є, щ RACAM і і є П і і і і і ✓ і і ь КМ № 679 і 24 (П Ukraine 2009 .) Д і і і і...
  • Page 346 DRIVER SUPPORT Camera unit Related information Limitations for camera unit (p. 345) • The camera unit is used by several driver sup- port systems and has the task of for example Recommended camera device maintenance • detecting lane lines or traffic signs. (p.
  • Page 347 DRIVER SUPPORT Limitations for camera unit Blocked unit If the driver display shows this symbol The camera unit has certain limitations - which in and the message " Windscreen turn also limits those functions that use the unit. sensor Sensor blocked, see Impaired vision Owner's manual ", this means that the...
  • Page 348 Instead, the whole windscreen should be temperature has fallen sufficiently. If not rectified it can lead to reduced perform- replaced. ance for the driver support systems that use the camera and radar unit. Before replacing a windscreen, contact • an authorised Volvo workshop to verify...
  • Page 349 DRIVER SUPPORT that the correct windscreen is ordered and fitted. The same type or Volvo-approved wind- • screen wipers must be fitted during replacement. IMPORTANT When the windscreen is replaced, the camera and radar unit must be recalibrated at the workshop to ensure the functionality of all the car’s camera and radar-based systems.
  • Page 350 DRIVER SUPPORT Recommended camera device City Safety™ The function helps the driver by automatically maintenance braking the car in the event of an imminent risk City Safety can alert the driver using a visual, of collision if the driver does not react in time by In order that the camera and radar unit shall acoustic and brake pulse warning to help braking and/or swerving.
  • Page 351 DRIVER SUPPORT Parameters and subfunctions for The driver is advised to read all sections • WARNING City Safety in the Owner's Manual that relate to City The City Safety is supplementary driver • Safety to learn about factors such as its City Safety can avoid a collision with a vehicle, a support intended to improve driving safety limitations and what the driver should be...
  • Page 352 DRIVER SUPPORT Subfunctions for City Safety City Safety can detect pedestrians, cyclists or 1 - Collision warning vehicles that are stationary or moving in the same The driver is first warned of a potentially immi- direction as the car and are ahead. City Safety nent collision.
  • Page 353 DRIVER SUPPORT Setting the warning distance for City The driver can always interrupt a braking inter- 3 - Auto Brake Safety vention by firmly depressing the accelerator The automatic brake function is activated last. pedal. City Safety is always activated but the driver can If in this situation the driver has not yet started to select the warning distance for the function.
  • Page 354 DRIVER SUPPORT Detection of obstacles with City warnings and instead leads to City Safety giving a NOTE Safety warning at a later stage. The warning with direction indicators for Rear The obstructions that City Safety can detect are Late warning distance should therefore only Collision Warning is deactivated if the warn- vehicles, cyclists, large animals and pedestrians.
  • Page 355 DRIVER SUPPORT clearest possible information about the body and Pedestrians City Safety can also detect pedestrians in the bicycle outline, requiring the ability to identify the dark if they are illuminated by the car's head- bicycle, head, arms, shoulders, legs, upper and lamps.
  • Page 356 DRIVER SUPPORT City Safety in cross traffic Large animals WARNING City Safety can help the driver when turning and City Safety is supplementary driver support, crossing the path of another oncoming vehicle at but it cannot detect all large animals in all sit- an intersection.
  • Page 357 DRIVER SUPPORT Limitations for City Safety in cross The following further criteria must also be fulfil- Related information traffic led: City Safety™ (p. 348) • In some cases City Safety may have difficulty your car must be travelling at no less than •...
  • Page 358 DRIVER SUPPORT City Safety steering assistance for straighten the car again after passing the obsta- NOTE evasive manoeuvre cle. The function uses the car's combined Camera City Safety steering assistance can assist the City Safety steering assistance can detect: and Radar unit, which has certain general lim- driver to steer away from a vehicle/obstacle itations –...
  • Page 359 DRIVER SUPPORT Limitations of City Safety steering City Safety when evasive has the opportunity to avoid a collision via a assistance when taking evasive manoeuvres are prevented steering manoeuvre. action City Safety has the facility to assist the driver by However, if City Safety anticipates that an evasive automatically braking the car earlier when it is City Safety may have limited functionality in cer-...
  • Page 360 DRIVER SUPPORT City Safety brakes for oncoming Limitations for City Safety when evasive For this function to work, the following criteria vehicles* must be met: manoeuvres are prevented City Safety can assist the driver to use emer- your car must be travelling at more than •...
  • Page 361 City Safety™ (p. 348) • In the event of high passenger compartment workshop - an authorised Volvo workshop is Limitations of City Safety (p. 359) • temperature caused by e.g. strong sunlight, the recommended.
  • Page 362 DRIVER SUPPORT Driver intervention Miscellaneous Warnings and brake interventions for • pedestrians and cyclists are deactivated Reversing at vehicle speeds exceeding 80 km/h WARNING When your own car is reversing, City Safety is (50 mph). temporarily deactivated. Warnings and brake interventions could •...
  • Page 363 DRIVER SUPPORT Related information City Safety™ (p. 348) • Limitations for camera unit (p. 345) • Limitations for radar device (p. 335) •...
  • Page 364 When City Safety brakes or has done an automatic braking, several of the driver display symbols may be illuminated in connection with a text message being shown. Automatic intervention City Safety The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Reduced functionality Service required...
  • Page 365 DRIVER SUPPORT Rear Collision Warning Limitations of Rear Collision NOTE Warning The Rear Collision Warning (RCW) function can The warning with direction indicators for Rear help the driver to avoid being hit by a vehicle In certain cases the RCW may have difficulty Collision Warning is deactivated if the warn- approaching from behind.
  • Page 366 DRIVER SUPPORT BLIS* from a constant glow to flashing with a more intense light. The BLIS function is intended to help the driver detect vehicles diagonally behind and to NOTE the side of the car so as to provide assistance in heavy traffic on roads with several lanes in the The lamp illuminates on the side of the car same direction.
  • Page 367 DRIVER SUPPORT Activate/deactivate BLIS Related information If BLIS was deactivated when the engine was switched off, it will continue to be deactivated Activate/deactivate BLIS (p. 365) • The BLIS function can be activated/deacti- when the engine is next started and no indicator Limitations of BLIS (p.
  • Page 368 DRIVER SUPPORT Limitations of BLIS Recommended maintenance for WARNING BLIS The BLIS function may have limitations in cer- BLIS does not work on sharp bends. • tain situations. To ensure optimal functionality, the surfaces BLIS does not work when the car is •...
  • Page 369 DRIVER SUPPORT IMPORTANT Repair of the BLIS and CTA functions' com- ponents or repainting the bumpers must only be performed by a workshop - an authorised Volvo workshop is recommended. Related information • BLIS* (p. 364) Cross Traffic Alert* (p. 369) •...
  • Page 370 Message Specification Blind spot sensor The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Service required Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system.
  • Page 371 DRIVER SUPPORT Cross Traffic Alert* CTA is only active if the car rolls backwards or if WARNING reverse gear has been selected. is a driver support that supplements The Cross Traffic Alert function is supple- • If CTA senses that something is approaching BLIS and is designed to help the driver detect mentary driver support intended to facili-...
  • Page 372 DRIVER SUPPORT Activate/deactivate Cross Traffic Limitations of Cross Traffic Alert Alert The CTA function may have limitations in cer- tain situations. The driver can choose to switch off the CTA function as follows: CTA does not perform optimally in all situations but has some limitations.
  • Page 373 • be performed by a workshop - an authorised in front of the sensors must be kept clean. section "Recommended maintenance for Volvo workshop is recommended. Cross Traffic Alert". Do not affix any objects, tape or labels in the •...
  • Page 374 Message Specification Blind spot sensor The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Service required Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system.
  • Page 375 DRIVER SUPPORT Road Sign Information* WARNING The Road Sign Information function (RSI ) can The Road Sign Information function is • help the driver to observe speed-related road supplementary driver support intended to signs and certain prohibition signs. facilitate driving and make it safer – it cannot handle all situations in all traffic, weather and road conditions.
  • Page 376 DRIVER SUPPORT Activating/deactivating Road Sign Road Sign Information with Speed Camera • NOTE Information Information (p. 379) If the Automatic Speed Limiter function is • Limitations of Road Sign Information • activated, road sign information is shown The Road Sign Information function is selectable (p.
  • Page 377 DRIVER SUPPORT Road Sign Information and sign If the car is equipped with Sensus Navigation*, An additional sign, such as display direct speed limit signs are normally displayed – "no overtaking", may be shown indirect speed limit signs are only displayed if together with the speed limit The Road Sign Information function (RSI map data has no information on the speed limit...
  • Page 378 DRIVER SUPPORT Example of direct speed limit Additional signs Some speed limits only apply after a certain distance or at a sign certain time of day. The driver's attention is drawn to this fact by means of a symbol for an additional sign below the speed symbol.
  • Page 379 DRIVER SUPPORT Road Sign Information and Sensus Road Sign Information with Speed Related information Navigation Warning and Settings Road Sign Information* (p. 373) • Speed Limit Warning Activating/deactivating Road Sign Informa- The subfunction • If the car is equipped with Sensus Navigation, is selectable - the driver can select On or tion (p.
  • Page 380 DRIVER SUPPORT Activating/deactivating Speed Settings 2. Select/deselect Road Sign Audio Warning warning in Road Sign Information to activate/switch off the acoustic warning. Adjust the limit for Speed Warning Road Sign Audio Warning The driver can select to receive a warning at a With the function Speed Limit Warning...
  • Page 381 DRIVER SUPPORT Road Sign Information with Speed For more information about speed warning in Related information Camera Information connection with speed camera - see also the Road Sign Information* (p. 373) • sections "Road Sign Information with Speed Road Sign Information with Speed Warning A car equipped with RSI and Sensus •...
  • Page 382 DRIVER SUPPORT Limitations of Road Sign Driver Alert Control NOTE Information The Driver Alert Control (DAC) function is The function uses the car's camera unit, intended to help make the driver aware that he The Road Sign Information (RSI ) function may which has some general limitations, see the or she is starting to drive less consistently, e.g.
  • Page 383 DRIVER SUPPORT A camera detects the edge markings painted on The warning is repeated after a time if driving WARNING the carriageway and compares the alignment of behaviour has not improved. An alarm from Driver Alert Control should be the road with the driver’s steering wheel move- taken very seriously, as a sleepy driver is often ments.
  • Page 384 DRIVER SUPPORT Activate/deactivate Driver Alert Select rest stop guidance in the Limitations of Driver Alert Control Control event of a warning from Driver Alert The Driver Alert Control (DAC) function may Control The Driver Alert Control (DAC) function can be have limitations in certain situations.
  • Page 385 DRIVER SUPPORT Lane assistance The function of the Lane Keeping Aid (LKA ) is to help the driver to reduce the risk of the car accidentally leaving its own lane on motorways and similar major routes. Lane Keeping Aid steers the car back into its lane and/or alerts the driver with vibrations in the steering wheel.
  • Page 386 DRIVER SUPPORT Lane assistance does not intervene Lane assistance symbols in the driver display • NOTE (p. 389) When a direction indicator is switched on, there are no steering corrections or alerts from Lane assistance. WARNING The Lane Keeping Aid function is supple- •...
  • Page 387 DRIVER SUPPORT Steering assistance with lane Activate/deactivate Lane Keeping comes on and the following message is dis- assistance played: For LKA steering assistance to work, the The lane assistance LKA function is selecta- ble - the driver can select On or Off. driver must have his/her hands on the steering –...
  • Page 388 DRIVER SUPPORT Select assistance option for lane Limitations of Lane assistance Related information assistance Lane assistance (p. 383) • In certain demanding conditions Lane assis- tance may have difficulty helping the driver cor- Speed-dependent steering force (p. 280) The driver can select how LKA should react if •...
  • Page 389 Specification Driver support system The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Reduced functionality Service required Windscreen sensor The ability of the camera to scan the roadway in front of the car is reduced.
  • Page 390 A text message can be cleared by briefly press- ing the button, located in the centre of the steering wheel's right-hand keypad. If a message remains: Contact a workshop – an authorised Volvo workshop is recommended. Related information Lane assistance (p. 383) •...
  • Page 391 DRIVER SUPPORT Lane assistance symbols in the Related information Unavailable driver display Lane assistance (p. 383) • Lane assistance LKA is visualised by symbols in the driver display depending on the situation. Here are some examples of symbols and the situations in which they are shown: Unavailable —...
  • Page 392 DRIVER SUPPORT Steering assistance at risk of Activating/deactivating Steering Related information collision assistance in the event of a collision Activating/deactivating Steering assistance • risk in the event of a collision risk (p. 390) Collision avoidance assistance function Symbols and messages for steering assis- is designed to help the driver reduce the risk of The function can be selected - the driver can •...
  • Page 393 DRIVER SUPPORT Steering assistance upon risk of Steering assistance level in the WARNING run-off event of a run-off risk The "Steering assistance at risk of lane • The subfunction's task is to help the driver The function has two activation levels on inter- departure"...
  • Page 394 DRIVER SUPPORT Activating/deactivating Steering Related information Steering assistance with brake intervention assistance in the event of run-off Steering assistance at risk of collision • risk (p. 390) Steering assistance upon risk of run-off The function can be selected - the driver can •...
  • Page 395 DRIVER SUPPORT Limitations for steering assistance Steering assistance upon risk of Related information upon risk of running off the road head-on collision Steering assistance at risk of collision • (p. 390) In certain demanding conditions the function The subfunction can help a distracted driver who may have difficulty helping the driver correctly.
  • Page 396 DRIVER SUPPORT Activating/deactivating Steering However, the function does not intervene with Related information assistance in the event of a collision steering assistance if the direction indicator is Steering assistance at risk of collision • risk with oncoming used. And if the function detects that the driver is (p.
  • Page 397 DRIVER SUPPORT Limitations for steering assistance Shift between On and Off cases it is recommended to switch off this func- upon risk of head-on collision using this button in the centre tion. display's function view. In certain situations the function may have lim- NOTE ited functionality and fail to intervene in the fol- This function is activated auto-...
  • Page 398 A text message can be cleared by briefly press- ing the button, located in the centre of the steering wheel's right-hand keypad. If a message remains: Contact a workshop – an authorised Volvo workshop is recommended. Related information Steering assistance at risk of collision • (p. 390)

