D-Link DIR-615+ User Manual

Wireless n 300 router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Version 1.00| 02/06/2020
User Manual
Wireless N 300 Router
DIR-615+

Advertisement

Table of Contents
loading

Related Manuals for D-Link DIR-615+

Summary of Contents for D-Link DIR-615+

  • Page 1 Version 1.00| 02/06/2020 User Manual Wireless N 300 Router DIR-615+...
  • Page 2 Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.

  • Page 3: Table Of Contents

    UPnP IGD ................87 Configuration ..............15 Remote Access ..............88 Home ....................16 TR-069 Client ..............92 Internet ...................16 Static Route ..............94 DIR-615 ...................17 Dynamic DNS ..............96 Wi-Fi Clients ................18 Bandwidth Control ............97 Settings ..................19 Ports Settings ..............98 Wizard ..................19 D-Link DIR-615+ User Manual...
  • Page 4 Routing Table ............... 112 DHCP ................113 Multicast Groups ............114 Diagnostics ................ 115 Ping .................. 115 Traceroute..............116 Troubleshooting ............117 Wireless Basics ...............121 What is Wireless? ..............122 Tips ....................124 Wireless Modes ................. 125 Networking Basics ............126 D-Link DIR-615+ User Manual...

  • Page 5: Package Contents

    If any of the above items are missing or damaged, please contact your local reseller. Note: Using a power supply with a different voltage rating than the one included with the DIR-615+ will cause damage and void the warranty for this product. D-Link DIR-615+ User Manual...

  • Page 6: System Requirements

    Utility Requirements • Safari 8 or higher • Chrome 48 or higher • Edge 20.10240 or higher Windows Users: Make sure you have the latest version of Java ® installed. Visit www.java.com to download the latest version. D-Link DIR-615+ User Manual...

  • Page 7: Introduction

    Introduction The D-Link DIR-615+ Wireless N 300 Router is an attractive, high-performance router that makes it easy to share broadband Internet connection with all your devices. Simply connect it to your broadband modem, then use the web-based Setup Wizard that guides you step by step through the configuration process.

  • Page 8: Features

    1 Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range. D-Link DIR-615+ User Manual...

  • Page 9: Hardware Overview

    A solid green light indicates that wireless is enabled. If the light is blinking green, data transmission is in Wireless LED progress. Power LED A solid green light indicates a proper connection to the power supply. D-Link DIR-615+ User Manual...

  • Page 10: Back Panel

    Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles. Press to start the WPS process and automatically create an encrypted connection to a WPS client. Long WPS/Reset Button press the button to reset the router to default settings. D-Link DIR-615+ User Manual...

  • Page 11: Installation

    • If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet. D-Link DIR-615+ User Manual...

  • Page 12: Wireless Installation Considerations

    1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

  • Page 13: Completing Setup

    There are several different ways you can configure your router to connect to the Internet and connect to your clients: • D-Link Setup Wizard - This wizard will launch when you log into the router for the first time. Refer to Setup Wizard on page 10.

  • Page 14: Setup Wizard

    (default: http://192.168.0.1). The wizard is designed to guide you through a step-by-step process to configure your new D-Link router and connect to the Internet. Click Start to continue. If your preferred language is English, click Yes to confirm. To select a different language for the interface, click No and select your language from the list.

  • Page 15: Advanced Settings

    Confirm your new password for the administrator account. Confirmation: Network name Create a name for your 2.4 GHz wireless network using up to 32 2.4GHz (SSID): characters. Click Apply to proceed to the router according to Configuration on page 15 D-Link DIR-615+ User Manual...

  • Page 16: Router Mode

    LAN connection, providing Internet access for an entire home or office. Router Mode is suitable for most wired home Internet connections. Follow the on-screen instructions to complete router mode setup. D-Link DIR-615+ User Manual...

  • Page 17: Ap Mode

    Additionally, you can use this mode to connect a wired device to a _Ext wireless network, which can be useful for devices that do not have a built-in wireless card, such as some smart TVs, game consoles, or DVRs. Follow the on-screen instructions to complete setup. D-Link DIR-615+ User Manual...

