  • Page 1 CleanTech ® EVO Wall Installation & Operation Manual...
  • Page 2 Meritech Systems, LLC. Satisfactory performance or effectiveness of the CleanTech ® Station cannot be guaranteed when other chemicals are used. FAILURE TO USE MERITECH SYSTEMS, LLC SUPPLIED CHECMICALS WILL VOID ANY AND ALL WARRANTIES...

  • Page 3: Table Of Contents

    Unpacking & Installing this EVO Station Cut Sheets & Installation Rough-In Diagrams Section 2: Installing & Using Hygiene Solutions Importance of Using Meritech Hygiene Solutions Installing Hygiene Solution Cartridges Section 3: How to Use the Display Touchscreen Station Setup Screens Hygiene Solution Installation &...

  • Page 4: Introduction

    Help & Support The first thing you need to know about us is that we're more than just an equipment manufacturer. When you partner with Meritech, our hygiene experts are here to help make sure that you have everything you need for hygiene excellence at your facility, starting with choosing the perfect place for your new automated hygiene equipment.

  • Page 5: Achieving The Perfect Hand Wash

    Achieving the Perfect Hand Wash ® The CleanTech EVO system provides a no-touch, completely automatic hand wash by sequentially delivering handwashing solution and water in a stimulating spray to the hands or gloves from fingertips to wrist. The system uses the UPX - UltraPure hand hygiene solution and water to remove more than 99.9% of pathogens from hands or gloves.

  • Page 6: Helpful Pointers For Trouble-Free Operation

    EVO Stations have been designed to be left in the power "on" mode over normal periods of operation. During extended periods of time (3 • months or longer) when the system will not be used, we recommend contacting Meritech Support at support@meritech.com or 800-932-7707 for assistance in prepping the station for this unused period of time.

  • Page 7: Optional Cleantech® Enhancements For This Evo Station

    ® Optional CleanTech Enhancements for this EVO Station Air Curtain At the end of every wash cycle, a curtain of air blows air on to the hands to partially dry them, reducing paper towel waste. This enhancement is ideal for companies seeking a “greener”...

  • Page 8: Section 1: Unpacking & Installing This Evo Station

    Specifications Before we get started, let’s review the specifications for the CleanTech ® EVO Wall Automated Handwashing System. For a list of parts, please contact the Meritech support team at support@meritech.com Features • Touch Screen Display • Auto Calibration •...
  • Page 9 35 - 100 PSI / 4 GPM minimum (3/8" ID supply line Min.) • Water Supply Hoses Included • Backflow preventor – ASSE 1024 Note: Consult Meritech if connecting more than 2 system on the same water lines • Drain • 1 1/2" Slip Drain P-Trap Included •...
  • Page 10 Important Information: Codes varies from municipality to municipality, Meritech has Maintenance designed in the devices listed above to meet most jurisdictions. • Daily, Weekly, & Quarterly (see maintenance section of this manual) Conformity and compliance to local and national plumbing / health...

  • Page 11: Handwash Temperature Control & Backflow Prevention

    Backflow Preventor Codes varies from municipality to municipality, Meritech has designed in the devices listed above to meet most jurisdictions. Conformity and compliance to local and national plumbing / health departments regulations regarding backflow prevention is theresponsibility of the installer.

  • Page 12: Unpacking & Installing This Evo Station

    If these hook-ups are not readily available, you will need to consult with your commercial plumber or electrician. Because of th e different building codes and licensing regulations, Meritech cannot accept responsibility for providing plumbing and electrical modifications to your facility. However, a Meritech installation specialist will be happy to provide the necessary guidance to ensure a correct installation.

  • Page 13: Cut Sheets & Installation Rough-In Diagrams

    Cut Sheets & Installation Rough-In Diagrams Air Curtain Inlet Water Inlet 1 ½” Drainpipe Fittings...
  • Page 14 IF YOU SHOULD EXPERIENCE ANY DIFFICULTY OR ARE UNSURE ABOUT THE INSTALLATION PROCEDURE, WE ENCOURAGE YOU TO CONSULT IMMEDIATELY WITH MERITECH. Meritech Systems, LLC 720 Corporate Circle, Suite K Golden, CO 80401 USA Website: www.meritech.com Phone: (800) 932-7707 Fax: (303) 790-4859...

  • Page 15: Section 2: Installing & Using Hygiene Solutions

    Download these efficacy studies and learn more at www.Meritech.com/efficacy Need to order more hygiene solutions? Go the Digital Owner’s Guide to order more solutions or contact the Meritech support team anytime at support@Meritech.com or 1(800) 932-7707 WARNING: The performance and effectiveness of CleanTech ®...

