Pictorial index

For safety

1

and security

Instrument

2

cluster

Operation of

3

each component

4

Driving

5

Interior features

Maintenance

6

and care

When trouble

7

arises

Vehicle

8

specifications

9

For owners

Index

Search by illustration

Make sure to read through them

How to read the gauges and meters, the variety of

warning lights and indicators, etc.

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advice which are necessary for

driving

Usage of the interior features, etc.

Caring for your vehicle and maintenance

procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Reporting safety defects for U.S. owners

Search by symptom

Search alphabetically

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the AVALON HYBRID 2017 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota AVALON HYBRID 2017

Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of warning lights and indicators, etc. cluster Operation of Opening and closing the doors and windows, adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Instrument cluster Reading this manual ....14 How to search......15 Pictorial index ......16 Instrument cluster Warning lights and For safety and security indicators ......86 Gauges and meters ..... 90 Multi-information display..94 1-1.
Page 3 4-5. Using the driving Driving support systems Toyota Safety Sense P..202 PCS (Pre-Collision 4-1. Before driving System) ......209 Driving the vehicle..... 156 LDA (Lane Departure Cargo and luggage.... 166 Alert with steering Vehicle load limits ..... 169 control) ......222 Trailer towing.....
Page 4 TABLE OF CONTENTS 5-4. Other interior features Interior features Other interior features..299 • Sun visors ..... 299 • Vanity mirrors ....299 5-1. Using the air conditioning system • Clock ......300 and defogger • Outside temperature Automatic air conditioning display ......
Page 5 Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers... 392 the vehicle exterior..326 If your vehicle has to be Cleaning and protecting stopped in an the vehicle interior... 329 emergency....... 393 6-2.
Page 6 TABLE OF CONTENTS Vehicle specifications Index What to do if... 8-1. Specifications (Troubleshooting)..... 472 Maintenance data (fuel, oil level, etc.) ..436 Alphabetical index ...... 476 Fuel information ....445 Tire information ....448 8-2. Customization Customizable features ..461 8-3.
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 10 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13 In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 15: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 476 ■ Searching installation position • Pictorial index....P. 16 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 472 ■ Searching by title • Table of contents .....P. 2...
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ......... . . P. 110 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ....... . . P. 193 Precautions against winter season ..... P. 269 Precautions against car wash .
Page 18 Pictorial index ■ Instrument panel Power switch ........P. 172 Starting the hybrid system/changing the modes .
Page 19 Pictorial index Multi-information display ......P. 94 Display ..........P. 94 Energy monitor .
Page 20 Pictorial index ■ Switches Driving position memory switches ....P. 133 Emergency flasher switch ......P. 392 Tire pressure warning reset switch.
Page 21 Pictorial index Audio remote control switches Telephone switches Talk switch “DISP” button........P. 95 Vehicle-to-vehicle distance button .
Page 22 Pictorial index ■ Interior SRS airbags ........P. 36 Inside lock buttons .
Page 23 Pictorial index Power outlets ........P. 302 Power outlet .
Page 24 Pictorial index Auxiliary box ........P. 293 Moon roof switches .
Page 25 For safety and security 1-1. For safe use Before driving...... 26 For safety drive ....28 Seat belts ......30 SRS airbags......36 Front passenger occupant classification system ..48 Safety information for children ......54 Child restraint systems..55 Installing child restraints..
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 28: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 143, 145) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 32 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge.
Page 33 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 34 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor (front seats) Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 35 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 36: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
Page 37 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front passen- ger from impact with interior components SRS knee airbags Can help provide driver and front passenger protection ◆...
Page 38 1-1. For safe use SRS airbag system components Front impact sensors Rear side airbags Knee airbags Side impact sensors (rear) Side impact sensors (front Driver airbag doors) Driver’s seat belt buckle Seat belt pretensioners and switch force limiters SRS warning light Front passenger airbag Front passenger’s seat belt Front side airbags...
Page 39 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 42 If the areas where the SRS airbags are stored, such as the steering wheel pad, and front and rear pillar garnishes are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger's seat.
Page 43 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 44 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 45 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 46 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 47 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 48: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. CTY11AX056 SRS warning light Seat belt reminder light...
Page 49 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front passenger seat...
Page 50 1-1. For safe use ■ Child restraint system with infant “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices...
Page 51 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 52 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 53 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 54: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 55: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 56 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/con- Forward facing ⎯ Convertible   vertible seat seat Booster seat ...
Page 57 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 58 1-1. For safe use WARNING ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 59: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 60 1-1. For safe use Installation with LATCH system Adjust the head restraint to the downmost position. (→P. 138) Widen the gap between the seat cushion and seatback slightly. Rear left seat only: Slide the rear center seat belt to the side prevent from getting...
Page 61 1-1. For safe use Type B  Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 62 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 63 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 64 1-1. For safe use Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and allow it to retract to put it in lock mode.
Page 65 1-1. For safe use ■ Booster seat Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 66 1-1. For safe use Child restraint systems with a top tether strap Adjust the head restraint to the downmost position. (→P. 138) Secure the child restraint sys- tem using the seat belt or LATCH anchors. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 67 1-1. For safe use WARNING ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (→P. 32) ■...
Page 68 1-1. For safe use WARNING ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Page 69: Exhaust Gas Precautions
Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 70: 1-2. Hybrid System
1-2. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving condi- tions, improving fuel efficiency and reducing exhaust emis- sions.
Page 71 1-2. Hybrid system ◆ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 72 For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 10 miles (16 km). If the hybrid battery becomes fully discharged and you are unable to start the hybrid system, contact your Toyota dealer.
Page 73 ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself.
Page 74: Hybrid System Precautions
1-2. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high volt- age system (about 650 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 75 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 76 If a warning light comes on, a warning message is displayed, or the 12- volt battery is disconnected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 77 1-2. Hybrid system WARNING ■ High voltage precautions This vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 78 Toyota dealer or a qualified service shop. If the hybrid battery is not dis- posed of properly, it may cause electric shock that can result in death or serious injury.
Page 79: Theft Deterrent System
1-3. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 80 1-3. Theft deterrent system ■ Certifications for the immobilizer system FCC ID: NI4TMIMB-3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 81: Alarm
1-3. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 82 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 83: Theft Prevention Labels
1-3. Theft deterrent system Theft prevention labels These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law.
Page 84 1-3. Theft deterrent system...
Page 85: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......86 Gauges and meters .... 90 Multi-information display....... 94 Energy monitor/ consumption screen..100...
Page 86: Instrument Cluster Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 87 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : If equipped : The light flashes to indicate a malfunction.
Page 88 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator EV drive mode indicator (→P. 184) (→P. 178) Headlight indicator Eco drive mode indicator (→P. 186) (→P. 259) Headlight high beam Sport...
Page 89 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 90: Gauges And Meters
2. Instrument cluster Gauges and meters Hybrid System Indicator Displays hybrid system output or regeneration level (→P. 92) Multi-information display Presents the driver with a variety of driving-related data (→P. 94) Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Trip meter reset knob/instrument panel light control knob →P.