  • Page 18: Client Mode

    Additionally, it can provide an added layer of isolation when connecting to a public network by hiding your computers and devices from other devices on the network, and keeping them in your own private network. Follow the on-screen instructions to complete setup. D-Link DIR-615+ User Manual...

  • Page 19: Configuration

    The navigation bar at the top of the page has quick access to Settings and Management functions. You may quickly jump back to the Home page at any time. Note: The system will automatically log out after a period of inactivity. D-Link DIR-615+ User Manual...

  • Page 20: Home

    To bring up more details about your Internet connection, click on the Internet icon. Click IPv4 or IPv6 to see details of the IPv4 connection and IPv6 connection respectively. To reconfigure the Internet settings, refer to Internet on page 19. D-Link DIR-615+ User Manual...
  • Page 21 To reconfigure the wireless settings, either click Go to settings, on the lower right, or click Settings in the navigation bar and then Wireless on the menu that appears. Refer to Wireless network on page 60 for more information. D-Link DIR-615+ User Manual...

  • Page 22: Wi-Fi Clients

    Click on the Connected Clients icon to view details about wireless clients connected to the router. On this page you can see all the clients currently connected to the router. Such devices are marked by the colored Wi-Fi logo. D-Link DIR-615+ User Manual...

  • Page 23: Settings

    Change Configuration will allow you to change your connection type and may disrupt active connections. Advanced Mode: Click here to see a list of Internet WAN connections and their status. You can add, delete or re-initialize a connection D-Link DIR-615+ User Manual...
  • Page 24 For PPTP refer to page 47 For L2TP refer to page 51 Note: this option can only be edited in the WAN/Adding mode. Toggle this switch to clone the MAC address of your NIC. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 25 For PPPoE IPv6 refer to page 37 For PPPoE Dual Stack refer to page 42 For PPTP refer to page 47 For L2TP refer to page 51 Note: This option can only be edited in the WAN/Creating mode. D-Link DIR-615+ User Manual...
  • Page 26 UI. Note that no two MAC address within the NIC: same subnet can be the same. Restore Default Click here to restore your router's default MAC address. MAC Address: D-Link DIR-615+ User Manual...
  • Page 27 ISP. Vendor ID: Specify a custom vendor ID. (Optional) Hostname: Specify a hostname here. This will be the name of your router when viewed from networking tools. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 28 Specify the default gateway address provided by your ISP. address: Primary DNS Specify the primary DNS server IP address assigned by your ISP. server: Secondary DNS Specify the secondary DNS server IP address assigned by your ISP. server: Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 29 Toggle this switch to enable firewall functionality. This setting is enabled by default. Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. D-Link DIR-615+ User Manual...
  • Page 30 Specify the default gateway address provided by your ISP. address: Primary DNS Specify the primary DNS server IP address assigned by your ISP. server: Secondary DNS Specify the secondary DNS server IP address assigned by your ISP. server: Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 31 MAC Address: Get IPv6: Choose Automatically, IPv6 by DHCPv6, by SLAAC, or DHCPv6 PD according to the type of IPv6 is used by your ISP. The default setting is Automatically. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 32 Toggle this switch to obtain gateway information through SLAAC. SLAAC: If Gateway by SLAAC is disabled, specify the Gateway IPv6 address Gateway IPv6 address: here. Obtain DNS Toggle this switch to obtain DNS information automatically. server addresses automatically: D-Link DIR-615+ User Manual...
  • Page 33 Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 34 Primary IPv6 DNS Specify the primary DNS server IP address assigned by your ISP. server: Secondary IPv6 Specify the secondary DNS server IP address assigned by your ISP. DNS server: Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 35 Specify the default gateway address provided by your ISP. address: Primary IPv6 DNS Specify the primary DNS server IP address assigned by your ISP. server: Secondary IPv6 Specify the secondary DNS server IP address assigned by your ISP. DNS server: D-Link DIR-615+ User Manual...
  • Page 36 Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 37 If Without authorization is disabled, specify the PPP username Username: provided by your ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. Service name: Specify the ISP service name (optional). Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 38 This configuration is uncommon and is disabled by default. Username: If Without authorization is disabled, specify the PPP username provided by your ISP. If Without authorization is disabled, specify the PPP password Password: provided by your ISP. D-Link DIR-615+ User Manual...
