Dorel Home Products 2110229 Manual

Convertible futon
Hide thumbs Also See for 2110229:

Advertisement

Quick Links

Download this manual
Weight Limit: 600 Lb / 272 Kg
C.W. - 2020/3/19
2014 Dorel Home Products All Rights Reserved
2110029 (Black), 2110229 (Light Gray), 2110329 (Mustard Yellow),
2110429 (Gray), 2110629 (Blue)
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Convertible Futon
Lot Number
B34211002900
1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2110229 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorel Home Products 2110229

Summary of Contents for Dorel Home Products 2110229

  • Page 1 Convertible Futon 2110029 (Black), 2110229 (Light Gray), 2110329 (Mustard Yellow), 2110429 (Gray), 2110629 (Blue) Weight Limit: 600 Lb / 272 Kg Thank you for purchasing from DHP! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.
  • Page 2 Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of Work in a spacious area and near where the unit will be used, preferably on a original purchase.
  • Page 3 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Seat Right Arm Left Arm Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
  • Page 4 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts Below part numbers list is unique to your product. IMPORTANT: Please keep it on hand when calling for replacement parts. Part Number 2110329 2110029 2110229 2110429 2110629 Part Labels (Mustard (Black) (Light Gray) (Gray) (Blue)

  • Page 5: Hardware Pack

    Hardware Pack Hardware Pack #: T2110429-00 M6 X 10mm Allen Key Wrench Spring Washer Washer 5/16" 5/16" 5/16" 5/16" X 120mm Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
  • Page 6 Step 1 Take out components contained in the compartment of A as shown. The arms and legs will be found in the compartment under the seat as shown.
  • Page 7 Step 2 Hand tighten the BOLTS into B & C . Note: Only screw in the shortest threaded part of the Bolts.
  • Page 8 Step 3 Attach B & C to A with WASHER SPRING WASHER NUTS shown.
  • Page 9 Step 4 Take off the caps from D. Attach D X 4 to A with PLASTIC WASHER Attach E X 2 to A with BOLT shown.

  • Page 10: Helpful Hints

    Helpful Hints Weight Limit: 600 Lb / 272 Kg Move your new furniture carefully, with two people lifting and carrying the unit to its new location. Your DHP furniture can be disassembled and reassembled to move. Clean the product with a soft damp cloth. DO NOT use harsh chemicals or abrasive cleaners.
  • Page 11 Fut n convertible NO LO REGRESE A LA TIENDA ! Si le faltan piezas o las que se incluyen est n da adas, con 2110029 (Negro), 2110229 (Gris claro), mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra.
  • Page 12 Una D X 4 con A con Ias ARANDELAS DE PLASTICO . Una E X 2 con A usando N mero de pieza Ios PERNOS ,como se muestra. 2110329 Etiqueta 2110229 2110429 2110629 2110029 (Amarillo de pieza (Negro) (Gris claro)
  • Page 13 L mites de peso: 600 Lb / 272 Kg Consejos tiles Mueva sus muebles nuevos con cuidado, con dos personas levantando y llevando el aparato a su nueva ubicaci n. Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de mudanza.

  • Page 14: Avant De Commencer L'assemblage

    Futon convertible NE RETOURNEZ PAS AU MAGASIN ! Si une pi ce est manquante ou endommag e, nous vous 2110029 (Noir), 2110229 (Gris clair), exp dierons avec plaisir vos pi ces de remplacement gratuitement. 2110329 (Jaune moutarde), Visitez www.dhpfurniture.com/fre/replacement-parts 2110429 (Gris), 2110629 (Bleu)
  • Page 15 Attacher D X 4 A avec RONDELLE EN PLASTIQUE . Attacher E X 2 A avec Num ro d'article BOULON .comme indiqu . 2110329 tiquette 2110429 2110629 2110029 2110229 (Jaune (Gris) (Bleu) d'article (Gris clair) (Noir) moutarde) None None None None...
  • Page 16 Limite de Poids: 600 Lb / 272 Kg Conseils utiles D placez votre nouveau mobilier avec soin, nous recommandons deux personnes pour soulever et transporter le mobilier vers son nouvel emplacement. Votre mobilier DHP peut tre d mont et reassembl pour faciliter les d m nagements.
