Preparation for using your new TV – Connections
CONNECTIONS AND EXTERNAL INPUT SETTINGS
1. Checking Items before Connecting
Please check the list below before connecting the product to other devices.
< Check items before connecting >
Check the instruction manual when connecting external devices. External products sometimes have
different buttons and locations.
A.
Do not connect the power unless every connection is well connected. The product may be
damaged if turned on while still in the process of being connected.
B.
Connect the left (white) and right (red) cables correctly to the sound cable.
C.
Check the terminals to connect the product to on the rear panel.
2. Connecting an Antenna
There are internal and external types of antenna.
< Connecting an Antenna >
A.
Use a coaxial cable to connect the rear panel of the TV's [AIR] or [CABLE] terminals and the wall
mount or external antenna.
B.
When an Air signal is required, connect to the [AIR] terminal. If a Cable signal is required,
connect to the [CABLE] terminal. If both Air and Cable are available, and then connect both [AIR]
and [CABLE] terminals.
C.
Connect the TV power cord when connecting everything else.
CAUTION
Avoid bending the copper tip at the center of the coaxial cable.
Cable TV network