Page 91 2. Instrument cluster Changing the trip meter display Switches between trip meter “A” and “B” displays. When the trip meter is displayed, pressing and holding the knob will reset the trip meter. Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter...
Page 92 2. Instrument cluster ■ The meters and display illuminate when The power switch is in ON mode. ■ The brightness of the instrument panel lights ● When the headlight switch is turned to on, the brightness will be reduced slightly unless the control knob is turned fully clockwise. ●...
Page 93 2. Instrument cluster ■ Customization The instrument panel light auto dimmer control can be changed. (Customizable feature: →P. 461) NOTICE ■ To prevent damage to the engine and its components ● When indicating the tachometer (Using the S mode driving): Do not let the indicator of the tachometer enter the red zone, which indicates the maxi- mum engine speed.
Page 94: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of driv- ing-related data. ● Trip information (→P. 95) Displays the following items: • Distance to empty • Average fuel economy • Current fuel economy •...
Page 95 2. Instrument cluster Trip information ■ Switching the display Items displayed switched pressing “DISP” button. ■ Distance to empty Displays the estimated maximum distance that can be driven with the quantity of fuel remaining. • This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that dis- played.
Page 96 2. Instrument cluster ■ Turn-by-turn navigation (vehicles with a navigation system) Displays information from the navigation system about the next turn on the guidance route. Setting up the displays ◆ Customizable items ■ Meter settings Item Settings Details Select to enable/disable the digital Digital Speed speedometer.
Page 97 2. Instrument cluster ◆ Changing the settings While the vehicle is stopped, press the “DISP” button until “Settings” screen appears. Press and hold the “DISP” button while the “Settings” screen is displayed. Press the “DISP” button to highlight the desired item. Press and hold the “DISP”...
Page 98 2. Instrument cluster To exit the “Settings” screen, press “DISP” button repeatedly until “EXIT” is highlighted and then press and hold the “DISP” button. If the Lane Departure settings screen is displayed, press the “DISP” button repeatedly until “RETURN” is highlighted, then press and hold the “DISP”...
Page 99 2. Instrument cluster ■ Setting display automatic cancelation In the following situations, setting display in which the settings can be changed through the “DISP” button will automatically be turned off. ● When a warning message appears while the setting display is displayed ●...
Page 100: Energy Monitor/Consumption Screen
2. Instrument cluster Energy monitor/consumption screen You can view the status of your hybrid system on the multi-infor- mation display and the audio system. Audio system Multi-information display Energy monitor ■ Audio system Press “APPS”. Select “Eco”. If the “Trip Information” or “Past Record” screen is displayed, touch “Energy”.
Page 101 2. Instrument cluster ■ Multi-information display Press the “DISP” button on the steering wheel several times to select the energy monitor dis- play. Multi-information Audio system display When the vehicle is powered electric motor (trac- tion motor) When the vehicle is powered gasoline engine When the vehicle is...
Page 102 2. Instrument cluster Multi-information Audio system display When there is no energy flow Hybrid battery (trac- tion battery) status Full Full...
Page 103 2. Instrument cluster Trip Information ■ Audio system Press “APPS”. (→P. 100) Select “Eco”. If “Energy Monitor” screen is displayed, touch “Fuel Consumption”. If “Past Record” screen is displayed, touch “Trip Information”. Fuel consumption in the past 15 minutes Displays the average vehi- cle speed since the hybrid system was started.
Page 104 2. Instrument cluster Past record screen ■ Audio system Press “APPS”. (→P. 100) Select “Eco”. If “Energy Monitor” screen is displayed, touch “Fuel Consumption”. If “Trip Information” screen is displayed, touch “Past Record”. Best past fuel consump- tion Update The average fuel consump- tion and graph are updated, and a new average fuel con- sumption record begins.
Page 105: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........106 3-2. Opening, closing and locking the doors and trunk Doors ........ 110 Trunk......... 116 Smart key system ..... 121 3-3. Adjusting the seats Front seats ......131 Driving position memory ......133 Head restraints....
Page 106: Keys
3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (→P. 121) • Operating the wireless remote control function Mechanical keys Key number plate Wireless remote control Locks all the doors (→P. 110) Unlocks all the doors (→P.
Page 107 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 108 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism.
Page 109 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
Page 110: Doors
3-2. Opening, closing and locking the doors and trunk Doors Unlocking and locking the doors from the outside ◆ Smart key system Carry the electronic key to enable this function. Grip the driver’s door handle to unlock the door. Some models, grip the passenger’s door handle to unlock all the doors.
Page 111 3-2. Opening, closing and locking the doors and trunk ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) ■ Security feature If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.
Page 112 3-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Unlocks the door Locks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 113 3-2. Opening, closing and locking the doors and trunk Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors.
Page 114 3-2. Opening, closing and locking the doors and trunk ■ Switching the door unlock function (some models) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the power switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 115 3-2. Opening, closing and locking the doors and trunk WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehicle, resulting in death or serious injury. ●...
Page 116: Trunk
3-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the trunk opener, entry function or wireless remote control. Opening the trunk from inside the vehicle Press the opener switch. Opening the trunk from outside the vehicle ◆...
Page 117 3-2. Opening, closing and locking the doors and trunk When closing the trunk Using the trunk grip, lower the trunk without applying force to the side and push the trunk down from the outside to close it. Luggage security system The trunk opener switch can be temporarily disabled to protect lug- gage stored in the trunk against theft.
Page 118 3-2. Opening, closing and locking the doors and trunk ■ Operation signal A buzzer sounds to indicate that the trunk has been opened. ■ Trunk light The trunk light turns on when the trunk is opened. ■ Function to prevent the trunk being locked with the electronic key inside ●...
Page 119 3-2. Opening, closing and locking the doors and trunk ■ In case the trunk opener is not actuated Pull down the rear armrest and open the door behind it. Pull the loop of wire to unlock the trunk lid. This is used in case the trunk lid cannot be unlocked due to a discharged bat- tery or other trouble.
Page 120 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 121: Smart Key System
3-2. Opening, closing and locking the doors and trunk Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ●...
Page 122 3-2. Opening, closing and locking the doors and trunk ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the Type A  doors The system can be operated when the electronic key is within about 2.3 ft.
Page 123 3-2. Opening, closing and locking the doors and trunk Alarm Situation Correction procedure An attempt was made to lock either front door by opening a door and Interior alarm pings Retrieve the electronic putting the inside lock once and exterior alarm key from the vehicle button into the lock sounds once for 5 sec-...
Page 124 3-2. Opening, closing and locking the doors and trunk The following table describes circumstances and correction procedures when alarms are sounded and a message or key icon is displayed. Interior Exterior Correction Situation buzzer buzzer procedure • Change the The electronic key was carried shift position outside the vehicle and the to P.
Page 125 3-2. Opening, closing and locking the doors and trunk Interior Exterior Correction Situation buzzer buzzer procedure • When doors were unlocked with the mechanical key and then the power Touch switch was pressed, the elec- electronic key tronic could to the power ⎯...
Page 126 3-2. Opening, closing and locking the doors and trunk ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly.
Page 127 3-2. Opening, closing and locking the doors and trunk ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 128 3-2. Opening, closing and locking the doors and trunk ■ Note for locking the doors ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly.
Page 129 3-2. Opening, closing and locking the doors and trunk ■ When the vehicle is not driven for extended periods ● To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ●...
Page 130 (→P. 121) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 131: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Driver’s seat  Passenger’s seat  Seat position adjustment switch Vertical height adjustment switch (if equipped for passen- Seatback angle adjustment ger’s seat) switch Lumbar support adjustment Seat cushion (front) angle switch (if equipped for passen- adjustment switch (if equipped ger’s seat) for passenger’s seat)
Page 132 3-3. Adjusting the seats ■ Power easy access system (vehicles with driving position memory) The auto away/return function enables easy access by activating when the driver attempts to enter or exit the vehicle. ● When the power switch has been turned to ON mode or the driver’s seat belt has been fastened, the driver’s seat will move forward.
Page 133: Driving Position Memory
3-3. Adjusting the seats ∗ Driving position memory This feature automatically adjusts the driver’s seat and outside rear view mirrors to make entering and exiting the vehicle easier or to suit your preferences. Power easy access system The seat is automatically adjusted to allow the driver to enter and exit the vehicle easily.