  • Page 39 Toggle this switch to enable PPP debug. This feature is disabled by default. Ethernet MAC address: The default MAC address is set to the Internet port’s physical interface MAC address on the router. You can edit that address manually here. D-Link DIR-615+ User Manual...
  • Page 40 Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 41 Specify the ISP service name (optional). Choose Automatically, IPv6 by DHCPv6, by SLAAC, or DHCPv6 PD Get IPv6: according to the type of IPv6 is used by your ISP. The default setting is Automatically. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 42 Username: If Without authorization is disabled, specify the PPP username provided by your ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. Service name: Specify the ISP service name (optional). D-Link DIR-615+ User Manual...
  • Page 43 Toggle this switch to enable the PPP server to directly assign IP addresses to PCs behind your router. This is disabled by default. PPP debug: Toggle this switch to enable PPP debug. This feature is disabled by default. D-Link DIR-615+ User Manual...
  • Page 44 Toggle this switch to obtain gateway information through SLAAC. SLAAC: IPv6 address: Specify the IPv6 address provided by your ISP. Prefix: Specify the prefix provided by your ISP. Gateway IPv6 Specify the default gateway address provided by your ISP. address: D-Link DIR-615+ User Manual...
  • Page 45 Toggle this switch to enable Routing Information Protocol (RIP). This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 46 Specify the ISP service name (optional). Get IPv6: Choose Automatically, IPv6 by DHCPv6, by SLAAC, or DHCPv6 PD according to the type of IPv6 is used by your ISP. The default setting is Automatically. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 47 This configuration is uncommon and is disabled by default. Username: If Without authorization is disabled, specify the PPP username provided by your ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. D-Link DIR-615+ User Manual...
  • Page 48 Toggle this switch to enable the PPP server to directly assign IP addresses to PCs behind your router. This is disabled by default. PPP debug: Toggle this switch to enable PPP debug. This feature is disabled by default. D-Link DIR-615+ User Manual...
  • Page 49 Toggle this switch to obtain gateway information through SLAAC. SLAAC: IPv6 address: Specify the IPv6 address provided by your ISP. Prefix: Specify the prefix provided by your ISP. Gateway IPv6 Specify the default gateway address provided by your ISP. address: D-Link DIR-615+ User Manual...
  • Page 50 Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 51 ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. VPN Server Specify the VPN server address provided by your ISP. address: Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 52 If Without authorization is disabled, specify the PPP username provided by your ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. VPN Server Specify the VPN server address provided by your ISP. address: D-Link DIR-615+ User Manual...
  • Page 53 Extra options: Specify extra options if required by your ISP. Static IP address: Specify the IP address provided by your ISP. PPP debug: Toggle this switch to enable PPP debug. This feature is disabled by default. D-Link DIR-615+ User Manual...
  • Page 54 Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 55 ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. VPN Server Specify the VPN server address provided by your ISP. address: Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 56 If Without authorization is disabled, specify the PPP username provided by your ISP. Password: If Without authorization is disabled, specify the PPP password provided by your ISP. VPN Server Specify the VPN server address provided by your ISP. address: D-Link DIR-615+ User Manual...
  • Page 57 Extra options: Specify extra options if required by your ISP. Static IP address: Specify the IP address provided by your ISP. PPP debug: Toggle this switch to enable PPP debug. This feature is disabled by default. D-Link DIR-615+ User Manual...
  • Page 58 Ping: Toggle this switch to enable WAN Ping. This setting is disabled by default. Isolate Toggle this switch to enable connection isolation. This setting is connection: disabled by default. Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 59: Vlan

    This column indicates the untagged ports belonging to the VLAN. Tagged port: This column indicates the tagged ports belonging to the VLAN. VLAN ID: Indicates the VLAN ID to which the tagged ports belong. Enable: Indicates whether the VLAN is enabled or not. D-Link DIR-615+ User Manual...
  • Page 60 If you have chosen to edit an existing tagged connection, or if you have chosen to add a bridge connection, select the tagged ports to be included in the VLAN. Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 61: Dns

    Hosts on page 58 for more information. Click Delete to delete a selected host from the list Delete: IP address: Indicates the IP address of the host. Name: Indicates the name of the host. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 62 Section 4 - Configuration Add Hosts Edit Host IP address: Specify the IP address of the host, or select from the drop-down menu. Name: Enter a name for the specified host. Click Save when you are done. D-Link DIR-615+ User Manual...

