- Page 1 INSTRUCTIONS FOR USE ODW8128G Warming drawer ODW8128GG...
-
Page 2: Table Of Contents
Contents Pictograms used ........Maintenance ..........Safety regulations ........Cleaning the exterior ........Use .............. Cleaning the interior ........Description of the appliance ......Troubleshooting ......... Control panel ..........Troubleshooting table ........Operation of the touch-sensitive buttons ..Environmental aspects ......Opening and closing the drawer .... -
Page 3: Pictograms Used
Pictograms used The following symbols are used throughout the manual, and they have the following meanings: INFORMATION! Information, advice, tip, or recommendation WARNING! Warning general danger ELECTRIC SHOCK! Warning danger of electric shock HOT SURFACE! Warning danger of hot surface DANGER OF FIRE! Warning danger of fire... -
Page 4: Safety Regulations
Safety regulations WARNING! READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! WARNING! This appliance and the accessible parts will become hot during use. Do not touch hot parts. Keep children younger than 8 away from the appliance unless they are under continuous supervision. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have... - Page 5 Safety regulations General ELECTRIC SHOCK! WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. Never use a steam cleaner for cleaning the appliance. Only clean the appliance when switched off. The steam of a steam cleaner could reach the conducting parts and cause an electrical short.
-
Page 6: Use
Description of the appliance The warming drawer can be used to warm dishes and keep food warm. 1. Operating panel ▸ Touch the on/off-key to switch on the warming drawer. 2. Drawer front ▸ Gently push the drawer front to open and close the drawer (push/pull system). 3. -
Page 7: Control Panel
Control panel 1. On/off-touch key with indication ▸ Touch to switch on the warming drawer. The on/off indicator light illuminates. Standby mode ▸ on/off light illuminates dimmed. Active mode ▸ on/off light illuminates. 2. - (minus) temperature key ▸ Touch to decrease the temperature setting. 3. -
Page 8: Opening And Closing The Drawer
Opening and closing the drawer 1. Push in the middle of the drawer front to open or close the drawer. WARNING! Never force the drawer to open. It could damage the closing mechanism (push/pull system). Loading capacity The maximum load depends on the dimensions and weight of your dishes. Dishes Tableware Full place settings and serving... -
Page 9: Applications
WARNING! The maximum load of the warming drawer is 25 kg. Damage to the appliance can occur if this load weight is exceeded. Applications The table lists various uses for the warming drawer. Select the to be heated food/crockery from the table. Set the temperature setting and duration for the food/crockery to be heated. - Page 10 Table continued from last page Food/crockery Setting Estimated duration Notes temperature Preheat tableware. Keeping eggs warm, e.g. 30 minutes till 1 hour hard-boiled eggs or scrambled Cover up the eggs. eggs. Leave in the Defrosting delicate 30 minutes packaging. deep-frozen food. Only use suitable Preheating drinking vessels, 30 minutes...
-
Page 11: Slow Cooking
Table continued from last page Food/crockery Setting Estimated duration Notes temperature Preheat tableware. Keeping beverages hot. 30 minutes to a max. of 1 hour Cover up the beverages. Prepare and chop Drying fruit. 6 hours and extend as up the fruit. required, with max. - Page 12 Table continued from last page Type of meat Searing on the hob Yarn in the warming drawer Time duration: 30 minutes till 1 hour Temperature Steak medallions. 1–2 minutes per side setting 6 Time duration: 30 minutes till 1 hour Medium-sized pieces of meat.
-
Page 13: Operation
Operation Operating the warming drawer WARNING! The operating panel must be kept clean and dry. Wash and dry your hands before use. The keys will otherwise not react or can come on accidentally. 1. Touch the on/off-key to switch on the drawer. 2. -
Page 14: Delayed Start Mode
Operation WARNING! Do not leave the warming drawer unattended for more extended periods when using continuous operation. Keeping food warm overly long can dry it out and even cause it to catch fire. This warming drawer is provided with a safety device that switches the drawer to standby mode after 12 hours of continuous operation. -
Page 15: Operating Modes
Operation The function is activated when the key is released. The duration and temperature displays illuminate briefly 3x. The Sabbath mode is activated. 2. Touch the on/off-key for 10 seconds to switch off the sabbath mode. The function is activated when the key is released. The duration and temperature displays illuminate briefly 3x. - Page 16 Operation HOT SURFACE! Risk of burns! The surface of the warming plate is hot. Items around the outside of the drawer get hotter than those in the middle. Always use protective gloves or oven cloths to remove the dishes. Heating cups and glasses The heating duration depends on the material and thickness of the dishes and their quantity, height and arrangement.
- Page 17 Operation Keeping food warm WARNING! Use this operating mode to keep food warm straight after being cooked. Do not use it for reheating refrigerated food. Never place hot saucepans or frying pans straight to the warming plate from the hob. This can damage the warming plate. 1.
- Page 18 Operation The recommended temperature setting and time duration illuminate. 3. Close the drawer. The control lamp will light up. The warming drawer heats up. 4. Open the drawer when the operating mode finishes. 5. Touch the on/off-key to switch off the appliance. 6.
- Page 19 Operation HOT SURFACE! Risk of burns! The surface of the warming plate is hot. Items around the outside of the drawer get hotter than those in the middle. Always use protective gloves or oven cloths to remove the dishes.
-
Page 20: Maintenance
Maintenance WARNING! Put the drawer in standby mode before starting cleaning. Do not clean the appliance with a steam cleaner. Do not use abrasive products, alcohol or solvents as they may damage the device. The front is made of stainless steel or glass and is prone to scratches. Use a special non-abrasive cleaning agent for stainless steel. -
Page 21: Troubleshooting
Troubleshooting The following is a list of faults that the user can quickly remedy after following the described solution. Call the service division if another fault is displayed, or the defect cannot be fixed. Troubleshooting table Problem Possible cause Solution The dish remains cold. -
Page 22: Environmental Aspects
Environmental aspects WARNING! Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician. Then remove the power cord from the appliance by cutting it off at the device. Disposal of the appliance and packaging Sustainable materials have been used during the manufacture of this appliance. -
Page 23: Installation
Installation Safety This appliance should only be connected by a registered installer! The electrical connection must comply with national and local regulations. The wall plug socket and plug should always be accessible. If the power cord is damaged, it should be replaced by the manufacturer or an authorised service technician, in order to avoid hazard. - Page 24 Installation Only use original replacement parts. These meet the required safety specifications. Please note that the appliance must not be mounted tilted or upended. The design of the appliance includes an oil-containing pump. Please refer to the installation instructions. The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings.
- Page 25 Installation and slow cooking. Any other use is prohibited and may be dangerous. The manufacturer disclaims liability in the event of improper use. Under certain conditions, the outside of the warming drawer may reach 70 °C (depending on the selected temperature and length of use).
-
Page 26: Preparation
Installation Preparation... -
Page 27: Appliance Dimensions
Installation Appliance dimensions Built-in dimensions... -
Page 28: Built-In
Installation Built-in... - Page 29 Installation...
-
Page 30: Your Notes
Your notes... - Page 31 Your notes...
- Page 32 888005 We reserve the right to make changes.