Page 134 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory. ■...
Page 135 3-3. Adjusting the seats ■ To stop the position recall operation part-way through Perform any of the following: ● Press the “SET” button. ● Press button “1” or “2”. ● Adjust the seat using the switches (only cancels seat position recall). ■...
Page 136 3-3. Adjusting the seats Memory recall function Each electronic key can be registered to recall your preferred driving position. ■ Registering procedure Record your driving position to button “1” or “2” before performing the following: Carrying only the key to which you want to link the driving position, shift the shift lever to P and then close the driver’s door.
Page 137 3-3. Adjusting the seats ■ Cancelation procedure Carry only the key to which you want to cancel the linked door unlock operation. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the power switch to ON mode. While pressing the “SET”...
Page 138: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats (except center seat) Pull the head restraints up.
Page 139 3-3. Adjusting the seats ■ Removing the head restraints (except rear center seat) Pull the head restraint up while pressing the lock release button. Lock release button ■ Installing the head restraints Front seats  Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 140 3-3. Adjusting the seats WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 141: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel The steering wheel can be adjusted to a comfortable position. Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 142 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 143: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 144 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 145: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 146 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing (vehicles with driving position memory) When the mirror select switch is in the L or R position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 147 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 148: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 149 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 150 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 151: Moon Roof
3-5. Opening, closing the windows and moon roof ∗ Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 152 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when The power switch is in ON mode. ■ Operating the moon roof after turning the hybrid system off The moon roof can be operated for approximately 45 seconds after the power switch is turned to ACCESSORY mode or turned off.
Page 153 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open warning buzzer The buzzer sounds and a message is shown on the multi-information display when the power switch is turned off and the driver’s door is opened with the...
Page 154 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 155: Driving
Driving 4-1. Before driving 4-5. Using the driving Driving the vehicle..... 156 support systems Toyota Safety Sense P ..202 Cargo and luggage ... 166 PCS (Pre-Collision Vehicle load limits ..... 169 System)......209 Trailer towing..... 170 LDA (Lane Departure Dinghy towing ....
Page 156: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system →P. 172 Driving With the brake pedal depressed, shift the shift lever to D. (→P. 180) Release the parking brake. (→P. 185) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 157 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 158 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. ■...
Page 159 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the hybrid system. Turning the hybrid system off while driving will not cause loss of steering or braking control, however, power assist to the steering will be lost.
Page 160 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
Page 161 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 162 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 163 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating.
Page 164 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 165 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 166: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 169) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing.
Page 167 4-1. Before driving Calculation formula for on your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (→P. 436) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 168 4-1. Before driving WARNING ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 169: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 170: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the...
Page 171: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground.
Page 172: 4-2. Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the parking brake is set. Check that the shift lever is in P. Firmly depress the brake pedal.
Page 173 4-2. Driving procedures Stopping the hybrid system Stop the vehicle. Set the parking brake (→P. 185), and shift the shift lever to P. Press the power switch. Driving-related data will be displayed on the multi-information display. (→P. 98) Changing power switch modes Modes can be changed by pressing the power switch with brake pedal released.
Page 174 4-2. Driving procedures When stopping the hybrid system with the shift lever in a posi- tion other than P If the hybrid system is stopped with the shift lever in a position other than P, a message indicating to shift the shift lever to P will be dis- played on the multi-information display.
Page 175 ■ If the “READY” indicator does not come on In the event that the “READY” indicator does not come on even after perform- ing the proper procedures for starting the vehicle, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning →P.
Page 176 4-2. Driving procedures ■ Operation of the power switch ● If the switch is not pressed shortly and firmly, the power switch mode may not change or the hybrid system may not start. ● If attempting to restart the hybrid system immediately after turning the power switch off, the hybrid system may not start in some cases.
Page 177 Do not depress the accelerator pedal unnecessarily. ● If the hybrid system becomes difficult to start, have your vehicle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the power switch If the power switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 178: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. This mode allows you to drive in residential areas early in the morning and late at night, or in indoor parking lots etc.
Page 179 4-2. Driving procedures ■ Switching to EV drive mode when the gasoline engine is cold If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically after a short period of time in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 180: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever While the power switch is in ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped. Shift position purpose Shift position Objective or function...
Page 181 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can then be selected by operating the shift lever, allowing you to drive in the shift range of your choosing. Upshifting Downshifting The selected shift range, from S1...
Page 182 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.) ■...
Page 183 4-2. Driving procedures ■ AI-SHIFT AI-SHIFT automatically selects the suitable gear according to driver perfor- mance and driving conditions. AI-SHIFT automatically operates when the shift lever is in the D position. (Shifting the shift lever to the S position cancels the function.) WARNING ■...
Page 184: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position after operation. Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 185: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while depress- ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■ Parking the vehicle →P.
Page 186: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: The headlights, parking lights, daytime running lights (→P. 187) and so on turn on and off auto- matically (when...
Page 187 4-3. Operating the lights and wipers ■ Daytime running light system (vehicles with halogen headlights) ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the hybrid system is started and the parking brake is released with the headlight switch off or in the “AUTO”...
Page 188 4-3. Operating the lights and wipers ■ Automatic headlight leveling system (if equipped) The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. ■...
Page 189: Automatic High Beam
4-3. Operating the lights and wipers ∗ Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or off as necessary.
Page 190 4-3. Operating the lights and wipers Turning the high beam on/off manually ■ Switching to low beam Pull the lever to the original position. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High...
Page 191 4-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 25 mph (40 km/h). •...
Page 192 • The driver believes that the high beam may be causing problems or dis- tress to other drivers or pedestrians nearby. ■ If the Automatic High Beam indicator flashes It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The automatic high beam can be deactivated.
Page 193: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Intermittent wiper with interval adjuster (if equipped) Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Wiper intervals can be adjusted when intermittent operation is...
Page 194 4-3. Operating the lights and wipers Washer/wiper dual operation Wipers will automatically operate a couple of times after the washer squirts.
Page 195 4-3. Operating the lights and wipers Rain-sensing windshield wipers (if equipped) With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing windshield wiper operation Low speed windshield wiper operation...
Page 196 4-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when The power switch is in ON mode. ■ Effects of vehicle speed on wiper operation (vehicles with rain-sensing windshield wipers) With low speed windshield wiper operation selected, wiper operation will be switched from low speed to intermittent wiper operation only when the vehicle is stationary.
