  • Page 1 Raffinato FIREPIT Installation guide and owner’s manual...

  • Page 2: Table Of Contents

    PLEASE SAVE THIS OWNER’S MANUAL FOR FUTURE REFERENCE Check with your municipality for regulations on the installation and use of outdoor fire pits. We also recommend that you contact your home insurance company and advise them of the acquisition of your new Techo-Bloc fire pit.

  • Page 3: Components

    WE RECOMMEND THAT GAS FIRE PIT PRODUCTS ARE INSTALLED BY PROFESSIONALS LOCALLY LICENSED BY THE AUTHORITY HAVING JURISDICTION IN GAS PIPING. REFER TO MANUFACTURER'S INSTALLATION AND OPERATION INSTRUCTIONS. Components A. Raffinato 90 mm corner block B. Raffinato C. Raffinato Cap 90 mm (with colour accent)(x10) 180 mm corner block 12"...

  • Page 4: Overall Dimensions

    (838 mm) (249 mm) - RAFFINATO RAFFINATO CAP 90 mm (PRE-CUT) ±33'' ±9 13/16'' - RAFFINATO D. RAFFINATO 180 mm CORNER BLOCK (249 mm) ELEVATION B E. RAFFINATO 90 mm CORNER BLOCK ELEVATION B ELEVATION B F. TECHO-BLOC PAVERS OR SLABS RECOMMENDED LOCATION FOR G.

  • Page 5: Positioning Reference Per Layer

    Positioning reference per layer Foundation FOR A GAS FIRE PIT, PLAN THE INSTALLATION preparation (GAS LINE, RISER) ACCORDINGLY WITH A PROFESSIONAL LOCALLY LICENSED BY THE AUTHORITY HAVING JURISDICTION IN PAVER SURFACE OR CONCRETE SLAB GAS PIPING. REFER TO If you are building the fire pit on an existing paver surface MANUFACTURER'S INSTALLATION AND OPERATION INSTRUCTIONS.

  • Page 6: Installation Of Blocks

    ENSEMBLE POUR INSTALLATION AU GAZ WOOD FIRE PIT SLEEVE INSERT INSTALLATION USE STEEL INSERT AS TEMPLATE DATE : DATE : 2022-12-20 2023-02-22 RAFFINATO FIREPIT FOYER RAFFINATO RAFFINATO DRAWN BY : DESSIN: THESE GRAPHICAL REPRESENTATIONS ARE INTENDED I.G. I. G. CE DESSIN EST DESTINÉ UNIQUEMENT À DES FINS...

  • Page 7: Operation And Maintenance

    TECHO-BLOC OUTDOOR FEATURES www.techo-bloc.com TYPICAL DETAILS FILE: RAFFINATO 90 mm CORNER BLOCK BLOC DU COIN RAFFINATO 90 mm RECOMMENDED LOCATION ON LAYER 2 FOR VENT ACCESSORY (GAS KIT) RECOMMENDED LOCATION ON LAYER 2 FOR IGNITION CONTROL (GAS KIT) RECOMMENDED LOCATION ON LAYER 2...
  • Page 8 › Do not burn charcoals, leaves, trash, paper, cardboard, and softwoods such as pine, cedar and plywood. › Do not use lighter fluid, gasoline, or other fire accelerants to start or maintain fires. › Never touch the steel insert and flange while a fire is lit. The steel insert and flange will become extremely and burn the skin on contact.

  • Page 9: Warranty

    Available in wood, natural gas & liquid propane burning options. Visit techo-bloc.com to discover more. Raffinato 12" × 24" caps included. Metal fire pit insert sold separately. The installation of a sleeve or accessory kit will prevent damages to your fire pit...
  • Page 10 5135 Surrett Dr., Archdale, NC 27263 OHIO 97 Industrial St., Rittman, OH 44270 PENNSYLVANIA 852 W. Pennsylvania Ave., Pen Argyl, PA 18072 PENNSYLVANIA 23 Quarry Rd., Douglassville, PA 19518 C O N T A C T U S TOLL FREE: 1.877.832.4625 WWW.TECHO-BLOC.COM PROUD MEMBER OF...
