Features; Payload; Dimensions - Tecnosystemi smart clima SCD500080 User Manual

CARATTERISTICHE
I supporti a pavimento con bacinella sono realizzate in lamiera elettrozincata e verniciata con polveri poliestere
altamente resistenti agli agenti atmosferici.
The floor mounts with tray are made from electrogalvanized sheet metal and coated with epoxy powders highly resistant
to atmospheric agents.
CODICE MODELLO
/ CODE / MODEL
SCD500080 "SBP" PICCOLA 820x360
SCD500081 "SBP" GRANDE 980x410
SCD500079 "SBP" MAXI 1100x570
SCD500122 "SBP" 1250x390
SCD500091 "SBP" BIG 1400x570
1
2
1
2
3
4
2

/ FEATURES

A
E
F
DIMENSIONI / DIMENSIONS
A [mm] B [mm] C [mm]
60
60
60
60
60
ANTIVIBRANTI "NO-SHOCK"
PIEDINI REGOLABILI / ADJUSTABLE FEET
PORTAGOMMA IN PLASTICA A 90°
BACINELLA / TRAY
D [mm]
130-170 360 205-310
130-170 410 230-360
130-170 570 400-520
130-170 410 230-360
130-170 570 400-520
3
/ "NO-SHOCK" ANTI-VIBRATION
/ PLASTIC HOSE FITTING AT 90°
D
B
C
E [mm] F [mm]
400-760 820
400-920 980
400-1040 1100
400-1190 1250
400-1340 1400
4
SMUSSI NON
QUOTATI
RACCORDI NON
QUOTATI
PORTATA

/ PAYLOAD

[kg]
150
150
150
200
200
QUOTE
INDICAZIONE D