Page 197 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 198: Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the power switch off. ● Confirm the type of fuel. ■...
Page 199: Refueling
4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 200 4-4. Refueling Opening the fuel tank cap With the doors unlocked, press the center of the rear edge of the fuel filler door. Push until you hear a click and take your hand away to slightly open the fuel filler door. Then open the door fully by hand.
Page 201 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 202: Toyota Safety Sense P
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 203 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 204 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor...
Page 205 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 206 ● Do not attach window tinting to the windshield. ● Replace the windshield if it is damaged or cracked. If the windshield needs to be replaced, contact your Toyota dealer. ● Do not get the camera sensor wet. ● Do not allow bright lights to shine into the camera sensor.
Page 207 ● Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the camera sensor.
Page 208 4-5. Using the driving support systems ■ Certification...
Page 209: Pcs (Pre-Collision System)
4-5. Using the driving support systems ∗ PCS (Pre-Collision System) The pre-collision system uses a radar sensor and camera sen- sor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal col- lision with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action and the potential brake pressure is increased to help the driver avoid the collision.
Page 210 4-5. Using the driving support systems ◆ Pre-collision warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 211 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 212 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 213 4-5. Using the driving support systems Changing settings of the pre-collision system ■ Disabling the pre-collision system Press the PCS switch for 3 sec- onds or more. The PCS warning light will turn on and a message will be dis- played on the multi-information display.
Page 214 4-5. Using the driving support systems ■ Operational conditions Availability of the pedestrian detection function depends on the region in which the vehicle was sold. (For specific countries/areas: →P. 209) Read the following for details: Region A  (The pedestrian detection function is available) The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high.
Page 215 4-5. Using the driving support systems Region B  (The pedestrian detection function is not available) The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle is high. Each function is operational at the following speeds: ●...
Page 216 4-5. Using the driving support systems ■ Pedestrian detection function The pre-collision system detects pedestri- ans based on the size, profile, and motion of a detected object. However, a pedes- trian may not be detected depending on the surrounding brightness motion, posture, angle...
Page 217 4-5. Using the driving support systems • When driving on a road where relative location to vehicle ahead in an adja- cent lane may change, such as on a winding road • When rapidly closing on a vehicle ahead • If the front of the vehicle is raised or lowered, such as when the road sur- face is uneven or undulating •...
Page 218 4-5. Using the driving support systems • When passing under an object (bill- board, etc.) at the top of an uphill road • When rapidly closing on an electric toll gate barrier, parking area barrier, or other barrier that opens and closes •...
Page 219 4-5. Using the driving support systems • If a vehicle ahead is carrying a load which protrudes past its rear bumper • If a vehicle ahead has extremely high ground clearance • If a vehicle ahead is irregularly shaped, such as a tractor or side car •...
Page 220 4-5. Using the driving support systems • If the front of the vehicle is raised or lowered • If the wheels are misaligned • If a wiper blade is blocking the camera sensor • The vehicle is wobbling. • The vehicle is being driven at extremely high speeds. •...
Page 221 ● If the PCS warning light continues to flash or the warning message does not disappear, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●...
Page 222: Lda (Lane Departure Alert With Steering Control)
4-5. Using the driving support systems LDA (Lane Departure Alert with steering ∗ control) Summary of functions When driving on highways and freeways with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane and provides assistance by operating the steering wheel to keep the vehicle in its lane.
Page 223 4-5. Using the driving support systems Functions included in LDA system ◆ Lane departure alert function When the system determines that the vehicle might depart from its lane, a warning is dis- played on the multi-information display and the warning buzzer sounds to alert the driver.
Page 224 4-5. Using the driving support systems ◆ Vehicle sway warning When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 225 Do not modify the suspension etc. If the suspension etc. needs to be replaced, contact your Toyota dealer. ● Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer.
Page 226 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates and a message is displayed on the multi-information display. Press the LDA switch again to turn the LDA system off.
Page 227 4-5. Using the driving support systems Indications on multi-information display LDA indicator The illumination condition of the indicator informs the driver of the system operation status. Illuminated in white: LDA system is operating. Illuminated in green: Steering wheel assistance of the steering control function is operat- ing.
Page 228 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 229 4-5. Using the driving support systems ■ Temporary cancellation of functions When operation conditions are no longer met, a function may be temporarily canceled. However, when the operation conditions are met again, operation of the function is automatically restored. (→P. 228) ■...
Page 230 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 231 Details/Actions The system may not be operating properly. “Check LDA System” → Have the vehicle inspected at your Toyota dealer. Dirt, rain, condensation, ice, snow, etc., are present on the windshield in “Forward Camera front of the camera sensor. System →...
Page 232 4-5. Using the driving support systems ■ Customization The following settings can be changed. Function Setting details Lane departure alert Adjust alert sensitivity Steering control function Turn steering wheel assistance on and off Turn function on and off Vehicle sway warning Adjust alert sensitivity For how to change settings, refer to P.
Page 233: Dynamic Radar Cruise Control
4-5. Using the driving support systems ∗ Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 234 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 235 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 236 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 237 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 238 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 239 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the button changes the vehicle-to-vehicle distance as fol- lows: Long Preceding vehicle mark Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 240 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 241 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 242 The sensor cannot detect correctly because it is covered in some way. ● Pre-collision braking is activated. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer.
Page 243 ● Pre-collision braking is activated. If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Warning messages and buzzers for dynamic radar cruise control Warning messages and buzzers are used to indicate a system malfunction or to inform the driver of the need for caution while driving.
Page 244 4-5. Using the driving support systems ■ When the sensor may not be correctly detecting the vehicle ahead In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 245 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 246: Cruise Control
4-5. Using the driving support systems ∗ Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Display Indicators Set speed Cruise control switch Setting the vehicle speed Press the “ON/OFF” button to activate the cruise control.
Page 247 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 248 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
Page 249 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON/OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 250: (Blind Spot Monitor)
4-5. Using the driving support systems ∗ BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 251 The outside temperature is extremely high or low ● The sensor voltage has become abnormal If a message continues to be displayed, have the vehicle inspected by your Toyota dealer. ■ Certification for the Blind Spot Monitor system FCC ID: OAYSRR2A This device complies with part 15 of the FCC Rules.
Page 252: The Blind Spot Monitor Function
Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles...
Page 253 4-5. Using the driving support systems The Blind Spot Monitor function detection areas The areas that vehicles can be detected in are outlined below. The range of the detection area extends to: Approximately 11.5 ft. (3.5 m) from the side of the vehicle The first 1.6 ft.
Page 254 4-5. Using the driving support systems ■ The Blind Spot Monitor function is operational when ● The BSM main switch is set to on ● Vehicle speed is greater than approximately 10 mph (16 km/h). ■ The Blind Spot Monitor function will detect a vehicle when ●...
Page 255 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow etc. •...
Page 256 4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 257: The Rear Cross Traffic Alert Function Detection Areas
4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 258 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. ● Small motorcycles, bicycles, pedestrians etc.
Page 259: Driving Mode Select Switch
4-5. Using the driving support systems Driving mode select switch The driving modes can be selected to suit driving condition. EV drive mode →P. 178 Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. When the “ECO”...
