enLink Status-T
Temperature Sensor Probes, User Guide
LoRaWAN Wireless Temperature Sensor Probes
LoRaWAN long range wireless
•
Battery powered
•
•
Up to 3 high accuracy stainless steel temperature probes
Built in "edge processing" to automatically generate alarms for many applications
•
Applications
•
Legionella compliance monitoring
Freezer monitoring
•
•
Food storage temperature monitoring
enLink Status-T accurately measures temperature with three
precision temperature probes with a range of –55°C to +125°C.
Temperature measurement via flexible, long lead probes allows
precise temperature monitoring in a wide variety of applications
including HVAC duct and pipes, food storage, soil, remote asset
and legionella monitoring.
The three high accuracy, high precision, digital temperature
sensors are housed in waterproof stainless probes connected via
flexible 1 metre length cables. Built in "edge processing"
automatically generates alarm messages for a range of
applications including legionella compliance and food temperature
monitoring.
Readings are transmitted to the cloud using long range LoRa
wireless, where the data can be displayed and analysed.
The unit is battery powered with long life of 3+ years
•
Remote asset temperature monitoring
Soil temperature monitoring
•
•
HVAC pipe and duct temperature
monitoring
#
.
Features
• Up to 3 temperature probes
• LoRa long range wireless
• Frequency Range 863-870MHz
• Frequency Range 902-928MHz
• Up to +16dBm Tx Power
• Built in USB port for power and
configuration
• Battery powered
• CE / FCC compliant
• RoHS compliant
• Made in the UK
*
Option/Model dependent, see Selection Guide
#
Dependent on settings and environment
*
*
*
Advertisement
Table of Contents
Related Manuals for Synetica enLink Status-T
Summary of Contents for Synetica enLink Status-T
- Page 1 • HVAC pipe and duct temperature monitoring Features enLink Status-T accurately measures temperature with three precision temperature probes with a range of –55°C to +125°C. Temperature measurement via flexible, long lead probes allows • Up to 3 temperature probes precise temperature monitoring in a wide variety of applications •...
- Page 2 Note: In LoRaWAN 1.1, AppEUI was renamed to JoinEUI. For many applications Synetica can supply enLink Status units with the AppEUI and AppKey pre-configured, so providing the LoRa gateway has the matching values, the join process will happen automatically once the Status unit is in wireless range and switched on.
- Page 3 When the device has successfully joined the network the Mode LED will blink GREEN five times to show that the join has been completed. The LED’s will then switch off to conserve the batteries. Blinking Green LED – Device Successfully Joined SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 3...
- Page 4 For many applications, Synetica can supply enLink units with the LoRaWAN AppEUI and AppKey parameters pre- configured to your requirements, whereby if the LoRa gateway has matching keys the join process will happen automatically once the unit is in wireless range and switched on.
- Page 5 The header will show ** Reboot Required ** as shown below. The new key settings will not take effect until the enLink device is restarted. Enter R to reboot followed by OK. The device will restart with the entered AppEUI and AppKey and attempt to join the LoRa network. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 5...
- Page 6 Select a fixed transmit interval from the menu options. 15 minutes or longer is recommended to extend battery life. Press Enter when the key is correctly entered to return to the Quick Start Settings Menu. SYNETICA enLink Status-T Quick Start Guide Rev 1.1...
-
Page 7: Alarm Configuration
To set the unit for No alarming, enter the A (Configure All Probes Simultaneously) and the screen below will show. Enter 1 and all alarms will be disabled. Each temperature probe can be configured individually if required using the menu above. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 7... - Page 8 Next enter H and set the upper bound hysteresis level (the value should be between 0 and 50) Enter X to exit to the Temperature probes menu and review the settings. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 8...
- Page 9 Note: Each temperature probe can be configured individually if required using the menus above. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 9...
- Page 10 Next enter Y and set the upper bound hysteresis level (the value should be between 0 and 50) Enter X to exit to the Temperature probes menu and review the settings. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 10...
- Page 11 Note: Each temperature probe can be configured individually if required using the menus above. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 11...
- Page 12 To set the unit for in band alarming, enter the A (Configure All Probes Simultaneously) and the screen below will show. Enter 4 (In band alarm), the menu below will show. Enter 6 (Options), the menu below will show. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 12...
- Page 13 Finally enter Y and set the Lower bound hysteresis level (the value should be between 0 and 50) Enter X to exit to the Temperature probes menu and review the settings. Note: Each temperature probe can be configured individually if required using the menus above. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 13...
- Page 14 To set the unit for Out of band alarming, enter the A (Configure All Probes Simultaneously) and the screen below will show. Enter 5 (Out of band alarm), the menu below will show. Enter 6 (Options), the menu below will show. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 14...
- Page 15 Finally enter Y and set the Lower bound hysteresis level (the value should be between 0 and 50) Enter X to exit to the Temperature probes menu and review the settings. Note: Each temperature probe can be configured individually if required using the menus above. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 15...
-
Page 16: Temperature Probe Connections
Two Temperature Sensor Probes Fitted Temperature Sensor Terminal Function Cable Colour Number Sensor 1,2 and 3 YELLOW Sensor 1 BLACK YELLOW Sensor 2 BLACK YELLOW Sensor 3 BLACK Three Temperature Sensor Probes Fitted SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 16... -
Page 17: Battery Installation/Replacement
Only install approved batteries: SAFT LS14500 or EVE ER14505 Lithium Thionyl Chloride AA Battery 3.6 Volt, or direct equivalent. Safe disposal • Please recycle responsibly, a wide range of schemes are available. • Do not dispose of in normal waste or in a fire. SYNETICA enLink Status-T Quick Start Guide Rev 1.1 Page 17... -
Page 18: Power Considerations
LoRaWAN Payload Decoder The latest LoRaWAN payload decoders and guides are available on the Synetica GitHub repository: https://github.com/synetica/enlink-decoder A live payload decoder which allows you to paste LoRa payloads in Hexadecimal or Base 64 and see the correctly decoded results can be found at the link below: https://synetica.github.io/enlink-decoder/...
