CMD Miro Installation & User Manual

Miro
Dimensions
Designed to fit onto desks with 16-27mm
thickness with the included clamp.
Mounting the base to the desk
Notch
The supplied foam pad If not already in place, fit
can be applied to the the 180° lockout bush
bottom of the base to with the notch facing
protect the desk surface. the left as shown
Use the 4mm Allen key Place the clamp cover
to tighten the 2x grub over the base with the
screws in the clamp into recess facing the desk
the base. edge. No fixing required.
Part No: 134330 Issue No: 001
Place the base near the
edge of the desk and
offer up the C-clamp as
shown.
The base is now secured
in place and ready for
the arm to be installed.
Installation, user and care guide
Contents
x1 x1
3mm
VESA
x1 x4
screws
Pre-tensioning the arm
Use the 5mm Allen key The base of the lower
to turn the bolt at the arm indicates which
base of the lower arm as direction to turn the bolt
shown. to suit the monitor.
Turn the bolt anti- Turn the bolt clockwise
clockwise to suit lower to suit heavier monitors
weight monitors. Do not upto a maximum weight
adjust beyond 'STOP'. of 10kg.
Installing the arm
Lower the arm assembly Guide the lug on the
down onto the installed side of the arm into the
base on the desk. slot on the lockout bush
as shown.
Installing the head onto the monitor
Align the VESA holes Fix in place with supplied
with those on the fixing screws.
monitor, either 75mm or
100mm spacing.
x1 x1 x1
4mm 5mm
x1 x1 x1
(if monitor weight is known)
The window on the
lower arm indicates the
current weight/tension
setting from 0-10 kg.
Ensure to align the
desired weight setting
centrally in the window.
The arm is now secured
in place and ready for
the head and monitor to
be installed.
Angle the metal spigot
on the head to the
position shown ready to
install on the arm.
x1