Page 260 4-5. Using the driving support systems ■ Operation of the air conditioning system in Eco drive mode Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency (→P. 274). To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode.
Page 261: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 262 4-5. Using the driving support systems ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel ◆ BSM (Blind Spot Monitor) (if equipped) →P. 250 When the TRAC/VSC/ABS systems are operating The slip indicator light will flash while the TRAC/VSC/ABS sys- tems are operating.
Page 263 When the message is displayed on the multi-information display show- ing that TRAC has been disabled even if the TRAC/VSC OFF switch has not been pressed TRAC and hill-start assist control cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, TRAC, VSC...
Page 264 Hill-start assist control operates for about 2 seconds after the brake pedal is released. ■ If the slip indicator comes on It may indicate a malfunction in the system. Contact your Toyota dealer. WARNING ■ The ABS does not operate effectively when ●...
Page 265 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 266: 4-6. Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the fol- lowing points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 267 4-6. Driving tips ◆ When braking Make sure to operate the brakes gently and in a timely manner. A greater amount of electrical energy can be regenerated when slow- ing down. ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy.
Page 268 4-6. Driving tips ◆ Luggage Carrying heavy luggage will lead to poor fuel economy. Avoid carry- ing unnecessary luggage. Installing a large roof rack will also cause poor fuel economy. ◆ Warming up before driving Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary.
Page 269: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 270 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Use the correct tire chain size when mounting the tire chains.
Page 271 4-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires. Do not install tire chains on the rear tires. ●...
Page 272 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 273: Interior Features
Interior features 5-1. Using the air 5-4. Other interior features conditioning system Other interior features ..299 and defogger • Sun visors ..... 299 Automatic air conditioning • Vanity mirrors....299 system......274 • Clock......300 Seat heaters/seat • Outside temperature ventilators......
Page 274: System
5-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls Front control panel (type A)  Front control panel (type B)  Rear control panel (if equipped) ...
Page 275 5-1. Using the air conditioning system and defogger ■ Adjusting the temperature setting To adjust the temperature setting, touch (driver’s side) to increase the temperature and touch (driver’s side) to decrease the temperature. The temperature for the driver’s, front passenger’s and rear seats (vehi- cles with a rear control switch) can be adjusted separately when: •...
Page 276 5-1. Using the air conditioning system and defogger ■ Fan speed setting To adjust the fan speed, touch and slide your finger toward “+” to increase the fan speed or “-” to decrease the fan speed. The fan speed can also be adjusted by touching “+”...
Page 277 5-1. Using the air conditioning system and defogger Using the automatic air conditioning system ■ Using automatic operation Touch The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. Adjust the temperature setting. To stop the operation, touch ■...
Page 278 5-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode and recirculated air mode each time the button is pressed. ■ Defogging the windshield Defoggers are used to defog the windshield and front side win- dows.
Page 279 5-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume change according selected airflow mode. ■ Adjusting the position of and opening and closing the air out- lets Front center outlets Front side outlets ...
Page 280 5-1. Using the air conditioning system and defogger ■ Operation of the air conditioning system in Eco drive mode In Eco drive mode, the air conditioning system is controlled as follows to pri- oritize fuel efficiency: ● When the outside temperature exceeds 68°F (20°C), the air conditioning system may switch to recirculated air mode automatically.
Page 281 5-1. Using the air conditioning system and defogger ■ When the outside temperature exceeds 75°F (24°C) and the air condition- ing system is on ● In order to reduce the air conditioning power consumption, the air condition- ing system may switch to recirculated air mode automatically. This may also reduce fuel consumption.
Page 282 5-1. Using the air conditioning system and defogger ■ Customization Settings (e.g. air conditioning setting, touch switch sensitivity) can be changed. (Customizable features →P. 461) WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.
Page 283: Seat Heaters/Seat Ventilators
5-1. Using the air conditioning system and defogger ∗ ∗ Seat heaters /seat ventilators The seat heaters warm the seats and the seat ventilators main- tain good airflow by blowing air through the seats. WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the seats when the heater is on: •...
Page 284 5-1. Using the air conditioning system and defogger ■ Front seats Vehicles with ventilator  Press the knob to release it, and turn the knob to the desired temperature setting. Press the knob to lock it when not in use. Ventilation Heat CTY57AX039...
Page 285 5-1. Using the air conditioning system and defogger ■ Rear seats ON/OFF The indicator illuminates when the seat heater is turned on. ■ The seat heaters/seat ventilators can be used when The power switch is in ON mode. ■ Automatic operation of the seat ventilator for the passenger's seat If a passenger leaves the passenger seat with the seat ventilator on, the seat ventilator will automatically turn off after approximately 10 minutes.
Page 286: 5-2. Using The Interior Lights
5-2. Using the interior lights Interior lights list Outer foot lights (if equipped) Ambient lights (if equipped) (→P. 288) Rear personal/interior lights (→P. 287) Front door courtesy lights Front personal/interior lights (→P. 287)
Page 287: Personal/Interior Light Main Switch
5-2. Using the interior lights Personal/interior light main switch Turns the lights on/off Turns the lights on/off linked to door position Personal/interior lights ■ Front Turns the light on/off ■ Rear Turns the light on/off If the lights are turned on by the personal/interior light main...
Page 288: Ambient Lights
5-2. Using the interior lights Ambient lights (if equipped) Each time the “MOOD” switch is pressed, brightness level changes. ■ Illuminated entry system The lights automatically turn on/off according to power switch mode, the pres- ence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed.
Page 289: List Of Storage Features
5-3. Using the storage features List of storage features Auxiliary boxes (→P. 293) Cup holders (→P. 292) Glove box (→P. 290) Console box (→P. 291) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: •...
Page 290: Glove Box
5-3. Using the storage features Glove box Open (pull up the lever) Lock with the mechanical key Unlock with the mechanical key The trunk opener main switch is located in the glove box. (→P. 117)
Page 291: Console Box
5-3. Using the storage features Console box Lift the lid while pulling up the lever to release the lock. ■ When using the console box lid as an armrest Slide the console box lid forward as needed. Slide the lid forward while pulling up the lever.
Page 292: Cup Holders
5-3. Using the storage features Cup holders Front Rear (type A)   Pull down the armrest. Rear (type B)  Pull down the armrest and open the lid. WARNING Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 293: Auxiliary Boxes
5-3. Using the storage features Auxiliary boxes Type A Type B   Press in the button. Push the lid. Type C  Opening Push the tray forward until it locks. Closing Push the tray forward to release the lock and the tray will automatically close.
Page 294 The LED indicators will be illuminated if the surface of the tray cools down. If the LED indicators flash even though the surface of the tray is not hot, the wireless charger may be malfunctioning. Consult your Toyota dealer.
Page 295 When the electronic key is out of the detection area ■ Certification for the wireless charger This device complies with Part 18 of the FCC Rules. Toyota Motor Sales, U.S.A., Inc. 19001 S. Western Avenue Torrance, CA 90501 WARNING ■...
Page 296 5-3. Using the storage features WARNING ■ When using wireless charger Avoid placing metal objects between the wireless charger and the mobile device when charging is active. Doing so may cause metal objects to become hot and could cause burns. NOTICE ●...
Page 297: Trunk Features
5-3. Using the storage features Trunk features Grocery bag hooks Cargo net (if equipped)
Page 298 5-3. Using the storage features NOTICE To prevent damage to the hooks, do not apply too much load to the hooks.
Page 299: Other Interior Features
5-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 300: Clock
5-4. Other interior features Clock The clock can be adjusted by pressing the buttons. Type A Type B   Adjusts the hours Pressing and holding the button adjusts the hours forward quickly 1 hour at a time. Adjusts the minutes Pressing and holding the button adjusts the minutes forward quickly by 1 minute at a time.
Page 301: Outside Temperature Display
When the vehicle is stopped, or moving at low speeds (less than 9 mph [15 km/h]). ● When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.) ■ When “---°F” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Page 302: Power Outlets
5-4. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. ■ Console box ■ Instrument panel Type A Type B  ...
Page 303 5-4. Other interior features ■ Rear armrest (if equipped) ■ The power outlets can be used when The power switch is in ACCESSORY or ON mode. NOTICE ● To avoid damaging the power outlets, close the power outlet lids when the power outlets are not in use.
Page 304: Armrest
5-4. Other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest. Rear sunshade (if equipped) The rear sunshade can be raised and lowered by pressing the switch shown below.