  • Page 63: Wan Failover

    Specify the number of consecutive failures before switching to the inspections of backup connection. active connection: Number of Specify the number of consecutive successes before switching to the inspection primary connection. of inactive connection: Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 64: Wireless Network

    Specify the desire SSID for your wireless network. All devices must (SSID): connect to this SSID. Hide SSID: Toggle this switch to prevent SSID broadcasting. Clients will still need to enter the correct SSID to connect to your network. D-Link DIR-615+ User Manual...
  • Page 65 WPA, WPA2, or WPA/WPA2 mixed. The default and recommended setting is WPA2-PSK. If you have selected WPA-PSK, WPA2-PSK, or WPA-PSK/WPA2-PSK mixed: Password: Specify a wireless password. Each device connecting to your network must enter this password. Encryption type: Select an encryption type. D-Link DIR-615+ User Manual...
  • Page 66 Encryption type: Select the encryption type. As of this writing, only AES is supported. Group key update Specify an update interval in seconds. The default setting is 3600. interval: Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 67: Network

    Specify the device domain name and URL to access the management utility. The default URL is http://dlinkrouter.local/ Dynamic IP Addresses Mode of Dynamic Select Disable, DHCP server, or DHCP relay. The default setting is IP address DHCP server assignment: D-Link DIR-615+ User Manual...
  • Page 68 Indicates the reserved static IP. MAC address: Indicates the MAC address for which the IP is reserved. Hostname: Indicates the hostname of the client for which the IP is reserved. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 69 Specify the MAC address of the client for which the IP address is reserved. Hostname: Specify the Hostname of the client for which the IP address is reserved. Click Apply to save changes or click the X in the upper right hand corner to cancel changes. D-Link DIR-615+ User Manual...

  • Page 70: Ipv6

    If Stateful has been selected, specify the end IP address in the DHCP server pool. Lease Time: If Stateful or Stateless has been selected, specify the lease time in minutes for dynamic IPv6 addresses. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 71 Specify the MAC address of the client for which the IP address is reserved. Hostname: Specify the Hostname of the client for which the IP address is reserved. Click OK to save changes or click the X in the upper right hand corner to cancel changes. D-Link DIR-615+ User Manual...

  • Page 72: Functions

    Indicates the number of the filter. Name: Indicates the name of the filter. State: Indicates whether the is enabled or disabled. Action: Indicates the action taken when the filter is triggered. IP version: Indicate to which IP version the filter applies. D-Link DIR-615+ User Manual...
  • Page 73 To enter a single address, use only the Start IPv4/IPv6 address field and leave the End IPv4/IPv6 address field blank. Subnet IPv4/IPv6 If you have selected Subnet, specify the destination subnet to filter. address: D-Link DIR-615+ User Manual...
  • Page 74 Specify multiple ports by separating them with commas. Specify port ranges by separating the beginning and end of the range with a colon. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 75 Loopback: LAN devices to connect directly to the DMZ host by using the WAN IP address IP Address: If DMZ is enabled, specify the IP address of the DMZ host. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 76 Indicates the number of the filter. Action: Indicates the action taken when the filter is triggered. MAC address: Indicates the MAC address to which the filter applies. Hostname: Indicates the hostname of the device to which the filter applies. D-Link DIR-615+ User Manual...
  • Page 77 Specify the MAC address of the host to which the filter will apply. This field is mandatory. Hostname: Specify the hostname of the host to which the filter will apply. This field is optional. Click Save when you are done, or click the X to cancel. D-Link DIR-615+ User Manual...
  • Page 78 MAC address. Delete: To delete an existing entry, click the checkbox corresponding to the entry you want to delete, then click on the Delete button. Click Apply when you are done. D-Link DIR-615+ User Manual...
  • Page 79 Toggle this switch to enable or disable the DoS Protection feature. Per Source IP Flood Toggle specific IP flood sources to filter. Some of these settings have subtypes. Other Settings Toggle specific attack types to filter. Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 80: Wi-Fi

    Indicates the time online in minutes. Last TX rate: Indicates the last recorded transmission rate in Mbps. Rx/Tx: Indicates total bytes received or transmitted this session. Power Saving Indicates the power saving status of the client. Mode: D-Link DIR-615+ User Manual...

