C&O ALLEGHENY
DIE-CAST STEAM ENGINE
OPERATING INSTRUCTIONS
Thank you for purchasing the RailKing die-cast C&O Allegheny steam locomotive. The
engine's die-cast body and tender are traditionally sized for operation on any O-31 or larger
layout. The engine is compatible with any standard AC transformer, (see page 25 for a
complete list of compatible transformers and wiring instructions) and is completely
compatible with most other 3-rail locomotives, rolling stock and accessories.
The locomotive and tender are equipped with either an electronic whistle or the
ProtoSound digital sound and train control system which contains several deluxe features
that are simple and fun to operate. Each feature is described among the following pages
which should be read before the engine is operated. For those of you who can't wait to get
started, the Quick Start Basic Operating Instructions found on pages 3 and 4 should be
read so that you understand the basics of the operating system. Please note that some
features are only found in the ProtoSound equipped engines and are marked as such.
Features not marked as ProtoSound features are available in both versions.