  • Page 399: Park Assist

    DRIVER SUPPORT Park Assist* The shorter the distance to the obstacle, the WARNING faster the signal sounds. Other sound from the The Park Assist Pilot function can assist the The Park Assist function is supplemen- • audio system is muted automatically. driver when manoeuvring in tight spaces by indi- tary driver support intended to facilitate cating the distance to obstacles through acous-...

  • Page 400: Park Assist Pilot Front, Rear And Along The Sides

    NOTE obstacle. When reversing with e.g. a trailer or bike car- rier on the towbar - without Volvo genuine Backwards trailer wiring - parking assistance may need to be switched off manually in order that the sensors do not react to them.

  • Page 401: Activating/Deactivating Park Assist Pilot

    DRIVER SUPPORT Activating/deactivating Park Assist Along the sides Related information Pilot Park Assist* (p. 397) • The Park Assist Pilot function can be activated/ Sensor fields from Park Assist Pilot for park- • deactivated. ing camera (p. 408) On/Off The front and side parking assistance sensors are activated automatically when the engine is started.

  • Page 402: Limitations Of Parking Assistance

    DRIVER SUPPORT Limitations of Parking assistance IMPORTANT NOTE The Parking Assistance System cannot detect Objects e.g. chains, thin glossy poles or low Since a towbar is configured with the car's everything in all situations and may therefore barriers may be in the "signal shadow" and electrical system, towbar protrusion is have limited functionality in some cases.

  • Page 403: Recommended Park Assist Pilot Maintenance

    DRIVER SUPPORT Recommended Park Assist Pilot maintenance For the Park Assist Pilot function to work opti- mally, its sensors must be cleaned regularly with water and car shampoo. Location of the parking sensors NOTE Dirt, ice and snow covering the sensors may cause incorrect warning signals, reduced or no function.
  • Page 404 One or more of the function's sensors are blocked - check and correct as soon as possible. Sensors blocked, cleaning nee- Park Assist System The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Unavailable Service required...

  • Page 405: Park Assist Camera

    DRIVER SUPPORT Park assist camera* Lines - activates/deactivates park assist lines The park assist camera can assist the driver Towbar* - activates/deactivates the towbar when manoeuvring in tight spaces by indicating obstacles with a camera image and graphics in park assist line* the centre display.

  • Page 406: Parking Cameras' Camera Views

    DRIVER SUPPORT Parking cameras' camera views Recommended parking camera maintenance • WARNING (p. 411) The function can display a composite 360° view The parking camera function is supple- • Symbols and messages for Park assist cam- • and separate views for each of the four cameras: mentary driver support intended to facili- era (p.
  • Page 407 DRIVER SUPPORT A camera symbol on the centre Objects shown in the centre display may appear 360° view* display's car symbol indicates slightly tilted — this is normal. which of the cameras is active. Forwards If the car is also equipped with Park Assist System * then distance to detected obstacles...

  • Page 408: Park Assist Lines For Parking Camera

    DRIVER SUPPORT Park assist lines for parking camera reversing into tight spaces and when connecting The sides a trailer. The Park assist cameras indicate the position of the car in relation to its surroundings by display- The lines on the screen are projected as if they ing lines on the screen.
  • Page 409 DRIVER SUPPORT Park assist lines in 360° view* Towbar assist line* IMPORTANT Remember, that with the rear camera • view selected, the monitor only displays the area behind the car. Be aware of the sides and front of the car when manoeu- vring in reverse.

  • Page 410: Sensor Fields From Park Assist Pilot For Parking Camera

    DRIVER SUPPORT Sensor fields from Park Assist Pilot 1. Press Towbar (1). The fields for the sensors for forwards and for parking camera reverse change colour as the distance to the > The park assist lines for the towbar's obstacle decreases – from AMBER through intended "path"...

  • Page 411: Starting The Park Assist Camera

    DRIVER SUPPORT Starting the park assist camera Right-hand side rear sensor field Sensor field to the sides Warning signals depend on the intended route of The park assist camera starts automatically Obstacle sector in the car's intended route in the car. When the steering wheel is turned, there- when reverse gear is engaged or manually with reverse –...

  • Page 412: Limitations For Park Assist Camera

    DRIVER SUPPORT Limitations for park assist camera Related information Blind sectors Park assist camera* (p. 403) • The park assist camera cannot detect everything in all situations and may therefore have limited functionality. A driver should be aware about the following examples of the park assist camera's limitations: WARNING Pay additional attention...

  • Page 413: Recommended Parking Camera Maintenance

    DRIVER SUPPORT Recommended parking camera Defective camera of this, the image may vary slightly in brightness maintenance and quality. Poor light conditions can result in If a camera sector is black and reduced image quality. contains this symbol then it The parking cameras positioned beside the rear means that the camera is out number plate holder, in the grille and in both...
  • Page 414 One or more of the function's sensors are blocked - check and correct as soon as possible. Sensors blocked, cleaning needed Park Assist System The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Unavailable Service required Related information A text message can be cleared by briefly press- If a message remains: Contact a workshop –...
  • Page 415 DRIVER SUPPORT Parking variants with Park Assist Park Assist Pilot* NOTE Pilot Park Assist Pilot (PAP ) helps the driver to The PAP function measures the space and park in or leave a parking space. Park Assist Pilot PAP can be used for the fol- steers the car - the driver's task is to: lowing different parking situations.
  • Page 416 DRIVER SUPPORT Parking with Park Assist Pilot Related information Perpendicular parking Park Assist Pilot* (p. 413) • Park Assist Pilot (PAP ) helps the driver park Leaving a car park with Park Assist Pilot via three steps. The function can also help the •...
  • Page 417 DRIVER SUPPORT 2. Tap on the Park In button in the function NOTE view or in the camera view. The distance between the car and parking > PAP searches for a parking space and spaces should be 0.5-1.5 metres (1.6-5.0 ft) checks whether it is big enough.
  • Page 418 DRIVER SUPPORT Perform the following to reverse the car into the Reversing in to the parking space Positioning the car in the parking space parking space: 1. Check that the area behind the car is clear, then engage reverse gear. 2.
  • Page 419 DRIVER SUPPORT Leaving a car park with Park Assist 2. Be prepared to stop the car when instructed need to turn the steering wheel back to the maxi- Pilot by the graphic and message on the centre mum steering angle in order to leave the parking display.
  • Page 420 DRIVER SUPPORT Limitations of Park Assist Pilot* A driver should be aware about the following IMPORTANT examples of Park Assist Pilot limitations: The Park Assist Pilot PAP function cannot Under certain circumstances, PAP is unable detect everything in all situations and may there- Parking is discontinued to find parking spaces - one reason for this fore have limited functionality.
  • Page 421 PAP system's parameters may then need to measure the parking space incorrectly. be updated. Consult a workshop - an author- During the search and check-measurement ised Volvo workshop is recommended. • of the parking space, PAP may miss objects positioned deep in the parking space.
  • Page 422 One or more of the function's sensors are blocked - check and correct as soon as possible. Sensors blocked, cleaning needed Park Assist System The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Unavailable Service required...

  • Page 423: Starting And Driving

    STARTING AND DRIVING...

  • Page 424: Starting The Car

    STARTING AND DRIVING Starting the car The remote control key is not physically used when starting the car since it is equipped with The car is started using the start knob in the tun- support for keyless starting (Passive start). nel console when the remote control key is in the passenger compartment.

  • Page 425: Switching Off The Car

    STARTING AND DRIVING Switching off the car Adjusting the steering wheel (p. 193) • IMPORTANT Using jump starting with another battery • The car is switched off using the start knob in If the engine fails to start after 3 attempts - (p.

  • Page 426: Ignition Positions

    STARTING AND DRIVING Ignition positions Using jump starting with another battery • Level Functions (p. 470) The car's electrical system can be set in different Odometer, clock and temperature • Selecting ignition mode (p. 425) • levels/positions and in this way make the differ- gauge are illuminated ent functions available.

  • Page 427: Selecting Ignition Mode

    STARTING AND DRIVING Selecting ignition mode Ignition position I - Turn the start knob • Level Functions clockwise and release it. The control auto- The car's electrical system can be set in different The headlamps come on. matically returns to its starting position. •...

  • Page 428: Alcohol Lock

    The car has an interface for the electrical con- nection of the different makes and models of All bypass activation is logged and saved in alcohol lock recommended by Volvo. The inter- the memory in the alcohol lock's control unit. face facilitates alcohol lock connection, and gives It is not possible to undo a bypass.