  • Page 81: Wps

    Encryption: Indicates the encryption used by the authentication method. Password PSK: Indicates the password of the network. Update: Click this button to refresh the page. Reset to Click here to clear WPS configuration data. Unconfigured: D-Link DIR-615+ User Manual...

  • Page 82: Wmm

    This setting is intended for advanced users only and is not recommended for most users. Access Point/Station If Work mode has been set to Manual, you can click on each row to configure advanced QoS settings for that connection type. D-Link DIR-615+ User Manual...

  • Page 83: Client

    If you choose Select network from list, select the network you wish to connect to and enter any necessary security information as prompted. If you choose Connect to hidden network, enter the Wi-Fi information below. D-Link DIR-615+ User Manual...
  • Page 84 Select the network authentication used by the hidden network. This authentication: must be specified correctly to connect. Password PSK: Specify the password or PSK used by the hidden network. This must be specified correctly to connect. Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 85: Client Shaping

    Enabled: Indicates if the rule is enabled. Add/Edit Rule Enabled: Toggle this switch to enable the rule MAC address: Specify the MAC address of the Wi-Fi client to which the rule will apply. Upload/Download D-Link DIR-615+ User Manual...
  • Page 86 Not limited: Toggle this switch to disable the limit for the corresponding transfer type. Maximum rate: If Not limited is disabled, specify a maximum transfer rate in megabits per second. Click Save when you are done. D-Link DIR-615+ User Manual...

  • Page 87: Additional

    Specify the method of channel auto select. Choose from BSS(by signal channel auto level) and FA & CCA (by volume of data transmitted). select: Short GI: Choose from Enable or Disable Drop multicast: Toggle to enable or disable. Adaptivity mode: Toggle to enable or disable. D-Link DIR-615+ User Manual...
  • Page 88 Specify how often (by the number of beacon frames) that DTIM is beacon frames): transmitted. By default this is set to 1. Station Keep Alive Specify the time interval (in seconds) between keep alive checks of (in seconds): wireless devices from your WLAN. D-Link DIR-615+ User Manual...

  • Page 89: Mac Filter

    Choose which SSID you want the rule to apply to. MAC Address: Specify the MAC address of the device. Hostname: Specify hostname of the device (optional). Enable Rule Toggle this switch to enable or disable the rule. D-Link DIR-615+ User Manual...
  • Page 90 MAC address of device Hostname: Hostname of device SSID: Name of wireless network Band: Frequency band Enabled: Current status of filter To delete a filter, select the corresponding check box then click on the delete symbol. D-Link DIR-615+ User Manual...

  • Page 91: Advanced

    Indicates the internal port used by the used by the UPnP connection. Public port: Indicates the port exposed to the internet used by the UPnP connection. Description: Indicates the description of the protocol used by the UPnP connection. D-Link DIR-615+ User Manual...

  • Page 92: Remote Access

    Toggle this switch to enable any remote host to access the GUI. This is not recommended. IP address: Specify the IP address of the remote host allowed to access the GUI. Mask: Specify the subnet mask of the remote host allowed to access the GUI. D-Link DIR-615+ User Manual...
  • Page 93 Section 4 - Configuration Remote Access (cont) Public Port: Specify the port over which the remote host will access the GUI. Choose HTTP, HTTPS, or TELNET as the protocol for remote access. Protocol: Click Save when you are done. D-Link DIR-615+ User Manual...
  • Page 94 Click this button to add additional remote IP fields. Public port (start/ Specify a start and an end port to which the rule will apply. If you wish end): to specify a single port, specify a start port only. D-Link DIR-615+ User Manual...
  • Page 95 Private Port (start/ Specify a start and an end port to which the rule will apply. If you wish end): to specify a single port, specify a start port only. Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 96: Tr-069 Client