  • Page 16: Installing Hygiene Solution Cartridges

    Installing Hygiene Solution Cartridges Unpacking and Installing the Meritech Hygiene Solution Cartridges All CleanTech ® EVO Automated Handwashing Stations require our hygiene solution cartridges to perform the perfect hand wash. To begin using y our system, install the UPX UltraPure hand hygiene solution, using the instructions below:...

  • Page 17: Section 3: How To Use The Display Touchscreen

    EVO station works during the setup process. Please note: touch the screen with a firm touch, the screen was designed to be durable so it will not respond to a light touch. For additional help using the display, please contact the Meritech support team at support@meritech.com or 1 (800) 932-7707.
  • Page 18 31 to set the date and time in the system. Unless written notice is provided otherwise by Customer to Meritech prior to the delivery of EVO system products, Customer ag rees and authorizes the sharing and uploading to Meritech’s or Meritech’s affiliated servers from Internet-connect-capable EVO system products the following data: customer identification, unit serial number, manufacturing date, operational, troubleshooting, and maintenance data.
  • Page 19 Station Setup Screens Configuring the Auto Warm Up Cycle schedule Configuring the Auto Warm Up Cycle will allow you to customize the specific days and times that the handwashing station needs to be at the optimum temperatures of 100-105° F for your staff. Once set, the station will automatically turn on get the handwashing station to parameters set. We recommend a water temperature range of 100–...
  • Page 20 The next 3 screens walk you through verifying the facility drain, hot & cold lines are connected and turned on. For step-by-step instructions please see page 12 of this manual that review these install instructions. Should you have any difficulty with these drain or water connections, please contact the Meritech support team.

  • Page 21: Hygiene Solution Installation & Setup Screens

    Hygiene Solutions Installation & Setup The next several pages will review the screens that will appear after the system installation screens. These next screens will walk you through the installing the hygiene solution cartridge(s) into your station. UltraPure Solution Installation Steps The screens shown to the right, will walk you through the steps to install the UP UltraPure Hand Hygiene Solution...
  • Page 22 SelfClean may not be available on all models of CleanTech ® EVO Stations. On the EVO Wall, the self-cleaning functionality of the station is a CleanTech ® Enhancement. For additional information please contact the Meritech sales team at support@meritech.com or 1(800) 932-7707.
  • Page 23 Hygiene Solutions Installation & Setup ® Priming the CleanTech Station After the solutions have been installed, the system is now ready to be primed. Priming mode will fill the solutions lines with the UP or SelfClean solutions so that the very first handwash is prepared for the first user.

  • Page 24: Using The Display Touchscreen

    Using the display touchscreen ® The next several pages will review the displays that are accessible to you now that the CleanTech station has been setup, configured and solution cartridges have been installed. These areas of the display can be accessed at any time now that the station has been setup. Navigating the Home Screen The home screen will always show on the Unlock Screen...
  • Page 25 Hygiene tips will also show on the home Steps to screen communicating the importance of Washing Your handwashing in preventing the spread of harmful pathogens. Hands These instructions and tips show in both English and Spanish. For help with additional languages, please contact the Meritech support team.
  • Page 26 Using the Display Touchscreen Countdown Timer During the automated hand wash, a countdown timer will display a large 12 second countdown timer. The purpose of this timer is to improve handwashing compliance and encourage users to keep their hands in the station for the full duration of the automated handwashing cycle. Once hands have passed the photoeye sensor and initiated the hand washing cycle, the system will go into a 1 second priming mode to prime the cylinders with water.