  • Page 429: Before Starting The Engine With The Alcohol Lock

    STARTING AND DRIVING Before starting the engine with the Brake functions Foot brake alcohol lock The car's brakes are used to reduce the speed The foot brake is part of the brake system. The alcohol lock is activated automatically and is or prevent the car from rolling.

  • Page 430: Brake Assistance

    The brake force can be boosted up to the brake pedal. system checked - an authorised Volvo level when the ABS system is engaged. The workshop is recommended. function is suspended when the pressure on the Symbols in the driver display brake pedal decreases.

  • Page 431: Braking On Wet Roads

    To keep the car as safe and reliable as possible, brakes. therefore maintain a greater safety distance to follow the Volvo service intervals as specified in This may also be the case after a car wash. It is vehicles in front. In addition, make sure you do the Service and Warranty Booklet.

  • Page 432: Parking Brake

    STARTING AND DRIVING Parking brake Activating and deactivating the Related information parking brake Activating and deactivating the parking brake • The parking brake prevents the car from rolling (p. 430) away from stationary by means of mechanically Use the parking brake to prevent the car from locking/blocking two wheels.
  • Page 433 STARTING AND DRIVING Deactivating the parking brake 4. With automatic gearbox: Automatic activation The parking brake is activated automatically: Select gear position D or R and depress the accelerator pedal. when the car is switched off and the setting • for automatic activation of the parking brake With manual gearbox: is activated in the centre display.

  • Page 434: Automatic Parking Brake Activation Setting

    Always use the parking brake when parking on a Choose whether the parking brake is to be acti- hill. Contact an authorised Volvo workshop if it is not vated automatically when the car is switched off. possible to deactivate or activate the parking WARNING brake after several attempts.

  • Page 435: Automatic Braking When Stationary

    Help when starting on a hill (p. 434) • (p. 430) released to ensure the car does not roll. Starter battery (p. 607) • Volvo service programme (p. 592) • The parking brake is activated if: the car is switched off • the driver's door is opened •...

  • Page 436: Activating And Deactivating The Automatic Brake At A Standstill

    STARTING AND DRIVING Activating and deactivating the Help when starting on a hill The function remains deactivated until it is • automatic brake at a standstill reactivated. Hill start assist, Hill Start Assist (HSA), prevents When the function is deactivated, hill start The automatic brake function at a standstill is •...

  • Page 437: Auto Braking After A Collision

    STARTING AND DRIVING Auto braking after a collision Gearbox Brake functions (p. 427) • In the event of a collision in which the activation The gearbox is part of the car's powertrain level is reached for the pyrotechnic seatbelt ten- (power transmission) between engine and drive sioners or airbags, or if a collision with a large wheels.

  • Page 438: Manual Gearbox

    STARTING AND DRIVING Manual gearbox Symbols in the driver display Follow the shifting pattern on the gear lever • and start from neutral position before moving If a fault should occur in the gearbox, the driver With a manual gearbox, the driver selects a suit- it to the R position.

  • Page 439: Gear Positions For Automatic Gearbox

    STARTING AND DRIVING Gear positions for automatic Select the P position when the car is parked or Drive position - D gearbox when starting the engine. The car must be sta- D is the normal driving position. Shifting up and tionary when the park position is selected.

  • Page 440: Changing Gear With Steering Wheel Paddles

    STARTING AND DRIVING Changing gear with steering wheel ate for the selected gear, in order to avoid jerking Manual gearshift mode - M paddles* and stalling. The manual gearshift mode can be selected at any time while driving. The car engine-brakes To return to automatic gear changing, press the The steering wheel paddles are a complement when the accelerator pedal is released.
  • Page 441 STARTING AND DRIVING In gear position M the steering wheel paddles are This is indicated by means of the figure for the automatically activated. current gear extinguishing. The exception is dur- ing engine braking - then the paddles are acti- vated for as long as engine braking is in pro- gress.

  • Page 442: Gear Selector Inhibitor

    STARTING AND DRIVING Gear selector inhibitor Deactivate automatic gear selector From park position - P inhibitor To select a gear position other than the P posi- The gear selector inhibitor prevents accidental tion, the brake pedal must be depressed and the changing between different gear positions in an If there is no power to the car, the automatic ignition position must be II.

  • Page 443: Kick-Down Function

    STARTING AND DRIVING Kick-down function Gear shift indicator Related information Gear selector inhibitor (p. 440) • The gear shift indicator in the driver display Kick-down is used when maximum acceleration shows the current gear during manual gearshift- Gear positions for automatic gearbox •...
  • Page 444 STARTING AND DRIVING With automatic gearbox The gear shift indicator shows the current gear in the driver display and uses an up arrow to indi- cate when shifting to a higher gear is recom- mended. Gear shift indicator in the 8-inch driver display. Gear shift indicator in the 8-inch driver display.

  • Page 445: All-Wheel Drive

    STARTING AND DRIVING All-wheel drive* Drive modes* When the car starts, it is in Comfort mode and the Start/Stop function is activated. These set- All-wheel drive, AWD (All Wheel Drive), means Selection of drive mode affects the car's driving tings make the car feel comfortable, the steering that the car is driving all four wheels at the same characteristics in order to enhance the driving and shock absorbers are adapted for normal driv-...
  • Page 446 STARTING AND DRIVING 3. In Presets , select a drive mode to start from: DYNAMIC Comfort Dynamic Dynamic mode means that the car has sport- • ier characteristics and faster response to Possible adjustments apply to settings for: accelerating. Driver Display •...

  • Page 447: Changing Drive Mode

    STARTING AND DRIVING Drive mode ECO Changing drive mode* 3. Press the drive mode control or tap directly on the touch screen to confirm the selection. Select the drive mode that best suits the current Drive mode Eco optimises the car's driving cha- >...
  • Page 448 STARTING AND DRIVING the accelerator pedal the gearbox is automatically The speed is outside the range of Cruise control Eco Cruise • disengaged from the engine whose speed is approx. 65-140 km/h (40-87 mph). When using the cruise control in the Eco drive reduced to idling speed with reduced consump- mode, the car's acceleration and deceleration will The road's downhill gradient is steeper than...
  • Page 449 STARTING AND DRIVING Eco gauge in the driver display With fuel-efficient driving, the gauge shows a Related information • low value with the pointer in the green zone. Changing drive mode* (p. 445) • With non-fuel-efficient driving, e.g. during • Activating and deactivating drive mode ECO •...

  • Page 450: Activating And Deactivating Drive Mode Eco With The Function Button

    STARTING AND DRIVING Activating and deactivating drive Start/Stop function Driving with start/stop function mode ECO with the function button With the Start/Stop function, the engine The Start/Stop function temporarily switches off There is a function button for Eco driving mode switches off temporarily when the car has stop- the engine when stationary and then restarts it in the centre display's function view unless the...
  • Page 451 STARTING AND DRIVING With automatic gearbox the accelerator pedal is depressed, or by No text is shown when the function is deacti- • vated. pressing the button on the left keypad Stop the car with the foot brake and then •...

  • Page 452: Deactivating The Start/Stop Function Temporarily

    STARTING AND DRIVING Deactivating the Start/Stop function Conditions for the Start/Stop With 8-inch driver display temporarily function The symbol is shown in the lower edge of the speedometer. In certain situations it may be desirable to tem- For the Start/Stop function to work requires that porarily deactivate the start/stop function.
  • Page 453 STARTING AND DRIVING The driver makes sweeping steering wheel With automatic gearbox: High humidity in the passenger compartment • • movements. forms misting on the windows. The driver is unbelted, the gear selector is in • The road is very steep. The environment in the passenger compart- •...
  • Page 454 STARTING AND DRIVING Related information Start/Stop function (p. 448) • Driving with start/stop function (p. 448) • Deactivating the Start/Stop function tempo- • rarily (p. 450)

  • Page 455: Level Control* And Shock Absorption

    STARTING AND DRIVING Level control* and shock absorption Shock absorption (Four-C) the best possible comfort and is regulated con- tinuously depending on the road surface, the The shock absorption is adapted according to the Level control and shock absorption are regula- car's acceleration, braking and cornering.
  • Page 456 Stop safely Suspension A fault has occurred. If the message appears whilst driving, contact a workshop Slow down Car too high An authorised Volvo workshop is recommended. Related information • Settings for level control* (p. 455) Drive modes* (p. 443) •...

  • Page 457: Settings For Level Control

    STARTING AND DRIVING Economical driving Settings for level control* Do not run the engine to operating tempera- • ture at idling speed, but rather drive with a Switch off the level control when the car is to be Drive economically and in a more eco-friendly normal load right after starting –...

  • Page 458: Preparations For A Long Trip

    STARTING AND DRIVING Preparations for a long trip Settings for car modem (p. 529) • WARNING Recommendations for loading (p. 580) Before a driving holiday or some other type of • Never switch off the engine while moving, long journey, it is important to check the car's such as downhill, this deactivates important Driving with a trailer (p.

  • Page 459: Winter Driving

    Winter driving Driving in water Slippery driving conditions To achieve optimum roadholding Volvo recom- For winter driving it is important to perform cer- Driving in water means that the car is driven in a mends using winter tyres on all wheels if there is...

  • Page 460: Opening And Closing The Fuel Filler Flap

    The filler pipe has two opening caps. The pump nozzle must be pushed past both caps before refuelling is started. Only locking and unlocking with the remote control key, keyless or via Volvo On Call affects the status of the fuel filler flap.

  • Page 461: Handling Of Fuel

    4. Do not overfill the tank but fill until the pump nozzle cuts out the first time. Do not use fuel with a lower quality than that rec- > The tank is full. ommended by Volvo, as this will negatively affect engine power and fuel consumption. NOTE WARNING...

  • Page 462: Petrol

    • cars with a petrol engine. which are not recommended will invalidate ing the catalytic converter. Volvo's guarantees and any supplementary Only use petrol from well-known producers. Fuel containing metallic additives must • service agreements; this is applicable to all Never use fuel of dubious quality.

  • Page 463: Petrol Particle Filter

    STARTING AND DRIVING Petrol particle filter Diesel larly drive at higher speeds to allow the petrol emission control system to regenerate. Petrol cars are fitted with particle filters for more Diesel is a type of engine fuel that is intended for efficient emission control.

  • Page 464: Empty Tank And Diesel Engine

    Volvo recommendations and NOTE generate increased wear and engine damage Before filling with fuel in the event of fuel that is not covered by the Volvo warranty. shortage: Stop the car on as flat/level ground as • Related information possible - if the car is tilting there is a risk Handling of fuel (p.

  • Page 465: Diesel Particulate Filter

    STARTING AND DRIVING Diesel particulate filter Points to remember when filling with a When driving short distances at low fuel can speeds in a diesel car Diesel cars are fitted with particle filters for more When filling diesel with a fuel can, use the funnel The capacity of the diesel emission control sys- efficient emission control.

  • Page 466: Emission Control With Adblue

    STARTING AND DRIVING ®17 ®20 Emission control with AdBlue If something is wrong, a message is shown in the Handling AdBlue driver display. AdBlue consists primarily of water (approx. AdBlue is an additive used in the SCR system 67.5% water and 32.5% urea). The fluid is not to reduce emissions of noxious substances from IMPORTANT flammable but should be handled with care...