    Specify the password for your ISP's ACS. Inform Settings Enable: Toggle this switch to enable active contact with your ISP's ACS. Interval: Specify the interval in seconds for each inform packet. Connection Request Settings Username: Specify the username here. D-Link DIR-615+ User Manual...
  • Page 97 Section 4 - Configuration TR-069 Client (cont) Password: Specify the password here. Request Port: Specify the request port here. Request Path: Specify the request path here. Click Apply when you are done. D-Link DIR-615+ User Manual...

  • Page 98: Static Route

    Choose the protocol used by the static route. Interface: Choose the interface used by the static route. Destination Specify the IP address of the destination. network: Destination Specify the netmask used by the destination IP. netmask: D-Link DIR-615+ User Manual...
  • Page 99 Section 4 - Configuration Static Route (cont) Gateway: Specify the gateway used by the static route. Metric: Specify a metric between 1 and 255. Click Save when you are done. D-Link DIR-615+ User Manual...

  • Page 100: Dynamic Dns

    Select the DDNS service you are using. Username: Specify the username for your DDNS service. Password: Specify the password for your DDNS service. Update period: Specify the update period in minutes. Click Save when you are done. D-Link DIR-615+ User Manual...

  • Page 101: Bandwidth Control

    Indicates the maximum bandwidth allowed over the port in kbps. Port Enable: Toggle this switch to enable bandwidth control on the specified port. Maximum rate: Indicates the maximum bandwidth allowed over the port in kbps. Click Save when you are done. D-Link DIR-615+ User Manual...

  • Page 102: Ports Settings

    To configure a port, click on the corresponding port you wish to configure. Speed: Specify from drop down list port speed. Autonegotiation Toggle this switch to enable/disable autonegotiation modes. Modes: Flow Control: Toggle this switch to enable/disable symmetric flow control. D-Link DIR-615+ User Manual...

  • Page 103: Redirect

    The Device is not Toggle this switch to enable notification if connection failure due to Configured: device not configured. No Connection: Toggle this switch to enable notification if connection failure to due no connection detected. D-Link DIR-615+ User Manual...

  • Page 104: Igmp

    Choose from drop down list which IGMP version to use. Interface: Choose from drop down list which interface to apply to Enable/Disable: Toggle this switch to set the address of outgoing IGMP packets equal to 0.0.0.0 Click APPLY when finished. D-Link DIR-615+ User Manual...

  • Page 105: Alg/Passthrough

    Toggle this switch to enable/disable the following: PPPoE passthrough RTSP IPsec passthrough High priority for IPTV L2TP passthrough High priority for service traffic PPTP passthrough High priority for service traffic High priority for Web interface and Telnet Click APPLY when finished. D-Link DIR-615+ User Manual...

  • Page 106: Management

    Displays default public time server. Click on 'x' to delete. Click ADD SERVER to add a new public time server. Main time zone Displays current time zone. To change time zone, choose from drop down list. Determine Timezone D-Link DIR-615+ User Manual...

  • Page 107: System Log

    Click to export log as text file. Settings Enable/Disable: Toggle this switch to enable/disable logging function. Type: Choose from drop down list type of diagnostics to log. Level: Choose from drop down list level of diagnostics to log. Click APPLY when finished. D-Link DIR-615+ User Manual...

  • Page 108: Administration

    Click to load previously saved configuration file to the device. Save: Click to save current settings. Reboot: Click to reboot device. Idle Time: Specify a period of inactivity (in minutes) after which the device will log you out. D-Link DIR-615+ User Manual...

  • Page 109: Telnet

    The Telnet page allows you to enable or disable access to the device settings via TELNET from your LAN. Enable/Disable: Toggle this switch to enable Telnet. Port: Specify port number for telnet access. Click APPLY when finished. D-Link DIR-615+ User Manual...

  • Page 110: Yandex.dns

    When selected, the service blocks access to malicious and fraudulent web sites as well as access to adult content. The selected filtering mode will be applied to all devices newly connected to the router's network. Click APPLY when finished. D-Link DIR-615+ User Manual...

