Loewe Assist Easy - Remote Control Manual

Insert batteries

Twist the battery compartment lid out in an anti-clockwise direction and then remove it. Insert a CR2032/DL2032 battery. The plus pole of the battery must point upwards here. Replace the battery compartment cover onto the remote control (observe the markings).

Scope of delivery

• Assist Easy remote control
• 2 CR2032 batteries
• These operating instructions

Introduction

Dear customer,
by purchasing the Loewe Assist Easy, you have acquired a highly versatile remote control. You can operate various Loewe devices with this remote control. So that you can use the Assist Easy remote control to the best advantage in your surroundings, some settings might have to be made.

For your safety

The operating and safety instructions in this manual are limited to the range of functions of the Loewe Assist Easy remote control Art. Nr.71540. That means: these instructions only describe how you call up a certain function with the Assist Easy, but not what exact effect this function has on the particular unit and what consequences this could have.

• It is imperative that you also comply with the operating and safety instructions of the particular unit.

For your own safety, and to prevent damage, protect the remote control from:

• Dripping or splashed water and dampness
• Cold, heat and large temperature variations
• Impacts and mechanical stresses
• Excessive heating by direct sunlight. naked flames and candles
• Ingress into the inside of the device

This remote control has been designed exclusively for use in domestic environments. The terms of the warranty only cover this normal use.
Only clean the remote control with a slightly moist, soft cloth. Do not use sharp or abrasive cleaners under any circumstances.

• Do not insert rechargeable batteries in the battery compartment of the remote control.
• The batteries used must not be exposed to excessive heat such as sunlight, fire or any other such heat sources!

Operating Loewe units

The audio functions of the TV button can be configured:

Press the MENU button and colour button at the same time and hold them down for 5 sec. The LED above the TV button flashes twice

Function	Button combination	Unit
Audio Functions	MENU + green	AudioVision/MediaVision 3D
	MENU + yellow	Mediacenter
	MENU + blue	Loewe TV

The AUDIO and RADIO buttons can be configured to operate certain Loewe products:

Press the button down that you wish to configure (AUDIO or RADIO) and then press REC/AUX at the same time; hold the buttons down for 5 sec.

The LED over the selected button flashes twice. Input the button combination from the table below (press the buttons one after another).

Button combination	Unit
Red	Loewe TV Radio
Green	Loewe Mediacenter
Blue + yellow	Loewe BluTechVision Interactive/3D
Yellow	Loewe AudioVision
Green + blue	Apple Remote
Green + yellow	Apple TV
Green + yellow + blue	SoundBox (RADIO)
Blue	SoundVision (AUDIO)
Red + blue	AirSpeaker
Red + green + yellow	MediaVision 3D
Red + green + yellow + blue	Reset all settings

Press OK
The LED above the button for the unit flashes twice.

Default setting

Key Overview

Loewe TV (Chassis SL2xx / SL3xx)

1. Sound mute/on
2. LED display for current operating mode
3. Operate TV set
4. Short press: Teletext/MediaText
   Long press: EPG
5. Short press: Home view on/off
   Long press: call System settings
6. V–/V+ Volume lower/higher
7. Station overview; MENU: confirm/call up
8. Short press: playback
   Long press: green colour button
9. Short press: jump back
   Long press: red colour button
10. DR+: direct recording / immediate recording
11. Switch on/off in standby mode
12. Operate the unit that has been set, e.g. SoundVision
13. Operate the unit that has been set, e.g. SoundBox
14. Short press: status display on/off
    Long press: close all displays
15. P+/P– Select station up/down
16. MENU: select/set
17. Short press: stop
    Long press: yellow colour button
18. Short press: jump forward
    Long press: blue colour button
19. DR+: pause (start time-delayed TV)

Loewe TV (Chassis SL1xx)