  • Page 467: Checking And Filling With Adblue

    30 °C (86 °F). The fluid must not be the driver display. stored in direct sunlight. The Volvo workshop tops up AdBlue when the AdBlue freezes at -11 °C (12 °F) but can be car is serviced, however, it must also be topped used again when the solution has thawed.
  • Page 468 STARTING AND DRIVING Filling 3. Fill with AdBlue of the correct quality When the AdBlue level starts Do not overfill the tank. The amount of to become low, a symbol illumi- AdBlue that can be filled is shown in the app nates in the driver display and Car Status AdBlue level low...

  • Page 469: Symbols And Messages For Adblue

    STARTING AND DRIVING Symbols and messages for ®23 AdBlue The emission control system continuously moni- tors the level, quality and dosage of AdBlue. If something is wrong, a message is shown in the driver display. Symbol Message Specification AdBlue level low The AdBlue level is low and the tank needs to be topped up.
  • Page 470 Engine start prohibited The system does not function as it should. Contact a workshop to check the function. Service of AdBlue system needed to allow restart An authorised Volvo workshop is recommended. Related information ® • Checking and filling with AdBlue (p.

  • Page 471: Overheating In The Engine And Drive System

    STARTING AND DRIVING Overheating in the engine and drive Transmission warm Reduce speed to Symbols in the driver display system lower temperature Transmission hot Symbol Specification Stop safely, wait for cooling . Follow the Under special conditions, for example hard driv- recommendation given, reduce speed or stop High engine temperature.

  • Page 472: Overloading The Starter Battery

    STARTING AND DRIVING Overloading the starter battery Using jump starting with another 4. Connect one of the red jump lead's clamps battery to the donor battery's positive terminal (1). The electrical functions in the car load the starter battery to varying degrees. Avoid using the igni- If the starter battery is discharged then the car IMPORTANT tion position II when the car is switched off.

  • Page 473: Towbar

    There may be different towbar variants available and car during the starting attempt. There is a the battery to explode. for the car. Contact a Volvo dealer for more infor- risk of sparks forming. mation. Do not connect the jump leads to any •...

  • Page 474: Specifications For Towbar

    STARTING AND DRIVING Specifications for towbar* Related information Dimensions, mounting points in mm (inches) Extendable and retractable towbar* (p. 473) • Dimensions and mounting points for towbar. 1121,9 (44,2) Driving with a trailer (p. 475) • 81,5 (3,2) Towbar-mounted bicycle rack* (p. 478) •...

  • Page 475: Extendable And Retractable Towbar

    STARTING AND DRIVING Extendable and retractable towbar* The extendable/retractable towbar is always easily accessible and simple to extend or retract as needed. In the retracted position, the towbar is completely concealed. WARNING Follow the instructions for retracting and extending the towbar carefully. Extending the towbar Press and release the button - extension might not start if the button is pressed for too...
  • Page 476 STARTING AND DRIVING Retracting the towbar IMPORTANT Make sure that there is no plug or adapter in the electrical socket when retracting the tow- bar. 1. Open the tailgate. Press and release the but- ton on the right-hand side at the rear of the cargo area - retraction might not start if the button is pressed for too long.

  • Page 477: Driving With A Trailer

    (up The brakes are loaded much more than usual • nector. Use an adapter approved by Volvo. Make to the maximum permissible weight). When the on long and steep downhill slopes. Downshift sure the cable does not drag on the ground.

  • Page 478: Trailer Stability Assist

    STARTING AND DRIVING Trailer stability assist* When driving in hilly terrain and hot Related information climates Trailer stability assist* (p. 476) • The function of trailer stability assist (TSA ) is Under certain circumstances, there may be a risk Checking trailer lamps (p. 477) •...

  • Page 479: Checking Trailer Lamps

    STARTING AND DRIVING Checking trailer lamps Related information enough to help the driver regain control of the car. Driving with a trailer (p. 475) • When connecting a trailer - check that all the trailer lamps work before departure. If snaking is not eliminated the first time that Electronic stability control (p.

  • Page 480: Towbar-Mounted Bicycle Rack

    Volvo's bicycle racks are availa- fog lamp to travel safely. ble for purchase at authorised Volvo dealers.

  • Page 481: Towing

    STARTING AND DRIVING Towing The car's driving characteristics are affected ity and increase fuel consumption. It may also when a bicycle rack is fitted on the towbar. For lead to an increased load on the towbar. During towing, the car is towed by another vehi- example, due to: cle by means of a towline.

  • Page 482: Fitting And Removing The Towing Eye

    STARTING AND DRIVING Fitting and removing the towing eye Jump starting WARNING Do not tow the car to jump start the engine. Use Use the towing eye for towing. The towing eye is The brake servo and power steering do not a donor battery if the starter battery is discharged screwed into a threaded socket behind a cover work when the engine is switched off - the...
  • Page 483 STARTING AND DRIVING 4. Screw the towing eye right in until it stops. Screw the eye in firmly. For example, thread Front: Remove the cover - press on the Rear: Remove the cover - press on the mark- through the wheel bolt wrench* and use it as marking with a finger.

  • Page 484: Recovery

    STARTING AND DRIVING Recovery Removing the towing eye Points to remember before using the towing Unscrew and remove the towing eye after – For recovery, the car is taken away with the help use and return it to its place in the foam The towing eye may be used to pull the car •...

  • Page 485: Homelink

    STARTING AND DRIVING ® ® HomeLink HomeLink is supplied built-in to the interior IMPORTANT ® rearview mirror. The HomeLink panel consists of ®28 HomeLink is a programmable remote control, Note that the car must always be transported three programmable buttons and one indicator integrated in the car's electrical system, which with the wheels rolling forward.

  • Page 486: Programming Homelink

    STARTING AND DRIVING ® Programming HomeLink 1. Aim the remote control towards the 3. Do not release the buttons until the indicator ® lamp has switched from flashing slowly HomeLink button to be programmed and Follow these instructions to program (approx.
  • Page 487 STARTING AND DRIVING www.youtube.com/HomeLinkGentex or call the Related information toll-free number 00 8000 466 354 65 (or the ® • Using HomeLink * (p. 486) toll number +49 6838 907 277) ® • HomeLink * (p. 483) Reprogramming individual buttons ®...

  • Page 488: Using Homelink

    STARTING AND DRIVING ® ® Using HomeLink Related information Type approval for HomeLink ® • HomeLink * (p. 483) ® When HomeLink is fully programmed it can be Type approval for EU ® used in place of the separate original remote •...