  • Page 111: Devices And Rules

    This column referes the the rule in place. Click on the rule to edit. Rules: IP address: This column indicates the IP address. MAC address: This column indicates the MAC address. Name: This column indicate the name. Mode: This column indicate the mode. Click APPLY when finished. D-Link DIR-615+ User Manual...
  • Page 112 To remove a rule for filtering, select the checkbox located to the left of the relevant rule and click the DELETE button ( ). Also you can remove a rule in the editing window. Click APPLY when finished. D-Link DIR-615+ User Manual...

  • Page 113: Firmware Update

    Specify server address from which to update firmware. URL: Enable/Disable: Toggle this switch to check for updates automatically. Click on CHECK FOR UPDATES to check for the latest firmware available from the remote server. Click on APPLY SETTINGS when finished. D-Link DIR-615+ User Manual...

  • Page 114: Statistics

    Network Statistics provides you with various statistics about data transmitted and received through the Internet. Network Statistics Name: Name of connection. IP - Gateway: IP Address and Gateway. Rx/Tx: Receive and Transmit volume. Rx/Tx Errors Number of Rx/Tx errors. Duration Duration of connection. D-Link DIR-615+ User Manual...

  • Page 115: Port Statistics

    The Port Statistics Page displays statics of traffic passing through the router by ports. Port Statistics Port: Name of port. Status: Current status of port. Traffic sent Amount of traffic sent in Mbyte. Traffic received Amount of traffic received in Mbyte. D-Link DIR-615+ User Manual...

  • Page 116: Routing Table

    Destination network address. Gateway: Gateway address. Subnet Mask: Subnet Mask address. Flags: Displays whether a route is up, to a gateway, to a host, created by a redirect, or modified by a redirect. Metric: Displays cost of route. D-Link DIR-615+ User Manual...

  • Page 117: Dhcp

    The DHCP page displays information on computers that have received IP addresses from the DHCP of the router. DHCP Hostname: Hostname of connected device IP Address: IP address from connected device. MAC: MAC address of connected device. Expires: IP address expiration date (lease time). D-Link DIR-615+ User Manual...

  • Page 118: Multicast Groups

    IPv4 IP Address: IP address of active IPv4 multicast group. Interface: Interface of active IPv4 mutlicast group. IPv6 IP Address: IP address of active IPv6 multicast group. Interface: Interface of active IPv6 mutlicast group. D-Link DIR-615+ User Manual...

  • Page 119: Diagnostics

    Number of data bytes to send. Wait Time: Time to wait for a response in seconds. Click OK to save or DEFAULT SETTINGS to reset back to default configuration. Click START to begin Ping Test or CLEAR to clear the results. D-Link DIR-615+ User Manual...

  • Page 120: Traceroute

    Number of probe packets to a hope. probes: Wait Time: Hope response time in seconds. Click OK to save or DEFAULT SETTINGS to reset back to default configuration. Click START to begin Traceroute or CLEAR to clear the results. D-Link DIR-615+ User Manual...

  • Page 121: Troubleshooting

    1. Why can’t I access the web-based configuration utility? When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website, nor do you have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility.
  • Page 122 • Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your web management.
  • Page 123 • Windows® 95, 98, and Me users type in command (Windows® NT, 2000, XP, Vista®, and 7 users type in cmd) and press Enter (or click OK). • Once the window opens, you’ll need to do a special ping. Use the following syntax: ping [url] [-f] [-l] [MTU value] Example: ping yahoo.com -f -l 1472 D-Link DIR-615+ User Manual...
  • Page 124 • To change the MTU, enter the number in the MTU field and click Apply to save your settings. • Test your email. If changing the MTU does not resolve the problem, continue changing the MTU in increments of ten. D-Link DIR-615+ User Manual...

  • Page 125: Wireless Basics

    D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business, or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when, and where you want it. You will be able to enjoy the freedom that wireless networking delivers.

  • Page 126: What Is Wireless

    Why D-Link Wireless? D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network.
  • Page 127 Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home Uses/Benefits • Gives everyone at home broadband access •...

