- Page 1 T-BAT-SYS-HV-S25 T-BAT-SYS-HV-S36 Installation Manual www.solaxpower.com eManual in the QR code or at http://kb.solaxpower.com/ 2022-12_Rev_00_EN...
- Page 3 Safety General Notice 1. Contents may be periodically updated or revised. SolaX reserves the right to make improvements or changes in the product(s) and the program(s) described in this manual without the prior notice. 2. The installation and maintenance can only be performed by qualified personnel who: •...
- Page 4 DANGER! In the case of any of following circumstances, electric shock may occur: • Disassemble the battery module; • Touch the battery module with wet hands; • Install or operate the battery module in places where there is excessive moisture or liquids.
- Page 5 Packing List BMS (TBMS-MCS0800) Communication cable × 1 Power cable (Black) × 1* (BMS port) Adjustable bracket × 1 Power cable (Red) × 1* Short power cable × 1 BMS × 1 M4×15 M6 Flange RNB5-6 Current Phillips-head Adjustable L bracket × 1 Rotation wrench ×...
- Page 6 Series Box Grounding cable × 1 Communication cable × 1 (COM port) Power cable (Black) × 1 Heater cable × 1 (HEAT port) Power cable (Red) × 1 Adjustable bracket × 1 BMS × 1 M4×14 M4×15 M4 Washer Phillips Head M6 Flange Phillips-head Adjustable L bracket ×...
- Page 7 Installation Space >100 mm >100 mm >100 mm >400 mm >400 mm >400 mm >400 mm 400~ One group Two groups *Note: The above figure shows an example of installation space of "One Group" and "Two Groups". Installation Tools Drill Measuring tape Marker Cross screwdriver...
-
Page 8: Mechanical Installation
Mechanical Installation *Note: Up to 9 battery modules can be installed in a group. If the battery module users purchased excesses 10 sets (including 10), a Series Box needs to be installed to connect two groups in series. Installation steps without Series Box Take the installation procedure for four battery modules as an example. - Page 9 Step 4: Secure and tighten M4x14 Phillips-head screw on both sides 0.9-1.1 N·m Step 5: Repeat the Step 3 and 4 to install the rest of battery modules Step 6: Join Adjustable Bracket and Adjustable L Bracket with M6 Flange Nut Place battery modules Attach M6...
- Page 10 Do not remove dust cover on the top battery φ 10 mm 90° ≥ 50 mm Remove bracket Remove Tapping screw dust cover 4 N·m Tighten Tighten Tighten 0.9-1.1 N·m 5 N·m...
- Page 11 Step 8: Place BMS Both sides 0.9-1.1 N·m Installation steps with Series Box The group The installation procedure for also needs these two groups is the same as bracket that for one group. Please refer to Step 1 to 8.
- Page 12 Current Terminal Connection 6.4 mm Length=28-30 mm 4-6 mm² Heat-shrink tubing Length=8-10 mm 4.5-5 N·m *Note: The grounding cable should be prepared by the users themselves. Communication Connection (connecting to inverter) Rotate anti-clockwise to loosen 1) White with orange stripes 2) Orange 3) White with green stripes 4) Blue...
- Page 13 Wiring *Note: Press the door panel at both sides of BMS before wiring. Wiring without Series Box Left side of BMS Short power cable Lock button There are two terminals at both ends. Waterproof Waterproof plug *Note: In case of one group, a waterproof cap shall be put on the unconnected COM port, as well as a waterproof plug on the unconnected HEAT port.
- Page 14 Right side of BMS Rotation wrench Power cable (red) Communication cable Lock button This type of terminal is available Grounding cable Power cable (black) on both power cables *Note: 1. Press and hold the Lock Button while unplugging the power cable, or it cannot be pulled out.
- Page 15 Wiring with Series Box Wiring between BMS and Series Box Power Heater cable cable (red) (HEAT port) Communication cable (COM port) Grounding cable Rotation wrench Power cable (black) Communication Heater cable cable (COM port) (HEAT port) Power cable (red) Grounding cable Power cable (black)
- Page 16 Make sure that the heater cable is locked Rotate anti-clockwise to remove waterproof plug Insert heater cable into HEAT port, and rotate clockwise to lock it Align the groove according to the arrows...
- Page 17 Right side of BMS Rotation wrench Power cable (red) Communication cable Lock button This type of terminal is available Grounding cable Power cable (black) on both power cables *Note: 1. Press and hold the Lock Button while unplugging the power cable, or it cannot be pulled out.
-
