- Page 1 INSTRUCTION MANUAL Mirrored Jewelry Armoire with Drawer SKY5948 Ver. 2...
-
Page 2: Tools Required
NOTICE Please retain these instructions for future reference. • Firmly secure all bolts, screws, and knobs before use. • Reconfirm that all bolts, screws, and knobs are secure every 90 days. • Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. - Page 3 HARDWARE FEMALE MALE LARGE WASHER SMALL WASHER RUNNER (L/R) RUNNER (L/R) 1 SET 1 SET 2 PCS 2 PCS PARTS ARMOIRE ARMOIRE SUPPORT SUPPORT BRACE 1 PC 2 PCS 1 PC CABINET TOP CABINET SIDE CABINET SIDE 1 PC 1 SET 1 PC CABINET BACK CABINET BASE...
-
Page 4: Product Assembly
PARTS DRAWER SIDE DRAWER BACK DRAWER BOTTOM 1 PC 1 PC 1 PC DRAWER FRONT 1 PC PRODUCT ASSEMBLY Attach one set of part H1 & H2 drawer sides to the part I drawer back with four part 5 screws. Insert the part J drawer bottom. - Page 5 PRODUCT ASSEMBLY Attach the part 9 knob to the part K drawer front with one part 8 screw. Attach the drawer front to the drawer assembly with four part 2 lag nuts and four part 1 lag bolts. Flip the drawer assembly attach the part 14 male runner set to the drawer sides with six part 10 screws.
- Page 6 PRODUCT ASSEMBLY Locate the part E1 & E2 cabinet sides and attach the part 13 female runner set with six part 10 screws. Attach the runner sets as shown with the runner wheel at the drawer compartment opening. Attach the cabinet side set to the part G cabinet base with four part 3 dowels and four part 5 screws.
- Page 7 PRODUCT ASSEMBLY Attach two part B armoire supports to the part C support brace with two part 3 dowels, two part 7 barrel nuts, and two part 6 barrel bolts. Attach the support assembly to the part D cabinet top with four part 7 barrel nuts and four part 6 barrel bolts.
- Page 8 PRODUCT ASSEMBLY Attach the part D cabinet top to the cabinet assembly with four part 3 dowels, four part 1 lag bolts, and four part 2 lag nuts.
- Page 9 PRODUCT ASSEMBLY Attach the part F cabinet back with twelve part 4 screws.
- Page 10 PRODUCT ASSEMBLY Attach the part A armoire to the supports with two part 12 connector sets, two part 15 washers, and part 16 washers. Insert two part 11 dowels into the corresponding holes, depending on your desired angle.
-
Page 11: Installing Batteries
INSTALLING BATTERIES This armoire requires a total of 3 AA batteries. Locate the battery compartment on the back of the armoire. Remove the cover plate and install three AA-batteries. -