  • Page 489: Compass

    STARTING AND DRIVING Activating and deactivating the Compass* Calibrating the compass* compass* The upper right-hand corner of the rearview mir- The earth is divided into 15 magnetic zones. The ror has an integrated display that shows the compass should be calibrated if the car is The upper right-hand corner of the rearview mir- compass direction in which the front of the car is moved between several magnetic zones.
  • Page 490 STARTING AND DRIVING 7. Cars with heated windscreen*: If the char- acter is shown in the display when the heated windscreen is activated, perform the calibration in accordance with point 6 above with the heated windscreen activated. 8. Repeat the above procedure as necessary. Related information Compass* (p.
  • Page 491 SOUND, MEDIA AND INTERNET...
  • Page 492 SOUND, MEDIA AND INTERNET Sound, media and Internet Audio settings Related information Media player (p. 501) • The audio and media system consists of media The audio system is preset for optimum sound player and radio. You can also connect a phone Radio (p.
  • Page 493 SOUND, MEDIA AND INTERNET Sound experience* Premium Sound* (Bowers & Wilkins) Related information Tone – settings for bass, treble, equalizer, Sound experience* (p. 491) • • Sound experience is an app that provides etc. access to further audio settings. Media player (p. 501) •...
  • Page 494 SOUND, MEDIA AND INTERNET Apps High Performance Pro* (Harman Kardon) The app view contains applications (apps) that Seat Optimisation - the sound can be opti- • give access to certain of the car's services. mised for Driver Rear Swipe from right to left across the centre dis- Surround - surround sound mode with level...
  • Page 495 SOUND, MEDIA AND INTERNET Downloading apps Start an app by pressing the app in the centre 3. Tap on the row for an app in order to expand display's app view. in the list and get more information about the New apps can be downloaded when the car is app.
  • Page 496 SOUND, MEDIA AND INTERNET Updating apps Deleting apps 2. Select Install all > Updating is started. The apps can be updated when the car is con- Apps can be uninstalled when the car is con- nected to the Internet. nected to the Internet. Update some 1.
  • Page 497 SOUND, MEDIA AND INTERNET Radio Start radio Digital radio* (p. 500) • RDS radio (p. 499) It is possible to listen to the AM and FM bands The radio is started from the centre display app • and to digital radio (DAB)*. When the car is view.
  • Page 498 SOUND, MEDIA AND INTERNET Changing radio band and radio Changing radio band and radio station 2. Select playback from Stations Favourites • station (p. 496) Genres Ensembles Setting radio favourites (p. 497) • There are instructions here for changing the 3.
  • Page 499 SOUND, MEDIA AND INTERNET Searching for radio stations Setting radio favourites Manual tuning The radio automatically compiles a station list of It is possible to add a radio channel to the Radio favourites the radio stations within the area that are trans- app and the favourites list for mitting the strongest signals.
  • Page 500 SOUND, MEDIA AND INTERNET Settings for radio Related information Announcements function must be acti- vated at the same time. Radio (p. 495) • There are various radio functions to activate and News : interrupts the current media play- Start radio (p. 495) deactivate.
  • Page 501 SOUND, MEDIA AND INTERNET RDS radio source is resumed when the message is fin- DAB* (digital radio) ished. Sort Services : option for how channels will • RDS (Radio Data System) means that the radio be sorted. Either alphabetically or by service Traffic Flash : receives information about automatically changes to the strongest transmit-...
  • Page 502 SOUND, MEDIA AND INTERNET Digital radio* Related information DAB subchannel Radio (p. 495) Secondary components are usually named sub- • Digital radio (DAB ) is a digital broadcasting channels. These are temporary and can contain Settings for radio (p. 498) •...
  • Page 503 SOUND, MEDIA AND INTERNET Media player Link between FM and digital radio* Related information Media playback (p. 502) • The function enables the digital radio (DAB) to The media player can play back audio from the switch from a channel with poor or no reception CD player* and from external audio sources con- Controlling and changing media (p.
  • Page 504 SOUND, MEDIA AND INTERNET Media playback Bluetooth connected device 1. Activate Bluetooth in the media source. 1. Insert a CD. The media player is controlled from the centre display. Several functions can also be operated 2. Connect media source. 2. Open the app from the app view.
  • Page 505 SOUND, MEDIA AND INTERNET Controlling and changing media Related information Change track/song - tap on the desired track in Handling the application menu in the driver • the centre display, press on under The playback of media can be controlled with display (p.
  • Page 506 SOUND, MEDIA AND INTERNET Searching media Similar - tap on the button in Media playback (p. 502) • order to use Gracenote to Enter the characters, letters and words man- It is possible to search by artist, composer, song • search for similar music on the ually in the centre display (p.
  • Page 507 SOUND, MEDIA AND INTERNET ® CD player* Gracenote Related information Media playback (p. 502) • The media player can play back CD discs with Gracenote identifies artist, album, song titles License agreement for audio and media compatible audio files. and associated images, which are shown during •...
  • Page 508 SOUND, MEDIA AND INTERNET ® Video Playing a video Playing back DivX ® Videos on USB-connected devices can be Videos are played using the app in the app This DivX Certified device must be registered in played back using the media player. view.
  • Page 509 SOUND, MEDIA AND INTERNET ® ® Settings for video Media via Bluetooth Connecting a device via Bluetooth ® It is possible to change certain video playback The car's media player is equipped with Connect a Bluetooth device to the car for wire- settings, e.g.
  • Page 510 SOUND, MEDIA AND INTERNET Media via USB port Connecting a device via USB port ® ® • Apple CarPlay * (p. 512) ® An external audio source, e.g. an iPod® or MP3 An external audio source, e.g. an iPod or MP3 Android Auto* (p.
  • Page 511 SOUND, MEDIA AND INTERNET Technical specifications for USB Compatible media formats Format File extension devices The following file formats must be used for .avi The following specifications must be met to media playback. allow the contents of the USB devices to be AVI (DivX) .avi, .divx Audio files...
  • Page 512 SOUND, MEDIA AND INTERNET ® Related information DivX Media player (p. 501) DivX certified devices have been tested for high- • No images are shown once the car reaches a quality DivX (.divx, .avi) video playback. When you Video (p. 506) certain speed but the sound will be heard the •...
  • Page 513 SOUND, MEDIA AND INTERNET Using the TV* Settings for TV* TV guide A programme guide is available with information The TV is started from the app view. Tap on the The option to make certain settings is available about TV programmes for up to 48 hours. in the top view or when the TV is in full screen app and select a channel.
  • Page 514 Settings for Apple CarPlay * (p. 514) 1. Connect an iPhone to the USB port. In the note that Volvo is not responsible for the content cases where there are two USB ports, the Voice recognition (p. 137) • in CarPlay.
  • Page 515 SOUND, MEDIA AND INTERNET 5. Tap on the desired app. Switch the connection between CarPlay Connect the car to the Internet via a phone • (Wi-Fi) (p. 528) and iPod > The app starts. Connect the car to the Internet via car •...
  • Page 516 SOUND, MEDIA AND INTERNET ® ® ® ® Settings for Apple CarPlay Related information Tips for using Apple CarPlay ® ® • Apple CarPlay * (p. 512) ® Settings for Apple device connected with Here are some useful tips for using CarPlay ®...
  • Page 517 When you use Android Auto, your car website: www.android.com/auto/. For third-party transfers certain information (including its apps, see Google Play. Please note that Volvo is location) to your connected Android phone. not responsible for the content in Android Auto. You are fully responsible for your and any Android Auto is started from the app view.
  • Page 518 SOUND, MEDIA AND INTERNET Using Android Auto* Settings for Android Auto* 3. If the setting for automatic start is not selected - open the Android Auto app from Android Auto To use the app, the app must be Settings for a phone that has been connected the app view.
  • Page 519 SOUND, MEDIA AND INTERNET Phone Tips for using Android Auto* Related information Android Auto* (p. 515) • Here are some useful tips for using Android A phone with Bluetooth can be connected wire- Auto. lessly to the car's built-in hands-free system. Using Android Auto* (p.
  • Page 520 SOUND, MEDIA AND INTERNET Connecting a phone to the car via Overview Connecting a phone to the car via Bluetooth • Bluetooth for the first time automatically (p. 520) Connecting a phone to the car via Bluetooth • Connect a phone with Bluetooth activated to manually (p.
  • Page 521 SOUND, MEDIA AND INTERNET 2. Open the phone tile in the centre display. Option 2 - search car from phone NOTE 1. Open the phone tile in the centre display. If there is no phone connected to the car, • The message function must be activated •...
  • Page 522 SOUND, MEDIA AND INTERNET Connecting a phone to the car via Removing devices connected to Bluetooth Ignition positions (p. 424) • • Bluetooth automatically (p. 522) Settings for Bluetooth devices (p. 526) • It is possible to connect a phone to the car auto- matically via Bluetooth.
  • Page 523 SOUND, MEDIA AND INTERNET Connecting a phone to the car via Disconnecting a Bluetooth- Switch between Bluetooth- Bluetooth manually connected phone connected phones It is possible to connect a phone to the car man- Disconnect a Bluetooth-connected phone from It is possible to switch between a number of ually via Bluetooth.
  • Page 524 SOUND, MEDIA AND INTERNET Removing devices connected to Managing phone calls Making multi-party calls Bluetooth During a call: Call handling in the car for a Bluetooth-con- It is possible to remove phones from the list of nected phone. 1. Press Add call registered Bluetooth devices, for example.
  • Page 525 Internet. • Answer Press with the steering wheel key- – pad. A dictation dialogue starts. Valid in certain markets only. Contact a Volvo dealer for more information. Only certain phones can broadcast messages from the car. For compatibility, see support.volvocars.com.
  • Page 526 SOUND, MEDIA AND INTERNET Settings for text messages Managing the phone book Message notification It is possible to activate and deactivate notifica- Settings for text messages on connected phone. When a phone is connected to the car with tions in the text message settings. Bluetooth, contacts can be managed directly in 1.
  • Page 527 SOUND, MEDIA AND INTERNET Settings for phone Head-up display* (p. 134) Sorting • The contact list is sorted in alphabetical order Audio settings (p. 490) When the telephone is connected to the car, the • where special characters and numbers are sorted following settings can be made: under .
  • Page 528 SOUND, MEDIA AND INTERNET Settings for Bluetooth devices Internet-connected car* NOTE Settings for Bluetooth-connected devices. When the car is connected to the Internet, it is Data is transferred when using the internet possible – for example – to use web radio and (data traffic), which can have a cost.
  • Page 529 Wi-Fi technologies and security (p. 532) • Connecting a phone to the car via Bluetooth • Volvo ID (p. 26) 3. If the phone has been connected via Blue- • for the first time (p. 518) tooth previously, press...
  • Page 530 (SIM card) for future use. To show a list of saved networks or manually delete saved networks, go to Create an Internet connection via Wi-Fi by teth- For cars equipped with Volvo On Call*, it is pos- Settings Communication Wi-Fi...
  • Page 531 SIM card PIN • Change PIN - a maximum of 4 digits can be entered. Disable PIN - select whether the PIN code shall be required for access to the SIM card. Only cars with Volvo On Call. * Option/accessory.
  • Page 532 SOUND, MEDIA AND INTERNET Sharing Internet access from the The network operator (SIM card) must support NOTE car via a Wi-Fi hotspot tethering (sharing of the Internet connection). Activation of Wi-Fi-hotspot can result in fur- When the car is online, its Internet connection 1.
  • Page 533 SOUND, MEDIA AND INTERNET No or poor Internet connection Remove Wi-Fi network Related information Internet-connected car* (p. 526) • Factors that affect the Internet connection. Removing a network that is not to be used. Wi-Fi technologies and security (p. 532) •...

  • Page 534: User Terms And Conditions And Data Sharing

    NOTE same time then it may result in reduced perform- Data sharing can be set from the centre display's After a visit to a Volvo workshop, you may ance. settings menu. need to reactivate data sharing so that the Related information online services and apps shall work again.

  • Page 535: Storage Space On Hard Disk

    SOUND, MEDIA AND INTERNET Storage space on hard disk It is possible to view how much free space there is on the car's hard disk. Storage information for the car's hard disk, including total capacity, available capacity and how much space is used for installed apps can be shown.

  • Page 536: License Agreement For Audio And Media

    Home Theater video files up to 576p (includ- conditions in the agreement. The following texts ing .avi, .divx). Download free software on are Volvo's agreements with manufacturers/ www.divx.com to create, play back and stream developers. digital video.
  • Page 537 SOUND, MEDIA AND INTERNET Parts of the content are copyright © of note servers will be terminated if you violate note has no obligation to provide you with new, Gracenote or its suppliers. these restrictions. If your license is terminated improved or additional data types or categories you agree to cease all use of Gracenote data, that Gracenote may provide in the future, and the...
  • Page 538 SOUND, MEDIA AND INTERNET source and binary forms, with or without THIS SOFTWARE, EVEN IF ADVISED OF THE PARTICULAR PURPOSE AND modification, are permitted provided that the POSSIBILITY OF SUCH DAMAGE. NONINFRINGEMENT. IN NO EVENT SHALL following conditions are met: Redistributions of SILICON GRAPHICS, INC.
  • Page 539 SOUND, MEDIA AND INTERNET The website provides the Source Code "As Is" PARTICULAR PURPOSE ARE DISCLAIMED. IN the above copyright notice(s) and this permission and without warranty of any kind. NO EVENT SHALL NTT BE LIABLE FOR ANY notice appear with all copies of the Data Files or DIRECT, INDIRECT, INCIDENTAL, SPECIAL, Software, (b) both the above copyright notice(s) By downloading Source Code, you expressly...
  • Page 540 SOUND, MEDIA AND INTERNET dealings in these Data Files or Software without Declaration of Conformity prior written authorization of the copyright holder.
  • Page 541 SOUND, MEDIA AND INTERNET Country/ Area Brazil: Este equipamento opera em caráter secundário isto e, náo tem direito a protecão contra interferéncia prejudicial, mesmo tipo, e não pode causar interferéncia a sistemas operando em caráter primário. Para consultas, visite: www.anatel.gov.br Manufacturer: Mitsubishi Electric Corporation Sanda Works 2-3-33, Miwa, Sanda-city.
  • Page 542 SOUND, MEDIA AND INTERNET Country/ Area Kazakh- stan: Model name: NR 0V Manufacturer: Mitsubishi Electric Corporation Exporting country: Japan...
  • Page 543 SOUND, MEDIA AND INTERNET Country/ Area China: ■ 使用频率 2.4 - 2.4835 GHz ■ 等效全向辐射 率(EIRP) 天线增益 10dBi 时 ≤100 mW 或≤20 dBm ① ■ 最大 率谱密度 天线增益 10dBi 时 ≤20 dBm / MHz(EIRP) ① ■ 载频容限 20 ppm ■ 帯外发射 率(在 2.4-2.4835GHz 頻段以外) ≤-80 dBm / Hz (EIRP) ■...
  • Page 544 SOUND, MEDIA AND INTERNET Country/ Area B 급 기기 (가정용 방송통신기자재) Korea: 이 기기는 가정용(B 급) 전자파적합기기로서 주로 가정에서 사용하는 것을 적으로 하며, 든 지역에서 사용할 수 있습니다. 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다. Malaysia This device has been certified under the Communications &...
  • Page 545 SOUND, MEDIA AND INTERNET Country/ Area Mexico: 低功率電波輻射性電機管理辦法 Taiwan: 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司 商號或使用者均不得擅自 變更頻率 加大功率或變更原設計之特性及功能 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立停用，改善至無干擾時方得繼續使用 前項合法通信，指依電信法規定作業之無線 電通信 低功率射頻電機須忍受合法通信或工業 科學及醫療用電波輻射性電機設備 之干擾 Related information Sound, media and Internet (p. 490) • Internet-connected car* (p. 526) • Media player (p. 501) •...

  • Page 547: Wheels And Tyres

    WHEELS AND TYRES...

  • Page 548: Tyres

    If you drive over kerbstones or deep holes • On delivery, the car is equipped with Volvo origi- manufacture. This is the tyre's DOT marking you can damage the tyres and/or wheel rims...

  • Page 549: Dimension Designation For Tyre

    10000 km (approx. 6200 miles) intervals. requirements for stability and driving cha- The car has an approval for the complete vehicle Volvo recommends the an authorised Volvo work- racteristics. Unapproved combinations of with certain combinations of wheel rims and...