Page 305 5-4. Other interior features ■ The rear sunshade can be used when The power switch is in ON mode. ■ Reverse operation feature To ensure adequate rear visibility, the rear sunshade automatically lowers when the shift lever is shifted to R. However, the rear sunshade is raised again if either of the following occurs: ●...
Page 306: Coat Hooks
5-4. Other interior features Coat hooks The coat hooks are provided with the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 307: Garage Door Opener
5-4. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manu- ...
Page 308 5-4. Other interior features  ■ Programming the HomeLink Point the remote control for the device 1 to 3 in. (25 to 75  mm) from the HomeLink control buttons. Keep the indicator light on the  HomeLink in view while pro- gramming.
Page 309 5-4. Other interior features Test the operation of the ® HomeLink by pressing the newly programmed button. If programming a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 310 5-4. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the  heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door opener motor.
Page 311  the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 312 5-4. Other interior features ® Operating the HomeLink   Press the appropriate HomeLink button. The HomeLink indicator  light on the HomeLink transceiver should turn on.  The HomeLink continues to send a signal for up to 20 seconds as long as the button is pressed.
Page 313 5-4. Other interior features ■ Before programming ● Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the Home-  Link ■ Certification for the garage door opener FCC ID: NZLWZLHL4 NOTE: This device complies with Part 15 of the FCC Rules.
Page 314: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 315 After you have signed the Telematics Subscription Service Agree- ment and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” button in your vehicle for further subscription details.
Page 316 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 317 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 318 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 319 5-4. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 320: Compass
5-4. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. ■ Operation To turn the compass on or off, press the switch for more than 3 seconds.
Page 321 5-4. Other interior features ■ Displays and directions Display Direction North Northeast East Southeast South Southwest West Northwest Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle.
Page 322 5-4. Other interior features ■ Deviation calibration Stop the vehicle. Press and hold the switch. A number (1 to 15) appears on the compass display. Referring to the map above, press the switch to select the num- ber of the zone you are in. If the direction is displayed several seconds after adjustment, the cali- bration is complete.
Page 323 5-4. Other interior features ■ Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: ● The vehicle is stopped immediately after turning. ● The vehicle is on an inclined surface. ● The vehicle is in a place where the earth’s magnetic field is subject to inter- ference by artificial magnetic fields (underground car park/parking lot, under a steel tower, between buildings, roof car park/parking lot, near an intersec- tion, near a large vehicle, etc.).
Page 324 5-4. Other interior features...
Page 325 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior..326 Cleaning and protecting the vehicle interior... 329 6-2. Maintenance Maintenance requirements ....332 General maintenance..334 Emission inspection and maintenance (I/M) programs......338 6-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 326: Maintenance And Care Cleaning And Protecting
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 327 ■ Precaution regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer.
Page 328 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 329: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 330 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 331 Water may also cause the body to rust. ■ When cleaning the inside of the windshield (vehicles with Toyota Safety Sense P) Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
Page 332: Maintenance Maintenance Requirements
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 333 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 334: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 335 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Hybrid transmission “Park” mecha- shift lever is in P, is the vehicle nism securely stopped? •...
Page 336 6-2. Maintenance Items Check points • Do the head restraints move Head restraints smoothly and lock securely? • Do the indicators and buzzers Indicators/buzzers function properly? Lights • Do all the lights come on? • Moves smoothly? • When parked on a slope and the Parking brake parking brake is on, is the vehicle securely stopped?
Page 337 6-2. Maintenance Vehicle exterior Items Check points • Do doors/trunk operate Doors/trunk smoothly? • Does the engine hood lock system Engine hood work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
Page 338: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 339: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
(→P. 350) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, Engine/power control non-amine, non-nitrite and non-borate coolant unit coolant level with long-life hybrid organic acid technology.
Page 340 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Make sure that the “READY”...
Page 341: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. WARNING ■...
Page 342: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 343: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Fuse boxes (→P. 375) Power control unit coolant radiator (→P. 349) Engine oil filler cap (→P. 345) Condenser (→P. 349) Engine oil level dipstick Electric cooling fans (→P. 344) Engine coolant reservoir Brake fluid reservoir (→P.
Page 344 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 345 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 346 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 347 6-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the full and low lines on the reservoir when the hybrid system is cold. ■ Engine coolant reservoir Reservoir cap “F” line “L” line If the level is on or below the “L” line, add coolant up to the “F”...
Page 348 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine/power control unit coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 349 Check the radiators and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■ When the hybrid system is hot Do not touch the radiators or condenser as they may be hot and cause seri- ous injuries, such as burns.
Page 350 6-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. “MAX” line “MIN” line ■ Adding fluid Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 351 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty. Add washer fluid. WARNING ■ When adding washer fluid Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 352: 12-Volt Battery
6-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located on the right-hand side of luggage compartment. Removing the 12-volt battery cover Pull the 12-volt battery cover while pressing down on the tab. Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps.
Page 353 12-volt battery. Take extra care when connecting the 12-volt battery if the power switch mode prior to dis- charge is unknown. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer.
Page 354 6-3. Do-it-yourself maintenance WARNING ■ Chemicals in the 12-volt battery The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: ●...
Page 355 Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Toyota dealer. NOTICE ■ When recharging the 12-volt battery Never recharge the 12-volt battery while the hybrid system is operating.
Page 356: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. Do not fail to initialize the tire pressure warning system after tire rotation.
Page 357 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 359) ◆ Initializing the tire pressure warning system ■...
Page 358 6-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system Park the vehicle in a safe place and turn the power switch off. Initialization cannot be performed while the vehicle is moving. Adjust the tire inflation pressure to the specified cold tire inflation pressure level.
Page 359 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 360 6-3. Do-it-yourself maintenance ■ Tire types ● Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 361 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equip- ment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 362 3 times. ● After performing initialization, the tire pressure warning light blinks for 1 minute then stays on while driving. If the inflation pressure of each tire is still not displayed, have the vehicle inspected by your Toyota dealer.
Page 363 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 364 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 365: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 443)
Page 366 ● Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer.
Page 367 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 368: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 369 6-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 370 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 371: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the power switch off. Open the glove box. (→P. 290) Remove the glove box cover. Press the tabs and remove the filter cover.
Page 372 6-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Schedule maintenance guide”...
Page 373: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the cover.
Page 374 6-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 375: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the power switch off. Open the Fuse box cover. Engine compartment (type A) Engine compartment (type B) ...
Page 376  Normal fuse Blown fuse Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact your Toyota dealer.
Page 377 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 378) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 378: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 444) Bulb locations ■...
Page 379 6-3. Do-it-yourself maintenance ■ Rear Rear turn signal light Back-up light...
