- Page 1 INSTRUCTIONS FOR USE ODW8123S / HZWE140 ODW8127A / HZWE140 warming drawer ODW8127B / HZWE140 ODW8127S / HZWE140 ODW8128G / HZWE140 ODW8327A / HZWE290 ODW8327S / HZWE290 ODW8328G / HZWE290...
-
Page 2: Table Of Contents
Contents Pictograms used ........Warming time ..........Safety regulations ........Installation ..........Use .............. Safety ............Operation ............ Built-in ............General ............Environmental aspects ......Operating elements ........Disposal of the appliance and packaging ..Operating principle ........Your notes ..........Selecting the temperature ...... -
Page 3: Pictograms Used
Pictograms used The following symbols are used throughout the manual, and they have the following meanings: INFORMATION! Information, advice, tip, or recommendation WARNING! Warning general danger ELECTRIC SHOCK! Warning danger of electric shock HOT SURFACE! Warning danger of hot surface DANGER OF FIRE! Warning danger of fire... -
Page 4: Safety Regulations
Safety regulations WARNING! READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! What you should pay attention to WARNING! This appliance and the accessible parts will become hot during use. Do not touch hot parts. Keep children younger than 8 away from the appliance unless they are under continuous supervision. - Page 5 Safety regulations A defective appliance may cause electric shock. Never switch on a defective appliance. Disconnect it and contact customer service. Improper installation and maintenance work or repairs are dangerous. Do not touch any conducting connections and do not change the electrical and mechanical design of the appliance. These may only be performed by authorized and trained technicians.
-
Page 6: Use
1. Fan and heating 2. Indicator light Flashes if the appliance is switched on. Lights up if the appliance is switched on and the drawer is closed. 3. Dial for setting the temperature. The temperature set is the temperature of the hot plate at the bottom of the drawer when the drawer is empty. -
Page 7: Operation
Operation General A protective grille prevents contact with the elements and the fan. Operating elements The drawer has an ON/OFF and temperature regulation dial. This dial is only visible when the drawer is open. When the drawer is closed, the indicator light on the front shows whether the appliance is switched on. -
Page 8: Warming Time
Operation Icon Temperature Function Application 30 °C Defrosting For defrosting food. Allowing dough to rise. 40 °C Defrosting 50 °C Warming cups and glasses. Warming coffee cups. 60 °C Warming crockery. Warming plates and dishes. Keeping food warm (eggs, bread). 70 °C Keeping food warm. -
Page 9: Installation
Installation Safety This appliance should only be connected by a registered installer! The electrical connection must comply with national and local regulations. The wall plug socket and plug should always be accessible. If the power cord is damaged, it should be replaced by the manufacturer or an authorised service technician, in order to avoid hazard. - Page 10 Installation Only use original replacement parts. These meet the required safety specifications. Please note that the appliance must not be mounted tilted or upended. The design of the appliance includes an oil-containing pump. Please refer to the installation instructions. The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings.
- Page 11 Installation Under certain conditions, the outside of the warming drawer may reach 70 °C (depending on the selected temperature and length of use). Always use oven mitts or gloves to remove the warmed tableware from the drawer. WARNING! Prior to connecting the drawer, ensure that all cables in your home’s electrical system are of sufficient diameter to supply the appliance properly.
-
Page 12: Built-In
Installation Built-in 1. Slide the appliance in the kitchen cupboard aperture. Check whether the casing fits correctly. 2. Open the drawer and secure the appliance to the cupboard using the 4 screws supplied. ODW8123S ODW8127A - ODW8127B - ODW8128G... - Page 13 Installation ODW8327A - ODW8328G ODW8327S...
- Page 14 Installation The aluminium profiles can be adjusted +/- 1 mm on the ODW8128G/ODW8328G. The front can be adjusted by a few millimetres for alignment with other appliances. Use the Allen key at the bottom of the appliance for this.
-
Page 15: Environmental Aspects
Environmental aspects Disposal of the appliance and packaging Sustainable materials have been used during the manufacture of this appliance. This appliance must be disposed of responsibly at the end of its service life. Ask your local authorities for more information about how to do this. -
Page 16: Your Notes
713090 We reserve the right to make changes.
