Power Acoustik FBX-10 Install Manual

Congratulations on your purchase of one of the finest woofers available for your vehicle today.
If you are an enthusiast that plays your system loud and hard, the FBX woofers will take you to the
limit. Our small sealed enclosure, high excursion design will move enough air to part your hair. Let
your woofers do all the talking to let everyone know you are a "Serious about your sound".
Please take a few moments to fill out the warranty card and review this manual before installing this woofer
for proper connections and box sizes.
Two pieces Die-cast Aluminum Basket
Black/Blue wrinkle finish w/ Diamond cut
Non-pressed paper cone
Large foam rubber surround
1-piece rubber gasket
Black spider
Woven tinsel lead through spider
Heavy Duty Connectors
Dual 4 ohm voice coil
SPL:
Magnet size:
Black ASV voice coil:10" - 2"
RMS Power ( watts): 10" – 600
MAX Power ( watts): 10" – 1200
Fs
Vas
Qms
Qes
Qts
Xmax
Power Acoustik FBX Woofers

Design Features

10" – 90 dB
10"- 130oz.

Thiele / Small Parameters

FBX-10
40.3 Hz
0.7 Cu. Ft.
5.31
0.74
0.6472
0.6"
12" – 91 dB
12" – 180oz.
12" - 2"
12" – 700
12" – 1400
FBX-12
30.6 Hz
1.85 Cu. Ft.
2.92
0.61
0.5035
0.6"
15" – 93 dB
15" – 290oz.
15" - 2.5"
15" – 800
15" – 1600
FBX-15
28 Hz
4.0 Cu. Ft.
3.36
0.6
0.5105
0.6"