Page 380 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beam (halogen bulb) Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set.
Page 381 6-3. Do-it-yourself maintenance ■ Headlight high beam and daytime running light (vehicles with halogen bulbs for low beams)/Headlight high beam (vehicles with discharge bulbs for low beams) Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise.
Page 382 6-3. Do-it-yourself maintenance ■ Front turn signal/parking light To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Remove the 3 fender liner clips. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
Page 383 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 384 6-3. Do-it-yourself maintenance ■ Rear turn signal light Open trunk remove the luggage trim cover clip. Pull the hook while depress- ing the button. Partly remove the luggage trim cover.
Page 385 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 386 6-3. Do-it-yourself maintenance ■ Back-up light Open trunk remove the clips. Then partly remove trunk panel cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 387 LED headlights), stop/tail lights, high mounted stoplight, outer foot lights and license plate light each consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 388 6-3. Do-it-yourself maintenance ■ When replacing light bulbs →P. 377 WARNING ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
Page 389 6-3. Do-it-yourself maintenance WARNING ■ Discharge headlights (if equipped) ● Contact your Toyota dealer before replacing the discharge headlights (including light bulbs). ● Do not touch the discharge headlight’s high voltage socket when the head- lights are turned on. An extremely high voltage of 30000 V will be discharged and could result in death or serious injury by electric shock.
Page 390 6-3. Do-it-yourself maintenance...
Page 391: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ..392 If your vehicle has to be stopped in an emergency ...... 393 7-2. Steps to take in an emergency If your vehicle needs to be towed ......394 If you think something is wrong ......
Page 392: Essential Information
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 393: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 394: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 395 7-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels. Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration.
Page 396 7-2. Steps to take in an emergency WARNING Observe the following precaution. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 397: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 398: If A Warning Light Turns On Or A Warning Buzzer Sounds
If the light turns off after the parking brake is fully released the system is operating normally. → Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light Indicates a malfunction in the vehicle’s charging system...
Page 399 Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; or • The seat belt pretensioner system → Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: •...
Page 400 PCS warning light • When the warning light flashes (and a buzzer sounds): Indicates a malfunction in the PCS (Pre-Collision System) → Have the vehicle inspected by your Toyota dealer immediately. • When the warning light flashes (and a buzzer does not...
Page 401 Indicates a malfunction in: • The electronically controlled brake system; or • The regenerative braking system → Have the vehicle inspected by your Toyota dealer immediately. Open door warning light (warning buzzer) Indicates that a door or the trunk is not fully closed →...
Page 402 7-2. Steps to take in an emergency : Brake system warning buzzer: When there is a possible problem that could affect braking performance, the warning light will come on and a warning buzzer will sound. Parking brake engaged warning buzzer: Parking brake engaged warning buzzer: The buzzer sounds to indicate that the parking brake is still engaged (with the vehicle having reached a speed of 3 mph [5 km/h]).
Page 403 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 404 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 405 7-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 406 7-2. Steps to take in an emergency WARNING TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly.
Page 407: If A Warning Message Is Displayed
Multi-information display If any of the warning messages is shown again after its correction pro- cedure has been performed, contact your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 408: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: →P. 356 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 409 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Luggage floor cover Spare tire Jack Tool tray Jack handle Wheel nut wrench...
Page 410 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 411 7-2. Steps to take in an emergency Taking out the jack and jack handle Remove luggage floor cover. Remove the jack.
Page 412 7-2. Steps to take in an emergency Taking out the spare tire Remove the luggage floor cover. (→P. 411) Remove the tool tray. Loosen the center fastener that secures the spare tire. WARNING ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
Page 413 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 414 7-2. Steps to take in an emergency Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 415 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered...
Page 416 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 417 7-2. Steps to take in an emergency ■ The compact spare tire ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 418 7-2. Steps to take in an emergency WARNING ■ When using the compact spare tire ● Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle. ●...
Page 419 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 420: If The Hybrid System Will Not Start
7-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate procedure: The hybrid system will not start even though the correct starting procedure is being followed.
Page 421 ● The 12-volt battery may be discharged. (→P. 424) ● One or both of the 12-volt battery terminals may be disconnected. (→P. 352) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 422: If The Electronic Key Does Not Operate Properly
7-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is interrupted (→P. 126) or the electronic key cannot be used because the battery is depleted, the smart key system and wire- less remote control cannot be used.
Page 423 7-2. Steps to take in an emergency Starting the hybrid system Ensure that the shift lever is in P and depress the brake pedal. Touch the Toyota emblem side of the electronic key to the power switch. The power switch will turn to ON mode.
Page 424: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid sys- tem if the 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 425 7-2. Steps to take in an emergency Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 426 ON mode. Make sure the “READY” indicator comes on. If the indicator does not come on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were connected.
Page 427 7-2. Steps to take in an emergency ■ When recharging or replacing the 12-volt battery ● In some cases, it may not be possible to unlock the doors using the smart key system when the 12-volt battery is discharged. Use the wireless remote control or the mechanical key to lock or unlock the doors.
Page 428 Do not allow children near the 12-volt battery. ■ After recharging the 12-volt battery Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 429: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has cooled down sufficiently, inspect the hoses and radia- tor core (radiator) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer.
Page 430 (The fan may not operate in freezing temperatures.) If the fan is not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 431 Start the hybrid system and check for the multi-information dis- play. If the message does not disappear: Stop the hybrid system and contact your Toyota dealer. If the message is not displayed: Have the vehicle inspected at the nearest Toyota dealer.
Page 432 7-2. Steps to take in an emergency WARNING ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 433: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the hybrid system. Set the parking brake and shift the shift lever to P.
Page 434 7-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the front wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 435: Vehicle Specifications
Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..436 Fuel information ....445 Tire information ....448 8-2. Customization Customizable features ..461 8-3. Items to initialize Items to initialize ....468...
Page 436: Specifications Maintenance Data
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 195.3 in. (4960 mm) Overall width 72.2 in. (1835 mm) Overall height 57.5 in. (1460 mm) Wheelbase 111.0 in. (2820 mm) Front 62.6 in. (1590 mm) Tread Rear 62.2 in.
Page 437 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is located on the top left of the instrument panel.
Page 438 8-1. Specifications Engine Model 2.5 L 4-cylinder (2AR-FXE) Type 4-cylinder in line, 4-cycle, gasoline 3.54 × 3.86 in. (90.0 × 98.0 mm) Bore and stroke Displacement 152.2 cu. in. (2494 cm Valve clearance Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane Rating 87 (Research Octane Number 91) or higher Fuel tank capacity...
Page 439 8-1. Specifications Lubrication system Oil capacity Drain and refill (Reference With filter 4.6 qt. (4.4 L, 3.9 Imp. qt.) Without filter 4.2 qt. (4.0 L, 3.5 Imp. qt.) : The engine oil capacity is a reference quantity to be used when changing the engine oil.
Page 440 8-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20...
Page 441 Capacity Power 3.4 qt. (3.2 L, 2.8 Imp. qt.) control unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 442 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Hybrid transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.
Page 443 8-1. Specifications Brakes Pedal clearance 3.62 in. (92 mm) Min. 0.04 ⎯ 0.24 in. (1.0 ⎯ 6.0 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) ⎯ 10 clicks Parking brake pedal travel Fluid type SAE J1703 or FMVSS No.116 DOT 3...
Page 444 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights ⎯ Low beam (discharge bulbs) Low beam (halogen bulbs) 9005 High beam 9005 Front turn signal/parking lights 7444NA 28/8 Exterior Side marker lights (bulb type) Side turn signal lights WY5W Rear turn signal lights Back-up lights Interior/front personal lights...
