- Page 1 40-VOLT MAX* | 2.0 Ah | 15-AMP | 13-INCH | SNOW SHOVEL COVER OPERATOR’S MANUAL Model iON13SS-LTE-HYB-RM A Division of Snow Joe , LLC ® Form No. iON13SS-LTE-HYB-RM-880E-V1 THANKS YOUR PURCHASE OF A REMANUFACTURED PRODUCT. To make sure you get the most out of your product, be sure to register online at snowjoe.com...
-
Page 2: General Safety Warnings
OPERATOR’S MANUAL Model iON13SS-LTE-HYB-RM A Division of Snow Joe , LLC ® Form No. iON13SS-LTE-HYB-RM-880E-V1 IMPORTANT! 7. Moving parts – Keep hands and feet away from moving parts. Keep guards in place and in proper working order. Safety Instructions CAUTION! Exercise caution to avoid slipping or falling. -
Page 3: Operation
Training • Never operate the hybrid snow shovel without proper guards and other safety devices in place and in proper • Read, understand, and follow all instructions on the working order. machine and in the manual before operating this unit. •... -
Page 4: Battery + Charger Safety Instructions
This hybrid snow shovel is double-insulated, eliminating the Despite all the safety precautions, caution must always be exercised when handling batteries. The following points must need for a separate grounding system. Use only identical be obeyed at all times to ensure safe use. Safe use can only replacement parts. - Page 5 ® ® 9. Avoid damage and shocks. Immediately replace batteries 1-866-SNOWJOE (1-866-766-9563) for assistance. that have been dropped from a height of more than one • Battery chemicals cause serious burns – Never let a meter or those that have been exposed to violent shocks, damaged battery pack contact the skin, eyes, or mouth.
-
Page 6: Electrical Safety
+ Sun Joe customer service ® ® center at 1-866-SNOWJOE (1-866-766-9563). 5. Do not keep the battery charger in places where the temperature is liable to reach over 104°F (40°C). In 3. Electrical plugs must match the outlet. Never modify particular, do not leave the battery charger in a car that is the plug in any way. - Page 7 ® extension cord with lighted end (Model PJEXT50-B). Visit snowjoe.com to purchase this extension cord online or, to order by phone, call 1-866-SNOWJOE (1-866-766-9563). • Do not use an extension cord over 100 ft (30 m). • Do not touch the appliance or its plug with wet hands or while standing in water.
-
Page 8: Safety Symbols
Safety Symbols The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions READ THE OPERATOR'S WARNING! Do not expose the MANUAL(S) –... -
Page 9: Technical Data
Know Your Hybrid Snow Shovel Read the owner’s manual and safety rules carefully before operating your hybrid snow shovel. Compare the illustration below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. -
Page 10: Carton Contents
® ® upper and lower tubes and secure the other end with the 1-866-SNOWJOE (1-866-766-9563). joint-fixing knob (Figs. 3 & 4). NOTE: Do not discard the shipping carton and packaging NOTE: You may have to carefully move the wiring inside material until you are ready to use your new hybrid snow the tube to one side if it blocks the path of the bolt. -
Page 11: Charger Operation
Positioning the Adjustable Handle 1. Loosen the handle knob. 2. Move and rotate the adjustable handle to a comfortable working position (Fig. 5). Lights Light Indicators Charge level button Fig. 5 The battery is at 30% capacity and requires charging The battery is at 60% capacity and requires charging soon The battery is at full capacity... -
Page 12: Charging The Battery
When you insert Snow Joe + Sun Joe customer service center at ® ® the battery into the charger, the bottom red light will 1-866-SNOWJOE (1-866-766-9563) for assistance. illuminate to indicate that the battery is charging (Fig. 9). - Page 13 7. When charging is complete, remove the battery from the • If the unit has the power cord connected WITHOUT the battery inserted: the unit will start with in AC mode. charger by pulling the push lock button and sliding the battery backward to unlock it from the charger (Fig. 10). • If the unit has the battery inserted WITHOUT the power cord connected: the unit will start in DC mode.
- Page 14 If you are using DC power mode: 4. Note that the hybrid snow shovel has a polarized male plug – one prong in the plug is slightly longer and wider 1. Open the battery compartment cover and slide the battery than the other (Fig.
-
Page 15: Operating Tips
To order genuine replacement parts or accessories for the Belt Snow Joe iON13SS-LTE-HYB-RM hybrid snow shovel, please ® visit snowjoe.com or contact the Snow Joe + Sun Joe ® ® customer service center at 1-866-SNOWJOE (1-866-766-9563). Proper Care for Battery + Charger... -
Page 16: Replacing The Belt
4. Disassemble the right side cover by removing the five (5) 7. Remove the old auger from the housing (Fig. 23). screws that hold it in place (Fig. 20). Fig. 23 Fig. 20 Auger 8. Install the replacement auger by following the above steps in reverse order (Fig. -
Page 17: Replacing The Scraper Blade
+ Sun Joe ® ® ® Fig. 27 customer service center at 1-866-SNOWJOE (1-866-766-9563) for assistance. 2. Remove the battery from the hybrid snow shovel before storing. 3. Store the hybrid snow shovel indoors in a locked, dry 4 screws place out of the reach of children to prevent unauthorized use or damage. -
Page 18: Service And Support
6. Do not dispose of batteries in fire. 7. Batteries should be recycled or disposed of as per state and local guidelines. Service and Support If your Snow Joe iON13SS-LTE-HYB-RM hybrid snow shovel ® requires service or maintenance, please call the Snow Joe + Sun Joe customer service center at ®... - Page 19 NOTE: Accessories are subject to change without any obligation on the part of Snow Joe + Sun Joe to provide notice of such ® ® changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe + Sun Joe customer ® ®...
- Page 20 NOTES...
- Page 21 NOTES...
- Page 22 NOTES...
- Page 23 We’re here to help Monday through Friday from 9AM to 6PM EST. You can reach us at 1-866-SNOWJOE (1-866-766-9563), online EXCLUSIONS: at snowjoe.com, via email at help@snowjoe.com or tweet us • Wearing parts like belts, augers, chains and tines are @snowjoe.