1. Sound mute/on
2. LED display for current operating mode
3. Operate TV set
4. Long press: Teletext
   Long press: EPG
5. Short press: Media Portal
   Long press: hide menu
6. V–/V+ Volume lower/higher
7. Station overview; MENU: confirm/call up
8. Short press: playback / time-delayed TV
   Long press: green colour button
9. Short press: jump back
   Long press: red colour button
10. DR+: recording / direct recording
11. Switch on/off in standby mode
12. Operate the unit that has been set, e.g. SoundVision
13. Operate the unit that has been set, e.g. SoundBox
14. Short press: status display on/off
    Long press: TV menu on/off
15. P+/P– Select station up/down
16. MENU: select/set
17. Short press: stop
    Long press: yellow colour button
18. Short press: jump forward
    Long press: blue colour button
19. Freeze frame on/off; DR+: pause (start time-delayed TV)

Loewe SoundVision

1. Sound mute/on
2. LED display for current operating mode
3. Operate TV set
4. Sleep function
5. Short press: "Main menu"
   Long press: hide menu
6. V–/V+ Volume lower/higher
7. MENU: confirm/call up
8. Short press: playback
   Long press: AUPEO!: Love
9. Short press: select title down
   Long press: AUPEO!: Ban
10. Manage Favourites
11. Short press: Switch on/off in standby mode
    Long press: Switch off in Energy Saving Mode
12. Operate the unit that has been set, e.g. SoundVision
13. Operate the unit that has been set, e.g. SoundBox
14. Short press: info menu
    Long press: Options menu
15. P+/P– Select title/radio station up/down; In the menu: browse
16. MENU: select/set
17. Short press: stop
18. Short press: select track up
    Long press: MusicID
19. Pause

Loewe AirSpeaker

1. Sound mute/on
2. LED display for current operating mode
3. Operate TV set
4. No function
5. No function
6. V–/V+ Volume lower/higher
7. No function
8. Playback
9. Select title down
10. Audio source selection through several presses
11. Switch on/off in standby mode
12. Operate the unit that has been set, e.g. SoundVision
13. Operate the unit that has been set, e.g. SoundBox
14. No function
15. No function
16. No function
17. Stop
18. Select track up
19. Pause

Loewe SoundBox

1. Sound mute/on
2. LED indicator light for current operating mode
3. Operate TV set
4. Short press: time
   Long press: alarm
5. Short press: iPod: Menu
   Long press: RADIO: save radio stations
6. V–/V+ Volume lower/higher
7. In the menu: confirm/call up; iPod: select/playback
8. Short press: playback/pause
   Long press: random replay order
9. Short press: select title down
   Long press: wind down
10. Audio source selection through several presses
    10 and at the same time 16 : FM radio: search forwards;
    10 and at the same time 16 : FM radio: search forwards
11. Switch on/off in standby mode
12. Operate the unit that has been set, e.g. SoundVision
13. Operate the unit that has been set, e.g. SoundBox
14. Short press: display functions
    Long press: settings menu
15. P+/P– radio station up/down
16. Index up/down; select in the iPod menu
17. Yellow colour button: short press: stop
    Long press: repeat
18. Short press: select title up Long press: wind up
19. Short press: continue pause/playback
    Long press: snooze/sleep mode

Loewe MediaVision 3D

1. Sound mute/on
2. LED display for current operating mode
3. Operate TV set
4. Short press: Sleep Timer
   Long press: title recognition
5. Short press: "Home" menu
   Long press: Menu: hide menu
6. V–/V+ volume up/down
7. In the menu: confirm/call up
8. Short press: playback
   Long press: green colour button
9. Short press: select title down
   Long press: red colour button
10. Repeat
11. Switch on/off in standby mode
12. Operate the unit that has been set, e.g. SoundVision
13. Operate the unit that has been set, e.g. SoundBox
14. Short press: title menu
    Long press: DISC: disc menu (DVD)
15. P+/P– select title/radio station up/down
16. Select/set
17. Short press: stop
    Long press: yellow colour button
18. Short press: select track up
    Long press: blue colour button
19. Pause