Page 445: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 446 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA’s lowest additives concen-...
Page 447 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 448: Tire Information
8-1. Specifications Tire information Typical tire symbols Full-size tire  Compact spare tire ...
Page 449 8-1. Specifications Tire size (→P. 451) DOT and Tire Identification Number (TIN) (→P. 450) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators (→P. 356) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 450 8-1. Specifications Typical DOT and Tire Identification Number (TIN) Type A Type B   DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identification mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year Manufacturer's code : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 451 8-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 452 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer...
Page 453 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 454 8-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 455 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 456 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty 12-volt battery, and special trim A metal support for a tire or a tire and tube...
Page 457 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 458 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 459 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 460 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 461: Customization
Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features It is possible to customize certain vehicle features using the audio system.
Page 462 8-2. Customization → ■ Smart key system and wireless remote control ( P. 110, 121) Customized Function Default setting setting Operation signal (Emergency flashers) Operation signal — (Buzzer) Operation buzzer volume Level 5 Off to level 7 Time elapsed before auto- matic door lock function is acti- 60 seconds 30 seconds...
Page 463 8-2. Customization ■ Wireless remote control (→P. 106, 110, 116) Customized Function Default setting setting Wireless remote control — Driver's door unlocked in one All doors Unlocking operation step, all doors unlocked in one unlocked in two step. steps Panic function —...
Page 464 8-2. Customization → ■ Trunk ( P. 116) Customized Function Default setting setting Trunk opener main switch Activated Deactivated — ■ Driving position memory (→P. 132, 136) Customized Function Default setting setting Driver’s seat movement when Full exiting the vehicle Partial Doors linked to the driving position memory recall func-...
Page 465 8-2. Customization ■ Automatic light control system (→P. 186) Customized Function Default setting setting Light sensor sensitivity Level 3 Level 1 to 5 0 seconds Time elapsed before head- lights automatically turn off 30 seconds 60 seconds after doors are closed 90 seconds ■...
Page 466 8-2. Customization Customized Function Default setting setting Time elapsed before the outer seconds foot lights turn off seconds seconds Enable/disable operation of the outer foot lights when you — approach the vehicle with the electronic key on your person Enable/disable operation of the outer foot lights when the —...
Page 467 8-2. Customization ■ Rear sunshade (→P. 304) Customized Function Default setting setting Reverse operation — 0 second Time elapsed before reverse operation feature acti- seconds — seconds vates seconds : If equipped WARNING ■ During customization As the hybrid system needs to be operating during customization, ensure that the vehicle is parked in a place with adequate ventilation.
Page 468: 8-3. Items To Initialize
8-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as the maintenance being performed on the vehicle: Item When to initialize Reference Message indicating mainte- • After the maintenance is per- P.
Page 469: For Owners
For owners Reporting safety defects for U.S. owners......470...
Page 470: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 471: Index
Index What to do if... (Troubleshooting) ....472 Alphabetical index ..... 476 For details of equipment related to the audio/navigation system, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”.
Page 472 Toyota dealer. (→P. 107) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (→P. 109) The doors cannot be locked or unlocked ● Is the electronic key battery weak or depleted? (→P. 373) ●...
Page 473 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start ● Did you press the power switch while firmly depressing the brake pedal? (→P. 172) ● Is the shift lever in P? (→P. 175) ●...
Page 474 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (→P. 401) ● The brake system warning light is on Is the parking brake released? (→P.
Page 475 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (→P. 408) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 476: Alphabetical Index
Alphabetical index Alphabetical index Alarm .......... 81 Alarm ........81 A/C ..........274 Warning buzzer ....398 Air conditioning filter ..... 371 Automatic air conditioning Anchor brackets ......59 system ........ 274 Antennas (smart key system) ....121 ABS (Anti-lock Brake Anti-lock Brake System) ........
Page 477 Alphabetical index Back-up lights Care ........326, 329 Replacing light bulbs..... 386 Aluminum wheels ....327 Wattage ........ 444 Exterior ......... 326 Interior ........329 Battery (12-volt battery) ..352 If the 12-volt battery is Seat belts......330 discharged......424 Cargo capacity......
Page 478 Alphabetical index Child safety ........ 54 Console box......291 12-volt battery Consumption screen....100 precautions....354, 428 Coolant ........347 Airbag precautions....39 Capacity........ 441 Child restraint system ..... 55 Checking....... 347 How your child should wear Preparing and checking the seat belt......
Page 479 Alphabetical index Doors ........110 Automatic door locking Daytime running light and unlocking system..113 system........187 Door glasses......148 Defogger Door lock ......112 Front windshield....278 Open door warning buzzer ... 122 Outside rear view mirrors..278 Open door warning light ..401 Rear window ......
Page 480 Alphabetical index Energy monitor......100 Engine Eco drive mode......259 ACCESSORY mode ..... 173 EDR (Event data recorder)..11 Compartment......343 Electric motor Engine switch ....... 172 (traction motor) ....... 70 Hood ........341 Electric Power How to start the Steering (EPS) .......
Page 481 Alphabetical index Flat tire........408 Garage door opener ....307 Floor mats ........26 Gauges ........90 Fluid Glove box ......... 290 Brake ........443 Grocery bag hooks....297 Hybrid transmission ....442 Washer ......... 351 Front passenger occupant Head restraints ......138 classification system ....
Page 482 Alphabetical index Horn .......... 141 Hybrid battery I/M test ........338 (traction battery)...... 74 Identification Hybrid battery Engine ........437 (traction battery) Vehicle........437 air vents ........75 Ignition switch Hybrid system......70 (power switch)....... 172 Emergency shut off system ..75 Illuminated entry system ..
Page 483 Alphabetical index Jack Lane Departure Alert with steer- Positioning a floor jack..342 ing control (LDA)....222 Vehicle-equipped jack... 409 LATCH anchors ......60 Jack handle ......409 LDA (Lane Departure Alert with Jam protection function steering control)....222 Moon roof......152 Lever Power windows.....
Page 484 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 339 Noise from under vehicle ... 8 General maintenance ... 334 Maintenance requirements ... 332 Resetting the message Odometer ........90 indicating maintenance is required......332 Engine oil......439 Malfunction indicator lamp..398 Opener Master warning light....
Page 485 Alphabetical index Parking brake......185 Radar cruise control (dynamic Operation ......185 radar cruise control) ..... 233 Parking brake engaged Radiator........349 warning buzzer ....398 Rear personal lights....287 Parking lights......186 Rear seat heaters ....283 Light switch ......186 Rear sunshade......
Page 486 Alphabetical index Seats......... 131 Adjustment......131 Safety Connect ......314 Adjustment precautions ..132 Seat belts........30 Child seats/child restraint Adjusting the seat belt .... 31 system installation....59 Automatic Locking Cleaning ....... 329 Retractor....... 32 Driving position memory ..133 Child restraint system Head restraints .....
Page 487 Alphabetical index Shift lever ......... 180 Spare tire........408 Hybrid transmission ....180 Inflation pressure ....443 If the shift lever Storage location....409 cannot be shifted from P ..182 Spark plug........ 441 Shift lock system ..... 182 Specifications ......436 Side airbags .......
Page 488 Alphabetical index PCS (Pre-Collision Switches BSM (Blind spot monitor) System) switch ....213 switch ......... 250 Power door lock switch..112 Compass switch....320 Power switch ......172 Cruise control switch..233, 246 Power window switches..148 “DISP” button ......95 Rear sunshade switch ..
Page 489 Trailer towing ......170 Initializing ......357 TOYOTA PARKING ASSIST Installing tire pressure MONITOR warning valves and Toyota Safety Sense P.... 202 transmitters......357 Automatic High Beam... 189 Registering ID codes .... 359 Dynamic radar cruise Tire pressure warning reset control ........
Page 490 Alphabetical index TRAC (Traction Control) ..261 Traction battery USB port (hybrid battery)......74 Traction motor (electric motor) ......70 Vanity lights Transmission ......180 Vanity lights ......299 Driving mode select switch ... 259 Wattage ........ 444 Hybrid transmission ....180 If the shift lever cannot be Vanity mirrors ......
Page 491 Alphabetical index Washer ........193 Checking....... 351 Warning buzzers Preparing and checking Approach warning....240 before winter ...... 269 Brake system ......398 Switch ........193 Downshifting ......181 Seat belt reminder ....401 Washing and waxing....326 Weight Warning lights......87 Cargo capacity......
Page 492 GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 341 P. 116 P. 200 Tire inflation Hood lock release lever pressure P. 443 P. 341 Fuel tank capacity 17.0 gal. (64.35 L, 14.2 Imp. gal.) (Reference) Fuel type Unleaded gasoline only P.
