CAUTION: ELECTRIC TOY:
Not recommended for children under 14 years of age without adult supervision. As with all electric products, precautions
should be observed during handling and use to prevent electric shock.
WARNING: When using electrical products, basic safety precautions should be observed, including the following:
Read this manual thoroughly before using this device.
M.T.H. recommends that all users and persons supervising use examine the hobby transformer and other electronic equipment
l
periodically for conditions that may result in the risk of fire, electric shock, or injury to persons, such as damage to the primary
cord, plug blades, housing, output jacks or other parts. In the event such conditions exist, the train set should not be used until
properly repaired.
Do not operate your layout unattended. Obstructed accessories or stalled trains may overheat, resulting in damage to your layout.
l
This train set is intended for indoor use. Do not use if water is present. Serious injury or fatality may result.
l
Do not operate the hobby transformer with damaged cord, plug, switches, buttons or case.
l
PLEASE READ BEFORE USE AND SAVE
®
McDonald's is a registered trademark of the McDonald's Corporation
McDonald's®
Restaurant
www.mthtrains.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAILKING McDonald's Restaurant and is the answer not in the manual?

Questions and answers

Summary of Contents for MTHTrains RAILKING McDonald's Restaurant

  • Page 1 This train set is intended for indoor use. Do not use if water is present. Serious injury or fatality may result. Do not operate the hobby transformer with damaged cord, plug, switches, buttons or case. PLEASE READ BEFORE USE AND SAVE www.mthtrains.com ® McDonald's is a registered trademark of the McDonald's Corporation...
  • Page 2 NPACKING Your Operating McDonalds Restaurant arrives requiring minimal assembly. Inside the box you will find the following parts: Activation Button ® McDonald's Building Ford Explorer 1 Activation Button 6 Wires (2 red, 4 black) SSEMBLY Attach the Ford Explorer to the tab in the recessed slot as shown.
  • Page 3 NSTALLATION Place in desired spot on layout. Wiring Connect Red wire to transformer AC and connect Black wire to activation button Connect Black wire to transformer ground Activation Button Connect Black wire to activation button Connect Red wire to transformer AC Connect Black wire to transformer ground...
  • Page 4 PERATING NSTRUCTIONS This operating McDonald's brings a touch of authentic Americana to any modern era layout. At the push of a button, the Ford Explorer pulls forward and places an order, then drives through to pay and pick up the food before pulling away from the window.
  • Page 5 IGHTBULB EPLACEMENT 1. Remove the twelve recessed screws as shown from the base of the structure. Use a magnetized screw driver and be very careful to not drop any screws inside the base. Doing so will require that the disk mechanism be removed in order to free the loose screws.
  • Page 6 IGHTBULB EPLACEMENT CONTINUED Lift building and carefully unplug three electrical connectors holding building to base. GENTLY LIFT COLUMN AWA Y FROM BASE TO UNPLUG INTERIOR LIGHT HARNESS CONTINUE LIFTING BUILDING AWA Y FROM BASE TO EXPOSE INTERIOR WIRING HARNESS & PLUGS GENTLY PULL EACH WIRE HARNESS PLUG...
  • Page 7 IGHTBULB EPLACEMENT CONTINUED 3. Pull bulb out and pop in replacement. 4. Re-connect electrical connectors as shown: -Large connector to large plug. -Red-wired connector to plug with red mark. -Black-wired connector to plug with no mark. -If you unplugged the blue-wired connector (unnecessary), it goes into plug with blue mark.
  • Page 8 Service & Warranty Information How to Get Service Under the Terms of the Limited One-Year Warranty When you suspect an item is defective, please check the operator's manual for standard operation and trouble- shooting techniques that may correct the problem. Additional information may be found on the M.T.H. Website. Should you still require service, follow the instructions below to obtain warranty service.