  • Page 128: Tips

    The wireless connection in public places is usually called “hotspots”. Using a D-Link USB adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like: airports, hotels, coffee shops, libraries, restaurants, and convention centers.

  • Page 129: Wireless Modes

    An Infrastructure network contains an access point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point. An Ad-hoc network contains only clients, such as laptops with wireless USB adapters. All the adapters must be in Ad-hoc mode to communicate. D-Link DIR-615+ User Manual...

  • Page 130: Check Your Ip Address

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 131: Statically Assign An Ip Address

    Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Step 5 Click OK twice to save your settings. D-Link DIR-615+ User Manual...

  • Page 132: Wireless Security

    WPA/WPA2 incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network. D-Link DIR-615+ User Manual...

  • Page 133: Technical Specifications

    1 Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors,including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. D-Link DIR-615+ User Manual...

  • Page 134: Regulatory Statements

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. D-Link DIR-615+ User Manual...
  • Page 135 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. D-Link DIR-615+ User Manual...
  • Page 136 Potencia máxima de Salida Frequenza/e Potenza max. Output Frequentie(s) Max. Output Power 5.15 – 5.25 GHz 200 mW 5.25 – 5.35 GHz 200 mW 5.47 – 5.725 GHz 2.4 G 2.4 – 2.4835 GHz 100 mW D-Link DIR-615+ User Manual...
  • Page 137 υλικολογισμικό του προϊόντος είναι διαθέσιμα για λήψη από τη σελίδα του προϊόντος στην τοποθεσία www.dlink. com. Par les présentes, D-Link Corporation déclare que ce produit, ces accessoires et ce logiciel sont conformes aux Français [French] directives 2014/53/UE.Le texte complet de la déclaration de conformité de l'UE et le icroprogramme du produit sont disponibles au téléchargement sur la page des produits à...
  • Page 138 2014/53/EU. Pełen tekst deklaracji zgodności UE oraz oprogramowanie sprzętowe do produktu można pobrać na stronie produktu w witrynie www.dlink.com. Desta forma, a D-Link Corporation declara que este produto, os acessórios e o software estão em conformidade Português [Portuguese] com a diretiva 2014/53/UE. O texto completo da declaração de conformidade da UE e do firmware...
  • Page 139 2014/53/EU. Hela texten med EU-försäkran om överensstämmelse och produkt-firmware kan hämtas från produktsidan på www.dlink.com. Hér með lýsir D-Link Corporation því yfir að þessi vara, fylgihlutir og hugbúnaður eru í samræmi við tilskipun Íslenska [Icelandic] 2014/53/EB. Sækja má ESB-samræmisyfirlýsinguna í heild sinni og fastbúnað vörunnar af vefsíðu vörunnar á www.
  • Page 140 Access Points unterstützen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link DIR-615+ User Manual...
  • Page 141 5 Ghz dentro de la UE. • Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link DIR-615+ User Manual...
  • Page 142 Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) en TPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link DIR-615+ User Manual...
  • Page 143 • Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link DIR-615+ User Manual...
  • Page 144 • Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link DIR-615+ User Manual...
  • Page 145 • Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link DIR-615+ User Manual...
  • Page 146 D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.
  • Page 147 D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.
  • Page 148 D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.
  • Page 149 D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné a nízkotoxické materiály.
  • Page 150 D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.
  • Page 151 D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.
  • Page 152 D-Link och miljön På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.
  • Page 153 Access Points unterstützen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link DIR-615+ User Manual...
  • Page 154 5 Ghz dentro de la UE. • Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link DIR-615+ User Manual...
  • Page 155 Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) en TPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link DIR-615+ User Manual...
  • Page 156 • Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link DIR-615+ User Manual...
  • Page 157 • Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link DIR-615+ User Manual...
  • Page 158 • Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link DIR-615+ User Manual...
  • Page 159 D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.
  • Page 160 D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.
  • Page 161 D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.
  • Page 162 D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné a nízkotoxické materiály.
  • Page 163 D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.
  • Page 164 D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.
  • Page 165 D-Link och miljön På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.

Table of Contents