  • Page 550: Dimension Designation For Wheel Rim

    WHEELS AND TYRES Dimension designation for wheel Speed rating WARNING Each tyre can withstand a certain maximum The lowest permitted load index (LI) and speed. Tyre speed rating, SS (Speed Symbol), Wheel and rim dimensions are designated in speed rating (SS) for the tyres for each must at least correspond with the car's top accordance with the examples in the table respective engine variant are shown in the...

  • Page 551: Tyres' Rotation Direction

    WHEELS AND TYRES Tyres' rotation direction Tread wear indicators on the tyres NOTE Tyres with a tread pattern which are designed to Tread wear indicators show the status of the Make sure that both pairs of wheels have the only turn in one direction have the direction of tyre's tread depth.

  • Page 552: Checking Tyre Pressure

    WHEELS AND TYRES Checking tyre pressure Adjusting tyre pressure Tyres are considered cold when they have the same temperature as the surrounding air. Correct tyre pressure helps to improve driving Tyre pressure decreases over time, this is a nat- stability, saves fuel and extends the service life of ural phenomenon.

  • Page 553: Recommended Tyre Pressure

    WHEELS AND TYRES Recommended tyre pressure 3. Refit the dust cap. Related information Recommended tyre pressure (p. 551) • The tyre pressure label on the driver's side door NOTE Checking tyre pressure (p. 550) pillar (between frame and rear door) shows •...

  • Page 554: Tyre Pressure Monitoring System

    WHEELS AND TYRES Tyre pressure monitoring system* Each tyre, including the spare tyre*, should be detects a fault, the symbol in the driver display checked once a month. When checking, the tyre will flash for about one minute and then remain The tyre pressure monitoring system , gives a should be cold and have the air pressure recom-...

  • Page 555: Calibrate The System For Tyre Pressure Monitoring

    WHEELS AND TYRES Calibrate the system for tyre pillar for Volvo's recommended tyre pres- Calibrate the system for tyre pressure moni- • pressure monitoring* sures. toring* (p. 553) If you change to tyres of a different size to • In order for the system for tyre pressure monitor-...
  • Page 556 WHEELS AND TYRES 5. Press TPMS 8. Run the car until calibration is complete. NOTE Calibration is performed when the car is Remember to always calibrate the tyre pres- driven at a speed above 35 km/h (22 mph). sure monitoring system when you have changed a wheel or if the tyre pressure has If the car's ignition is switched off before cal- been changed according to the tyre pressure...

  • Page 557: See Tyre Pressure Statue In The Centre Display

    Indirect Tyre Pressure Monitoring System (ITPMS) The figure is schematic. Layout may vary depending on car model or updated software. An authorised Volvo workshop is recommended. * Option/accessory.

  • Page 558: Action In The Event Of Warning For Low Tyre Pressure

    WHEELS AND TYRES Action in the event of warning for Calibrate the system for tyre pressure moni- • NOTE low tyre pressure toring* (p. 553) To avoid incorrect tyre pressure, the pressure See tyre pressure statue in the centre dis- •...

  • Page 559: When Changing Wheels

    Check that the tyre dimension is approved for use on the car. Contact an authorised Volvo workshop for updat- ing the software at each change of tyre dimen- sion. A software download may be necessary both when changing to larger and smaller dimen- sions, and also when switching between summer and winter wheels.

  • Page 560: Wheel Bolts

    Only use rims that are tested and approved by often, or for a longer time than is required Volvo and which are Volvo genuine accessories. just to change a wheel, use of a garage jack is recommended. In this instance,...

  • Page 561: Removing A Wheel

    WHEELS AND TYRES Removing a wheel 1. Set up the warning triangle and activate the WARNING hazard warning lights if a tyre is being Instructions for removing a wheel when chang- Apply the parking brake and set the gear • changed in a trafficked location.
  • Page 562 WHEELS AND TYRES 5. Screw together the towing eye with the 8. When raising the car, it is important that the 11. Turn the jack so that the crank is as far away wheel wrench* until the stop position as per jack* or lifting arms are fitted in the intended from the side of the car as possible, at which the instructions.

  • Page 563: Fitting The Wheels

    WHEELS AND TYRES Fitting the wheels 1. Clean the surfaces between wheel and hub. WARNING Instructions for fitting a wheel when changing 2. Put on the wheel. Tighten the wheel bolts Apply the parking brake and set the gear • wheels.

  • Page 564: Spare Wheel

    • Settings for level control* (p. 455) If the spare tyre is damaged then a new one can be purchased from a Volvo dealer. On all-wheel drive cars, the drive on the • When changing wheels (p. 557) •...

  • Page 565: Taking Out The Spare Wheel

    1. Take out the wheel bag enclosed in the foam block and put the wheel in the bag. Contact a Volvo dealer for advice about which wheel rim and type of tyre are most suitable. 2. Screw back the mounting screw that held the spare wheel in place.

  • Page 566: Snow Chains

    Volvo therefore recom- mends not to drive on winter tyres that have a WARNING Volvo does not recommend the use of • tread depth of less than 4 mm (0.15 inches). show chains on wheel dimensions Use Volvo genuine snow chains or equivalent greater than 18 inches.

  • Page 567: Emergency Puncture Repair Kit

    NOT be used. NOTE You can obtain more information on snow chains from a Volvo retailer. Sealing fluid expiry date The sealing fluid is effective at sealing tyres The bottle of sealing fluid must be replaced if the...

  • Page 568: Using A Puncture Repair Kit

    WHEELS AND TYRES Using a puncture repair kit Connecting WARNING Seal a puncture with the emergency puncture Please keep the following points in mind repair kit, Temporary Mobility Kit (TMK). when using the tyre sealing system: Overview The sealing fluid bottle contains 1) rubber •...
  • Page 569 Do not remove the bottle when the punc- • again. Bottle removal must be performed at a ture repair kit is being used. WARNING workshop, Volvo recommends an authorised Do not remove the air hose when the • Volvo workshop. Inhaling car exhaust fumes could result in puncture repair kit is being used.
  • Page 570 The journey authorised tyre centre. WARNING should not be continued. Call roadside assis- tance for recovery to a tyre centre. Volvo rec- Make sure that nobody is standing near the ommends an authorised tyre centre. NOTE car and gets the sealing fluid splashed onto them when the car is driven away.

