R-410A
ZF SERIES
3 - 6.3 Ton
50 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation safety information . . . . . . . . . . . . . . . . . . . . . . . 7
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging and handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Condensate drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Service access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Typical cool/heat control wiring (Smart Equipment™ ZF036-
076) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power and control wiring. . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional electric heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Optional gas heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Gas connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
L.P. units, tanks, and piping . . . . . . . . . . . . . . . . . . . . . . . 14
Vent and combustion air hoods. . . . . . . . . . . . . . . . . . . . . 15
RRS economizer interface overview . . . . . . . . . . . . . . . . . 16
Smart Equipment™ economizer sequences. . . . . . . . . . . 16
Dry bulb changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Single enthalpy changeover . . . . . . . . . . . . . . . . . . . . . . . 17
Dual enthalpy changeover . . . . . . . . . . . . . . . . . . . . . . . . 17
Auto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Free cooling operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Power exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Jade Economizer interface overview . . . . . . . . . . . . . . . . 22
ZF036-076 unit weights. . . . . . . . . . . . . . . . . . . . . . . . . . . 25
PHASING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Supply air blowers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Checking supply airflow rate . . . . . . . . . . . . . . . . . . . . . . . 35
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Cooling sequence of operation . . . . . . . . . . . . . . . . . . . . . 37
1 Control wire sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Electric heater supply air limitations . . . . . . . . . . . . . . . . 13
3 Gas heat application data . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Gas pipe sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Smart Equipment™ Economizer Board details . . . . . . . 19
7 ZF036-076 imperial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8 ZF036-076 metric . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9 ZF036-076 unit accessory weights . . . . . . . . . . . . . . . . . 25
10 ZF036-076 physical data. . . . . . . . . . . . . . . . . . . . . . . . . 26
11 Electrical data ZF036-076 . . . . . . . . . . . . . . . . . . . . . . . . 28
12
Electric heat correction factors . . . . . . . . . . . . . . . . . . . . 28
13 Voltage limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
14 Utilities entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
15 Minimum clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
side duct applications . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
TABLE OF CONTENTS
Electric heating sequence of operations . . . . . . . . . . . . . . 39
Safety controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . . . . . . 40
Gas heating sequence of operation . . . . . . . . . . . . . . . . . 40
Gas heat operation errors . . . . . . . . . . . . . . . . . . . . . . . . . 40
Flash codes or error messages. . . . . . . . . . . . . . . . . . . . . 41
Heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . . . . . . 41
Start-up (cooling). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Prestart checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Post start checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Shutting down the unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Start up (gas heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Pre-start checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Post start checklist (gas) . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Manifold gas pressure adjustment . . . . . . . . . . . . . . . . . . 43
Pilot checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Burner instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Burner air shutter adjustment . . . . . . . . . . . . . . . . . . . . . . 43
Checking gas input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Adjustment of temperature rise . . . . . . . . . . . . . . . . . . . . . 44
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cooling troubleshooting guide. . . . . . . . . . . . . . . . . . . . . . 45
Gas heat troubleshooting guide . . . . . . . . . . . . . . . . . . . . 46
Flash code troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 47
Symptomatic troubleshooting . . . . . . . . . . . . . . . . . . . . . . 49
Unit flash codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Fan on and off delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Typical wiring diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Simplicity® Lite control board . . . . . . . . . . . . . . . . . . . . . . 58
Smart Equipment™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Start-up sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
LIST OF TABLES
application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
19 Belt drive motor and drive data . . . . . . . . . . . . . . . . . . . . 35
20 Static resistances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
21 Limit control setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
22 Electric heat anticipator setpoints . . . . . . . . . . . . . . . . . . 40
23 Limit control setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
24 Gas heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . 41
25 Gas rate - cubic feet per hour . . . . . . . . . . . . . . . . . . . . . 44
26 Simplicity Lite unit control board flash codes . . . . . . . . . 51
27 Ignition control board flash codes . . . . . . . . . . . . . . . . . . 51
28 Smart Equipment™ UCB details . . . . . . . . . . . . . . . . . . 52
29 Cable for FC buses and SA buses in order of preference 57
Advertisement
Table of Contents
Troubleshooting
Related Manuals for York ZF076
Summary of Contents for York ZF076
-
Page 1: Table Of Contents
R-410A ZF SERIES 3 - 6.3 Ton 50 Hertz TABLE OF CONTENTS General ......... . 3 Electric heating sequence of operations . - Page 2 5725848-XIM-A-0319 LIST OF FIGURES 1 Recommended drain piping ..... . . 9 22 Gas valve piping ......40 2 Compressor restraining bracket .
-