  • Page 27: Administrative Area Of The Touchscreen Display

    Administrative Area of the Touchscreen Display The next several pages will review the displays that are only accessible to administrators who are authorized with the pin toconfigure the station and view hygiene compliance information. These areas of the display can only be accessed with the customer pin. Customer Pin Check Once You Touch the Lock Symbol...
  • Page 28 Once in the Main Menu, you can select any of the sub-menus this will guide you to the specific area. These sub-menus area outlined within this manual as indicated in the table below. Menus with a symbol are only accessible by Meritech Technicians Menu Area Pages in this manual...
  • Page 29 The below system Settings screen allows you to adjust the network settings, units, date & time, water temperature, and language. Menus with a symbol are only accessible by Meritech Technicians * Menus only accessible by Meritech Technicians...
  • Page 30 Admin Area Settings - Network Network screens allow you to make edits to the Network connections...
  • Page 31 Admin Area Settings - Time Admin Area Settings - Units If connected via Wi-Fi the Date & Time function will be automatic Units' menu you allows you to and will not need to be adjusted. switch from Imperial to Metric. Only use this menu to adjust Date &...
  • Page 32 The water temperature screen and its sub-menus allow adjustment to Auto Warm Up and Over Temp Shutdown Menus with a symbol are only accessible by Meritech Technicians Menu used to adjust the Auto Warm Up cycle by Enabling and adjusting time and days per week.
  • Page 33 Admin Area Settings – Language This screen allows you to set the language for the EVO Handwashing Station. Right now, only English is available, however other languages are being developed. To change the language, click on the English bar above to then scroll through a list of languages and hit “Apply”.
  • Page 34 Admin Area of the Touchscreen Display System Health System Health Screen Gives Real Time Data on the Health of the Facility and System as well as Current Solutions Levels, & any Error Codes If one of these settings is out of parameter a station error code will be displayed. Some of these items might self-correct in time.
  • Page 35 The EVO station also has a video on how to change solutions for your maintenance team. There are also QR codes under Owners Guide and Meritech Website that will guide you to many documents to help with all your hygiene needs...
  • Page 36 Admin Area of the Touchscreen Display Compliance Within the Compliance menu you will be able to perform a few functions Enable or Disable the Auto Count Rest. Auto Count Reset allows for a time of day you chose for the Hygiene Events in the Home screen to be reset to zero.
  • Page 37 ID, customer pin #, last service date, & last calibration date Calibration This station has already been calibrated to ensure maximum performance. For calibration information see the CleanTech station's "Product Support" screen or reach out to the Meritech support team.

  • Page 38: Section 4: Maintenance & Components Of This Evo Station

    Section 4 Protect Your Station Meritech does not recommend hose down or Maintenance & Components of this EVO Station power washing any CleanTech ® EVO stations. Hand Wipe Only Cleaning & Maintenance Instructions for this EVO Station To maintain your EVO stations cleanliness and high-quality handwashing that is expected from a CleanTech station.
  • Page 39 Touch Screen Cleaning & Disinfection When cleaning a touchscreen, it is important to realize they are sensitive to chemicals and high pressure washdown. They are also subjected to scratching if cleaning with abrasive cloths that will then affect the operation of the touchscreen. Cleaning and disinfection are two different steps.

  • Page 40: Major Components Of This Evo Station

    Major Components of this EVO Station External Components Touch Screen Display Top Cover Handwash Cylinders Photoeye Lens (4) Solution Door, Access Latch & Optional Key...
  • Page 41 Internal Components Top Cover Screws (solutions door must be opened to access screws for Bottle Pierce Tube top cover removal) Assy. (internal to solution receptacle) – UPX & SelfCleanX Station Serial Label Solutions Bottle Vent Check Valve (back side of receptacle) Solutions Receptacle Solutions Receptacle Tilting Latch...
  • Page 42 System Power Switch, Fuse Internal Components Holder, IEC Power Cord SelfCleanX Solutions Pump Location (if equipped) UPX Solutions Pump Handwash Temp Sensor Air Curtain Valve (thermostatic mixing valve) ASSE 1070 (if equipped) Water Valve & Backflow Facility Hot & Cold-Water Preventor –...
  • Page 43 Internal Components Electronics Module Display Enclosure & Motor & Pulley for Cylinders HDMI Cables Wi-Fi Dongle Cylinder Idler Bearings 24 VDC Power Supply 12 VDC Power Supply Drive Belts Photoeye Receiver Photoeye Emitter Solutions Door Striker Plate Handwash Cylinders Top Cover Mounts...

  • Page 44: Section 5: Warranty And Terms & Conditions Of Sale

    Product. A replacement part/product assumes the remaining Warranty Period of the original Product or thirty (30) days from the date of replacement or repair, whichever provides longer coverage to the Original Purchaser. When a product or part is exchanged, any replacement item becomes the Original Purchaser’s property and the replaced item becomes Meritech’s property. Any suspected defect shall be subject to inspection and confirmation by Meritech.
  • Page 45 INDEMNIFICATION: Buyer agrees to protect, indemnify, hold harmless and defend Meritech and its members, managers, officers, affiliates, agents and employees against any and all losses, damages, claims, lawsuits, demands, causes of action, judgments, liabilities and exp enses (including attorneys’...