  • Page 571: Inflating Tyres With The Compressor

    WARNING ventilation. Check the tyre pressure regularly. WARNING Volvo recommends that the car is driven to the Do not leave children in the car without nearest authorised Volvo workshop for the supervision when the engine is running. replacement/repair of the damaged tyre. Advise the workshop that the tyre contains sealing fluid.
  • Page 572 WHEELS AND TYRES Related information IMPORTANT Recommended tyre pressure (p. 551) • Risk of overheating. The compressor must not Using a puncture repair kit (p. 566) • run for more than 10 minutes. Emergency puncture repair kit (p. 565) • 5.
  • Page 573 LOADING, STORAGE AND PASSENGER COMPARTMENT...
  • Page 574 LOADING, STORAGE AND PASSENGER COMPARTMENT Passenger compartment interior Rear seat Related information Using the cigarette lighter* (p. 573) • Overview of the passenger compartment's inte- rior and storage locations. Electrical sockets (p. 575) • Using the glovebox (p. 578) • Front seat Sun visors (p.
  • Page 575 LOADING, STORAGE AND PASSENGER COMPARTMENT Tunnel console Using the cigarette lighter* WARNING The tunnel console is located between the front The cigarette lighter can be a complement to the Keep loose objects such as mobile phones, seats. 12 V socket in the front section of the tunnel cameras, remote controls for accessories, etc.
  • Page 576 LOADING, STORAGE AND PASSENGER COMPARTMENT Related information Passenger compartment interior (p. 572) •...
  • Page 577 12 V electrical socket* in the cargo area. If a problem occurs with an electrical socket, contact a workshop - an authorised Volvo work- shop is recommended. 12 V electrical socket 12 V electrical socket in tunnel console, rear seat.
  • Page 578 LOADING, STORAGE AND PASSENGER COMPARTMENT Status indication Reason Action Steady green light The socket is delivering current to a connected device. None. Blinking orange light The temperature of the socket's voltage converter is too high (because for Remove the plug and let the voltage converter cool example the accessory draws too high a current or the passenger compart- down before reinserting the plug.
  • Page 579 LOADING, STORAGE AND PASSENGER COMPARTMENT Using electrical sockets Using 12 V sockets NOTE 1. Remove the blanking plug (tunnel console) 12 V sockets can be used for various accesso- Remember that use of the electrical socket or fold down the cover (cargo area) in front ries designed for this, such as music players, with the engine switched off entails a risk of of the socket and plug in the accessory's...
  • Page 580 The accessories must have a CE marking, UL Never modify or repair the high-voltage socket yourself. Volvo recommends that an marking or an equivalent safety marking. authorised Volvo workshop should be contac- Never allow sockets, connectors or •...
  • Page 581 LOADING, STORAGE AND PASSENGER COMPARTMENT Locking and unlocking the glovebox* The glovebox can be locked, e.g. when the car is taken in for service, left at a hotel or similar. The glovebox can only be locked/unlocked with the accompanying key. The figure is schematic - the design may vary.
  • Page 582 LOADING, STORAGE AND PASSENGER COMPARTMENT Sun visors Cargo area Recommendations for loading There are sun visors in the roof in front of the The car has a flexible cargo area that makes it There are a number of things to remember when driver and the front seat passenger which can possible to transport and secure large objects.
  • Page 583 (p. 583) order to achieve the maximum possible safety headlining, may be compromised. during a journey. Volvo's load carriers are availa- Roof load and loading on load carriers • ble for purchase at authorised Volvo retailers.
  • Page 584 • Fitting and removing the safety net* • (p. 587) • Fitting and removing cargo cover* (p. 583) Fitting and removing safety grilles* (p. 585) • It is possible to reorder additional elastic straps at a Volvo retailer. * Option/accessory.
  • Page 585 LOADING, STORAGE AND PASSENGER COMPARTMENT Load retaining eyelets Through-load hatch in the rear seat Fitting and removing cargo cover* Use the load retaining eyelets to fasten straps in The hatch in the rear seat's backrest can be In the extended position, the cargo cover pre- order to anchor items in the cargo area.
  • Page 586 LOADING, STORAGE AND PASSENGER COMPARTMENT Operating cargo cover* Removing cargo cover In retracted position: There are two extended positions for the cargo cover - a full-cover position and a loading posi- 1. Depress the button on one of the retracted tion, where it is partially extended to make it eas- cargo cover's end pieces and lift out that ier to reach further into the cargo area.
  • Page 587 The safety grille is crash-tested in accordance with the ECE R17 legal requirement and fulfils Volvo's strength requirements. Retracting 1. From the full-cover position: Lift up the handle and pull it backward to dis- engage the cargo cover's attachment pins and then release.
  • Page 588 Before first installing the safety grille, the existing plastic roof mountings must be replaced with steel roof mountings. Volvo recommends that replacing roof mountings is performed at an Position the safety grille's brackets on the Insert the supplied screw and tighten using authorised Volvo workshop or retailer.
  • Page 589 LOADING, STORAGE AND PASSENGER COMPARTMENT Fitting and removing the safety net* Fitting the safety net The safety net prevents loads from being thrown WARNING forward in the passenger compartment in the event of sudden braking. It is necessary to ensure that the upper secur- ing points of the safety net are fitted correctly The safety net is fitted into four mounting points.
  • Page 590 LOADING, STORAGE AND PASSENGER COMPARTMENT First aid kit* 5. Tension the safety net with the anchoring straps. The first aid kit contains first aid equipment. Removing the safety net Store the first aid kit in an appropriate place in The safety net can be easily removed and folded the cargo area, e.g.
  • Page 591 LOADING, STORAGE AND PASSENGER COMPARTMENT Warning triangle Use the warning triangle to warn other road users if the car is stationary in traffic. Also activate the hazard warning flashers. Storage spaces The warning triangle is located in the compart- ment on the inside of the tailgate. Folding up the warning triangle Grasp the grip on the tailgate's panel to open the hatch for the warning triangle.
  • Page 593 MAINTENANCE AND SERVICE...
  • Page 594 Wi-Fi to perform IMPORTANT fault-tracing and software download. For this type For the Volvo warranty to apply, check and of communication, the car only connects to a follow the instructions in the Service and workshop's network. It is not possible to connect Warranty Booklet.
  • Page 595 MAINTENANCE AND SERVICE Download Center Managing system updates via the NOTE Download Centre Several of the car's systems can be updated Data download may affect other services that System updates for online car and infotainment from the centre display with an online car transmit data, e.g.
  • Page 596 MAINTENANCE AND SERVICE Car status Cancelling software download Navigating in the centre display's views • (p. 107) Tap on X in the activity indicator that has – The car's general status can be shown in the Install replaced at the start of the download. ®...
  • Page 597 4. Make sure that the correct Volvo ID is filled request. Create a Volvo ID and register it to the car. • The booking enquiry sent from the car includes Select the Volvo retailer you would like to 5. Make sure that the desired Workshop •...
  • Page 598 Navigating in the centre display's views • meter reading • (p. 107) the car's vehicle identification number • Volvo ID (p. 26) • 1. Open the Car Status app from the app view (VIN Internet-connected car* (p. 526) in the centre display.
  • Page 599 Raise the car NOTE When raising the car it is important that the car Volvo recommends only using the jack that jack or the workshop/garage jack is fitted to the belongs to the car model in question. If a jack intended points on the car’s underbody.
  • Page 600 MAINTENANCE AND SERVICE The triangles in the plastic cover indicate the locations of the lifting points (marked in red). Related information Removing a wheel (p. 559) • Jack* (p. 557) • • Settings for level control* (p. 455) * Option/accessory.
  • Page 601 NOTE If the warning symbol is lit or the warning sig- nal is heard despite the bonnet being closed properly, contact an authorised Volvo work- shop. Bonnet not completely closed. The figure is schematic - parts may vary depending on car model.
  • Page 602 Troubleshooting and repair The air conditioning system contains fluorescent tracing agents. Ultraviolet light must be used dur- ing leak detection. Volvo recommends that an authorised Volvo workshop is contacted. Cars with R134a refrigerant Bonnet completely closed. The figure is schematic - parts may vary depending on car model.
  • Page 603 6 minutes after the engine has been switched off. Always have the engine cleaned by a work- shop - an authorised Volvo workshop is rec- ommended. There is a risk of fire if the engine is hot.
  • Page 604 Volvo recommends that oil changes are car- ried out at an authorised Volvo workshop. Volvo uses different systems to warn about the oil level if it is too low/high, or in the event of low oil pressure. Certain engine variants have an oil...
  • Page 605 Engine oil level with the message Service required , visit a workshop - an authorised Volvo workshop is recommended. The oil level may be too high. 1. Open the Car Status app from the app view in the centre display.
  • Page 606 MAINTENANCE AND SERVICE Topping up coolant NOTE The coolant cools the internal combustion If the right conditions for measuring the oil engine to the correct operating temperature. The level (time after engine shutdown, the car's heat that is transferred from the engine to the inclination, outside temperature, etc.) are not coolant can be used to heat the passenger com- met, then the message...
  • Page 607 For information about bulbs not covered in Only new coolant should be used when • this article, contact a Volvo dealer or a certi- replacing major cooling system compo- fied Volvo service technician. Open the lid on the plastic cover.
  • Page 608 MAINTENANCE AND SERVICE NOTE If an error message remains after the broken bulb has been replaced then we recommend visiting an authorised Volvo workshop. NOTE Outside lighting such as headlamps and rear lamps may temporarily have condensation on the inside of the lens. This is normal, all exte- rior lighting is designed to withstand this.
  • Page 609 The battery terminals on the car's starter battery in the luggage/cargo area must not be used. During charging, both the starter battery and the support battery are charged. An authorised Volvo workshop is recommended.
  • Page 610 MAINTENANCE AND SERVICE Location IMPORTANT NOTE If the following instruction is not observed The life of the battery is shortened if it then the energy saving function for infotain- becomes discharged repeatedly. ment may be temporarily disengaged, and/or The life of the battery is affected by several the message in the driver display about the factors, including driving conditions and cli- starter battery's state of charge may be tem-...
  • Page 611 Capacity (Ah) According to EN standard. Cold Cranking Amperes. Volvo recommends entrusting battery replace- ment to an authorised Volvo workshop. IMPORTANT If the battery is replaced, make sure you replace it with a battery with the same size, cold starting capacity and type as the original battery (see the decal on the battery).
  • Page 612 Start/Stop function tions or problems - an authorised Volvo workshop until the battery has been recharged by the is recommended. car. In an outside temperature of approx.
  • Page 613 MAINTENANCE AND SERVICE Symbols on the batteries 150×90×130 mm Size, L×B×H (5.9×3.5×5.1 There are information and warning symbols on Avoid sparks and naked inches) the batteries. flames. Capacity (Ah) According to EN standard. Cold Cranking Amperes. Use protective goggles. IMPORTANT Risk of explosion.
  • Page 614 In a right-hand drive car the central damage to the electrical system and possibly the circuit. Volvo recommends contacting an electrical units under the glovebox change sides. lead to fire.
  • Page 615 MAINTENANCE AND SERVICE Fuses in engine compartment (p. 614) • Fuses under glovebox (p. 617) •...
  • Page 616 MAINTENANCE AND SERVICE Fuses in engine compartment Fuses in the engine compartment protect engine and brake functions, amongst other things.
  • Page 617 Engine Control Module (ECM) Solenoid clutch A/C; Lambda Left-hand headlamp, certain sond, centre (petrol); Lambda variants of LED Starter motor sond, rear (diesel) Right-hand headlamp, certain Starter motor Shunt variants of LED An authorised Volvo workshop is recommended. * Option/accessory.
  • Page 618 MAINTENANCE AND SERVICE Related information Function Ampere Function Ampere Fuses and central electrical units (p. 612) • – – Shunt Heated windscreen* right- Replacing a fuse (p. 612) • hand side Shunt Heated windscreen* left-hand Supplied when the ignition is side switched on: Engine control Heated windscreen* left-hand...
  • Page 619 MAINTENANCE AND SERVICE Fuses under glovebox Fuses under the glovebox protect, amongst other things, electrical sockets, displays and door modules.
  • Page 620 Diagnostic socket OBDII belt reminder/Indicator for air- Driver display Centre display bag on the front passenger seat) Keypad in centre console Fan module for climate control – – system, front Sun sensor An authorised Volvo workshop is recommended. * Option/accessory.
  • Page 621 Fuses in cargo area Coolant pump Control module for online car; – – Control module for Volvo On Call Door module in left-hand front Door module in left-hand rear door door Control module for suspension Audio control module (ampli-...
  • Page 622 MAINTENANCE AND SERVICE Fuses in cargo area Fuses in the cargo area protect, amongst other things, power seats*, airbags and seatbelt ten- sioners. * Option/accessory.
  • Page 623 MAINTENANCE AND SERVICE The central electrical unit is located on the right-hand side. On the inside of the cover there are tweezers that The fuse box in the engine compartment also facilitate the procedure for the removal and fitting provides space for several spare fuses. of fuses.
  • Page 624 Seatbelt pretensioner module, of nitrous oxides (diesel) left-hand side – – Power operated tailgate* Parking camera* All Wheel Drive (AWD) control module* Electrically operated front pas- – – senger seat* – – An authorised Volvo workshop is recommended. * Option/accessory.
  • Page 625 MAINTENANCE AND SERVICE Function Ampere Seat heating right-hand side rear* – – Related information Fuses and central electrical units (p. 612) • Replacing a fuse (p. 612) • * Option/accessory.
  • Page 626 Cleaning leather upholstery (p. 627) Only use cleaning agents and car care products • Dirt, stains and grease from fingers can affect recommended by Volvo. Clean regularly and the centre display's performance and readability. Cleaning the leather steering wheel •...
