D-Link DI-634M Quick Installation Manual

D-Link DI-634M Quick Installation Manual

108g mimo wireless router
Hide thumbs Also See for DI-634M:

Advertisement

Quick Links

Download this manual
This product can be set up using
any current web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 7.
Before You Begin
1. If you purchased this router to share your high-speed Internet connection with other
computers, you must have either an Ethernet-based Cable or DSL modem with an
established Internet account from an Internet Service Provider (ISP).
2. It's best to use the same computer that is connected to your modem for configuring
the DI-634M 108G MIMO Wireless Router. The DI-634M acts as a DHCP server and
will assign all the necessary IP address information on your network. See Appendix
at the end of this Quick Installation Guide or the Manual on the CD-ROM for
setting each network adapter to automatically obtain an IP address.
Check Your Package Contents
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
DI-634M 108G MIMO Wireless Router
CD-ROM (containing Manual and Warranty)
Ethernet (CAT5 UTP/Straight Through) Cable
5V DC Power Adapter
specifications subject to change without notice. DI-634M. 12302004
Using a power supply with
a different voltage rating will
damage and void the warranty
of this product.
1
DI-634M
108G MIMO
Wireless Router

Advertisement

loading

Related Manuals for D-Link DI-634M

Summary of Contents for D-Link DI-634M

  • Page 1 If any of the above items are missing, please contact your reseller. ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DI-634M. 12302004...
  • Page 2 First, connect the power adapter to the receptor at the back panel of the DI-634M and then plug the other end of the power adapter to a wall outlet or power strip. The Power LED will turn ON to indicate proper operation.
  • Page 3 Connecting Additional Computers To The DI-634M Using additional Ethernet (CAT5 UTP) cables, connect your Ethernet-equipped computers to the remaining Ethernet LAN ports on the back panel of the DI-634M. Power LED – a solid light indicates a proper WLAN LED – a solid light...

  • Page 4: Using The Setup Wizard

    Using The Setup Wizard Open your Web browser and type “http://192.168.0.1” into the URL address box. Then press the Enter or Return key. The logon pop-up screen will appear. Type “admin” for the username and leave the password field blank. Click Once you have logged in, the Home screen will appear.
  • Page 5 The Setup Wizard (continued) You will see the following screens Click Next Set up your new password. You have the option to establish a password. Click Next Choose your time zone from the drop down list. Click Next...
  • Page 6 The Setup Wizard (continued) A this point, the setup wizard will try to auto-detect your Internet connec- tion type. If you have a Dynamic or PPPoE connection, you will be brought to the corresponding page. Otherwise, you will see the following screen: Select your Internet Connection.
  • Page 7 The Setup Wizard (continued) If your ISP requires a Static Address, and this option is selected, then this screen will appear: Enter the IP address information originally provided to you by your ISP. You will need to complete all the required fields. Click Next Please continue to Wireless Setup.

  • Page 8: Wireless Setup

    Click Next If you wish to use encryption for your 802.11g network, the DI-634M is capable of two levels of wire- less encryption - 64-bit and 128- bit. By default the encryption is disabled. You can change the encryption settings for more secure wireless communication.

  • Page 9: Test Internet Connection

    Your Setup is Complete! Click Restart Click Close Test Internet Connection You will be returned to the Home tab. Close the web browser window and relaunch your Web browser (i.e., Internet Explorer or Netscape Navigator), to link to your favor- ite Web site to test your Internet connection.
  • Page 10 To connect to the network, make sure the network adapter in your computer is configured properly. Here’s how to configure the network adapter to obtain an IP address automatically for the DI-634M Wireless Broadband Router. Microsoft Windows XP: Go to Start > right click on My Network Places >...
  • Page 11 Apple Macintosh OS X: Go to the Apple Menu Click on System Preferences and Select Network Click on Network Select Built-in Ethernet in the Show pull down menu Select Using DHCP the Configure pull down menu Click on Apply Now The IP address information, the Subnet Mask, the Router’s IP address and the Ethernet...

  • Page 12: Technical Support

    Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our website, or by phone.
