enLink Status-L
Water Leakage Sensor User Guide
LoRaWAN Wireless Water Leakage Sensor
•
LoRaWAN long range wireless.
•
Battery powered
•
Available with various leak detection rope lengths
•
Detects leaks over the entire length of the cable
•
Configurable alarm threshold sensitivity
•
Adaptive transmission intervals
enLink Status-L detects the presence of water leaks, flooding
and condensation using water detection cable. Leakage or
moisture is detected over the entire length of the cable,
various cable lengths are available to facilitate leakage
sensing over a wide area.
When a leak is detected, a message is transmitted using
long range LoRa wireless to generate an alarm, so early
action can be taken.
Readings are transmitted to the cloud using long range LoRa
wireless, where the data can be displayed and analysed.
The unit is battery powered with long life of 3+ years
A built in USB port allows all parameters including detection
thresholds, sampling interval, wireless signal strength and
wireless network configuration to be viewed and set using
simple menus via any USB enabled host such as a PC or
Mac.
Features
• Various Rope lengths available
• LoRa long range wireless
• Frequency Range 863-870MHz
• Frequency Range 902-928MHz
• Up to +16dBm Tx Power
• Built in USB port for power and
configuration
• Battery powered
• CE / FCC compliant
#
.
• RoHS compliant
• Made in the UK
*
Option / Model dependent
#
Dependent on settings and environment
*
*
Advertisement
Related Manuals for Synetica enLink Status-L
Summary of Contents for Synetica enLink Status-L
- Page 1 • Configurable alarm threshold sensitivity • Adaptive transmission intervals enLink Status-L detects the presence of water leaks, flooding Features and condensation using water detection cable. Leakage or moisture is detected over the entire length of the cable, • Various Rope lengths available various cable lengths are available to facilitate leakage •...
- Page 2 Introduction enLink Status-L Water Leak Sensor helps protect your critical infrastructure from water related damage which could be caused by issues like faulty HVAC systems, leaks in pipes and adverse weather conditions. The unit detects the presence of water using a special conductive water detection cable. The leak detection sampling interval and detection thresholds can be user configured for the application.
- Page 3 When the device has successfully joined the network the Mode LED will blink GREEN five times to show that the join has been completed. The LED’s will then switch off to conserve the batteries. Blinking Green LED – Device Successfully Joined SYNETICA enLink Status-L User Guide Rev 1.5 Page | 3...
- Page 4 Setting / changing the enLink LoRaWAN keys For many applications, Synetica can supply enLink units with the LoRaWAN AppEUI and AppKey parameters pre-configured to your requirements, whereby if the LoRa gateway has matching keys the join process will happen automatically once the unit is in wireless range and switched on.
- Page 5 AppKey which you can then edit. R will set a random AppKey. Press Enter when the key is correctly entered to return to the Quick Start Settings Menu. AppKey setting Press X from the Quick Start Settings Menu to return to the enLink Main menu. SYNETICA enLink Status-L User Guide Rev 1.5 Page | 5...
- Page 6 Adaptive Max interval acts like a heartbeat, so if no change of alarm state occurs then a message is sent at the Adaptive Max interval. Press Enter when the key is correctly entered to return to the Quick Start Settings Menu. SYNETICA enLink Status-L User Guide Rev 1.5 Page | 6...
- Page 7 The O option allows the leak detection threshold to be set according to the required sensitivity. The defaults are: • L - Lower bound alarm level 400.0 kOhms • Y - Lower bound hysteresis ±100.0 kOhms SYNETICA enLink Status-L User Guide Rev 1.5 Page | 7...
- Page 8 From the configuration menu, the D option displays live readings The Live display menu above can be used to verify the sensitivity settings before deployment. SYNETICA enLink Status-L User Guide Rev 1.5 Page | 8...
- Page 9 Water Leak Cable Connections. enLink Status-L has an 8-way terminal block with screwless terminals for rapid connection of the leak cable. The cable is not polarity sensitive, so either cable can be attached in any order. Attach the leader cable to the...
-
Page 10: System Testing
Leak Status on the Live Display screen. Verify that a LoRaWAN message is sent to the application. The cable will need to be completely dry before the leak status returns to normal. SYNETICA enLink Status-L User Guide Rev 1.5 Page | 10... -
Page 11: Battery Installation/Replacement
Only install approved batteries: EVE ER14505 / SAFT LS14500 Lithium Thionyl Chloride AA Battery 3.6 Volt, or direct equivalent. Safe disposal • Please recycle responsibly, a wide range of schemes are available. • Do not dispose of in normal waste or in a fire. SYNETICA enLink Status-L User Guide Rev 1.5 Page | 11... -
Page 12: Technical Support
LoRaWAN Payload Decoder The latest LoRaWAN payload decoders and guides are available on the Synetica GitHub repository: https://github.com/synetica/enlink-decoder A live payload decoder which allows you to paste LoRa payloads in Hexadecimal or Base 64 and see the correctly decoded results can be found at the link below: https://synetica.github.io/enlink-decoder/...