  • Page 627 Only use cleaning agents and car care products display must be free from sand and dirt. parts (p. 628) recommended by Volvo. Clean regularly and treat stains at once for best results. Vacuuming IMPORTANT is important prior to using cleaning agents.
  • Page 628 Remove inlaid carpets for separate cleaning of Cleaning interior plastic, metal and wood • textile cleaning agent is available from Volvo the floor carpet and the inlaid carpets. Use a vac- parts (p. 628) retailers. Ensure that the seatbelt is dry before uum cleaner to remove dust and dirt.
  • Page 629 UV radia- IMPORTANT of the leather shall be preserved. Volvo offers a tion. comprehensive product – Volvo Leather Care Kit/ Sharp objects, e.g. rings, can damage the Related information Wipes –...
  • Page 630 A fibrillated fibre or microfibre cloth, lightly mois- Related information tened with water, available from Volvo retailers, is Cleaning the exterior (p. 628) recommended for cleaning interior parts and sur- •...
  • Page 631 Polish and wax the car if the paintwork is dull or The car should be washed as soon as it Only paint treatment recommended by Volvo to give the paintwork extra protection. The car becomes dirty. This means that the car is easier should be used.
  • Page 632 MAINTENANCE AND SERVICE Wash using a sponge, car shampoo and Cleaning the wiper blades (p. 632) • • NOTE plenty of lukewarm water. Cleaning exterior plastic, rubber and trim • Outside lighting such as headlamps and rear Clean the wiper blades with a lukewarm soap components (p.
  • Page 633 NOTE 3. Drive into the car wash. Volvo recommends that the car is not washed 4. Switch off the "Automatic braking at in an automatic car wash during the first few standstill" function using the button months (this is because the paintwork has on the tunnel console.
  • Page 634 MAINTENANCE AND SERVICE High-pressure washing Cleaning the wiper blades Rustproofing (p. 634) • The car should be washed as soon as it The car should be washed as soon as it becomes dirty. This means that the car is easier becomes dirty.
  • Page 635 Exterior plastic, rubber and trim tion and destroy the surface treatment. components A special cleaning agent available from Volvo Related information retailers is recommended for the cleaning and Parts that should be washed using a cleaning agent with Cleaning the exterior (p.
  • Page 636 In the Only use rim cleaning agent recommended by chassis, exposed components of the wheel sus- Volvo. pension are made of corrosion-resistant cast alu- Strong rim cleaning agents can damage the sur- minium.
  • Page 637 MAINTENANCE AND SERVICE Car paintwork Touching up minor paintwork damage The paintwork consists of several layers and is an important part of the car's rustproofing, and Paint is an important part of the car's rustproof- should therefore be checked regularly. ing and should therefore be checked regularly.
  • Page 638 Touch-up pens and spray paints are available from Volvo retailers. NOTE If the stone chip has not penetrated down to the meal and an undamaged layer of paint...
  • Page 639 MAINTENANCE AND SERVICE Replacing the wiper blade, rear window Lift the cover for the wiper arm's bracket. Be 7. Lower the wiper arm. careful that the wiper arm does not mistak- enly fall down to the windscreen again. IMPORTANT Check the blades regularly. Neglected main- tenance shortens the service life of the wiper blades.
  • Page 640 MAINTENANCE AND SERVICE Replacing windscreen wiper blades Press and hold the lock button located NOTE on the wiper blade mounting and at the The wiper blades sweep water away from the When replacing the wiper blades, note that windscreen and rear window. Together with the same time pull the blade straight out par- they have different lengths.
  • Page 641 MAINTENANCE AND SERVICE Wiper blades in service position are not on. Service mode is activated/deactivated Related information via the function view in the centre display: Using the rain sensor (p. 171) • In some situations, the windscreen's wiper blades must be set in service position (vertical Using windscreen and headlamp washers Press the Wiper Service...
  • Page 642 Filling washer fluid Prescribed grade: Washer fluid recommended Using the rain sensor's memory function • by Volvo – with frost protection during cold (p. 172) Washer fluid is used for cleaning the headlamps weather and for temperatures below freezing Using the rear window wiper and washer as well as the windscreen and rear window.
  • Page 643 SPECIFICATIONS...
  • Page 644 The illustration is schematic - details may vary depending on market and model. Knowing the car's type designation, vehicle iden- tification and engine numbers can facilitate all contact with an authorised Volvo retailer regar- ding the car and when ordering spare parts and accessories.
  • Page 645 SPECIFICATIONS Decal for type designation, vehicle identifica- Decal A/C system for cars with refrigerant Decal for engine code and the engine's serial tion number, permissible maximum weights and R134a. number. code designation for exterior colour and date of manufacture. The decal is positioned on the door pillar, and will be visible when the right-hand rear door is opened.
  • Page 646 SPECIFICATIONS NOTE It is not intended that the decals illustrated in the owner's manual should be exact replicas of those in the car. They are included to show their approximate appearance and locations in the car. The information that applies to your particular car can be found on the decal on the car.
  • Page 647 SPECIFICATIONS Dimensions Measurement of car length, height, etc. can be read in the table. Dimensions inches Dimensions inches Dimensions inches Load height 25.4 Rear track Ground clearance 1610 63,4 Front track 1603 63,1 Wheelbase 2872 113,1 1610 63,4 1600 63,0 1603 63,1 Length...
  • Page 648 SPECIFICATIONS Dimensions inches Width including door 2040 80,3 mirrors Width including folded- 1916 75.4 in door mirrors At kerb weight + 2 people. (Varies slightly depending on tyre dimension, chassis option, etc.) Including roof antenna, for kerb weight. Applies to cars with 16 inch wheels. Applies to cars with 17 inch wheels.
  • Page 649 SPECIFICATIONS Weights NOTE Max. gross vehicle weight, etc. can be read on a The documented kerb weight applies to cars label in the car. in the standard version - i.e. a car without extra equipment or accessories. This means Kerb weight includes the driver, the fuel tank that for every accessory added the loading 90% full and all fluids.
  • Page 650 SPECIFICATIONS Towing capacity and towball load Max. weight braked trailer Towing capacity and towball load for driving with NOTE a trailer can be read in the tables. Use of vibration dampers on the towbar is recommended for trailers heavier than 1800 kg.
  • Page 651 SPECIFICATIONS Max. weight unbraked trailer Max. weight unbraked trailer (kg) Max. towball load (kg) Related information Type designations (p. 642) • Weights (p. 647) • Driving with a trailer (p. 475) • • Trailer stability assist* (p. 476) * Option/accessory.
  • Page 652 SPECIFICATIONS Engine specifications NOTE Engine specifications (power, etc.) for each Not all engines are available in all markets. respective engine alternative can be found in the table below. Engine Output Output Max. rated power Max. rated power Torque No. of cylinders Engine code (kW/rpm) (hp/rpm)
  • Page 653 SPECIFICATIONS Engine oil — specifications Engine oil grade and volume for each respective engine alternative can be read in the table. Volvo recommends: Engine Oil grade Volume, incl. oil filter Engine code (litres, approx.) B4204T23 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0W-20...
  • Page 654 Volvo Car Corporation driving conditions. It provides extra protection for disclaims any liability for any such damage. the engine. Volvo recommends that oil changes are car- Volvo recommends: ried out at an authorised Volvo workshop. Related information Engine oil —...
  • Page 655 Under normal driving conditions, the transmis- The medium in a hydraulic brake system is approved by Volvo. If the coolant is concentra- sion fluid does not need to be changed during called brake fluid, and it is used to transfer pres- its service life.
  • Page 656 SPECIFICATIONS ®2 Fuel tank - volume Air conditioning — specifications Tank capacity for AdBlue The fuel tank's filling capacity can be read in the The car's climate control system uses a freon- The refillable tank capacity for the additive table below. free refrigerant, either R1234yf or R134a AdBlue is approx.
  • Page 657 SPECIFICATIONS Decal for R1234yf WARNING Symbol Meaning The air conditioning system contains pressur- A trained and certified technician is ised refrigerant R1234yf. In accordance with required in order to service the SAE J2845 (Technician Training for Safe mobile air conditioning system Service and Containment of Refrigerants (MAC) Used in Mobile A/C System), service and...
  • Page 658 SPECIFICATIONS Fuel consumption and CO Economical driving (p. 455) • emissions Fuel consumption and CO emissions can be negatively impacted by a number of factors. Examples of causes of increased fuel consump- tion include: If the car is equipped with extra equipment •...
  • Page 659 SPECIFICATIONS Approved tyre pressures NOTE Approved tyre pressures for each engine alterna- All engines, tyres or combinations of these tive can be found in the table. are not always available in all markets. Engine Tyre size Speed Load, 1-3 persons Max.
  • Page 660 SPECIFICATIONS Performance Top speed can be read in the table below. NOTE If there are no performance data then they are available in the accompanying supple- ment. Related information Engine specifications (p. 650) •...
  • Page 661 ALPHABETICAL INDEX ALPHABETICAL INDEX Adaptive Cruise Control 302, 304, 305, Air distribution 1, 2, 3 ... 306, 307, 309, 311, 312, 313, 314, 315, 316 Air vents 202, 203 change cruise control functionality change fault tracing defrosting function Recirculation managing speed 305, 306 table of options overtaking...
  • Page 662 ALPHABETICAL INDEX play media 502, 503 Brake fluid Text message grade Backrest Auto climate control Brake functions front seat, adjusting 178, 179, 182, Auto hold Brake light 183, 184, 185, Automatic brake Brakes rear seat, lowering activate and deactivate Anti-lock braking system, ABS Bag holder after collision automatic when stationary...
  • Page 663 ALPHABETICAL INDEX Cargo area operation 104, 107, 111, 116 Cleaning 626, 627, 628 lighting overview automatic car wash mounting points settings 124, 125 car washing 628, 629, 631, 632, 633, 634 protective net switch off and change volume centre display symbols in status bar Fabric upholstery 624, 625, 627...
  • Page 664 ALPHABETICAL INDEX Collision warning 348, 363 Cover Diesel particle filter cargo area Collision warning system Digital radio (DAB) Pedestrian detection Crash, see Collision Dimensions Radar sensor Cross Traffic Alert – CTA 369, 370, 371, 372 Towbar Colour code, paint Cruise control 293, 294 dipped beam Colour codes...
  • Page 665 ALPHABETICAL INDEX messages Economical driving 445, 455 Engine compartment settings coolant ECO pressure 551, 657 Engine oil Driver performance 83, 84 Electrically operated parking brake overview Driver profile Electrical socket Engine drag control edit 129, 130, 131 using select Engine oil 601, 652 Electrical system adverse driving conditions...
  • Page 666 ALPHABETICAL INDEX adjusting the passenger seat from the driver's seat Lumbar support Gearbox Air distribution massage 182, 183, 184 automatic Air vents multi-function control 182, 183, 184, manual Control 219, 220 185, Gear positions Side supports Fault tracing for the camera sensor 345, 348 automatic gearbox store position...
  • Page 667 Head up display IAQS (Interior Air Quality System) activate and deactivate Internet, see Internet-connected car IC (Inflatable Curtain) settings Internet-connected car ID, Volvo store position 136, 180, 181 book service and repair Identification number Head-up display send car information Ignition position...
  • Page 668 ALPHABETICAL INDEX Keyboard 118, 121 Level control Lighting, bulb replacement change language damping Limitations for Driver Alert Control settings Keyless Limp home Locking/unlocking License agreement 89, 534 Load carriers settings Lifting tool Loading touch-sensitive surfaces Lighting General Keypad in the steering wheel active bending lights load retaining eyelets Key tag...
  • Page 669 ALPHABETICAL INDEX Motion sensor Main beam PACOS (Passenger Airbag Cut Off Switch) 53 Maintained climate comfort Paddle on the steering wheel start/shut-off Paintwork maintenance colour code cargo area Rustproofing damage and touch-up 635, 636 Manual gearbox Panorama roof opening and closing pinch protection Max.
  • Page 670 ALPHABETICAL INDEX Parking climate remove Protective grille Symbols and messages text message Protective net voice control Parking heater Pump up tyre Pilot Assist 318, 321, 322, 323, 324, Passenger Airbag Cut Off Switch Puncture 325, 326, 328, 329, 330, 331, 332 Passenger compartment filter overtaking 328, 329...
  • Page 671 ALPHABETICAL INDEX lowering the backrest Remote control key Temperature battery replacement connect to driver profile Safety Rearview and door mirrors detachable key blade pregnancy compass loss Dipping Safety mode range door 163, 164 start/movement electrically retractable Remote control key system, type approval 251 Sealing fluid heating Remote updates...
  • Page 672 ALPHABETICAL INDEX Sensus Speed ratings, tyres paddle connection and entertainment steering wheel adjustment Spin control Sensus Navigation Steering wheel paddles Stabiliser Service position trailer Stickers location Service programme Stability and traction control system 281, 284 operation 282, 283 Stone chips and scratches 635, 636 Set time interval Stability system...
  • Page 673 ALPHABETICAL INDEX Collision Warning with Auto Brake Total airing function TSA - trailer stability assist parking climate Towbar TSA - Trailer stability assist Symbols and messages for Assistance at foldable Tunnel console risk of collision specifications Tunnel detection system updates Towing 479, 482 Towing capacity and towball load...
  • Page 674 174, 175 tread depth Voice recognition washer fluid, filling tread wear indicators VOL marking windscreen tyre pressure monitoring Volvo ID Waxing tyre pressure table create and register winter tyres Weights kerb weight Wheel bolts lockable Wheel change...
  • Page 675 ALPHABETICAL INDEX Wi-Fi connect car to Internet delete network share internet connection, hotspot technology and security Windows and glass Windscreen heating projected image 134, 136 Windscreen washing Windscreen wiper rain sensor 171, 172 Winter driving Winter tyres Winter wheels Wiper blades changing 636, 638 Service position...
  • Page 676 ALPHABETICAL INDEX...
  • Page 678 TP 26369 (English Int.), AT 1817, MY19, Copyright © 2000-2018 Volvo Car Corporation...

Table of Contents

Save PDF
