- Page 1 Gewässer- Umwelt- Schutz GmbH -Set-up system -Set-up system Assembly instruction Made in Germany Made in Germany...
- Page 2 • The -Set-up systems must be adjusted horizontally with the feet. • Modification or alteration of the compo- nents supplied by GUS Gewässer-Um- welt-Schutz GmbH is not permitted and may cause malfunctions. • The -Set-up systems and components must not be operated in areas with increased risk of damage.
- Page 3 Special solution with additional support of the cross struts Special constructions: -Set-up system, depending on the requirement Material: Material: Steel hot-dip galvanized S235 Processing: welds according to DIN EN ISO 9606-1 Scope of delivery: foot & connector, longitudinal & cross braces...
- Page 4 4 oelprotektor.de Recycling Removal of packaging All products are carefully packed for trans- port. Make a valuable contribution to waste prevention and conservation of raw materi- als and dispose of packaging materials only at designated collection points. Warranty Warranty conditions are listed in GTC „All- gemeine Geschäftsbedingungen“.
- Page 5 • Only mount the system with the max. permissible load weight. Preparation Place all components in the desired position (Fig. 1). Longitudinal brace Fig. 2: Completely pre-assemb- led for quick assembly Fig. 1 Connector Cross brace Foot with anti-vibration mat...
- Page 6 6 oelprotektor.de For installation, we recommend mounting the cross braces with the open side facing up and the longitudinal braces with the opening facing down. Adjust the height of the feet to the desired position and tighten the nuts of the feet fi rmly (Fig.
- Page 7 -Set-up system – Assembly instructions Check the position of the cross struts. They should be optimally aligned under the to be mounted. Screw the cross struts with the sliding nuts. Fig. 6 Special solution for chillers (Fig. 7) In the case of a special construction with a planned Beam (Fig.
- Page 8 GUS Gewässer-Umwelt-Schutz GmbH Bentheimer Straße 300 48531 Nordhorn +49 5921 71347-0 info@oelprotektor.de oelprotektor.de June 2023 Stand: Juni 2023 We reserve the right to amend this document. Änderung vorbehalten. Für Irrtümer und Druck- Any liabiliy for errors and misprints of this document is fehler übernehmen wir keine Haftung.
