Blu-ray disc recorder
Table of Contents

Advertisement

Quick Links

Dear customer
Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully.
Before connecting, operating or adjusting this product, please read the instructions completely.
Please keep this manual for future reference.
This Blu-ray Disc Recorder is for viewing and recording free to view channels only. It does not receive
pay TV or encrypted channels.
DVB and the DVB logos are trademarks of the DVB Project.
∫ Region management information
BD-
This unit plays BD-Video marked with
Video:
labels containing the region code "B".
Example:
Web Site: http://www.panasonic-europe.com
Model number suffix "EB" denotes UK model.
EB
Operating Instructions
Blu-ray Disc Recorder
Model No.
DVD-
This unit plays DVD-Video marked with
Video:
labels containing the region number "2" or
"ALL".
Example:
2
DMR-BW880
DMR-BW780
2
3
ALL
5
VQT2J65
